- Page 1 Orbital Sander EZ-Sand Operator’s Manual...
-
Page 2: Operator Safety Instructions
English - EN Section - A Operator Safety Instructions DANGER means: Severe bodily injury or death can occur to you or other personnel if the DANGER statements found on this machine or in this Owner’s Manual are ignored or are not adhered to. Read and observe all DANGER statements found in this Owner’s Manual and on your machine. -
Page 3: Introduction & Machine Specifications
Section - A English - EN Introduction & Machine Specifications Model EZ Sand - HDTR Code Number 07163A Voltage Frequency 115V / 60Hz Amperage (A) Motors (3) 1/3 hp each Pad Size (3) 7” O.D. each Power Cable 40 Ft. 12/3 Ga. Gray Rubber Jacketed Orbits Per Minute 5000 Each Motor Orbit Diameter... -
Page 4: Machine Transportation
English - EN Section - A Machine Transportation To transport the machine, follow this procedure: 1. Unplug machine from wall outlet and wrap cord. 2. Raise and lock the handle to the vertical and upright position. To lock the handle, unhook the knurled collar by raising and twisting it (See Figure 1), and then allow it to slide into the black cast iron weight (See Figure 1A). -
Page 5: Machine Setup
Section - A English - EN Machine Set-Up To prepare the machine for use follow this procedure: 1. Familiarize yourself with the machine. Read all danger, warning, and caution statements and the Operator’s and Parts Manual before operating the machine. If you or the operator are unable to read English, have this manual fully explained before attempting to operate this machine. -
Page 6: Dust Collection
English - EN Section - A Dust Collection This sanding machine is designed to be operated with a 1.5” Hose From remote vacuum dust collection system or with the included Vacuum System dust bag. (Not Included) Preparing Remote Vacuum Dust Collection Systems To prepare the machine for remote vacuum dust collection systems that have a 2”... - Page 7 Section - A English - EN Operating Instructions Follow this procedure for sanding floors: 1. Move machine to work location. Decide the best approach to sanding the desired area. When sanding the area, work so that you are moving away from the power supply.
-
Page 8: Troubleshooting
English - EN Section - A Troubleshooting Problem Possible Cause Solution No Power. Check power supply and connection. Motor will not start. Interlock not depressed. Depress Interlock before activating control lever. Defective switch / Bad Connection Contact an authorized American Sander Technology Dealer. Low voltage from excessive length or Use a 14 Ga extension cord, not to exceed 50’...
