Ceramic fuse base D01 D02
CAUTION!
Installation by electricians only!
Fuse link replacement
Unscrew the fuse carrier
Dimensions [mm]
Replace the fuse link
ETI, d.o.o.
Obrezija 5
SI-1411 Izlake
INSTALLATION INSTRUCTION
Installation
Snap on DIN rail
Disassembly
Using a screwdriver
Screw back the fuse
pull down on the metal
carrier
snap-on unit
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ETI D01
Summary of Contents for ETI D01
- Page 1 INSTALLATION INSTRUCTION Ceramic fuse base D01 D02 Dimensions [mm] Installation Snap on DIN rail CAUTION! Installation by electricians only! Fuse link replacement Disassembly Using a screwdriver Replace the fuse link Unscrew the fuse carrier Screw back the fuse pull down on the metal...
- Page 2 INSTALLATION INSTRUCTION Fuse-switch disconnector VLD01 Dimensions [mm] Installation Snap on DIN rail. CAUTION! Installation by electricians only! Disconnector switched off/on Disassembly Using a screwdriver, pull down on the plastic snap-on unit. ETI, d.o.o. Obrezija 5 SI-1411 Izlake...
- Page 3 INSTALLATION INSTRUCTION PFB D01 D02 Dimensions [mm] Installation Snap on DIN rail CAUTION! Installation by electricians only! Fuse link replacement Disassembly Using a screwdriver Unscrew the cap Replace the fuse link Screw the cap back pull down on the plastic snap-on unit ETI, d.o.o.
- Page 4 Fuse link replacement Disassembly Using a screwdriver Open the panel. Push down the Replace the Push back the fuse- pull down on the fuse-link. link holder and close fuse-link plastic snap-on unit. the panel. holder ETI, d.o.o. Obrezija 5 SI-1411 Izlake...
