GAC 103 Series Quick Start Manual

1
INTRODUCTION
The 103 Series Integral Actuator is a field-proven proportional actuator
designed to mount directly to the Delphi DPG/DP210 Pump. No
external linkage or brackets are required to install this actuator. When
de-energized, the 103 Series Electric Actuator provides the function of
the fuel shutoff solenoid. This is accomplished by an internal spring that
returns the fuel metering valve linkage to the no-fuel position when the
actuator is de-energized.
Since there are no sliding parts in the 103 Series electric actuator and
the unit is sealed, outstanding reliability and no maintenance are the
resulting qualities.
♦ 12 or 24 V DC
♦ Mounts directly to Delphi DPG/DP210 Pump
♦ No external linkages or brackets required
♦ Fast response; < 45 ms
♦ Functions as a fuel shutoff solenoid when governor system is de-
energized
The following installation kits are needed when installing these actuators on a Delphi DPG, DP210G, or DPGE:
• ADD103B-12 12 V DC / Packard Connector with Mating Connector Kit EC1300 / With Installation Kit KT292 (O-Ring, Bolts)
• ADD103B-24 24 V DC / Packard Connector with Mating Connector Kit EC1300 / With Installation Kit KT292 (O-Ring, Bolts)
2
SPECIFICATIONS
POWER INPUT
Operating Voltage (B-Series)
(L-Series)
Normal Operating Current
(B-Series)
(L-Series)
Maximum Current
(B-Series)
(L-Series)
ENVIRONMENT
Operating Temperature Range
Relative Humidity
Shock
Vibration
Agency
103 Series
Integral Electric Actuator
12 or 24 V DC Available
12 V DC
1.9 A at 12 V DC
1.5 A at 24 V DC
1.3 A at 12 V DC
2.7 A at 12 V DC
1.9 A at 24 V DC
1.8 A at 12 V DC
-40° to +180 °F
[-40 ° to +83 °C]
up to 100 %
20G, 11 ms
± 4g, 25 - 100 Hz
RoHS Compliant
1
PHYSICAL
Dimensions
Weight
Mounting (B-Series)
(L-Series)
MATING HARDWARE
All Models
ADD103B
ADD103L
Come with cable harness already
ADE Models
103 Series Integral Electric Actuator 4-2021-D2
Governors America Corp. © 2021 Copyright All Rights Reserved
See Section 3 Outline Drawing
1.0 lbf
Directly to Delphi Type DPG /
DP210G/310G
Customer Specific Pump
Come with mounting hardware
and O-ring
Packard Mating Connector
Customer Specific JD Mating
Connector
installed to mating connector
PIB2045
