Arjo Miranti Quick Reference Manual

QUICK REFERENCE GUIDE - FUNCTIONS
Miranti
Hand control
Emergency stop
Push button and pull out
battery.
Backrest and hook rope
1
Attach hook rope to the button
head on the side of the stretcher.
Control panel
Emergency high/low
1
Unplug the hand control.
2
Turn hook upwards.
08.CE.05EN_1 • 06/2020 • Page 1/2
Raise the stretcher.
Lower the stretcher.
Raise the backrest.
Lower the backrest.
Apply the central brake.
Flashing light = brakes activated
Release the central brake.
2
Insert thin, blunt object into the hole
and press to raise or lower the lift bath
trolley.
Do not use sharp object.
3
Use buttons to raise
or lower the backrest
