Adjustment - iFIT Pro-Form PFBE11420.0 User Manual

ADJUSTMENT

The weight bench is designed to be used with your own weight set (not included). This section explains how to
adjust the weight bench. See EXERCISE GUIDELINES on page 14 for important exercise information, and
refer to the accompanying exercise guide to see the correct form for several exercises. Refer also to the exercise
information accompanying your weight set for additional exercises.
Make sure that all parts are properly tightened each time the weight bench is used. Replace any worn parts
immediately. The weight bench can be cleaned with a damp cloth and a mild, non-abrasive detergent; do not use
solvents.
ADJUSTING THE BACKREST
The Backrest (8) can be used in a declined position,
a level position, or either of two inclined positions.
To use the Backrest in the declined position, remove
the Backrest Support (14) and lay the Backrest on
the Crossbar (2).
To use the Backrest (8) in the level position or an
inclined position, lift the Backrest and insert the
Backrest Support (14) through one of the sets of
holes in the Uprights (1). Rotate the Backrest
Support so that the clip (A) is wrapped around an
Upright as shown.
WARNING:
the Backrest (8) in a level position or an
inclined position, insert the Backrest
Support (14) completely into both Uprights
(1) and rotate it so that the clip (A) is
wrapped around an Upright.
ATTACHING WEIGHTS TO THE LEG LEVER
To use the Leg Lever (6), slide the desired weights
(B) (not included) onto the weight tube (C). Secure
the weights with the Spring Clip (10).
WARNING:
than 50 lbs. (23 kg) on the Leg Lever (6).
When using the Leg Lever, place a barbell
with the same amount of weight on the
Weight Rests (not shown) to balance the
weight bench.
When using
Do not place more
8
6
10
C
B
12
1
1
A
14
2
