3 Device Installation
Installation on the wall
① Attach the mounting template sticker to the wall, and drill holes according to the mounting
paper.
② Fix the back plate on the wall using the wall mounting screws.
③ Attach the device to the back plate.
④ Fasten the device to the back plate with a security screw.
1
1.55m
3
②
①
2
4
3
