OPERATING AND MAINTENANCE MANUAL
Product:
Type:
DESIGNED AND MANUFACTURED BY:
T & R Test Equipment Limited
Keens Lane, Worplesdon, Guildford, Surrey, GU3 3LS, United Kingdom
Telephone: 01483 235757
Fax.:
01483 235759
3 Phase Secondary Current Injection Test Set
200A-3PH/E
e-mail: sales@trtest.com
Web:
www.trtest.com
Advertisement
Related Manuals for T&R 200A-3PH
Summary of Contents for T&R 200A-3PH
- Page 1 OPERATING AND MAINTENANCE MANUAL Product: 3 Phase Secondary Current Injection Test Set Type: 200A-3PH/E DESIGNED AND MANUFACTURED BY: T & R Test Equipment Limited Keens Lane, Worplesdon, Guildford, Surrey, GU3 3LS, United Kingdom Telephone: 01483 235757 e-mail: sales@trtest.com Fax.: 01483 235759 Web: www.trtest.com...
- Page 3 GENERAL SAFETY STATEMENT The following safety precautions should be reviewed to avoid injury to the user and damage to the product (and other products connected to it). To avoid potential hazards only use this product as specified. Only suitably qualified personnel should use this equipment. Servicing of this product should only be carried out by suitably qualified service personnel.
-
Page 5: Table Of Contents
CONTENTS Description of Equipment Operation of Equipment Maintenance Instructions Standard Accessories Overall Performance Specification Calibration Results Test Certificate Revision... -
Page 7: Description Of Equipment
DESCRIPTION OF EQUIPMENT Electrical Specification Variable 3 Phase Supply Timer Control Output Control Construction... - Page 8 Electrical Specification 1.1.1 The supply voltage for the equipment is 415V (380v if requested) , 3 phase, 50/60Hz. The unit will tolerate an input voltage variation of ± 6%. IMPORTANT: The Unit Must be Connected to a 4 Wire Supply. 1.1.2 The maximum power supply requirements will be 1100VA per phase.
- Page 9 Variable Three Phase Output 1.2.1 There are three independently controllable outputs available from the equipment. These outputs are 120º apart electrically. 1.2.2 The equipment's output terminals are located on the top edge of the front panel. Each terminal is clearly marked showing the output phase and polarity. 1.2.3 Each output phase is controlled by moving the appropriate regulator control knob in a clockwise direction.
- Page 10 Timer Control 1.3.1 The timer system will have the following parameters: Range: 0-999.999 seconds (Quartz locked) Resolution: 0.001 seconds Accuracy: Contact mode ± 2ms Current mode ± 3ms for test currents 20-40% on each range Current mode +3ms or -1ms for test currents 40-100% on each range NOTE: Timing results obtained with test currents below 20% of the selected ammeter range, and on measured times of 19ms and below, are of...
- Page 11 Output Control 1.4.1 The output from the unit is controlled by the illuminated output ON and OFF push-buttons. These push-buttons are located on the front panel of the unit. 1.4.2 The output is automatically switched off by the following actions: Depressing the OFF push-button.
- Page 12 Construction 1.5.1 The unit is housed in a steel case complete with a detachable lid and carrying handles located at each end of the case.
- Page 13 OPERATION Supply Voltage Connections Front Panel Control Functions Connections and Timing Functions Method of Operation...
- Page 14 Supply Voltage Connections 2.1.1 The 200A-3PH/E is provided with a 5 core supply cable. These cores are marked to ensure the correct phase rotation . The mains input lead is marked as follows: Brown Black Black Neutral Blue Earth Green and Yellow...
