Summary of Contents for Alcad 900 Series
- Page 1 ANTENAS TV BANDA UHF TV ANTENNAS UHF BAND ANTENNES TV BANDE UHF ANTENAS TV BANDA UHF UHF ANTENNEN SERIE 900 SERIES...
- Page 2 CARACTERÍSTICAS PRINCIPALES MAIN FEATURES PRINCIPALES CARACTERISTIQUES CARACTERISTICAS PRINCIPAIS WESENTLICHE KENNZEICHEN CÓDIGO-CODE-CODE-CODIGO-CODE 9000039 9000042 9000032 9000043 9000047 TIPO-TYPE-TYPE-TIPO-TYP BU-289 BU-269 BU-247 BU-569 BU-547 CANALES 470-862 470-862 470-686 470-862 470-686 CHANNELS CANAUX CANAIS 21- 69 21- 69 21- 47 21- 69 21- 47 KANÄLE GANANCIA GAIN...
- Page 3 BU-247 G (dBd) BU-247 HOR (f=686 MHz) VER (f=686 MHz) -20 -10 BU-289/269/559/547 BU-547 BU-569 G (dBd) G (dBd) BU-269 BU-289...
- Page 4 COMO MONTAR LA ANTENA BU-289 HOW TO MOUNT THE ANTENNA BU-289 COMMENT MONTER L'ANTENNE BU-289 COMO MONTAR A ANTENA BU-289 WIE WIRD DIE ANTENNE MONTIERT BU-289 COMO MONTAR LA ANTENA BU-269/247 HOW TO MOUNT THE ANTENNA BU-269/247 COMMENT MONTER L'ANTENNE BU-269/247 COMO MONTAR A ANTENA BU-269/247 WIE WIRD DIE ANTENNE MONTIERT BU-269/247...
- Page 5 COMO PREPARAR EL CABLE COAXIAL HOW TO PREPARE THE COAXIAL CABLE COMMENT PREPARER LE CABLE COAXIAL COMO PREPARAR O CABO COAXIAL WIE BEREITET MAN DAS KOAXIAL-KABEL VOR 10mm 10mm COMO MONTAR LA CAJA DEL DIPOLO HOW TO MOUNT THE DIPOLE BOX COMMENT MONTER LE BOITIER DU DIPOLE COMO MONTAR A CAIXA DO DIPOLO WIE MONTIERT MAN DIE DIPOL-BOX...
-
Page 6: Declaration Of Conformity
Manufacturer's Name: Pol. Ind. Arreche-Ugalde, 1 Manufacturer's Address: Apdo. 455 20305 IRUN (Guipúzcoa) SPAIN declares that the product 900 Series: ANTENNAS Product Name: BU-289, BU-269, BU-247, BU-569, BU-547 Model Number(s): Product Option(s): INCLUDING ALL OPTIONS is in conformity with: Safety:...
