Original
Original
Original
Original
Original
Operating
Operating
Operating
Operating
Operating
Instructions
Instructions
Instructions
Instructions
Instructions
Power Hoe
Power Hoe
Power Hoe
Power Hoe
Power Hoe
900 / 900-S
900 / 900-S
900 / 900-S
900 / 900-S
900 / 900-S
0900 041
0900 141
with Honda engine
3214_2,4205_1
Before commissioning the machine, read operating
instructions and observe warnings and safety instructions.
Operating Instructions No. 998 789 02.10
Advertisement
Table of Contents
Related Manuals for Agria 900
Summary of Contents for Agria 900
- Page 1 Instructions Instructions Instructions Instructions Power Hoe Power Hoe Power Hoe Power Hoe Power Hoe 900 / 900-S 900 / 900-S 900 / 900-S 900 / 900-S 900 / 900-S 0900 041 0900 141 with Honda engine 3214_2,4205_1 Before commissioning the machine, read operating instructions and observe warnings and safety instructions.
- Page 2 Visual check from them. We reserve the right for improvements without changing these instructions. Clutch Hoeing drive fast slow open Closed Wear protective gloves - Service = contact Your agria workshop Wear solid shoes agria Power Hoe 900 / 900-S...
-
Page 3: Designation Of Parts
Designation of Parts Type 900 13 14 Type 900-S featuring side-adjustable steering handle 25 24 13 14 agria Power Hoe 900 / 900-S... - Page 4 26 Extension for 65cm working width 27 R-clip to lock the depth bar 28 Push plate for steering handle side adjustment 29 Fuel tap on the right-hand side in the travelling direction 30 Fuel tank agria Power Hoe 900 / 900-S...
-
Page 5: Table Of Contents
....3 Operation Commissioning the Machine ..22 Unpacking and assembly .. 6 - 7 Starting the Engine (Type 900) ..23 Starting the Engine (Type 900-S) . 24 Recommendations Shutting off the Engine ....25 Lubricants, Anti-Corrosive Agents .. 8 Hoeing ........... -
Page 6: Unpacking And Assembly
Adjust the handlebar to the desired height and lock with eccentric lever (2). Mount hoeing tools and hoeing guards. Mount depth bar Mount front support wheel Carry out all steps for start- ing-up agria Power Hoe 900 / 900-S... - Page 7 Adjust the handlebar to the desired height and lock clamp- ing lever (4). Mount hoeing tools and hoe- ing guards. Mount depth bar Mount front support wheel Carry out all steps for start- ing-up agria Power Hoe 900 / 900-S...
-
Page 8: Recommendations Lubricants, Anti-Corrosive Agents
Only use suitable This engine runs smoothly on conven- tools to pull off the flywheel. tional unleaded regular and super- grade petrol as well as on leaded supergrade petrol. Do not add oil to petrol. agria Power Hoe 900 / 900-S... -
Page 9: Safety Instructions
Due use includes compliance with shut off. manufacturer’s instructions on opera- tion, maintenance and repair. Careful with rotating tools – keep at a safe distance! Any unauthorized changes to the power hoe render manufacturer liability null and void. agria Power Hoe 900 / 900-S... - Page 10 During operation keep a distance to the machine as defined by the length of the steering handle, especially when you turn the machine. Riding on the machine during operation or in transport is not permitted. agria Power Hoe 900 / 900-S...
- Page 11 For all other Do not maintain or clean the machine versions, remove the spark plug connec- while the engine is running. tor. Before you work on the engine, always remove the spark plug connector. agria Power Hoe 900 / 900-S...
- Page 12 Make sure fuel is of specified quality. Only use original agria spare parts. All Store fuel in approved cans only. other commercial spare parts must cor- Liquids leaking under high pressure, e.g.
- Page 13 Do not work without protective guards mounted. Before starting the engine, bring guards in proper position. Wear solid shoes. Danger – foreign objects may get air- borne. Keep clear off machine while engine is running. agria Power Hoe 900 / 900-S...
