2.6

Elevator Restriction Unit ID

Use the eight position DIP Switch labelled SW2 to set the Elevator Restriction

Unit ID. Give each ERU a different Unit ID.

SW2 is shown in Figure 12.

The individual switches are numbered 1 to 8 from left to right, and are marked as

either ON or OFF. The first six switches (1, 2, 3, 4, 5 and 6) set the ID.

Note:

Table 1:

Elevator Control Unit SW2 DIP Switch Settings

Lobby Control Unit ID # Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6

0 (Not allowed as an

Elevator Control Unit ID. 0 is

used for PC ID.)

Elevator Restriction System Installation and Operation Manual

Every Elevator Restriction Unit in a given TX3 System requires

a unique ID. Do not duplicate Unit IDs.

OFF

Installing the Elevator Restriction Unit

OFF
