Page 1 Kalypso VIDEO PRODUCTION CENTER Reference Manual SOFTWARE VERSION 11.0 071817605 MARCH 2005...
Page 2 +33 1 45 29 73 00 Germany, Europe +49 6150 104 782 +49 6150 104 223 Copyright © Thomson Broadcast and Media Solutions All rights reserved. Grass Valley Web Site www.thomsongrassvalley.com web site offers the following: — Current versions of product catalogs, brochures,...
Page 3: Table Of Contents
Contents Preface ..............About This Manual .
Page 4 Contents Kalypso Classic System Signal Flow ....... . . Kalypso HD System Signal Flow ........Section 2 —...
Page 5 Contents Master E-MEM Operating Modes (Normal Mode or 300 Mode) ..Master E-MEM Enable Buttons ........Master E-MEM Keypad.
Page 6 Contents Emergency Bypass ..........Router Assignment .
Page 7 Contents Profiles Menu ............Suite Prefs Menus .
Page 8 Contents Security Account Setup Menu ........Remote Aux Panel Setup Menu .
Page 9 Contents PBus & GPI Out Enables Menu ........Aux Bus Menu .
Page 10 Contents Transform Engine Menu Delegation ....... . Input Freeze ........... . . Blur .
Page 11 Contents Matte Menu and Mix Through Video Transitions ..... . . Source Select Menu ..........Effects Send Menu .
Page 12 Contents Effect Send Select Menu ......... . . Borderline Menu .
Page 13: Preface
Preface About This Manual This Kalypso Reference Manual is designed for operators of Kalypso systems. This manual is for both Kalypso Classic and Kalypso HD/Duo systems. Standard Documentation Set The standard Kalypso documentation set consists of a: • User Manual, •...
Page 14: Other Documentation
Preface Other Documentation The Kalypso Machine Control Interfaces Installation Instructions , provided with the KAL-IF-PROFILE and KAL-IF-VTR options, contains information about installing and conﬁguring external machine control software. The Kalypso Emergency Bypass Option Instruction Manual , shipped with the Emergency Bypass option hardware, contains information about installing, conﬁguring, and operating this option.
Page 15: Section 1 - System Overview
Section System Overview Introduction The Kalypso Video Production Center is much more than a switcher. The Kalypso system not only features powerful digital video switching, mixing, and keying with E-MEM, but also provides integrated control of other production devices (e.g., facility routers, external effects systems, DDRs).
Page 16: 4-M/E Kalypso Classic Options
Section 1 — System Overview • Effects Send (internal and external) available on every key bus, • Unlimited re-entry, • Look ahead and other preview modes, • Touch screen Menu panel, • Local Aux panel, with source name display standard, •...
Page 17: 2-M/E Kalypso Classic Standard Features
Introduction • Machine control of VTRs via Ethernet, • AMP Serial Machine Control, • Additional Tally Module, adding 64 more tally contacts, • Backup Video Processor power supply, • Redundant Main panel power supply, • 24 and 32-Crosspoint Remote Aux panels, •...
Page 18: Kalypso Hd Features
Section 1 — System Overview Kalypso HD Features 4-M/E Kalypso HD Standard Features • 720p/59.94 and 60, • 1080i/29.97, 30, and 25, • 1080sf/24, 25, 30 • 15 auto-timed inputs (conﬁgured as single inputs or video/key pairs), • 48 timed outputs (conﬁgured as single outputs or video/key pairs), •...
Page 19: 2-M/E Kalypso Hd System Standard Features
Introduction • Chromatte Advanced Dual Chroma Keyer, adds two ﬂoating chroma keyers, able to be assigned to any keyer in the system at any time. Up to eight dual chroma keyers (16 total) can be installed, • FlexiKey Programmable Clean Feed, permits two independent program streams, using key substitution, through one or more M/Es, •...
Page 20: 2-M/E Kalypso Hd System Options
Section 1 — System Overview 2-M/E Kalypso HD System Options The 2-M/E Kalypso system has the same options as the 4-M/E Kalypso system, with the following differences: • 2 - 3 M/E upgrade (2-M/E to 3-M/E, or 3-M/E to 4-M/E system), and •...
Page 21: Control Surface
System Components Figure 1. 4-M/E Kalypso System Components Menu Panel Removable Local Aux Panel Media Video Processor Frame Drives Bypass Active Emergency Bypass Assign 4-M/E Select Source Main Panel Video Processor Power Supply Frame Control Surface The modular design of Kalypso control panels provides ﬂexibility for mounting component panels in various environments, and allows the addition of specialized accessory control panels.
Page 22 Section 1 — System Overview Figure 2. Kalypso Control Surface Menu Panel Local Aux Panel 4-M/E Main Panel Zip Drive Local Aux Panel Menu Panel Integrated into 2-M/E Main Panel 2-M/E Main Panel Zip Drive 1-M/E Main Panel Menu Panel (option) Zip Drive (customer supplied option)
Page 23: 4-M/E Kalypso System
System Components 4-M/E Kalypso System 4-M/E Main Panel The Main panel provides real time button, knob, and lever arm control of the Kalypso system. The panel is organized into subpanels that contain groups of related controls (Figure Figure 3. Kalypso 4-M/E Main Panel Source M/E Source Name M/E Keyer...
Page 24 Section 1 — System Overview Two models of 4-M/E Main panel exist. Late model designs shipping at the time of this manual’s publication have the connections shown in Figure This model Main panel works with the Enhanced Menu panel. Figure 4. Late Model 4-M/E Main Panel, Rear View AC In Panel Panel...
Page 25 System Components Earlier model 4-M/E Main panels have additional connectors (Figure used with the original Kalypso Menu panel. If this model is modiﬁed for Enhanced Menu panel operation, the indicated connectors are inactive. Figure 6. Early Model 4-M/E Main Panel, Rear View AC In SCSI* Mouse*...
Page 26: Menu Panel
Section 1 — System Overview The actual location of and type of equipment installed in early model Main panels varies, depending on date of manufacture. Some earlier designs used Hard Disk drives with the Real Time (RT) processor, and some used Disk on Chip hardware.
Page 27 System Components Ports located on the rear of the Menu panel (Figure 9) provide connections to the Main panel, Video Processor frame, an external Zip drive, a PS/2 mouse and keyboard, and other devices. Figure 9. Enhanced Menu Panel, Bottom View of Connectors Alternative Four Hole Pattern for = Hole pair for Adaptable Mounting Bracket (5) Adjustable Freestanding Console Bracket...
Page 28 Section 1 — System Overview The Menu System Processor for these models resides in the Main panel, and so extra connections are required for operation (Figure 11). Figure 11. Original Menu Panel, Bottom View of Connectors Bottom View Side View 8.4 in.
Page 29: Local Aux Panel
System Components Local Aux Panel The Local Aux panel provides control of the Kalypso System Aux buses, Still Store source selection, some switched preview, and also supports Router source selection and Emergency Bypass option operation (Figure 13). Figure 13. Kalypso Local Aux Panel Source Select Emergency Bypass (4) Bus #1...
Page 30: Removable Media Drives
Section 1 — System Overview The Local Aux panel is generally installed directly above the left side of the Main panel so the Source Select buttons are aligned, though it can be mounted in any convenient location. If the Emergency Bypass option is installed, a redundant power supply for the Local Aux panel is available to ensure bypass operation even if the Main panel loses power.
Page 31 System Components Figure 15. Kalypso 2-M/E Main Panel Bank Delegation ----- M/E Modifiers ----- Subpanel Keyers, Masks Mattes, Local Aux Aux Bus M/E Status Macros Subpanels Copy/Swap Subpanel Status Display Displays (2) Subpanel Subpanels Source Name Displays (3) Machine Control Preview M/E Keyer Transition...
Page 32 Section 1 — System Overview Late model Kalypso 2-M/E Main panels have connectors at the rear that are identical to those on a late model 4-M/E system, except there are addi- tional Local Aux panel connections (Figure 16). Figure 16. Late Model 2-M/E Main Panel, Rear View Emergency Diagnostic Emergency...
Page 33 System Components Early model 2-M/E Main panel rear connectors are shown in Figure 18. If modiﬁed for Enhanced Menu panel operation the indicated connectors are inactive. Figure 18. Early Model 2-M/E Main Panel, Rear View Emergency Diagnostic Emergency Redundant Bypass Mixer Bypass Router DC Power In Menu Panel...
Page 34: 1-M/E Main Panel
Section 1 — System Overview 1-M/E Main Panel A 1-M/E Main panel is intended to act as an accessory control surface for a 4-M/E or 2-M/E Kalypso system, not as the primary system control point. A 1-M/E Main panel can be used for pre- or post-production, or be used during live production to permit another operator to assist the TD.
Page 35 System Components The 1-M/E Main panel has a reset button on the rear and one inside the lever arm slot, to permit easy reset when installed in a console. Figure 21. Kalypso 1-M/E Main Panel, Rear View LINE 1 SATELLITE DIAGNOSTIC RESET COM 1...
Page 36: Control Panel Options
Section 1 — System Overview Control Panel Options Remote Aux Panels Remote Aux panels provide control of selected Kalypso Aux buses from a remote location. Three 24-Crosspoint and two 32-Crosspoint Remote Aux panels are available for 4-M/E and 2-M/E systems. Any combination of these aux panels may be used in a Kalypso system.
Page 37 System Components All three 24-Crosspoint panels have the same rear panel layout (Figure 25). Figure 25. 24-Crosspoint Remote Aux Panel Rear Panel Test Mode Panel Address and Force High Tally Communications Bus DC Power Joystick Override FORCE HIGH TALLY TEST PANEL DC POWER MODE...
Page 38: Shot Box Option
Section 1 — System Overview Both 32-Crosspoint Panels have the same rear panel layout (Figure 29). These panels have a built-in power supply and use a standard removable AC power cable. Figure 29. 32-Crosspoint Remote Aux Panel Rear View AC Power Camera Joystick Override RATED VOLTAGE RANGE: 85-260 VAC CAMERA JOYSTICK...
Page 39: Kalypso Classic Video Processor Frame
System Components Kalypso Classic Video Processor Frame 4-M/E Kalypso Classic Video Processor Frame The Kalypso Classic Video Processor frame houses most of the system elec- tronics, with slots in the front and rear that hold individual modules. The front bay holds system control, video routing, and signal processing mod- ules.
Page 40 Section 1 — System Overview The rear bay holds input and output modules and provides reference and system control connections. A fully loaded system is shown in Figure Some of the modules illustrated are optional and may not be included in your Kalypso system.
Page 41: 2-M/E Kalypso Classic Video Processor Frame
System Components 2-M/E Kalypso Classic Video Processor Frame The 2-M/E Kalypso Classic system uses the same frame hardware as the 4-M/E Kalypso system, except some slots are not ﬁlled in the standard con- ﬁguration. Because only two M/Es are standard (M/E 1 and PGM PST), only two M/E modules and two crosspoint modules are provided (Figure 33).
Page 42 Section 1 — System Overview The standard 2-M/E Kalypso system includes one Input module and the Effects Send module to support video inputs and outputs (Figure 34). Up to four additional Input and Output modules can be installed. Slot B16 (labeled on the frame as Output 1, 1-8) is not available for use on a standard 2-M/E Kalypso system.
