- Page 1 Intel R1000 Development Platform Quick Start Guide July 2007 Revision 1.1 317118 Document Number:...
- Page 2 The Intel R10000, Intel R1000 Development Platform and the Intel R1000 Firmware may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.
-
Page 3: Table Of Contents
Reference documents................5 Intel R1000 Quick Start ..................6 Overview ....................6 Intel® R1000 Development Platform Package..........6 Reading Tags with the Intel R1000 Development Platform ......10 Changing the Host Interface from USB to UART ........13 Next Steps ..................14 317118-001 / Quick Start Guide... -
Page 4: Revision History
Introduction Revision history Document Revision Description Revision Date Number Number Initial release. April 2007 317118 Updated with Release 1.1 July 2007 § 317118-001 / Quick Start Guide... -
Page 5: Introduction
Introduction Introduction The Intel® R1000 Development Quick Start Guide explains how to set up an Intel® R1000 Development Platform and start reading tags out of the box. Reference documents Document Document # Intel RFIR Transceiver Interface API Reference Manual 313410... -
Page 6: Intel R1000 Quick Start
Intel R1000 Quick Start Overview The Intel R1000 Development Platform package, when used in conjunction with a host platform, provides the components required to implement and evaluate the Intel R1000 and Intel R1000 Firmware as used in an RFID reader environment. - Page 7 Figure 2: Intel R1000 development platform underside of chassis Figure 3 shows the topside of a typical Intel R1000 Development Platform unit. 317118-001 / Quick Start Guide...
- Page 8 Intel R1000 Quick Start Figure 3: Intel R1000 development platform chassis top view 3. External 5V power supply module (110/240V) 4. External power supply power cord Figure 4 shows the power supply module and power cord. Figure 4: Power supply and power cord...
- Page 9 Figure 5 shows the USB and Serial cables Figure 5: USB and serial cable 7. Ten (10) Intel R1000 chips 8. Intel R1000 Collateral CD. The CD contains the following Intel R1000 software files: Intel R1000 Firmware binary file Intel R1000 host software binary files (Windows XP, Windows CE and Linux versions.
-
Page 10: Reading Tags With The Intel R1000 Development Platform
Base board & PA BOM 2. Hard copy of this Quick Start Guide Note: In order to use the Intel R1000 Evaluation Platform the users must supply the following components: 1. A Host platform. For the remainder of this document the host platform is assumed to be an IA-32 (aka. - Page 11 TX1/RX3 and RX3 Note: Ensure that the tag is stationary, positioned directly in front of the antenna at a distance of about 1 meter. The goal is to verify correct setup rather than to exercise the Intel R1000 read range or rate.
- Page 12 When the last screen appears, click the “Finish” button to dismiss the New Hardware Wizard 5. Launch the RFID Tracer Application by selecting > Start > Programs > Intel RFID SDK > Intel RFID Tracer 6. Execute an inventory command from the Intel RFID Tracer application and verify that the tag data for the tag in the field of view of the antenna is returned to the Tracer main window.
-
Page 13: Changing The Host Interface From Usb To Uart
The development platform requires the USB cable to be plugged in to the PC in order to power up even if using the serial port. This is because the platform was designed for USB operation. When designing a system around the R1000 the USB port can be omitted. -
Page 14: Next Steps
Use the code example in the “R1000 Firmware Datasheet” Appendix D. Next Steps Once the basic operation of the Intel R1000 Development Platform has been verified, we advise that you become familiar with the capabilities of the Intel R1000 and related 317118-001 / Quick Start Guide... - Page 15 Intel R1000 Quick Start related hardware and software components. Please refer to the table below for a quick reference on how the documents relate to the Intel components. Component Document Intel R1000 Intel R1000 Datasheet Intel R1000 Firmware Datasheet Intel R1000 Firmware...
