Summary of Contents for Baumatic BT85GL
- Page 2 User Manual for your Baumatic BT85GL Cooker Hood 90 cm Glass Chimney Hood NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it...
-
Page 3: Table Of Contents
YOUR COOKER HOOD’S SPECIFICATIONS ….……………..………….3 IMPORTANT SAFETY INFORMATION……………………………….…4-5 CARING FOR THE ENVIRONMENT…………………………………………6 USING YOUR COOKER HOOD………………………………..……………..7 MAINTAINING AND CLEANING YOUR COOKER HOOD ……….8-10 INSTALLATION INSTRUCTIONS ……………………….……...….11-19 INSTALLATION NOTES – EXTRACTION / PURIFYING VERSION .….18 NOTE ON INSTALLING THE VERSION WITH LOWER BRACKET..……19 TROUBLESHOOTING ……………………………………………20 CONDITIONS OF GUARANTEE……………………………………………21 CONTACT DETAILS…………………………………………………………..22... - Page 4 Specifications of your BT85GL Cooker Hood Congratulations on purchasing a Baumatic Cooker Hood! To fully enjoy using your appliance long into the future, please firstly familiarise yourself with its specifications, safety advice and operational instructions included in this manual. You will also need this manual to ensure that your Cooker Hood has been installed properly.
-
Page 5: Important Safety Information
Important Safety Information: Any installation work must be carried out by a qualified electrician or competent person. The hood must be installed in accordance with the installation instructions and all measurements followed. If the cooker hood is installed for use above a gas appliance then the provision for ventilation must be in accordance with the Gas Safety Codes of Practice BS.6172,... -
Page 6: Important Safety Information
Important Safety Information: o Ensure the ducting for the extractor function has the same diameter as the outlet hole all the way through. Keep young children from using, playing with or tampering with the cooker hood. Older children and infirm persons should be supervised if they are using the cooker hood. -
Page 7: Environmental Note
Environmental Note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. CONFORMITY TO W.E.E.E. -
Page 8: Using Your Baumatic Cooker Hood
Using your Baumatic Cooker Hood: To use your cooker hood: Make sure it has been properly installed. Find the CONTROL PANEL. It is located centrally at the front of the canopy. The CONTROL PANEL contains keys as shown in the Figure below. -
Page 9: Special Functions
Using your Baumatic Cooker Hood: SPECIAL FUNCTIONS Your Baumatic Cooker Hood also has advanced features. These are: Reminder to clean the Metal Grease Filters After every 30 hours of use, your cooker hood’s microprocessor will alert you to clean the metal grease filters. -
Page 10: Cleaning Your Baumatic Cooker Hood
Cleaning your Baumatic Cooker Hood: Cleaning your Baumatic Cooker Hood: Before cleaning, always ensure that you IMPORTANT!: have switched your cooker hood OFF at the omni-polar switch, set at the wall from the cable: Cleaning Clean the external parts with mild liquid detergents on a damp cloth. - Page 11 Maintenance - Cleaning the Anti-grease Filters First remove the grille by pulling down on it. Undo the side catches. You can now clean the anti-grease filter grilles. Soak them for about one hour in hot water with a grease-loosening detergent then rinse off thoroughly with hot water.
-
Page 12: Maintenance – Changing The Light Bulb And Carbon Filter
Maintenance – Changing the Light Bulb and Carbon Filter Changing the light bulb Before changing the light bulb, ensure that the appliance is not live (i.e., ensure that you have switched it off so that it’s in the ‘0’ position). Remove the metal anti-grease filters (see Figure 2 below) and find the old bulb located in the light fixture up inside the exposed canopy. -
Page 13: Installing / Changing The Carbon Filter
Installing / Changing the Carbon Filter ______________________________________________________________________________________ Installing / Changing the Carbon Filter. Your Baumatic Cooker Hood uses a CARBON FILTER to purify the air for the air recirculation function. You will find that one filter will attach to the fan motor’s front (please see figures at bottom of page). -
Page 14: Electrical Connection
INSTALLATION INSTRUCTIONS - Electrical Before installation and usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the identification plate (found inside your Cooker Hood) and all the data inside the appliance are exactly the same as the voltage and frequency in your home. -
Page 15: Installation Instructions
SEE PAGE 15 NOW TO UNDERSTAND CRUCIAL DIFFERENCES IN THESE. NOTE: Your Baumatic Cooker Hood should only be fitted on a wall. Do NOT position it any less than 700 mm (70 cm) above the hob. 1) Remove the metal grease filters... -
Page 16: Attaching The Hood
INSTALLATION INSTRUCTIONS Fitting the Chimney Pipe – Attaching the Hood Note the tabs at the back of the hood. Take the two casings ‘A’ & ‘B’. Rest the bottom of casing ‘A’ on the top of the hood. 2) Fix casing ‘A’ onto the hood, using the screws ‘K’... - Page 17 Extraction / Air Purifier Modes of Operation EXTRACTION OPERATION – Installation Instructions Ensure that you have fitted the union (‘N’) to the upper part of the hood using the packaged two screws supplied inside the packing (Fig. 1 – on right). Using a 125 mm diameter pipe, connect the union (N) on the upper part of the hood (see Fig.
-
Page 18: Installation Instructions
INSTALLATION INSTRUCTIONS ATTACHING THE GLASS Remove the metal grease filters from the hood. Slacken both anchoring screws ‘F’ (respectively on the left and right). Remove the anchoring corner marked with the letter ‘Z’, pulling it upwards. Place the glass ‘Q’ on the upper shelf of the hood, pushing it towards the wall. -
Page 19: Troubleshooting
If something has gone wrong with your Cooker Hood, checking against this chart might keep you from having to call for service. Symptom The cooker hood will not start! The cooker hood is not working effectively! The cooker hood has switched off during operation! Troubleshooting •... -
Page 20: Conditions Of Guarantee
In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fitted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date. - Page 21 +44 118 931 0035 Service Telephone +44 118 933 6911 Service Fax +44 118 986 9124 Spares Telephone +44 118 933 6922 Technical / Advice Telephone +44 118 933 6933 E-mail: sales@baumatic.co.uk technical@baumatic.co.uk Http (Internet site): www.baumatic.com Baumatic UK/cod. 1230000666...