Page 43: Kalypso Classic M/E Module Control Assignments
System Components Kalypso Classic M/E Module Control Assignments Table 1 shows how the Main panel banks are assigned to M/E modules in a factory conﬁgured Kalypso Classic Video Processor frame. Table 1. Banks and M/E Module Locations Video Processor Frame Slot Bank 4-M/E 2-M/E...
Page 44: Kalypso Hd/Duo Video Processor Frame
Section 1 — System Overview Kalypso HD/Duo Video Processor Frame The Kalypso HD Video Processor frame houses most of the system elec- tronic. Slots in the front hold system control, video routing, and signal pro- cessing modules. A fully loaded system is shown in Figure 31.
Page 45 System Components The rear of the Video Processor frame has input and output connectors and provides reference and system control connections (Figure 32). Figure 36. Kalypso Video Processor Frame, Rear View Air Exhaust Timecode Reader Input 15 Standard Inputs SD Reference (with up to 5 Looping Input 15 Input options...
Page 46: Kalypso Video Processor Power Supply
Section 1 — System Overview Kalypso Video Processor Power Supply A separate Video Processor Power Supply provides power to the Kalypso Video Processor. The same type of power supply is used by Kalypso Classic and Kalypso HD systems. The Video Processor Power Supply frame holds up to three Video Processor Power Supply modules (Figure 37).
Page 47: Video Processor Frame Options
System Components Video Processor Frame Options Still Store Option The Kalypso Still Store is used to grab, save, and display images. Still Store features include: • Instant access to non-volatile stills (ﬁxed names “Still 1”, “Still 2”, etc.), • Up to 1800 full frame images, •...
Page 48 Section 1 — System Overview Transform Engine features include: • Source and Target space selection, • 3-D Locate, Size Locate, Rotate, Spin, Locate Axis, • Anti-alias ﬁltering control through transform parameters, • Aspect, Skew, Perspective, • Post Transform, • Global channel on each M/E and PGM PST, to which the Transform Engine channels in that M/E can be individually assigned, •...
Page 49: Kalypso Facility Example
Kalypso Facility Example Kalypso Facility Example A simpliﬁed diagram of a small live studio is shown in Figure 39. In this facility the Kalypso Video Production Center has control of a portion of the facility router for pre-selecting various sources into the switcher. The camera control operator is able to remotely control a Kalypso Aux bus for selecting camera views to shade.
Page 50: Functional Overview
Section 1 — System Overview Functional Overview Kalypso System Control System control for the Kalypso Video Production Center is designed for ﬂexibility and simplicity. Ethernet and other standard data interfaces are used for system component interconnections. Multiple hard disks are included to permit storage of large numbers of data ﬁles.
Page 51 Functional Overview Late model 2-M/E Kalypso system control is the same as the 4-M/E Kalypso system, except the Local Aux panel is built into the 2-M/E Main panel (Figure 41). Figure 41. Late Model 2-M/E Kalypso Control Kalypso Video Processor Frame Still Store LAN To networked image sources...
Page 52 Section 1 — System Overview Early model Kalypso system control is shown in Figure 42 (4-M/E system) Figure 43 (2-M/E system). Figure 42. Early Model 4-M/E Kalypso Control Kalypso Video Processor Frame Still Store LAN To networked image sources Tally (Relay) 16 GPI In 16 GPI Out Shot Box...
Page 53 Functional Overview Figure 43. Early Model 2-M/E Kalypso Control. Kalypso Video Processor Frame Still Store LAN To networked image sources Tally (Relay) 16 GPI In 16 GPI Out Shot Box 8 Serial 2 Synchronous Serial Boot Facility LAN Config BU Ethernet Flash Hard...
Page 54 Section 1 — System Overview Kalypso Reference Manual...
Page 55: Video Signal Flow
Functional Overview Video Signal Flow The Kalypso Video Production Center has been designed for operational ﬂexibility. This is reﬂected in the basic system architecture. For example, all the outputs from every M/E are routed back to the video crosspoint matrix, making all these signals accessible to the entire system (see Figure 44 Figure 45...
Page 56: Kalypso Classic System Signal Flow
Section 1 — System Overview Kalypso Classic System Signal Flow Figure 44. Simpliﬁed Kalypso Classic Video Flow Diagram (part 1) Video or Key Signals Deserializer and Reclock M/E 1 Program A Serializer M/E 1 Program B M/E 1 Program C M/E 1 Program D M/E 1 Preview A M/E 1 Preview 2...
Page 57 Functional Overview Figure 45. Simpliﬁed Kalypso Classic Video Flow Diagram (part 2) Effects Send Module Standard 8 Dual Outputs 41 - 48 2 of 8 Channels Shown Channels Shown in Output Mode Switches Up for Effects Send Mode Output Mode with No Shape/Unshape: Input A = Video or Key Input B = Video or Key To/From All...
Page 58: Kalypso Hd System Signal Flow
Section 1 — System Overview Kalypso HD System Signal Flow Figure 46. Simpliﬁed Kalypso HD Video Flow Diagram Video or Input Crosspoint PGM/PST - Output Key Signals Variable Delay Deserializer and Reclock Variable Delay Serializer Variable Delay Variable Delay Variable Delay 12 Dual Variable Delay Outputs Per...
Page 59: Section 2 - Control Panels
Section Control Panels Introduction A basic Kalypso system is equipped with a Main panel, a Local Aux panel, a Menu panel, and removable media drives. These separate control panel components make up a Kalypso control surface. Interactions occur between the components of the control surface. For example, changing controls on the Main panel can change the status of soft buttons on the Menu panel, and vice versa.
Page 60: Alternate Action
Section 2 — Control Panels On some single press buttons, pressing the button again while the action is being performed (the button will be lit) halts the action. The Auto Trans button is an example of a single press button that can be halted. Alternate Action Some system functions have two states, and are turned on and off by a single alternate action button.
Page 61: Double Press
Introduction ling keyer opacity to controlling border opacity. A hold down latch param- eter exists in user conﬁguration that permits single handed operation by extending the hold down behavior for a user-speciﬁed period of time after the button is released. Hold down buttons that do not light during normal use will go high tally when a hold down is active.
Page 62: Dialogs And Prompting
Section 2 — Control Panels Flashing tally is reserved for situations where the operator needs to be aware that some expected panel behavior has been changed (see Dialogs and Prompting below). Tallys will be off for buttons whose functions are off or not available. If a disabled button is pressed a warning notiﬁcation occurs (audible beep and/or message on the Menu panel).
Page 63 Introduction matte generators, making dedicated controls for each object unfeasible. Delegation connects a group of controls, typically a subpanel, to a partic- ular object. Delegation can greatly reduce confusion over which button to press or which knob to turn to control each object in the system. See the sep- arate Kalypso User Manual for more information about delegation.
Page 64 Section 2 — Control Panels • DPOP (Double Press Open) and SPOP (Single Press Open) Menu dele- gation, in which double or single pressing a button brings up the appro- priate menu on the Menu panel. Active DPOP and SPOP buttons and their menus are listed in Table 3 Table 3.
Page 65: Time Value Entry
Introduction • Keypad delegation. Besides being used to recall effects, the E-MEM and Master E-MEM keypads are also used to enter numeric values. Pressing a numeric preﬁx button delegates the keypad to numeric entry for that function. The numeric preﬁx buttons and controlled numeric functions are listed in Table Table 4.
Page 66: 4-M/E Main Panel
Section 2 — Control Panels To enter only ﬁelds, use two separators before the number. For example, a time of 30 ﬁelds (one half second on 60 hz systems) is entered by typing: • • Enter You can actually enter any combination of seconds, frames and ﬁelds. The Kalypso system will do the conversion and display the result in seconds, frame, ﬁeld format.
Page 67: Source Selection
4-M/E Main Panel Figure 47. 4-M/E Main Panel and Subpanels Source M/E Source Name M/E Keyer M/E Status E-MEM Transition M/E Modifiers Selection (4) Displays (3) Delegation (4) Displays (4) Subpanels (3) Subpanels (4) Subpanel (option) Macros Machine Control Preview PGM/PST Effects Edit Transform...
Page 68 Section 2 — Control Panels Figure 48. 4-M/E Kalypso System Source Selectors on Main Panel, Left Side Source Selection 32 Buttons Per Row Source Select Buttons (2 Rows) NetWk Black East Feed Background Source Select Buttons (2 Rows) Source Name Display Pressing a button on an M/E row selects the source mapped to that button on the controlled bus, and the source button will go high tally if on-air, or...
Page 69: Source Button Tally
4-M/E Main Panel Figure 49. 4-M/E Kalypso System Source Selectors on Main Pane, Right Side Hold Hold Hold Hold Hold Hold Hold Hold Source Shift Shift Near Near Select Drop Drop Buses Buses Shift Shift Split Split Side Side Side Side Modifiers Source selection interacts directly with the Source Select Modiﬁers area of...
Page 70: Hold Buttons
Section 2 — Control Panels Usually there is always one source tallied on each bus. However, if a source that is not mapped to a button on the bus is selected (perhaps by an E-MEM recall of an effect using different button mapping), the entire button row will be dark.
Page 71: Source Name Displays
4-M/E Main Panel When the button is held down, all the source selection buttons Router Asgn on the Main panel change to control router sources. See Router Interface Operation in the Kalypso User Manual for speciﬁc operating instructions. button on M/E 2 and the button on M/E 3 are inac- Keyer Copy Src Copy...
Page 72: Source Select Modifier Buttons
Section 2 — Control Panels Source Select Modiﬁer Buttons A group of source select modiﬁer buttons are located below each M/E’s Status display. These buttons affect the source selection buttons in that M/E. Holding down a source select modiﬁer button changes what source will be selected when an M/E source button is pressed.
Page 73 4-M/E Main Panel Key Split Each key source button normally controls crosspoints on two buses (key cut, key ﬁll) at the same time. The source select modiﬁer button is Key Split used to select a different key cut signal to use with the currently selected key ﬁll signal.
Page 74: M/E Status Displays
Section 2 — Control Panels M/E Status Displays Each M/E has an M/E Status display that reports the current state of that M/E. The M/E status display has Keyer, Background, and Transition sec- tions, and has a Lever Arm Bar graph (Figure 51).
Page 75: Additional Keyer Status Information
4-M/E Main Panel Additional Keyer Status Information The keyer section displays the following information for each Keyer of that M/E. The name of the current state is displayed. • Key On or Off. • Key Invert. • Key is Matte Fill. •...
Page 76: Lever Arm Progress Bar
Section 2 — Control Panels Lever Arm Progress Bar The lever arm progress bar shows the current location of a transition, as a percent of completion. It also shows the location of the lever arm and whether it is out of sync with the transition. Transition progress is reported with a vertical transition bar with thin lines at the limits.
Page 77: Transition Subpanels
4-M/E Main Panel Transition Subpanels Each M/E on the Kalypso system, including PGM PST, is functionally identical to each other and provides complete mix, wipe, and keying capa- bilities. Each M/E has a transition subpanel used to control these compos- iting operations (Figure 53).
