Motorola MH7020 Quick Start Manual

Ac2200 mesh-ready wifi router with motorola whole home tri-band wifi compatibility
Hide thumbs

Advertisement

Quick Links

Quick Start
AC2200 Mesh-Ready WiFi Router
with
Motorola Whole Home Tri-Band
WiFi Compatibility
MODEL MH7020

Advertisement

loading

  Related Manuals for Motorola MH7020

  Summary of Contents for Motorola MH7020

  • Page 1 Quick Start AC2200 Mesh-Ready WiFi Router with Motorola Whole Home Tri-Band WiFi Compatibility MODEL MH7020...
  • Page 2: Included In The Box

    Included in the box Motorola Router Power Adapter Ethernet Cable (varies by region) Para una Guía de Inicio Rápido en español, por favor vaya a www.motorolanetwork.com/MH7020IR...
  • Page 3: Let's Get Started

    QR code The app will then ask you if you want to install a Satellite. Since the MH7020 does not come with a Satellite, tap Done with Setup. Now enjoy the app. You can easily elect to keep your original WiFi name and password, as we recommend.
  • Page 4 Internet access. Plug the included Ethernet cable between the WAN/LAN port on your MH7020 and the LAN port of your modem or the Ethernet jack of your in-building network. If you are using a modem, switch the power of the modem off now.
  • Page 5: Expanding Your Network

    Motorola MH7021 Satellite to create a whole home Mesh Network to improve your WiFi coverage. As an AC2200-Ready router, the MH7020 has a third WiFi band that is available to connect to MH7021 Satellites. Normally this...
  • Page 6: Rear Panel

    WAN/LAN and LAN ports On this MH7020 Router, the WAN/LAN port is a WAN port. Use this port to connect your Router to your modem’s LAN port. If you later add a Satellite unit to your network, the WAN/LAN port on the Satellite is a LAN port.
  • Page 7 Front Panel Light The Motorola Logo on the front of the units will change colors to indicate the status. Color Description Connected to your modem. Solid Green Unit is powering up. After power up, blinking green indicates the WAN port is not connected to your Blinking Green modem.
  • Page 8: Troubleshooting Tips

    Troubleshooting Tips What if I can’t make an Internet connection right after installation? • First turn the modem that provides your Internet connection off for at least 8 seconds, then on, to see if that fixes the problem. • Check that the Router’s power adapter is plugged into a live outlet, and the power button is pushed in.
  • Page 9 You may need a Satellite unit to provide coverage throughout your home. The MH7021 is a single Satellite unit designed to work with the MH7020 WiFi Router. You may add up to 3 satellites to your MH7020. MH7020 Quick Start...
  • Page 10 Do you have any other questions? We have lots more information at www.motorolanetwork.com/mentor We like to help. Please visit our support website or call our support specialists. Our website has our Motorola Mentor information, and also provides returns and warranty information. www.motorolanetwork.com/support Email: support@motorolanetwork.com...
  • Page 11: Limited Warranty

    MTRLC LLC warrants this product against defects in material and workmanship for a warranty period of 2 years. To read the full warranty, please go to www.motorolanetwork.com/warranty Label Symbols Symbol Indicates DC voltage AC voltage For indoor use only Class II equipment Energy Efficiency Marking MH7020 Quick Start...
  • Page 12: Safety Precautions

    MTRLC LLC PO Box 121147 Boston, MA 02112-1147 © Motorola Mobility LLC 2020. MOTOROLA, the Stylized Motorola Logo, and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. Minim is a registered trademark of Minim, Inc. All other trademarks are the property of their respective owners.
