emaux AFS40 Instruction Manual

Installation diagram
Qmax Hmax Power
Model
E
3 (m)
(m / h) P1 (kW)
3
G2 /
AFS40 78 13 3.0
or
AFS55 90 17.5 4.0
4FBT
V / Hz esp: See pump nameplate. Liquid temperature: 4 ~ 50
Storage temperature: -10 ~ Relativa Air Humidity: 95 Max.
+50 .
Pump parts for AFS
Key No. Part No.
1 89023501 Union
2 89023502 Screw with Nut & Washer
3 01112094 Pump Body
4 02010251 O-Ring for Flange
5 89023503 Nut for Impeller
6 01271049 Impeller AFS40
6 01271050 Impeller AFS55
7 04015054 Mechanical Seal
8 89023504 Screw
9 01112095 Pump Flange
10 89023505 Screw
11 01112096 Base
12 01031040 Wire Box
13 02010265 Box Slinger
14 01031041 Fan
15 01031042 Fan cover
77
4
215
245
430
Description
4-4
95
E
180
280
When installing and using this electrical equipment, basic safety
precautions should always be followed, including the following:
Qty
1) READ AND FOLLOW ALL
2 INSTRUCTIONS
6 2 WARNING )
do not permit children to use this product
1
unless they are closely supervised at all
1
times.
1
3.WARNING
1
Connected only to grounding type rece-
1
ptacle protected by a ground fault circuit
1
interrupter(GFCI). Contact a qualified
4
electrician if you cannot verify that the
1
receptacle is protected by GFCI.
2
4 CAUTION Do not bury cord. Locate )
1
cord to minimize abuse from lawnmowers,
1 hedge trimmers, and other equipment.
1
5 CAUTION )
1
parts will injure people, don't make
1
the electric pump running before then
pipeline have been connected.
6 WARNING )
electrical shock, replace damaged
cord immediately.

1) General

These instructions are for correct installation, and optimum performance of the Bath
pumps, so they should be read carefully. These are single-stage centrifugal pumps
designed to operate with compact hydromassage equipment, They are equipped with
a total-emptying system to prevent the discharge of residual liquid in each stopping.
These units are designed to operate with clean water at a maximum water temperature
of 50°C. Built of top quality materials, they are subjected to strict hydraulic and electrical
controls and are carefully verified. Correct installation is ensured by following these
instructions and those of the wiring diagram; otherwise, over loads may be produced in
the motor. We decline responsibility for any damage caused by not following these
instructions.
SWIMMING TRAINING PUMP
INSTRUCTION MANUAL
AFS SERIES PUMPS

IMPORTANT SAFETY INSTRUCTIONS

7 WARNING )
electrical shock, do not use extension
To reduce the risk of injury.
cord to connect unit electric supply;
provide a properly located outlet.
8 CAUTION )
spapools, swimmingpools, massage
Risk of Electrical Shock.
stations, cleaning system.
9)Do not install within an outer encl-
osure or beneath the skirt of a hot tub
unless so marked.
10) This appliance is not intended for use
by young children or infirm persons unless
they have been adequately supervised by
a responsible person to ensure that they
can use the appliance safely.
In case the running
11) Young children should be supervi-
sed to ensure that they do not play with
the appliance.
12 SAVE THESE INSTRUCTIONS )
To reduce the risk of
1-4
To reduce the risk of
Jetpump for jetted bathtubs,
EMPU16022762