Page 78: Main Transition Controls
Section 2 — Control Panels Main Transition Controls The main transition controls are used to select the signal elements that will be involved in the transition, deﬁne the type of transition, and perform the transition. Transition Elements The upper group of buttons selects the elements that will change during the next transition.
Page 79 4-M/E Main Panel buttons select one of two user adjustable wipe transi- Wipe 1 Wipe 2 tions. Each predeﬁned wipe can use either the Complex A or Complex B wipe generator or one of the Utility buses as the wipe shape. Wipe pattern selections are made in the Wipe menu, which these buttons DPOP to.
Page 80 Section 2 — Control Panels when it has been selected. The button is unique, in that its func- Preset Black tion is activated on the release of its button press, not on ﬁrst press as are all other buttons. This is necessary to support fade to black. Two successive transition commands ( button, button, or...
Page 81: Keyer Transition Controls
4-M/E Main Panel Keyer Transition Controls Each keyer has its own cut and mix transition system, separate from the main M/E transition mechanism. Individually numbered Key 1-4 Cut button pairs located to the right of the control Key 1-4 Mix Transition Lever Arm these transitions.
Page 82: Other Transition Control Interactions
Section 2 — Control Panels When a button is pressed, the and the four Trans Rate Auto Trans Key 1-4 Mix buttons will ﬂash and the E-MEM readout prompts for the rate to be set. Pressing one of the ﬂashing buttons delegates the E MEM keypad to that transition rate and its current rate appears on the readout.
Page 83: M/E Keyer Delegation Buttons
4-M/E Main Panel M/E Keyer Delegation Buttons The M/E Keyer delegation buttons allow the operator to make quick and sure changes to any desired keyer. These buttons can also be used to momentarily delegate a key bus for source selection, and can be used for hold to preview.
Page 84: Multiple Keyer Delegations
Section 2 — Control Panels Multiple Keyer Delegations The M/E Keyer Delegation buttons can delegate the Keyers, Mattes, Masks, and/or the Transform subpanels to more than one keyer. If a sub- panel’s controls have been delegated to multiple keyers, the subpanel del- egation buttons will go off, to indicate a single keyer is not being controlled by that subpanel.
Page 85: M/E Modifiers
4-M/E Main Panel M/E Modiﬁers The M/E Modiﬁers area is divided into four subpanels corresponding to Keyers, Masks, Mattes, and Copy/Swap functions (Figure 55). Figure 55. M/E Modiﬁers on Main Panel M/E Modifiers Area Mattes Subpanel Copy Swap Subpanel Masks Subpanel Keyers Subpanel Delegation determines which M/E and keyer, or matte is being controlled at any given time by the M/E Modiﬁers controls.
Page 86: Keyers Subpanel
Section 2 — Control Panels Keyers Subpanel The Keyers subpanel (Figure 56) provides controls that can be delegated to control any of the 16 Kalypso keyers (4 in each M/E). Many buttons in this subpanel are organized into interconnected groups, allowing selection of only one button at a time in each group.
Page 87 4-M/E Main Panel Manual delegation of an individual keyer involves selecting one button in each group. Two additional delegation buttons are also used for masking (see Inhibit and Force Mask Delegation Buttons on page 91). Manually changing the selection in one of these button groups does not change the current selection in the other group.
Page 88 Section 2 — Control Panels Key Type Buttons The four buttons in the Key Type button group selects from ﬁve different key types for the delegated keyer. Single button selection is available for Fixed Linear Key, Luminance Key, Chroma Key, and Preset Pattern. An Adjustable Linear Key is also available.
Page 89 4-M/E Main Panel Matte Fill Button button determines what signal will be used as the key ﬁll by Matte Fill the keyer. When off, the key ﬁll signal currently selected on the ﬁll bus will be used. When on, a matte signal will be used. Video Key Button button determines what signal the keyer will use to cut the Video Key...
Page 90: Masks Subpanel
Section 2 — Control Panels Borderline and Related Buttons The buttons in this group can be used to add various types of border edges around the keyed area of the delegated keyer or preset pattern border. Do not confuse this Borderline feature with a wipe transition pattern border, which is a different feature.
Page 91 4-M/E Main Panel force masks may be set up for each keyer. Masks can be created by pattern generators, or can be based on a video source that has been clip and gain adjusted to create the mask control signal. Masks cannot be applied to preset patterns.
Page 92 Section 2 — Control Panels Mask Control Knobs Masks subpanel knobs are used to control mask opacity, position, size, edge softness, edge location, and clip and gain. The overall opacity of any delegated mask can be controlled by holding down the button and adjusting the knob in Inhibit Mask...
Page 93 4-M/E Main Panel When is selected with off, the following knobs are available Sep Edges (Figure 58). Preset Pattern can also be adjusted using these mask controls. Figure 58. Box Pattern Mask Knob Parameters without Separate Edges Box Edge Softness Masks Vertical Location Top / Soft / Gain...
Page 94 Section 2 — Control Panels When is selected the following knobs are available Utility 1 Utility 2 (Figure 60). control is not available for utility masks. Joystick Figure 60. Utility Mask Knob Parameters Masks Gain Top / Soft / Gain Clip Left / Horiz Right / Vert...
Page 95: Mattes Subpanel
4-M/E Main Panel Mattes Subpanel The Mattes subpanel is used to control the Kalypso system’s 58 Matte gen- erators. Mattes can be used in backgrounds, in the borders of keys and wipes, to edge preset patterns, and as matte ﬁll. Figure 61.
Page 96 Section 2 — Control Panels Mattes Subpanel Delegation Buttons M/E and keyer delegation is controlled with four button groups (M/E and Background, Keyer and Wipe, Key Matte Type, and Base/Wash Fill. • The M/E 1-3 Pgm Pst , and Bkgd 1-2 buttons manually delegate the Mattes subpanel to control either an M/E or one of the two Background mattes.
Page 97 4-M/E Main Panel Mattes Subpanel Delegation Control Buttons buttons in the Delegation Control group affect Auto Deleg Last Deleg the current delegation of the Mattes subpanel. (The Keyers/Masks sub- panel has its own independent delegation control buttons for those sub- panels).
Page 98 Section 2 — Control Panels Note When a Background matte generator has been selected for control, only the Keyer Wipe button will light when either the Keyer Wipe, C1 Wipe, or C2 Wipe button is pressed. Background mattes have their own simple wipe pattern generator producing a single line that can be rotated, offset, softened, and textured.
Page 99 4-M/E Main Panel For example (Figure 62), delegating to the transition, then selecting Wipe 1 for the wash gives the knob Offset control (if the C1 pattern gener- C1 Wipe ator is assigned to Wipe 1). This wash edge will track the transition as it is being performed.
Page 100 Section 2 — Control Panels When either is selected when a wash is active, the Bkgd 1 Bkgd 2 Keyer Wipe geometry button will light and the knobs control the Offset and Softness of the wash edge (Figure 64). Backgrounds actually do not use Keyer wipe generators.
Page 101: Copy/Swap Subpanel
4-M/E Main Panel Copy/Swap Subpanel The Copy/Swap subpanel is located at the upper right corner of the Main panel (Figure 66). Figure 66. Copy Swap Subpanel Copy Swap Subpanel M/E Modifiers Mattes Copy / Swap Active Copy Swap Buttons (3) Wash Geometry Base Base...
Page 102 Section 2 — Control Panels To Copy an M/E, press , press the Mattes delegation button of the M/E Copy source M/E, then press the Mattes delegation button of the destination M/E. To Swap M/Es, press , press the Mattes delegation button of the M/E Swap ﬁrst M/E to swap, then press the Mattes delegation button of the other M/E to swap.
Page 103: E-Mem Subpanels
4-M/E Main Panel The transform data, however, is still transferred to the destination M/E even if a Transform Engine is not acquired. If the destination M/E subse- quently acquires a Transform Engine, the copied transform effects will run correctly. Swap operations acquire Transform Engines from the source M/E, and so should not cause any Transform Engine acquisition failures.
Page 104: Keypad Numeric Entry Buttons
Section 2 — Control Panels Keypad Numeric Entry Buttons The E-MEM keypad has 12 numeric entry buttons ( ) and Undo/• Enter ﬁve preﬁx buttons. The preﬁx buttons are used to delegate the keypad to different numeric entry functions (see below). Same Bank Effect Recall The default use of the keypad when a preﬁx button is not active is to recall an effect to that M/E.
Page 105: Keypad Prefix Buttons
4-M/E Main Panel Keypad Preﬁx Buttons The same keypad buttons are used to enter values for different functions. The preﬁx buttons ( , ↑/ ) determine Lock/Learn Effect Dis Bank Trans Rate which function will be affected by the values entered. Some functions are nested.
Page 106 Section 2 — Control Panels The next empty register will receive the effect data and become the current effect. This action will not occur and an error will be displayed if there are no empty registers. To learn M/E settings to a register in a different bank, the new bank must be speciﬁed.
Page 107 4-M/E Main Panel being executed terminates the sequence operation. Any any effect dissolve (or effect run) will complete, and the last recalled register will remain the current effect. Note that once a register has been learned as a sequence, it will always proceed to the next programmed register when recalled as a sequence.
Page 108: Time Value Entry
Section 2 — Control Panels Trans Rate Button button on the E-MEM subpanel is used to set transition rates Trans Rate for M/E main and keyer transitions. See Transition Rates on page 81 more information. When either the preﬁx buttons are lit, the button Effect Dis Trans Rate...
Page 109: Run And Recall Control
4-M/E Main Panel Entries in seconds can be entered by adding one separator. For example, a time of 1 second is input by pressing: • Enter An odd ﬁeld is input by pressing as the last entry. For example, a time of one second 15 frames and one ﬁeld is input by pressing: •...
Page 110: E-Mem Readout Display
Section 2 — Control Panels E-MEM Readout Display The E-MEM readout display has 16 alphanumeric characters, and is used to show the status of the current register status, display messages, and prompt the user. When displaying the status of the current effect, the ﬁrst readout character position is either blank or indicates with an “L”...
Page 111: Master E-Mem Subpanel
4-M/E Main Panel Master E-MEM Subpanel The Master E-MEM subpanel (Figure 70) is organized similar to an indi- vidual E-MEM subpanel, but has additional capabilities. Like the E-MEM subpanel on each M/E, the Master E-MEM subpanel can be used to Learn and Recall effects for PGM PST (with Lock, Sequence, and Effect Dissolve control).
Page 112: Master E-Mem Operating Modes (Normal Mode Or 300 Mode)
Section 2 — Control Panels Master E-MEM subpanel operation is closely related to the Effects Edit and Effect Run subpanels, which are used to edit and run effects. Functionally, these three subpanels actually form one integrated set of E-MEM controls. The Master E-MEM keypad can also be delegated to enter values for other Main panel controls (including any knob).
Page 113: Master E-Mem Keypad
4-M/E Main Panel Delegates Button button affects the behavior of the Enable buttons, and is used Delegates when editing effects. During effect editing, you may want to apply edits to only some of the levels in an effect, but permit other levels to run along with the levels being edited.
