http://kb.fortinet.com/kb/microsites/microsite.do?cmd=displayKC&docType=kc&externalId=10338&
sliceId=1&docTypeID=DT_KCARTICLE_1_1
3) Load pre-format image
a) When the download completes, the console displays a message similar to:
Save as Default firmware/Run image without saving:[D/B/R]
b) Press R.
c) The system will start and open card mode selection menu will appear:
Opencard Mode Selection Menu:
[1] Pre-Format
[2] F1-Format
[3] GetInfo
d) Enter selection 1 for pre-format
e) Upon completion "Preformat succeeded" will be displayed
Below is a sample console output for the pre-format image loading when following the above steps:
FortiGate-80C (16:50-09.27.2011)
Ver:04000009
Serial number: FGT80C3910000000
RAM activation
Total RAM: 1024MB
Enabling cache...Done.
Scanning PCI bus...Done.
Allocating PCI resources...Done.
Enabling PCI resources...Done.
Zeroing IRQ settings...Done.
Verifying PIRQ tables...Done.
Disabling local APIC...Done.
Boot up, boot device capacity: 7636MB.
Press any key to display configuration menu...
..
[G]:
Get firmware image from TFTP server.
[F]:
Format boot device.
[B]:
Boot with backup firmware and set as default.
[I]:
Configuration and information.
[Q]:
Quit menu and continue to boot with default firmware.
[H]:
Display this list of options.
Enter Selection [G]:
Enter G,F,B,I,Q,or H:
Please connect TFTP server to Ethernet port "1".
Enter TFTP server address [192.168.1.168]:
Enter local address [192.168.1.188]:
Enter firmware image file name [image.out]:
MAC:00090F4660A2############
Total 13588979 bytes data downloaded.
Verifying the integrity of the firmware image.
Total 65536kB unzipped.
Save as Default firmware/Backup firmware/Run image without saving:[D/B/R]?
................................................................
Reading boot image 3954827 bytes.
Initializing firewall...
G
FGT_80C-FORMAT.3.0.0.1001.out
R
