1. Observe the safety and ESD precautions at the beginning of this chapter.
2. Holding the DIMM only by its edges, remove it from its antistatic
package.
3. Orient the DIMM so that the two notches in the bottom edge of the
DIMM align with the keyed socket.
4. Insert the bottom edge of the DIMM into the socket, and press down
firmly on the DIMM until it seats correctly.
5. Gently push the plastic ejector levers on the socket ends to the upright
position.
6. Repeat the steps to install each DIMM.
7. Run the SCU to configure the system and to properly attribute ECC
memory.
Make sure you run the SCU to configure ECC memory
Failure to do so may degrade the performance of the server.

Memory, Removing DIMMs

CAUTION, use care when removing DIMM
Use extreme care when removing a DIMM. Too much
pressure can damage the socket slot. Apply only enough
pressure on the plastic ejector levers to release the DIMM.
1. Observe the safety and ESD precautions at the beginning of this chapter.
2. Gently push the plastic ejector levers out and down to eject a DIMM
from its socket. Refer to the figure, "Installation and locations of
memory DIMM sockets" on page 82, as necessary.
3. Hold the DIMM only by its edges, being careful not to touch its
components or gold edge connectors. Carefully lift it away from the
socket, and store it in an antistatic package.
4. Repeat to remove other DIMMs as necessary.
5. Run the SCU to configure the system and to properly attribute ECC
memory.
