DIMENSIONS unit: mm (inch)
21.5 (.85)
10 (.39)
TERMINAL ASSIGNMENTS unit: mm (inch)
INPUT RESISTOR
(model: REM2)
4
1
8
5
12
9
14 13
Input shunt resistor attached
for current input.
SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM
+
SIGNAL SOURCE
The M2VF2, by its fast-response feature, is not designed to eliminate noise present in the input signal. Use a shielded twisted-pair cable to
prevent noise from entering through the input wiring.
The described response time may not be assured with the current output when the cable's line capacitance is greater than 2000 pF.
Specifications are subject to change without notice.
SEN TRONIC
AG
Produkte, Support und Service
84 (3.31)
114 (4.49)
• When mounting, no extra space is needed between units.
Isolation
Low Drift
1
*
Amplifier
R
4
5
8
Base Socket
*Input shunt resistor attached for current input.
Rugghölzli 2
CH - 5453 Busslingen
MODEL: M2VF2
6 (.23)
DIN RAIL
4
1
35mm wide
8
5
2–4.2x5
(.17x.20)
MTG HOLE
6 (.24) deep
12
9
8–M3
SCREW
14 13
15 (.59)
[4 (.16)]
23 (.91)
Z
S
Output
+
9
Driver
OUTPUT
12
13
U(+)
POWER
14
V(–)
Tel. +41 (0)56 222 38 18
Fax +41 (0)56 222 10 12
mailbox@sentronic.com
www.sentronic.com
