The TX3-IP Module ribbon cable connects to the P3 connector on the controller
board. It has an RJ-45 connector that connects to the Ethernet network using a
standard Ethernet cable. See Figure 14.
IP Module Ribbon Cable
RJ-45
Connector
Figure 14.
IP Module Data and Ethernet Connectors
For instructions on how to install the TX3-IP Module, see LT-1161 TX3-IP
Module Installation Instructions.
Note:
The TX3-IP Module can be installed only on TX3-ER-8-A and
TX3-ER-8-B.
Elevator Restriction System Installation and Operation Manual
Installing the Elevator Restriction Unit
29
