Pro-Form 890E User Manual page 7

The scan
modeÑ
Mode
Repeatedly
Arrow
press the
mode button
until an arrow
appears under
Mode
the scan sym-
Button
bol. When the
scan mode is
selected, the console will display the speed, time,
distance, lap and calorie modes, for 5 seconds
each, in a repeating cycle.
The speed,
time, distance,
Mode
lap, or calorie
Arrow
modeÑ
Repeatedly
press the
mode button
until an arrow appears below or above the
desired mode symbol. Make sure that there is not
an arrow under the scan symbol.
To reset the display, press the on/reset button.
Turn off the power
5
To turn off the power, simply wait for about
six minutes. If the pedals are not turned and the
console buttons are not pressed for six minutes,
the power will turn off automatically.
HOW TO SELECT KILOMETRES OR MILES
The console can
1
display distance
and speed in either
kilometres or miles.
If a ÒKPHÓ appears
in the display, dis-
tance and speed
Screws
will be shown in
kilometres; if a
ÒKPHÓ does not
2
appear, distance
and speed will be
shown in miles.
Battery
Switch
To change the unit
Door
of measurement,
first remove the
four screws attach-
ing the console
(see drawing 1). Lift the console a few inches and turn
it over, being careful not to pull on the wires. Next,
look into the hole below the battery door, and locate
the small switch (see drawing 2). (Note: It may be
necessary to look into the hole and to the left side to
find the small switch.) Slide the switch up or down to
change the unit of measurement. re-attach the con-
sole with the four screws.
10
7. Attach the Handlebar (18) to the Handlebar Post
(19) with two M10 x 22mm Button Head Bolts (55)
and two M10 Lock Washers (61).
8. Make sure that all parts are tightened before you use the exercise cycle. To protect the floor from damage,
place a mat beneath the exercise cycle.
7
55
61
18
19
7
