AdvANCed SeCurITy
ANd NeTwork MANAGeMeNT
AXIS 211M offers the highest degree of security by using
multiple, password-protected user access levels, IP address
filtering, HTTPS encryption and IEEE 802.1X network access
control. With the appropriate access rights, video from
AXIS 211M can be accessed from any computer, anywhere, at
any time.
IPv6 is supported in addition to IPv4, as insurance against
the growing shortage of IP addresses, eliminating the need
for network address translation and simplifying configuration.
Network utilization is optimized with the support for Quality of
Service (QoS), which enables reservation of network capacity
and prioritization of mission-critical surveillance in a QoS-
aware network.
A TypICAl INSTAllATIoN
AXIS 211M
Network Camera
Loudspeaker
Give instructions, orders or
provide help by connecting
a loudspeaker to the camera.
Microphone
Use the built-in micro-
phone or an external
audio device to listen in on
an area.
dIMeNSIoNS
Measurements in millimeters (inches)
powerful eveNT MANAGeMeNT
AXIS 211M allows for powerful event management with multi-
window motion detection, audio detection and I/o (input/
output) for connecting devices such as sensors and external
relays to activate lights or open/close doors. Pre/post-image
alarm buffering secures images just before and after an alarm.
AXIS 211M is supported by AXIS Camera Station video
management software, which offers remote video monitoring,
recording and playback.
oPEN ProGrAMMING INTErFACE For
CUSToMIZED APPLICATIoNS
AXIS 211M supports the industry standard Axis Application
Programming Interface, AXIS vAPIX™ API, which facilitates the
development of customized software solutions. The API ensures
compatibility with the market's widest range of third-party
video management software, available from Axis Application
Development Partners.
Axis
network
cameras
PoE switch
Facilitate the installation by
powering the cameras via a
Power over Ethernet-enabled
switch.
PC with video
management
software
Monitor, record and
play back video.
PC
Monitor the
cameras remotely
over the WAN or
Internet network.
