Installation, Operating and
Maintenance Instructions
HADEF Spur Gear Hoist
Type 16/12-EX
Explosion proof design
II 2G Ex h IIB T3 Gb or
DANGER!
Not to be used with IIC gases and IIB gases hydrogen sulphide and ethylene oxide and
light metal and shock sensitive dusts.
It is not allowed to use the equipment in area at risk from explosion where gas AND
dust does both exist at the same time!
5.52.190A.01.01.04
II 2D Ex h IIIA T200°C Db
Rev.04
Advertisement
Table of Contents
Related Manuals for HADEF 16/12-EX
Summary of Contents for HADEF 16/12-EX
- Page 1 Installation, Operating and Maintenance Instructions HADEF Spur Gear Hoist Type 16/12-EX Explosion proof design II 2G Ex h IIB T3 Gb or II 2D Ex h IIIA T200°C Db DANGER! Not to be used with IIC gases and IIB gases hydrogen sulphide and ethylene oxide and light metal and shock sensitive dusts.
-
Page 2: Table Of Contents
Heinrich de Fries GmbH Heinrich de Fries GmbH, Gauss Str. 20, D-40235 Düsseldorf Heinrich De Fries GmbH will be named HADEF in the following text. Original operating- and maintenance instructions in German language. Translation in other languages is made of the German original. -
Page 3: Information
11.1 General ..........................15 11.2 Monitoring ........................15 11.3 Replacing the load chain ....................15 Inspection ..................15 12.1 Periodic checks ....................... 15 12.2 Checking the load chain ....................16 12.3 Checking the load hook ....................17 12.4 Check of the pawl ......................17 12.5 Check of the brake system ..................... -
Page 4: Safety
Failure to follow the instructions of this manual can lead to unpredictable hazards. For any resulting damage or personal injury, HADEF assumes no liability. The unit was designed and built following a risk analysis and careful selection of the harmonized standards that are to be complied with, as well as other technical specifications. -
Page 5: Requirements For The Operating Personnel
customers equipment at site must comply with currently applicable ATEX-regulations WARNING! It is not allowed to make constructive changes of the equipment! Requirements for the operating personnel The units may only be operated by qualified persons that are appropriately trained and that are familiar with it. -
Page 6: Basic Safety Measures
NOTICE! If the units are not used appropriately, it is not possible to ensure safe operation. The owner and operator have sole liability for all personal injury and damage to property arising from inappropriate use. DANGER! It’s only allowed to use the unit in the EX-classification which is named on the type plate; or in lower classes Basic safety measures ... - Page 7 Check the grease level of the bearings regularly Exchange friction surfaces in time and (an exception to this are electric units - maintenance of the brakes must only be effected by HADEF). Protect the device from impact, friction, rough handling and moisture.
-
Page 8: Explosion Protection
Explosion protection The EX classification of the unit is indicated on a separate plate, situated on the unit. Illustration 2 Example of ATEX classification: Ex h CE-marking European Union explosion-proof operating material danger of mine damp device group / application other areas prone to explosion for use in zone 0 device category... - Page 9 DANGER! The classification for the device can be found on the EX-type plate on the unit. The device must only be used in the classification stated or in a lower classification. 2.6.2 Surface temperature of the devices DANGER! The temperature class mentioned on the EX-type plate on the unit must be observed, - make sure that the max.
- Page 10 Explosion hazards … recognizing and preventing! 2.6.4 5.52.190A.01.01.04...
-
Page 11: Transport And Storage
Transport and Storage CAUTION! Transport may only be done by qualified personnel. No liability for any damage resulting from improper transport or improper storage. Transport The devices are checked and if so adequately packed before delivery. Do not throw or drop the equipment. ... -
Page 12: Functions
Functions The load is lifted or lowered by pulling one of the chain falls of the endless hand chain of the hoist. A load pressure brake prevents automatic lowering of the load after releasing the hand chain. In combination with hand geared trolleys, the trolley is moved to the left or to the right side by pulling the hand chain. -
Page 13: Tools
Generally, additional lifting gear (e.g. fork lift, lifting platforms) will be required for the assembly. These must take the weight of the devices securely. Tools Control Only people that are familiar with the operation of the lifting devices and cranes may be entrusted with their operation. -
Page 14: Commissioning
Commissioning General Should the unit be used in Germany: Please observe the validated, national accident prevention regulations. For other countries: Inspections as above. Please observe the national rules and regulations and the instructions in this manual! NOTICE! Hoists up to 1000 kg capacity and without motor-driven trolleys of hoisting unit must be tested by a “qualified person”... -
Page 15: Functional Test
10.2 Functional test Lifting gear Check lifting and lowering functions, initially without a load. Then check the brake function under load. The load must be securely held. Trolleys Carefully move the trolley to the end positions and check the positions of the end stops. Maintenance 11.1 General... -
Page 16: Checking The Load Chain
CAUTION! When the wear limit is reached, the part must be exchanged by a new, original part. daily 1st maintenance Inspection Inspection Mainte- commissioning checks after Maintenance nance 3 months every every 3 months 12 months Check screw connections Check lifting, lowering functions. Check brake function for ratchet lever hoists: Check free-wheeling mechanism of the chain... -
Page 17: Checking The Load Hook
WARNING! When the dimensions listed in the table are reached due to wear or deformation, the chain must be replaced! DANGER! In case of corrosion and/or wear of the surface coating, the chains must be exchanged by original chains. 12.3 Checking the load hook Load hook X = measuring distance hook mouth width... -
Page 18: Check Of The Suspension Bolt
12.6 Check of the suspension bolt Suspension bolt dv min 5000-50000 23,8 Service 13.1 Load chain Wear at the links is mainly due to insufficient maintenance of the chain. To ensure optimal lubrication of the links, the chain must be lubricated at regular intervals, depending on usage. -
Page 19: Gear
13.4 Gear Regular checks of lubrication are necessary. The teeth must be cleaned and re-lubricated after approx. 3 years. We recommend to use a lubricant of class EP2 or similar products. In case of severe conditions of use (e.g. dust, regular lifting of the nominal load,etc.), please shorten maintenance intervals. 13.5 Gear spring pressure brake During the check, brake lining wear is verified. -
Page 20: Remedy
Remedy Problem Cause Remedy Overload reduce the load to nominal load load got stuck set the load free again Do maintenance and brake linings are worn exchange the brake linings Load chain is twisted Align the load chain Load is not lifted Do maintenance and replace defective parts by original Defect of chain, gear or chain wheels spare parts...