- Page 15 Front Panel Control Functions (Figure 1) 2.2.1 ITEM FUNCTION Supply ON/OFF switch To isolate all supply leads from the mains supply . Supply ON lamp To indicate supply is connected, (RED) the ON/OFF switch is closed and that the supply fuse is healthy. Output OFF illuminated push-button Indicates output is OFF (GREEN)
- Page 16 Figure 1 Front Panel Layout - 200A-3PH/E scits Earth terminal Input socket Supply ON/OFF switch Output fuses Output terminals Auxiliary supply sockets, fuse and ON/OFF switch Timer Contact sockets Timer mode switch Output ON push-button Output OFF push-button Current operated phase selector switch...
- Page 17 Connections and Timing Functions 2.3.1 The following figures give the connections and associated timing functions for various relay types. 2.3.2 Figure 3a Over current relays 2.3.3 Figure 3b Devices with no auxiliary contacts 2.3.4 Figure 3c Phase relationships IMPORTANT NOTES When connecting live contacts to the contact terminals ensure that care is taken when making the connection.
- Page 18 Figure 3a Over Current Relays Relay coils under test Relay Contacts CONNECTIONS 1. Timer mode switch setting to N/C or N/O 2. Relay contacts to red and blue contact terminals 3. Relay coils to the desired outputs TEST PROCEDURES 1. Switch on the main supply switch 2.
- Page 19 Figure 3b Timing Devices with No Auxiliary Contacts Device under test CONNECTIONS 1. Timer mode switch setting to 2. Connect the device to the desired outputs TEST PROCEDURES 1. Switch on the main supply switch 2. Select timer mode to the OFF position 3.
- Page 20 Figure 3c Phase Relationships SUPPLY 200A-3PH/E NOTE Other phases can be shifted by 180° by connection reversal DELTA output connections are not valid Diagrams above show equal output currents. Unequal currents are valid...
- Page 21 Method of Operation 2.4.1 Connect the equipment via the mains cable provided, to a 3-phase 4-wire supply. 2.4.2 Connect the output leads to the desired output terminals which are located on the top panel. The methods of connection are described in Section 2.3. Select the desired output.
- Page 22 MAINTENANCE The switches and contactors should be occasionally examined for signs of wear and contact erosion. Badly eroded contacts should be replaced immediately. The voltage regulator should be regularly examined, particularly in respect of the brushes, in order that the latter can be replaced before excessive wear has taken place.
-
Page 23: Standard Accessories
STANDARD ACCESSORIES Spare fuses supplied 3 off T5A 1¼ inch 2 off T63mA 20mm 1 off F500mA 20mm The following items are provided with the equipment: Mains input lead. Operating & Maintenance Manual. -
Page 25: Overall Performance Specification
OVERALL PERFORMANCE SPECIFICATION Insulation Resistance at 1000V DC The insulation resistance will not be less than 10 megohms between mains input to frame and all isolated outputs, and all combinations of isolated output to isolated output. Applied Voltage Test Mains input to frame and all isolated outputs 2kV RMS for 1 minute. All combinations of isolated output to isolated output. -
Page 27: Calibration Results
CALIBRATION RESULTS Equipment Serial Number ..........Ammeter Circuits Standard Equipment’s Ammeter Ammeter A phase B phase C phase 200A 160A 200A range 120A Standard Equipment’s Ammeter Ammeter A phase B phase C phase 100A 100A range Standard Equipment’s Ammeter Ammeter A phase B phase C phase... -
Page 29: Test Certificate
TEST CERTIFICATE PRODUCT TYPE: 200A-3PH/E scits PRODUCT SERIAL NUMBER: TEST PROCEDURE: As routine test sheet:- 200A3PHE rts.doc TESTED BY: ........PASSED BY: ........DATE: ........... -
Page 31: Revision
REVISION Product / Type: 3 Phase Secondary Current Injection Test Set / 200A-3PH/E File: 200A-3PHE manual v8.doc Author: D. Buckle Issue / Date: 8 / 19.04.2001 Modified By: D. Buckle Checked By: I.D.W. Lake Date: 19.04.2001... - Page 32 Drawings Required A2/000307 latest issue...
