Page 22
CPS Telecom 1. Power ON/OFF Button When the power ON / OFF button pressed for more than 3 seconds, start‐up sound occurs with company logo and the radio turns ON. Push again power ON/OFF button while the radio power is ON, the power is OFF with "Good bye" sound 2. PTT Button Pressing PTT button, the radio mode is transmission and releasing the button, it is receiving mode. It is recommended to talk 5~10cm away ...
Page 23
www.cps‐telecom.com 8 . P1, P2, P3 Programmable Button If you push the P button for more than 2 seconds, the P button has two functions of Short Key and Long Key. The Short Key is set by PC program and Long Key is defined in the body. P Key Short Key Long Key P1 Programmable Key Lock ON/OFF P2 Programmable Flash Light ON/OFF P3 Programmable Vibration mode ON/OFF 9. EAR/MIC Jack This jack is used to connect external speaker Mic, and headset, etc. 10. Micro USB Jack ...
Page 24
CPS Telecom 2)Please charge the battery before using the radio for best performance and safety. 3)When you charge the battery that is installed in the Radio, please turn off the radio first to charge the battery 2 . Charging time Low battery voltage maybe cause to reduce communication coverage and also make the performance worse. Please charge the battery in case of following: 1)When you think that the performance of the radio has degradation. 2)The red lamp on RX/TX LED blinks. (every 0.5 second), during transmission or reception. 3)When the battery icon is blinks 4)While the radio is in use, “beep” sounds. ...
Page 26
CPS Te elecom 1 . Con ntact List Set a c contact list (set to CPS S program) and will be e pressing t the PTT button n to call. If yo ou want to c call with ano other registe ered contact t, after you sel lect a contac ct from the c contact list a and press th he PTT butto on, it ...
Page 27
www.cps‐telecom.com 2)Inbox It is possible to store up to 10 incoming messages. When you choose contents stored in the list, you can see the received messages. When the received message is more than 10, the earliest incoming message is cleared first and it is registered. If you want to delete incoming messages, it can be deleted by selecting delete all menu. 3)Outbox It is possible to store up to 10 outgoing messages. When you choose contents stored in the list, you can see the outgoing messages. When the outgoing message is more than 10, the earliest outgoing message is cleared first and it is registered. If you want to delete outgoing messages, it can be deleted by ...
Page 28
CPS Telecom 4. Call Recording This function is used to save the outgoing and incoming calls content. If the recorded content is not required, it can be completely deleted. Calls list can store up to 63 and one call list will be limited to 2 minutes and 30 seconds. If you want to use the call recording function, you can select in the settings. 5. Scan When turning ON the scan operation, to start the scan in the order of ...
www.cps‐telecom.com the digital channels. The setting of voice encryption code is using the CPS program, the total number of encryption can be set from 0 to 65535. 3) VOX VOX function is transmitted by detecting a voice level without Using the PTT button VOX sensitivity level is 1 ‐ 5 steps, you can set using the CPS program. 4) Lone worker It is function to inform others about your safety within the time set in the menu. Setting time supports up to 1‐100 minutes. 5) BCL/BCLO If the another user on the currently used channel, it is the ability to limit the transmission so as not to interfere. BCL: If the current channel is busy, the transmission prohibition BCLO: The ability to send regardless of the user of the current channel 6) Button Lock With the exception of the minimum of buttons necessary for the user to prevent unwanted terminal operation, it is the ability to limit the operation. When the button lock is on, all buttons ...
Page 30
The function is to adjust the brightness. The brightness can be set from 1 to 7 step. LED Status display setting. The feature is to set the LED status display. It can be set detailed using the CPS program. 10)LED Control ...