-
Page 14: Specifications
A (Type 900) ..... 280–460 mm adjustable without tools (Type 900-S) ..280–650 mm Weight: k ....>900 mm at h = 800 mm Type 900 (0900 041) ..approx. 35 kg Type 900-S (0900 141) . approx. 44 kg Noise levels: Noise level at operator’s ear .... -
Page 15: Engine
(with oil level at “max” = upper level mark) Valve lash (engine cold) Continuous operation possible up to Intake: ......0.15 ± 0.04 mm 20° inclination (37 %) Outlet: ......0.20 ± 0.04 mm agria Power Hoe 900 / 900-S... -
Page 16: Devices And Operating Elements Engine
The power hoe is equipped with a worm does not need maintenance. We recom- gear with 1 forward speed. mend to have the necessary check-ups done by an expert only. agria Power Hoe 900 / 900-S... -
Page 17: Safety Circuit Lever (Type 900)
(position HOEING). See chapter “Hoeing”! min. = NEUTRAL To start the engine, move the speed control lever to position “START/Choke” or “NEUTRAL”. Attention: The hoeing tools are rotating until the machine is in position “min.” agria Power Hoe 900 / 900-S... -
Page 18: Safety Circuit Lever (Type 900-S)
A/24 tween engine and tools is made and the A/25 hoeing tools start operating. With the control lever pulled, this connec- tion is disengaged and the tools come to a stop. agria Power Hoe 900 / 900-S... -
Page 19: Steering Handle
Then release the push plate and slightly move the handlebar to the right and left until the gears lock into mesh. agria Power Hoe 900 / 900-S... -
Page 20: Hoeing Tools
Insert the bolts (F/4) into the holes in Fit hoeing tools with bolts (F/4). In- the hub and secure them with R-clips sert the bolts into the holes in the hub (F/6). and secure them with R-clips (F/6). agria Power Hoe 900 / 900-S... -
Page 21: Depth Bar
A/27 two attachment holes. A/21 Optional depth bar Available for version 900-S (0900 141) This depth bar (accessory no. 1001 511) (H/1) is available as an option to improve depth control in loose soils. Remove the standard depth bar (A/21) and replace it by the optional depth bar, using the R-clip (H/2). -
Page 22: Commissioning And
Note: For reasons of transport, the engine is not filled with engine oil! Before you operate the engine the first time, fill in engine oil (see engine operating instruc- tions)! agria Power Hoe 900 / 900-S... -
Page 23: Starting The Engine (Type 900)
Do not let it snap back. Attention: The hoeing tools are rotating! Once the engine has startet, slowly push speed control lever to position “min.” The hoeing tools are rotating until the machine is in position “min.” agria Power Hoe 900 / 900-S... -
Page 24: Starting The Engine (Type 900-S)
Do not let it snap back. Attention: The hoeing tools are rotating! Once the engine has startet, slowly push speed control lever to position “min.” The hoeing tools are rotating until the machine is in position “min.” agria Power Hoe 900 / 900-S... -
Page 25: Shutting Off The Engine
The speed control lever also serves as engine shut-off lever. When necessary, move the speed control lever to STOP to stop the engine. Have the engine cooled down before parking the power hoe in closed rooms. agria Power Hoe 900 / 900-S... -
Page 26: Hoeing
. The hoeing tools start rotating. To adjust the desired working depth, set the depth bar to one of the two depth settings. agria Power Hoe 900 / 900-S... -
Page 27: Danger Zone
Remove jammed objects only by means of tools, e.g. a wooden stick. To clean and exchange the hoeing tools, only recline the machine back- wards onto the handlebar (before, re- move the depth bar). agria Power Hoe 900 / 900-S... -
Page 28: Maintenance
Check O-rings and ex- change them, if necessary. Oil filling quantity is approx. 0.3 l. 1 Transmission oil filling and control plug 2 O-ring 3 Transmission oil drain plug 4 O-ring agria Power Hoe 900 / 900-S... - Page 29 – Risk of fire! Check before each operation. Speed Control Devices for actuating engine speed must be adjusted correctly to start, operate and shut off the engine at correct speed rates. - Service agria Power Hoe 900 / 900-S...
-
Page 30: Clutch Hand Lever (Type 900-S)
2. Use set pin (4) to press cable end (3) out of bracket in hand lever Adjust the set pin (4) to a play of X 1. Hook the cable end into the bracket with the set pin 2. Fit retaining spring (2) agria Power Hoe 900 / 900-S... -
Page 31: Engine
Apply grease generously to leave a grease ring around bearings to prevent water, plant sap, and dirt from pen- etrating. agria Power Hoe 900 / 900-S... -
Page 32: Storage
Engine preservation Drain fuel completely and let the engine run until it comes to stop due to lack of fuel or add fuel stabilizer (agria No. 799 09) - observe enclosed instructions! Let engine run for approx. 1 minute. -
Page 33: Varnishes, Wear Parts
704 31 Hoeing tine, left 704 32 Hoeing tine, right 704 42 Linch pin 2 x 43 704 18 Pin for hoeing tools 704 31 704 32 Spare Parts 997 085 Power hoe 900 agria Power Hoe 900 / 900-S... -
Page 34: Troubleshooting
6. Troubleshooting Observe safety instructions! Have all serious malfunctions on the machine or engine repaired by your agria workshop. They have the proper tools. Improper repairs can only add to the damage. Problem Possible cause Possible solution Page Engine - Spark plug connector not connected... - Page 35 - Hand clutch lever misadjusted Adjust clutch free play - Worn out clutch Exchange clutch cone Excessive - Loosened attachment bolts Tighten attachment bolts vibration For this purpose contact your agria workshop BM = See engine operating instructions agria Power Hoe 900 / 900-S...
-
Page 36: Inspection And Maintenance Sheet
= Each time before you take up operation = After each cleaning BM = See engine operating instructions = Maintenance to be executed by your agria workshop = Checks and maintenance to be executed by operator W = Maintenance to be executed by professional workshop... - Page 37 Power Hoe 900 / 900-S...
- Page 38 Power Hoe 900 / 900-S...
-
Page 39: Conformity Declaration
Conformity Declaration agria Power Hoe 900 / 900-S... - Page 40 GmbH Bittelbronner Straße 42 D-74219 Möckmühl Tel. +49/ (0)6298 /39-0 Fax +49/ (0)6298/39-111 e-mail: info@agria.de Internet: www.agria.de Your local agria specialist dealer:...