Page 114 Section 2 — Control Panels (See Lock/Learn Button on page 105.). The button can Lock/Learn Lock/Learn also be used with the button to update register header informa- Mod/MdAll tion. See Learn Modify on page 124. (See Sequence Button on page 106.) (See Effect Dissolve Button on page...
Page 115: Master E-Mem Direct Bank Selection Buttons
4-M/E Main Panel +/- Button button changes the sign of the value currently being input on the Master E-MEM keypad. This button can be pressed either before or after the value has been typed into the keypad, but before it is completed with .
Page 116 Section 2 — Control Panels button can be used to copy information into the next empty reg- Put Eff ister by pressing: Put Eff Undo/• Enter Put Eff is an E-MEM operation and can be reversed with ↑ Bank Undo/• Get Effect Button button copies the contents of a speciﬁed register to the current Get Eff...
Page 117: Master E-Mem Readout Display
4-M/E Main Panel number and press to move the cursor to the speciﬁed time, or press Enter to move it that time amount (negative numbers move the cursor back- Trim ward). Pressing the • button as the time value and then pressing Undo/ Enter moves the cursor to the start of the master timeline (zero time).
Page 118: Recall And Run Control Modifiers
Section 2 — Control Panels Figure 71. Master E-MEM Readout Display Skewed Current Effect Name Put and Get Prompts Effect Indicator (First 9 Characters) Put To 15 B2 23 Name Get From 18 Selected Current Bank Number Effect Number If there is more than one current effect register (different E-MEM levels were independently recalled from different registers, also called a skewed effect) a triangle symbol is displayed between the current bank number and the current register number.
Page 119: Effects Edit Subpanel
4-M/E Main Panel Effects Edit Subpanel The Effects Edit subpanel contains two work buffer buttons that can be used to return the system to a known state (Figure 72). Figure 72. Effects Edit Subpanel Effects Edit Timeline Navigation Clear Clear Prev Prev Next...
Page 120: Restore Work Buffer Button
Section 2 — Control Panels When source memory is on, six separate actions can be performed with the button. Clear Wk Bfr • Pressing once clears all the work buffers parameters except Clear Wk Bfr those associated with source memory in all levels enabled in the Master E-MEM subpanel.
Page 121: Mode Selection Group
4-M/E Main Panel – Moves the cursor to the last keyframe of the effect. These buttons are inactive during effect runs. Additional timeline navigation buttons reside in the Master E-MEM sub- panel (Timeline Navigation Buttons on page 116). Mode Selection Group –...
Page 122: Timeline Edit Button Group
Section 2 — Control Panels Timeline Edit Button Group – When the cursor is on at least one keyframe, pressing the Delete Delete button deletes the keyframe(s) at the current cursor location and removes the duration to the next master timeline keyframe. Note that this also deletes the same duration from other delegated timelines, including those that have the cursor on the path.
Page 123: Timeline Modify, Insert Button Group
4-M/E Main Panel Timeline Modify, Insert Button Group – The button is used to change existing keyframes on a Mod/MdAll Mod/MdAll timeline, or add new ones. Only levels delegated for editing are affected. Pressing this button once performs a function. Double pressing this Modify button performs a function.
Page 124 Section 2 — Control Panels Inactive Controls , and buttons are inactive in Release Partial KF Mark Mark Block Clear Marks 11.0. Learn Modify Each E-MEM register contains header information, along with keyframe data. This header information applies to the entire effect and is not keyfra- mable.
Page 125: Effects Run Subpanel
4-M/E Main Panel Effects Run Subpanel The Effects Run subpanel primary function is to control the running of multiple keyframe effects. Also located on this subpanel is the Hold Inputs button used to control E-MEM source changes (Figure 73). Figure 73. Effects Run Subpanel Effects Run Stop Stop...
Page 126: Run Control Buttons
Section 2 — Control Panels Run Control Buttons – When the button is on, subsequent effects runs will stop Stop Next Stop Next at the next keyframe encountered. With this feature on, you can step key- frame by keyframe through an effect by pressing the button repeatedly.
Page 127: Transform Subpanel
4-M/E Main Panel Transform Subpanel The Transform subpanel (Figure 74) is be used to control image and wipe pattern placement, size, angle, and other attributes. This panel is equipped with a Joystick, particularly suitable for adjusting position and rotation parameters. The Joystick can also be used to select a color from an image (for example, chroma key backing color) using an on-screen cursor.
Page 128: Joystick
Section 2 — Control Panels Joystick The Kalypso system Joystick is a precision three-axis device. Moving the joystick towards or away from you controls the Y-axis, moving the Joystick left and right controls the X-axis, and rotating the Joystick controls the Z- axis (Figure 75).
Page 129: Transform Buttons
4-M/E Main Panel joystick is delegated to multiple points of use. For example, it is possible to delegate the joystick to M/E 3 Key 1 and Key 2 where Key 1 has a Trans- form Engine and Key 2 does not. In this case, the Key 1 button will be high tally but the Key 2 button will low tally.
Page 130 Section 2 — Control Panels Source and Target Space Related Buttons The Source and Target Space buttons affect the ﬁve other transform param- eter buttons in that group ( Loc 3D Size Loc Rot, Locate Axis Spin button delegates source space control of the selected trans- Src Space form parameter.
Page 131: Axis Buttons
4-M/E Main Panel button controls the movement of an image along the X and Post T-form Y axes of two-dimensional screen space (this appears to move over a ﬂat space and perspective changes do not occur). Deﬂecting the Joystick along its Z axis will scale the picture in 2D (post scale).
Page 132: Macro Delegation
Section 2 — Control Panels Macro Delegation button delegates a keyer source select button row Macro Deleg (PGM PST K1/K3 is the default) for macro operations and reports that macro mode is active (high tally). Pressing toggles the macro Macro Deleg delegation on and off.
Page 133: Insert Delay
4-M/E Main Panel If another macro register button is pressed while a macro is being recorded, the macro contents of this other macro are appended to the currently recorded macro. There is no cross-reference or call other macro function- ality. Therefore, one macro can be appended to another macro in this manner and if the original macro is deleted the new macro will still play correctly.
Page 134: Pre Attach, Post Attach, Replace Attach
Section 2 — Control Panels Pre Attach, Post Attach, Replace Attach Macros can be attached to other panel buttons so the macro runs when that button is pressed. Macros can run before the normal function of that button, after the normal function, or completely replace that button func- tion.
Page 135: Macro Alternate Buttons
4-M/E Main Panel macro register buttons, or with the Macro menu. The button is Attach Enable active whether or not macro mode is active, so it can be instantly turned on and off at any time. Macro Alternate Buttons The PGM PST K1/K3 M/E re-entry buttons (the default macro row) are labeled with additional macro capabilities (Figure 77).
Page 136: Machine Control Subpanel
Section 2 — Control Panels Machine Control Subpanel The Machine Control subpanel (Figure 78) can be used to control devices like DDRs, VTRs, still stores, character generators, etc. This subpanel can also control the Kalypso Still Store and GPIs to any external device. Figure 78.
Page 137: Readout Display
4-M/E Main Panel Once delegated to a bus, any source selected on that bus will be subject to Machine Control subpanel commands. The current bus selection is saved as part of User Prefs. The new bus will be used for device control delegation until changed by the user or a User Pref with a different bus selection is loaded.
Page 138: Control Of Devices With Still Recall Only
Section 2 — Control Panels button plays the controlled device. When Gang Roll is Play/Gang Roll active, multiple devices can be triggered for playback simultaneously. For DDRs and VTRs, pressing Fast Fwd fast forwards or rewinds to the beginning or end of the currently loaded clip. VTRs will require time for these actions.
Page 139: Auto Start
4-M/E Main Panel Auto Start button is used to make an external machine start playing Auto Start when it is taken on-air. To do this, delegate the device with the PGM PST B bus, then press so it is illuminated. On-air status causing playback Auto Start can be achieved by a bus source change, turning on a key, or recalling an E-MEM register, to name a few.
Page 140: Preview Signal Selection
Section 2 — Control Panels The Preview subpanel also works with the Local Aux panel, which pro- vides a selection mechanism for viewing sources and program outputs of the M/Es on the switched preview output. Note that the switched preview will automatically show the appropriate signal during Hold to Preview, Show Key, Color Pick and Auto Key Setup operations, replacing whatever signal may have been selected for previewing.
Page 141: Local Aux Panel Source Selection
Local Aux Panel Figure 80. Local Aux Panel Source Select Emergency Bypass (4) Bus #1 Aux Bus Status M/E Select Source Select Modifiers (6) Bus #1 (32) (option) Delegation (15) Display (2 segments) Bus #2 (4) for Bus #1 Bypass Active Emergency Bypass Bypass...
Page 142: Source Selection Buses
Section 2 — Control Panels Source Selection Buses Source selection on the Local Aux panel is identical to the Main panel. Thirty two source buttons are available in a single row on each bus. The source name display between the buses identify the sources available for selection on both buses.
Page 143: Router Assignment
Disk Drives Router Assignment The Local Aux panel can be assigned to control external router source selec- tions, if conﬁgured for that feature, using the Router Assignment buttons at the lower left of the panel. See Router Interface Operation in the Kalypso User Manual for operating information.
Page 144: 2-M/E Main Panel
Section 2 — Control Panels 2-M/E Main Panel The 2-M/E Main panel is similar to the 4-M/E panel (Figure 81). Instead of 3 M/Es and a PGM PST, the 2-M/E Main panel has one M/E bank and one PGM PST bank, though three M/Es and PGM PST are accessible via dele- gation.
Page 145: Bank Delegate Subpanel
2-M/E Main Panel Bank Delegate Subpanel The two banks on the 2-M/E Main panel can be delegated to control dif- ferent M/Es (provided the Kalypso Video Processor is equipped with addi- tional M/E modules). The Bank Delegate subpanel is located at the upper center of the panel (Figure 82).
Page 146: Master E-Mem Subpanel
Section 2 — Control Panels Master E-MEM Subpanel On the 2-M/E Main panel, the Master E-MEM subpanel (Figure 83) always operates as Master E-MEM. Delegating the PGM PST bank to control an M/E does not change this panel into a dedicated E-MEM subpanel. You can use the Enable buttons to delegate control of the Master E-MEM panel to the desired E-MEM levels.
Page 147: Macros Subpanel
2-M/E Main Panel Macros Subpanel The Macros subpanel on the 2-M/E Main panel is located next to the Keyers subpanel, at the upper center part of the panel (Figure 85). See Macros Subpanel on page 131 for speciﬁc information. Figure 85. 2-M/E Macros Subpanel Macros Macros Subpanel...
Page 148: Local Aux Subpanel
Section 2 — Control Panels Local Aux Subpanel The 2-M/E Main panel has a built-in Local Aux subpanel is located at the (Figure 86). This subpanel performs the same functions as the separate Local Aux Panel used by the 4-M/E Kalypso system. The 2-M/E Local Aux subpanel has 24 source selection button columns, rather than the 32 on the 4-M/E Kalypso system.
