- Page 1 BAIN-MARIE Instruction Manual Marketed globally by: ADEXA DIRECT LIMITED Ground Floor, Unit 1, 214 Purley Way, Croydon CR0 4XG United Kingdom T:(+44)01483 931040 service@adexa.co.uk www.adexa.co.uk...
-
Page 2: Specification
Instruction Manual The Electric Bain marie design combines the advantages of stylish design, efficient construction, ease of operation and simple maintenance. The Bain marie temperature can be easily adjusted to suit cooking requirements, and, while mainly used for crepe. WARNING: Any modifications or incorrect installation, unauthorized adjustments or maintenance by unauthorized personnel may result in property loss or injury. -
Page 3: Explosive View
Instruction Manual Thermostat:30-95C: Used to set or adjust the temperature of the cooking plate. The numbers on the dial correspond with the grill plate temperature. The “0” position is off. Power Indicator: This light indicates the power on. Heat Indicator: This light indicates the element is heating. -
Page 4: Circuit Diagram
Instruction Manual ITEM QTY/pcs Water Pan water pipe Seal Gasket Screws Machine's body Water Valve Power Switch Thermostat knob Thermostat dial Heat indicator Thermostat Temper limiter Supporting S/S tube Cable Cable locker Ceramic terminal Cancelled this part after improvement Heater Insulation Cotton Heater plate Bottom Plate... -
Page 5: Troubleshooting
Instruction Manual Troubleshooting PROBLEM CAUSED SOLUTION Indicator light will not turn on and unit Plug not properly in-serted Plug unit in will not heat On&Off power switch broken Replace power switch Tighten both sides of electric heater Heating indicator is not on.The Electric heater tubes is not ...
