ANTENAS TV BANDA UHF
TV ANTENNAS UHF BAND
ANTENNES TV BANDE UHF
CÓMO CONECTAR EL CABLE COAXIAL EN LA CAJA DEL SIMETRIZADOR
HOW TO CONNECT THE COAXIAL CABLE TO THE MATCHING TRANSFORMER
COMMENT RELIER LE CÂBLE COAXIAL DANS LE BOÎTIER DU SYMÉTRISEUR
1
2
3
4
SERIE 900 SERIES
12 mm
3±1
8±1mm
Ø 6,5 - 6,8 mm
CM-004
9120039
Ø 6,9 - 7,2 mm
MC-302
9080023
5
CÓMO MONTAR LA ANTENA
HOW TO MOUNT THE ANTENNA
COMMENT MONTER L'ANTENNE
2
3
MONTAJE DE LA POLARIDAD HORIZONTAL O VERTICAL
MOUNTING IN EITHER HORIZONTAL OR VERTICAL POLARITY
MONTAGE EN HORIZONTAL OU VERTICAL
HORIZONTAL
AJUSTE DEL ÁNGULO DE ELEVACIÓN
ELEVATION ANGLE ADJUSTMENT
RÉGLAGE DE L'ANGLE D'ÉLÉVATION
6
7
1
VERTICAL
30°
Advertisement
Related Manuals for Alcad 900 Series
Summary of Contents for Alcad 900 Series
- Page 1 ANTENAS TV BANDA UHF TV ANTENNAS UHF BAND ANTENNES TV BANDE UHF SERIE 900 SERIES CÓMO CONECTAR EL CABLE COAXIAL EN LA CAJA DEL SIMETRIZADOR MONTAJE DE LA POLARIDAD HORIZONTAL O VERTICAL HOW TO CONNECT THE COAXIAL CABLE TO THE MATCHING TRANSFORMER MOUNTING IN EITHER HORIZONTAL OR VERTICAL POLARITY COMMENT RELIER LE CÂBLE COAXIAL DANS LE BOÎTIER DU SYMÉTRISEUR...
- Page 2 EN ISO/IEC 17050-1:2004 according to EN ISO/IEC 17050-1:2004 Pertes de retour Polarización HOR/VER Polarity Company Name: ALCAD, S.L. Polarisation Company Address: Pol. Ind. Arreche-Ugalde, 1 Ángulo de apertura ° H Apdo. 455, 20305 IRÚN (Guipúzcoa), SPAIN Beam width declares that the product °...