Page 149: 1-M/E Main Panel
1-M/E Main Panel 1-M/E Main Panel A 1-M/E Main panel (Figure 87) is designed to operate in conjunction with a 4-M/E or 2-M/E Main panel as an accessory workstation. Though the 1-M/E Main panel has only one M/E control bank, it can be delegated to control any of the M/Es of a 2 or 4-M/E Kalypso system.
Page 150: Bank Delegate Subpanel
Section 2 — Control Panels Bank Delegate Subpanel The Bank Delegate subpanel selects which Kalypso system M/E will be controlled by the 1-M/E Main panel, and also affects how the E-MEM sub- panel operates. Figure 88. 1-M/E Bank Delegate Subpanel Bank Delegate Subpanel...
Page 151: E-Mem Subpanel
1-M/E Main Panel E-MEM Subpanel The E-MEM subpanel is used to Learn and Recall E -MEM effects, and also has E-MEM Recall and Run controls. Figure 89. E-MEM Subpanel Master E-MEM E-MEM Indicator Subpanel Readout Master Display E-MEM Misc Misc Select Stop Next...
Page 152: Master E-Mem Mode
Section 2 — Control Panels Master E-MEM Mode The E-MEM subpanel operates as Master EMEM when delegated to Pgm Pst in the Bank Delegate subpanel. In this mode you can enable multiple E-MEM levels for control, and the buttons listed above are active. The E-MEM indicator illuminates in this mode.
Page 153: Menu/Joystick Delegate Subpanel
1-M/E Main Panel Menu/Joystick Delegate Subpanel The Menu/Joystick Delegate subpanel has a built-in menu display, which can be used instead of a separate Menu panel. This subpanel also has a joy- stick which can be delegated for various purposes. This subpanel is also used to adjust Source Name Display contrast.
Page 154: Source Selection
Section 2 — Control Panels Source Selection Source selection on the 1-M/E Main panel is identical to the 2 and 4-M/E subpanels, except there are 12 source select buttons. The 1-M/E Main panel does not have M/E status displays. The bus indicators for each button Shift row indicates whether that row is in shifted source selection mode.
Page 155: Transition Subpanel
1-M/E Main Panel Transition Subpanel The Transition subpanel operates essentially the same as a 2 or 4-M/E Main panel, except there are no Keyer Cut buttons. Lever Arm sync indicators and a Transition Rate readout has been added, to display information reported in the M/E Status displays of 2 and 4-M/E Main panels.
Page 156: 1-M/E Main Panel Reset
Section 2 — Control Panels 1-M/E Main Panel Reset A reset button is located inside the lower Transition Lever Arm slot, besides on the rear panel, permitting easy reset should the unit be installed in a console or rack. The button can be pressed with a small screwdriver. Macros Subpanel On a 1-M/E Main panel the Macro buttons are located at the center left of the panel...
Page 157: Section 3 - Menus
Section Menus Introduction The Kalypso system’s Menu panel provides capabilities that compliment the operation of the Main panel and the Local Aux panel. The Menu panel controls most system functions, and has additional controls not available on the Main panel (for example, wipe pattern selection, chroma key manual controls, and conﬁguration menus).
Page 158: Enhanced Menu Panel
Section 3 — Menus Enhanced Menu Panel The Enhanced Menu panel (Figure 94) includes a touch screen display, ﬁve knobs for adjusting parameter values, a cooling fan, and an internal CD-ROM drive. Figure 94. Enhanced Menu Panel Soft Knobs (5) Touch Screen Display CD-ROM...
Page 159: Touch Screen
Introduction played. The button for the currently displayed menu will be high tally. Menu selection is also available via the Home menu (Figure 102 on page 166). Touch Screen CAUTION Do not apply any sharp or rigid object (no pens or pencils) to the touch screen display surface.
Page 160: Data Pads And Touch Buttons
Section 3 — Menus gations may also be available to access speciﬁc parameters. In general, once a menu category/subcategory has been selected, levels of delegation are available in a left to right and top to bottom order. This generally results in placing some parameters next to the soft knobs for easy adjustment.
Page 161: Menu Top Line
Introduction Note that a single touch of a data pad will not change any Kalypso system settings, but just brings up controls that permit changes. You can safely touch any data pad to explore that object’s parameters and settings. Actual changes are enacted on the screen with the touch buttons, by turning a soft knob, or by entering a value on a keypad.
Page 162: Menu Category Selection
Section 3 — Menus Menu Category Selection Menu category selection touch buttons are arranged along the bottom of the screen ( , etc. in the example). Touching one of these Mode B-Line Priority buttons takes you directly to that category. The currently selected category is shown by the green indicator on the touch button.
Page 163: Menu Access Touch Button
Introduction Menu Access Touch Button In some cases it is handy to jump to a different menu and delegation to adjust related controls. For example, an operator setting up a mask may need to adjust a pattern in the wipe menu. To make menu navigation easier, a menu access button can be included on one menu that links to a different, related menu.
Page 164: Alphanumeric Keypad
Section 3 — Menus Alphanumeric Keypad Touching the pad for a text parameter brings up an alphanumeric keypad (Figure 99). You can also use a standard computer keyboard to enter infor- mation while this display is active. Figure 99. Alphanumeric keypad Scrolling Lists When multiple items are available for selection, scrolling lists are used Figure 100.
Page 165: Menu Summaries
Menu Summaries Figure 101. Paired Scroll Lists with Lock On Menu Summaries In the remainder of this section, ﬁgures of several Kalypso system menus are presented to familiarize you with various screen layouts. Because each menu controls different aspects of the Kalypso system, the screen parame- ters and organization will vary, but the basic principles previously described are followed.
Page 166: Home Menu
Section 3 — Menus Home Menu The Home menu (Figure 102) is used to access the other Kalypso system menus. Touch the button of the desired menu type to go directly to that menu. If multiple menus are available for that type, the last selected menu will be displayed.
Page 167 Home Menu Table 7. Menu Selection Button Functions Menu Buttons Purpose Timeline E-MEM effect timeline display E-MEM E-MEM registers load and save Copy Swap Copy Swap menu controls (M/E, Wipe, Matte, Keyer, and Source Memory) Still Store Still Store controls Matte Matte adjustment controls T-Form...
Page 168: Daily Setups Menus
Section 3 — Menus Daily Setups Menus The Daily Setups menus contain controls operators may need to change routinely to meet various project requirements. Daily Setups Save-Load Menu The Daily Setups Save-Load menu employs the Kalypso ﬁle browser and is used to save and load User Proﬁles, Suite Proﬁles, and Source Memory information.
Page 169: Profiles Menu
Daily Setups Menus Proﬁles Menu The Proﬁles menu is used to load User Proﬁle and Suite Proﬁle ﬁles from speciﬁc folders on the Video Processor frame hard disk or Zip disk. Only these ﬁle formats are supported in this menu. The menu is accessed by touching (Figure 104)
Page 170: Preview Prefs Menu
Section 3 — Menus Preferences, touch . Various Suite Preference controls Daily Setups Suite Prefs are available by selecting a subcategory touch button on the left side of each menu. Preview Prefs Menu The Preview Prefs menu is used to activate preview screen overlays. The menu is accessed by touching Daily Setups Suite Prefs...
Page 171: Default Keyframe Menu
Daily Setups Menus To Activate a Preview Overlay: 1. Select the desired Preview output by touching its data pad in the Preview Modes pane. 2. Touch the desired overlay buttons in the Safe Title/Action pane. When is selected, horizontal and vertical soft knob and data pad User Lines controls are available.
Page 172: E-Mem Prefs Menu
Section 3 — Menus Note You should save your current Suite Proﬁle, which includes the Default Key- frame settings, before resetting to factory defaults. E-MEM Prefs Menu E-MEM Prefs menu is used to set E-MEM level assignments, and to select 300 Mode operation.
Page 173 Daily Setups Menus Default assignments are shown in Table 8. You can to reassign E-MEM levels to different Enable buttons with the E-MEM Prefs menu. Table 8. E-MEM Level Default Assignments E-MEM Level E-MEM Sub Level Button Misc 1 Background 1 and 2 Macros Misc 3 Aux buses...
Page 174: Master E-Mem Mode
Section 3 — Menus On the left individual levels can be selected for assignment (the selected level is yellow). Touching one of the E-MEM Enable buttons will assign that level to that button. Click on to return to the previous menu, from Done which you can access other levels to change.
Page 175: Video Settings Menu
Daily Setups Menus To Program a GPI: 1. Select the GPI input to program from the scrolling list in the central pane. 2. Select the action and appropriate qualiﬁers on the remainder of the menu. Figure 109, GPI 1 has been programmed to transition Key 1 on the PGM PST A bus.
Page 176: Matte Limiting
Section 3 — Menus Matte Limiting Matte Limiting determines how the matte generators produce colors. Limits can be imposed to prevent downstream signal problems. – This limiter mode produces colors that decode to valid RGB Decodable components. Not all valid RGB colors can be transmitted in NTSC, how- ever.
Page 177: M/E Output Blanking
Daily Setups Menus M/E Output Blanking Production switchers normally regenerate a clean blanking interval. When the switcher must pass ancillary information such as embedded audio, this blanking regeneration can be disabled. This following settings apply to the output blanking of all the M/Es. –...
Page 178: Logical Source Selection Pane
Section 3 — Menus Figure 111. Source Patch Menu Logical Source Selection Pane The Source Patch menu has a scrolling list of Logical sources displayed in ascending Logical ID order. The Logical Source soft knob can be used to scroll up and down the list and select a different Logical source. Touching the soft knob label data pad brings up a numeric keypad that can be used to scroll the list to the entered Logical ID number and select that source.
Page 179 Daily Setups Menus neering source by eye. Touching the soft knob label data pad brings up a numeric keypad that can be used to select an Engineering source by its Engineering ID number. Engineering source selection is also possible using a source picker. Touching an Engineering Source data pad in the Logical source selection pane brings up a scrolling Engineering source picker (Figure...
Page 180: Display Color
Section 3 — Menus Display Color The Main panel and Local Aux panel source name displays can display red, green, and amber colors, which can be applied either to the text or the back- ground. One example of using these tri-color displays is to make the names of all the cameras appear green, all the character generators appear yellow, and the network feeds appear red.
Page 181: Source Memory Menu
Daily Setups Menus Source Memory Menu The Source Memory menu is used to enable and disable Source Memory. The menu is accessed by touching Daily Setups Suite Prefs Source Memory (Figure 113). Figure 113. Source Memory Menu When (green indicator on the button is illuminated), key type and Enabled source memory settings will change as different sources are selected on that bus.
Page 182 Section 3 — Menus Source Memory Operation Rule Changes Starting with Kalypso software version 10.0 the following rules for Source Memory Operations apply: • While Source Memory is active, if it is loaded or copied or swapped, the new Source Memory will be immediately applied to the Current Work Buffer.
Page 183: Key Drop Menu
Daily Setups Menus Key Drop Menu The Key Drop menu is used to automatically drop selected key signals when an on-air hot cut occurs. Each M/E has its own set of Key Drop con- trols. The menu is accessed by touching Daily Setups Suite Prefs Key Drop...
