Step 5
Connect wall panel zip to the roof
and base zips (under Velcro flaps).
Step 6
Zip the wall panel to the roof and base.
Assembly Instructions
Two Person Assembly Recommended
Lock poles into connecters
by rotating left or right
Insert pole into connector
(ensure poles are fully inserted)
Equipment Hangers
Lower Equipment Hanger
Parts List
Red Pole
Yellow pole
x11
x12
3-Way
Corner
x8
NOTE
Rotate locking
mechanism until it clicks
Insert pole into connector
(ensure poles are fully inserted)
If unable to Insert pole
Upper Equipment Hanger
Green Pole
Straight
x16
Connector
x8
3-Way
Equipment
T Piece
Hanger Ends
x10
x8
Advertisement
Table of Contents
Related Manuals for Mammoth Tents Elite 240L
Summary of Contents for Mammoth Tents Elite 240L
- Page 1 Assembly Instructions Step 5 Two Person Assembly Recommended Connect wall panel zip to the roof and base zips (under Velcro flaps). Lock poles into connecters by rotating left or right Insert pole into connector (ensure poles are fully inserted) NOTE Rotate locking mechanism until it clicks Insert pole into connector...
- Page 2 Step 1 Step 3 Insert ceiling poles into 3-way corners and 3-way T pieces. Lay out base ensuring Velcro flap is in front right corner. Fit equipment hanger ends to poles. Position equipment hangers as required. Assemble floor poles, 3-way corners and 3-way T pieces as shown. 3-Way T Piece 3-Way Corner Equipment...