Page 184: Bus Linking Menu
Section 3 — Menus Bus Linking Menu The Bus Linking menu allows the operator to set up bus links and source associations and enable the linking. This menu is accessed via Daily Setups, Suite Prefs, Bus Linking (Figure 115). Refer to the separate Kalypso User Manual for speciﬁc instructions on how to use the Bus Linking feature.
Page 185: Bus Picker
Daily Setups Menus Bus Picker Touching the data pad at the top of either the Controlling Bus or Linked Bus pane facilitates selecting a bus via a popup bus picker (Figure 116). Figure 116. Bus Picker Popup The type of bus to display ( ) is chosen with the Bus M/E Buses Aux Buses...
Page 186: Shortcut Menu
Section 3 — Menus Shortcut Menu Touching the button brings up a menu that can help Display Shortcut Menu reduce the time required to build Link Mapping tables (Figure 117). Figure 117. Bus Linking Shortcut Menu The current Controlling Bus and Linked Bus are identiﬁed in the data pads at the top of the pane.
Page 187: Display All Links Menu
Daily Setups Menus Display All Links Menu Touching the button on the Bus Linking menu brings up a Display All Links scrolling list of all the deﬁned bus links (Figure 118). This can be used to help manage the links. Buses that are not linked are not shown. Figure 118.
Page 188: Button Mapping Menus
Section 3 — Menus Button Mapping Menus The Button Mapping menus are used for source to button mapping, which permits arranging sources in any order on the source selection buses. This menu is also used to map Joystick overrides. The menu is accessed by touching (Figure 119).
Page 189 Daily Setups Menus When is selected, a Remote Panels panel appears permitting selec- Remote tion of multiple remote panels (Figure 120). Figure 120. Source Button Mapping Menu, Remote Panel Type Selected See Button Mapping in the Kalypso User Manual for speciﬁc operating instructions.
Page 190: Aux Delegation Mapping Menus
Section 3 — Menus Aux Delegation Mapping Menus The Aux Delegation Mapping menus are used to map the delegation buttons on the Local Aux panel, and on any conﬁgured Remote Aux panels. The menu is accessed by touching Daily Setups User Prefs Aux Deleg Mapping (Figure...
Page 191: Shift Preferences Menu
Daily Setups Menus Shift Preferences Menu The Shift Preferences menu is used to conﬁgure which source will be selected on the Kalypso Main panel or Local Aux panel when a shift mod- iﬁer button is not held down. Shift preferences can be set on individual buses.
Page 192: Source Display Menu
Section 3 — Menus Source Display Menu The Source Display menu is used to conﬁgure source name displays. The source name displays can show the names of the unshifted sources, show the shifted sources, or show both in a split display. The menu is accessed by touching (Figure 123).
Page 193: Clip Hi Lo Preferences Menu
Daily Setups Menus Clip Hi Lo Preferences Menu The Clip Hi-Lo Preferences menu controls how Clip and Gain knobs behave. The menu is accessed by touching Daily Setup User Prefs Clip Hi-Lo (Figure 124). Prefs Figure 124. Clip Hi-Lo Prefs Menu The Clip and Gain knobs on the Kalypso system Main panel and Menu panel can control either Clip and Gain, or Clip Hi and Clip Low, depending on the preference set.
Page 194: Double Press Alternate Source Selection
Section 3 — Menus Double Press Alternate Source Selection Selected buses on the Kalypso Main panel can be conﬁgured to take the alternate (shifted or unshifted) source when the source select button is pressed twice quickly. The ﬁrst press will still shows the original source, then the second press selects the alternate source.
Page 195: Eic Login Menu
Daily Setups Menus EIC Login Menu The EIC Login menu is used to log in as the Engineering In Charge (EIC). The menu is accessed via . This menu is different, Daily Setups EIC Login depending on whether Single Suite mode or Multi Suite mode is active. Figure 126 illustrates this menu in Single Suite mode.
Page 196 Section 3 — Menus An Identity pane appears on the EIC Login menu when in Multi Suite mode (Figure 127). When logged in as the EIC (a password may be required), the buttons in this pane are active, permitting access to either control surface in either suite.
Page 197: Eic Login Shortcut
Daily Setups Menus EIC Login Shortcut If while in an Engineering Setup menu you attempt to make a change when not logged in as the EIC, the EIC login popup appears (Figure 128), allowing you to login without having to navigate to the Daily Setups EIC login menu.
Page 198: Acquire Resources Menu
Section 3 — Menus Acquire Resources Menu The Acquire Resources menu (accessed via ) is used to Daily Setups Acquire specify what resources are desired for use by a suite, and acquire and release those resources (Figure 129). This menu only becomes available when Multi Suite mode is in operation, In Single Suite mode the Acquire button is grayed out, as depicted in proceeding menus.
Page 199: Physical Components Pane
Daily Setups Menus A Desired indicator column shows what logical components are desired for use by that suite. A green box indicates that resource is desired, and a blank area indicates the resource is not desired. Touching the button in the Desired central Resource Action pane toggles this status on and off for the dele- gated component.
Page 200: Resource Action Panes
Section 3 — Menus Resource Action Panes The middle panes control the actual acquisition and release of resources. The upper middle pane is delegated with the Logical buttons in the left pane to a speciﬁc logical component. The contents of this pane is context sensitive depending on the type of resource delegated.
Page 201 Daily Setups Menus When a Transform Engine or Chroma Keyer Logical component has been delegated, the upper Resource Action pane changes (Figure 130). Figure 130. Acquire Resources Menu with Chroma Keyer Selected Touching the top data pad brings up a popup keypad. Entering a value speciﬁes the total number of the currently delegated component type desired by the suite.
Page 202: Configuration Data
Section 3 — Menus button releases all components, including those marked as Release All desired. This should only be used to shut down a suite when not in use, making all the resources available to the other suite. Conﬁguration Data The desired resource list is part of Suite Preferences.
Page 203: Eng Setups Menus
Eng Setups Menus Eng Setups Menus The Eng Setups menus contain controls generally used by engineering per- sonnel to setup and conﬁgure the Kalypso system. Note Eng Setups conﬁguration procedures are covered in the separate Kalypso Installation and Service Manual. Eng Setup Save-Load Menu The Eng Setup Save-Load menu employs the Kalypso ﬁle browser and is used to save and load Engineering Setup information.
Page 204 Section 3 — Menus current path is displayed at the top of the pane. Touching an icon selects that item. Touching a selected icon de-selects it. Double touching a folder or drive icon opens it. On the upper right, below the top line message area, is a ﬁle operations message pane.
Page 205: Source Definition Menu
Eng Setups Menus Source Deﬁnition Menu Kalypso system sources are deﬁned in the Source Deﬁnition menu. Touching a source button on the scrolling list at the top of the screen selects that source for deﬁnition. The data pads and touch buttons in the remainder of the screen applies to the selected source.
Page 206: Output Assignments Menu
Section 3 — Menus Output Assignments Menu The Eng Setups Output Assignments menu is used to assign Kalypso system outputs to speciﬁc physical connectors on the rear of the Video Pro- cessor frame. The menu is accessed by touching Eng Setup Outputs (Figure 133).
Page 207 Eng Setups Menus If Multi Suite mode is active, the Suite pane becomes available in the Output Assignments menu (Figure 134). Figure 134. Output Assignments Menu, Multi Suite Mode, buttons are used to assign the currently selected Suite 1 Suite 2 output to a suite.
Page 208: Port & Device Definition Menus
Section 3 — Menus Port & Device Deﬁnition Menus The Eng Setups Port and Device menus are used to create and edit Device Deﬁnitions. Each Device Deﬁnition contains the settings required to use the unique features of that device. DDRs, VTRs, and DPMs are associated with sources, while GPI and PBus devices are not.
Page 209 Eng Setups Menus Touching an already deﬁned item in the scrolling Device List on the left brings up information for that device. Figure 136 shows the settings for a Krystal DPM. Figure 136. Port & Device Deﬁnition Menu, Krystal DPM Kalypso Reference Manual...
Page 210 Section 3 — Menus Touching the button brings up a menu used to create a new New Device device deﬁnition (Figure 137). Figure 137. Port & Device Deﬁnition Menu, New Device The AMP Serial feature is a software enabled option, available only when the feature has been activated.
Page 211: Tally Menus
Eng Setups Menus Tally Menus The Tally menus are used to conﬁgure the tally system. There are multiple tally calculators, three different tally calculation methods, and user assign- ment of tally relays. The results of the tally calculators are applied to the tally relays on the Tally modules in the Video Processor frame, and those relays control external tally lights.
Page 212: Tally Relay Assignments Menu
Section 3 — Menus Tally Relay Assignments Menu Touch (the Relay Assign button is in the Function Eng Setup Tally, Relay Assign pane) to access the Tally Relay Assignments menu (Figure 139). Figure 139. Tally Relay Assignments Menu Kalypso Reference Manual...
Page 213: Router Interface Setup Menu
Eng Setups Menus Router Interface Setup Menu The Router Interface Setup menu (Figure 140) is used to set the IP Address(es) the Kalypso system will use to communicate to the external router. The Connection Status indicator is red when communication is not detected, and is green when communication is established.
Page 214: System Menus
Section 3 — Menus System Menus The System menus are used to set various system parameters. Subcategory selection buttons for these controls are located on the left. Suite Deﬁnition Menu The Suite Deﬁnition menu is accessed by touching Eng Setup System Suite Def (Figure...
Page 215: Still Store Pane
Eng Setups Menus Note If this ﬁeld is changed, the Kalypso Menu application must be exited and relaunched or the Menu panel must reset before the Menu will use this dif- ferent IP address to communicate with a Video Processor frame. buttons toggle between Single and Multi Suite Single Suite Multi Suite...
Page 216: Security Account Setup Menu
Section 3 — Menus Security Account Setup Menu Security setup is covered in the separate Kalypso Installation and Service Manual. Remote Aux Panel Setup Menu The Aux Panel Conﬁguration menu is accessed by touching Eng Setup , then touching either the buttons.
Page 217 Eng Setups Menus When in Multi-Suite mode a menu similar to Figure 143 is displayed. Figure 143. Eng Setup Aux Panel Menu, Multi-Suite Modes buttons assign that Aux panel to control the Suite 1 Indep Suite 2 Indep Aux buses of that suite. The conﬁguration settings for this Aux panel are saved with Eng setups, however, and so are independent from individual Suite and User Pref settings.
Page 218: Emerg Bypass Menu
Section 3 — Menus Emerg Bypass Menu Emergency Bypass option conﬁguration, installation, and operation is covered in the separate Kalypso Emergency Bypass Instruction Manual. This option supports Kalypso Classic and Duo systems, but does not operate with Kalypso HD systems when run in HD mode. Kalypso Classic Sync/Timing Menu On Kalypso Classic systems, the Sync/Timing menu, accessed via Eng Setup...
Page 219: Kalypso Hd/Duo Sync Timing Menu
Eng Setups Menus Kalypso HD/Duo Sync Timing Menu Kalypso HD and Duo systems have a different Sync Timing Menu that, besides reporting the Sync Ref status, includes other controls (Figure 145). Figure 145. Sync/Timing Menu, HD System A Timing Analyzer is available, as well as controls to select the sync refer- ence that switches the system between HD and SD operating modes.
Page 220: Install Options Menu
Section 3 — Menus Install Options Menu The Instal Options menu (Figure 146) is used to authorize software enabled options. This procedure is covered in the separate Kalypso Installation and Service Manual. Figure 146. Install Options Menu Kalypso Reference Manual...
Page 221: Test Patterns Menu
Eng Setups Menus Test Patterns Menu The Eng Setup-Test Patterns menu (Figure 147) allows the selection of dif- ferent video test patterns. The chosen test pattern will be displayed when the Test source is selected. Figure 147. Test Patterns Menu Kalypso Reference Manual...
Page 222: Macro Menus
Section 3 — Menus Macro Menus The Macro menus provide access to many, but not all, Kalypso system macro functions. With Kalypso software version 11.0 the Macro menus can be used to: • Record a new macro and append record onto an existing macro, •...
Page 223: Macro Save Load Menu
Macro Menus Macro Save Load Menu The Macro Save Load menu (Figure 148) is accessed by touching the Save Load category selection button at the bottom of the Macro menu. Figure 148. Macro Save-Load Menu This menu operates the same as he other save load menus (for example, E-MEM, Eng Setup, and Daily Setups Save-Load).
Page 224: Macro Catalog Menu
Section 3 — Menus Macro Catalog Menu The Macro Catalog menu (Figure 149) is used to record, play, and name macros. It is also used to include a macro in an E-MEM. Figure 149. Macro Catalog Menu Macro Catalog Pane The Macro Catalog pane has a scrolling list of all 100 macro registers.
Page 225: Control Pane
Macro Menus Control Pane The buttons in the Control pane affect the selected macro register, per- forming the labeled functions. CAUTION Unlike macro operations on the Main panel, you must ﬁrst select the desired register and then press the desired macro function button (Record, Append, Delete Macro).
Page 226: Append Macros Pane
Section 3 — Menus Append Macros Pane You can append the contents of one macro into another macro using the Macro Catalog menu. After touching either the button on Record Append the menu, touching another Macro Register button on the menu opens an Append Macros pane (Figure 150).
Page 227: Soft Knob Register Selection
Macro Menus Soft Knob Register Selection Macro registers can be selected using the labeled soft knob on the right, and a speciﬁc register number can be entered on the data pad to go directly to that register. E-MEM Pane The E-MEM pane is used to add a macro to an E-MEM. Touching the E-MEM data pad opens the Macro selection menu, from which you select the desired macro.
Page 228: Macro Copy Swap Menu
Section 3 — Menus Macro Copy Swap Menu The Macro Copy/Swap menu (Figure 151) is accessed by touching the category selection button at the bottom of the Macro menu. This Copy Swap menu can also be accessed via the Copy Swap menu. Figure 151.
Page 229: Macro Attachments Pane
Macro Menus Note Macro attachments are saved and loaded with User Prefs. One set of attach- ments exists for each control surface. Be sure the User Prefs you load are compatible with the Macro registers you are currently using, to avoid acci- dentally running incorrect attached Macros.
Page 230 Section 3 — Menus Note The display will show buttons for the maximum used by a Kalypso system. This means that if you have a 2-M/E system, the button set will still display all the buttons for a 4-M/E system. Ignore any extra buttons displayed. Selecting a Panel Button for a Macro Attachment You can use the Macro Attach menu to select a panel button, by touching the section (M/E 1 - Misc) and scrolling the list to display the button name.
Page 231: Unattach Macros
Macro Menus Unattach Macros button is used to clear all the current macro Remove all Attachments attachments. A popup pane appears asking you to conﬁrm the action. Panel Attach Mode The buttons in the Panel Attach Mode duplicate the functions of those ﬁve Macro subpanel buttons on the Kalypso Main panel, and are also included on the menu as a convenience.
Page 232: File Operations Menu
Section 3 — Menus File Operations Menu The File Operations menu employs the Kalypso ﬁle browser. This menu is used to navigate through the available ﬁle hierarchies, create folders, rename folders and ﬁles, and copy/paste ﬁles. Only mapped network drives and selected areas of the Kalypso system are accessible. The menu is reached by touching (Figure 154).
Page 233 File Operations Menu button goes to the top directory that displays the local and network drives. Also displayed is the Frame User Directory, which provides access to the Kalypso Video Processor frame. Individual ﬁles and folders located on the Kalypso Menu panel NT desktop are not shown. button opens the selected folder or drive.
Page 234: Status/Diags - Versions Menu
Section 3 — Menus Status/Diags - Versions Menu The Versions menu displays currently loaded software versions for all the Kalypso system components. This menu also displays Node Names and Types and Control Surface assignments deﬁned for Resource Sharing (Figure 155). Touch to access this menu.
Page 235: External Device E-Mem Menus
External Device E-MEM Menus External Device E-MEM Menus The External Device menus are used to control external devices that have been conﬁgured with the Kalypso system. Five menus are available: • Enables – Enables and disables control of external devices. •...
Page 236: Devices Pane
Section 3 — Menus Disabling device control temporarily can be useful. For example, during a rehearsal you may not want to cue or roll VTRs. With the External Device Enables menu you can control which devices will respond without having to rebuild effects or change engineering conﬁguration.
Page 237 External Device E-MEM Menus button accesses the External Device Mapping menu Map Sources (Figure 158). This menu will allow the user to map any or all of the Kalypso sources to editor sources. The menu does not know how many sources the editor can control, so it is the responsibility of the user to map the correct number of sources based on the protocol used by the editor device.
Page 238: Dpm Panes
Section 3 — Menus button accesses shortcuts for the Editor menu Mapping Shortcuts (Figure 159). Figure 159. Editor Mapping Shortcuts Menu • Touching the button does a quick mapping of the sources Map Sources 1:1 1 to 1, (Switcher Source 1 to Editor Source 1, etc.). •...
Page 239 External Device E-MEM Menus and the buttons toggle on and Switcher Controls DPM DPM Controls Aux Bus off. The three possible combinations are: is On and is On. Switcher Controls DPM DPM Controls Aux bus The switcher changes to the aux bus are sent as a request to the DPM. The DPM replies to the switcher with the report of the new source.
Page 240 Section 3 — Menus button accesses shortcuts for the DPM menu Mapping Shortcuts (Figure 161). Figure 161. DPM Mapping Shortcuts Menu • Touching the button does a quick mapping of the sources Map Sources 1:1 1 to 1, (Switcher Source 1 to Editor Source 1). •...
Page 241: External Device Time Code Selection
External Device E-MEM Menus External Device Time Code Selection On the External Device Enables menu you can specify what type of time- code the Kalypso system will use with each device. The current time code mode is displayed in the Time Code column (Figure 156 on page 235).
Page 242: Timeline Events Menu
Section 3 — Menus Timeline Events Menu After the external devices are conﬁgured with the Kalypso system, they can be controlled using events learned to effect keyframes. Events act as triggers for speciﬁc behaviors, similar to GPI or Peripheral Bus II commands. As each keyframe with an event is encountered during an effect run, that event information is sent to the external device, commanding it to action.
Page 243: Device Pane
External Device E-MEM Menus Device Pane The Device pane on the left is a scrolling list of all conﬁgured external devices, as described in the External Device Enables menu on page 236. The name of each device is shown on the left, and its status is indicated in the adjacent box (see Device Statuses on page 236).
Page 244: External Device Control Menu
Section 3 — Menus button instructs the device to stop playback when that keyframe Stop is encountered. Turning on automatically turns off if it was Stop Play selected. button turns off events at the current keyframe for only the Clear Events delegated device.
Page 245: Device Name
External Device E-MEM Menus The smaller control panes on the right have , and Cue to Begin Stop Play control buttons. Var Play Speed button turns the variable speed function On and Off. When On, the device will play at the speed displayed when the Play button is pressed.
Page 246: Preset And Program Clip
Section 3 — Menus Preset and Program Clip Devices that allow clip selection (DDRs for example) are loaded with a spe- ciﬁc clip with the data pads. Touching these pads Preset Clip Program Clip bring up a clip picker menu. If the device is using the optional AMP Serial Machine Control feature, both folder and clip selections are available (Figure 166).
Page 247: Clip Browser
External Device E-MEM Menus The External Device Event List menu is accessed by touching Extern Device (Figure 167). The Event List itself appears in the right pane, list Event List editing controls appear in the central pane, and a clip browser from which clips are selected appears in the left pane.
Page 248: List Edit
Section 3 — Menus clips are stored in a News8 folder, and others are stored in a News10 folder, the clips in the News10 folder will appear above those in the News8 folder (1 precedes 8). List Edit The buttons in this pane select what action will be performed when a clip is selected in the Clip Browser, and are also used to edit the order of clips in the Event List on the right, and to save, load, and unload Event Lists.
Page 249: Event List
External Device E-MEM Menus Figure 168. External Device Event List File Browser button brings up a ﬁle browser (Figure 168), allowing you to Save List navigate to a folder location, create a new folder, name the Event List, and it to that location. When a list is saved using this button, the list Save remains loaded in the Event List pane.
Page 250: Event List Automation
Section 3 — Menus Event List Automation When combined with , an event list provides a Auto Start Off Air Adv nearly automatic way to play out clips during a scripted show like a news cast. Once the event list is created and loaded into a DDR channel, taking the channel to air will play the current clip and taking the channel off air will cue up the next one.
Page 251: E-Mem Control
External Device E-MEM Menus The External Device Links menu has two panes with scrolling lists, each listing the devices setup for Kalypso system control. A primary device is selected in the Primary Links pane on the left, and the devices that are to be linked to that primary device are selected in the pane on the right.
Page 252: R-Mem Menus
Section 3 — Menus R-MEM Menus The R-MEM menus are used on Kalypso systems that have been conﬁgured with an external router. Additional routed sources become available for pre-selection on the Kalypso source select buttons, increasing the number of inputs the Kalypso system can handle at one time. R-MEM Save-Load Menu The R-MEM Save-Load menu employs the Kalypso ﬁle browser and is used to save and load Router Memory ﬁles.
Page 253: R-Mem Menu
R-MEM Menus R-MEM Menu The R-MEM menu is used to learn, recall, and preview R-MEM registers. R-MEM registers are similar to E-MEM registers, but hold router source information used with the Kalypso system router interface feature. By recalling R-MEMs you can change one or more router sources associated with Kalypso system sources.
Page 254: Router Select Menu
Section 3 — Menus Router Select Menu The Router Select menu is used to select a different router source for a par- ticular router destination, and so changes that switcher source signal on the Kalypso system. It is also used to set router protections. The menu is accessed by touching (Figure 172).
Page 255: Pbus & Gpi Out Menus
PBus & GPI Out Menus PBus & GPI Out Menus The PBus (Peripheral Bus II) & GPI menus are used to specify the sending of trigger commands to external devices. GPI and PBus triggers are placed on keyframes when an effect is created. When working on an effect, this menu is used to change the working buffer to include trigger commands.
Page 256 Section 3 — Menus Up to 16 PBus triggers (0-15) can be associated with each external device on the PBus. When a device is deﬁned (Eng Setups), names can be given to the device and each of its triggers. The actual action performed when a partic- ular trigger is sent is determined by the external device.
Page 257: Gpi Out Triggers Menu
PBus & GPI Out Menus GPI Out Triggers Menu The GPI Out Triggers menu is used to specify the sending of GPI type com- mands to external devices. The Kalypso system supports a total of 16 GPI outputs (1-16). The menu is reached by touching PBus &...
Page 258: Pbus & Gpi Out Enables Menu
Section 3 — Menus GPI Out Deterministic Triggers Kalypso version 10.1 adds a one ﬁeld delay for GPI Out triggers to improve the deterministic behavior of E-MEM effects containing these triggers. Note Any E-MEM effects built with earlier software versions that rely on determin- istic timing of GPI or PBus triggers will need to be tested and probably adjusted.
Page 259: Aux Bus Menu
Aux Bus Menu Aux Bus Menu The Aux Bus menu is a source selector for Aux buses and can be used to deﬁne the B channel of an Aux Pair as either . It also allows the Video operator to set up the to be selected in Near Side Source Far Side Source...
Page 260 Section 3 — Menus panel is used to change the B side source. When a different source is chosen for the B channel (not associated with the video signal in the Sources menu) the SPLIT indicator will light to indicate a split key has been performed. Paired outputs are typically used with external DPMs.
Page 261: Timeline Menus
Timeline Menus Timeline Menus The Timeline menus provide a graphical representation of the current effect. Timeline menus can be used in conjunction with the Keyframe Edit controls in the Master E-MEM subpanel on the Main panel. The Timeline menus provide also editing controls for modifying keyframe effects on the timeline.
Page 262: Timeline - Edit Menu
Section 3 — Menus Timeline – Edit Menu The Timeline – Edit menu is accessed by touching . When an Timeline Edit effect is has been recalled the Timeline – Edit menu shows the location in time of all the keyframes for the currently enabled groups, and displays the current location of the time and edit cursors (Figure 178).
Page 263: Effect Editing Controls
Timeline Menus Two types of master timeline keyframes exist. Those from timelines that are delegated for editing are solid (edit keyframes). Those created from time- lines that are not delegated for editing are colored cyan (time keyframes). Conceptually, there are actually two timelines superimposed on one another, the edit timeline and the time (or run) timeline.
Page 264 Section 3 — Menus The following soft knob controls are also available on all Timeline menus: soft knob is used to scroll to or enter the number of the key- Go to KF frame to move the cursor to. soft knob is used to scroll the cursor through the time of Jog Effect an effect.
Page 265 Timeline Menus button brings up a screen that permits control of E-MEM level Enable enables and delegates (Figure 179). Figure 179. Timeline Menu Enables and Delegations Controls Kalypso Reference Manual...
Page 266: Timeline - Adjust Time Menu
Section 3 — Menus Timeline – Adjust Time Menu The Timeline – Time Adjust menu is used to modify keyframe duration. The Timeline-Time Adjust menu is accessed by touching Timeline Time Adjust (Figure 180). Figure 180. Timeline- Adjust Time Menu The controls on this menu are duplicated in other Timeline menus, with the following exception: •...
Page 267: Interpolation Paths Menu
Interpolation Paths Menu Interpolation Paths Menu Path control determines how interpolation is performed through key- frames. S-Linear, Linear, and Curve path types are supported, in addition to Path Hold. These path types provide ﬁne control of the dynamics of the effect.
Page 268 Section 3 — Menus control parameters of all of those items simultaneously. The Select All buttons are used for making and clearing delegations for all the Deselect All items in that pane. Levels selected for path control can be similar to one another, or they can be dissimilar.
Page 269 Interpolation Paths Menu Graphic symbols representing the Linear, S-Linear, Curve, and Hold path types appear on the Path control buttons. The selected path type symbol also appears next to each group delegation button. This symbol also appears next to each level or sublevel delegation button when all the sub- levels and/or groups for that item have the same path type (Figure 182).
Page 270: E-Mem Menus
Section 3 — Menus E-MEM Menus E-MEM - Save-Load Menu The E-MEM Save-Load menu employs the Kalypso ﬁle browser and is used to save and load E-MEM ﬁles. Only this ﬁle format is supported in the menu. The menu is accessed by touching (Figure 183).
Page 271: Source Holds Menu
E-MEM Menus Source Holds Menu The Source Holds menu is used to program holds into E-MEM effects. The menu is accessed by touching (Figure 184). E-MEM Source Holds Figure 184. Source Holds Menu During E-MEM recalls and effect runs sources can be programmed to change.
Page 272: Copy Swap Menus
Section 3 — Menus Copy Swap Menus The Copy Swap menus are used for copying setups from one part of the system to another. For example, if a chroma key was set up on M/E 1, but the operator needs the key while M/E 1 is in use, he can copy the keyer’s setup to M/E 2 and place the chroma key on air there.
Page 273: Copy Swap Me Menu
Copy Swap Menus Copy Swap ME Menu The Copy Swap ME menu is used to copy an entire setup from one M/E to another. Touch to access the menu (Figure 186). Copy Swap Figure 186. Copy Swap ME Menu Kalypso Reference Manual...
Page 274: Copy Swap Wipe Menu
Section 3 — Menus Copy Swap Wipe Menu The Copy Swap Wipe menu is used to copy wipe settings from one location to another. Touch to access the menu (Figure 187). Copy Swap Wipe Figure 187. Copy Swap Wipe Menu Kalypso Reference Manual...
Page 275: Copy Swap Matte Menu
Copy Swap Menus Copy Swap Matte Menu Touch to access the Copy Swap Matte menu (Figure 188). Copy Swap Matte Figure 188. Copy Swap Matte Menu Some combinations of M/E level, Key level, and matte generator level do not exist. For example, in Figure 188, the destination matte is M/E 1’s Trans Wipe.
Page 276: Copy Swap Keyer Menu
Section 3 — Menus Copy Swap Keyer Menu Touch to access the Copy Swap Keyer menu (Figure 189). Copy Swap Keyer Figure 189. Copy Swap Keyer Menu The menu enables the copying and swapping of entire keyers, including the mapping of key cutter and key ﬁll sources. It is a direct copy of what is currently in the chosen From keyer, including key type, key split condition, and all parameters describing the key’s behavior.
Page 277: Copy Swap Source Memory Menu
Copy Swap Menus Copy Swap Source Memory Menu Touch to access the Copy Swap Source Memory Copy Swap Source Memory menu (Figure 190). Figure 190. Copy Swap Source Memory Menu The user delegates the M/E level, the keyer within the M/E, and the num- bered input source to the keyer.
Page 278 Section 3 — Menus When the button is off, the user can select a single source by All Sources touching the Source text box. This pops up the Source Picker menu arranged in numerical order, see Figure 191. Figure 191. Copy Swap Source Picker Menu Copying or swapping of keyer parameters applies only to like types of keying.
Page 279: Copy Swap Macro Menu
Still Store Menus Several defaults can be transferred in a single operation. The To pane’s selectors change to on/off LED buttons. The user can choose any combina- tion of default. The following scenarios might exist allowing the user to copy: •...
Page 280: Still Store Playback Menu
Section 3 — Menus Still Store Playback Menu The Still Store Playback menu provides menu delegation to an output, still and clip selection, clip playback, video/key pair control, and position and crop controls. Touch to access this menu (Figure 192). Still Store Playback Figure 192.
Page 281: Preset Transfer To Program
Still Store Menus When an item is loaded to either a button it is automati- Program Preset cally locked into the cache, which protects it from being overwritten by other caching operations. When an item is unloaded from an output, either by being replaced with another item or with the button, the Unload Output...
Page 282: Unload Output Button
Section 3 — Menus Unload Output Button Pressing unloads the item from the delegated Still Store Unload Output output. Note The Unload Output button will blank any image currently being used on that output, even if it is on-air. Start at KF Button button is used to set a trigger for a Still Store animation clip Start at KF cue and play command at the current location of an E-MEM effect.
Page 283: Folder Browser
Still Store Menus Folder Browser Below the scrolling list is a data pad that reports the path of the currently selected folder (whose items are displayed above), and number of items in the list is reported on the right (Figure 192 on page 280).
Page 284: Playback Controls
Section 3 — Menus button chooses the currently selected folder for use by the Use Selected Still Store. The browser will close, the Still Store Playback menu will reap- pear, and the items in the selected folder will be displayed in the scrolling list.
Page 285 Still Store Menus The Playback menu position and crop controls only apply to the Program output, not Preset. If modiﬁed crop values are applied to the Program output, transferring an item to Program from Preset will clear the modiﬁed values and the position and crop values saved with the Preset image will be used.
Page 286 Section 3 — Menus Touching the data pad brings up a similar menu with Crop Top Crop , and controls (Figure 195). The image can be Bottom Crop Left Crop Right Crop cropped to any rectangular shape. These controls are keyframeable but res- olution is limited to pixels and lines so interpolated motion may not appear smooth.
Page 287: Still Store Create Edit Menu
Still Store Menus Still Store Create Edit Menu The Still Store Create Edit menu provides many of the same controls as the Playback menu, but also provides still capture, clip recording, save con- trols, and also provides access to clip mark and loop editing controls. Touch to access this menu (Figure 196).
Page 288 Section 3 — Menus button permits grabbing only the key portion of an image. This Grab Key button is active only after a Video and Key grab has been performed. can be used if the video and key are supplied from separate sources Grab Key or are laid down sequentially on a graphics reel.
Page 289: Create Edit Menu Position And Crop Controls
Still Store Menus Create Edit Menu Position and Crop Controls Touching the Position and Crop data pads brings up the same controls available from the Still Store Playback menu (see Figure 194 on page 285 Figure 195 on page 286). These controls affect what is displayed on the Still Store output and what metadata will be saved with that item.
Page 290: Freeze And Clip Playback Editing Controls
Section 3 — Menus Note When the cache is full, older items will be uncached to make room for the new item. Long duration recordings involve lots of data and will clear many cached items. Saving a long recording also takes considerable time. Fenced recording can be used to reduce storage requirements and save times.
Page 291: Freeze Controls
Still Store Menus Freeze Controls The Freeze controls affect the appearance of a still image or a stopped clip. These controls are keyframeable. button selects a two ﬁeld display. This display offers the highest Frame resolution, but moving video can cause ﬂicker between the ﬁelds. buttons selects the speciﬁed single ﬁeld display.
Page 292: Clip Loop Controls
Section 3 — Menus Note The Disable Marks button is intended for use as a clip playback debugging tool. The button automatically turns off when a different item is loaded to an output, when the output delegation is changed, and when the pane is closed with the Show Details button.
Page 293: Still Store Icons
Still Store Menus The Loop data pad at the bottom of the pane displays the loop points and loop count. Touching this data pad brings up a pane of soft knob controls on the right (Figure 200). Figure 200. Still Store Create Edit Menu, Loop Controls Note Loop button settings are ignored when Disable Marks is turned on.
Page 294 Section 3 — Menus button on the Still Store Playback or Create Edit menu Legend and Options brings up descriptions of what each icon represents (Figure 201). Pressing brings back the previous menu. Cancel Figure 201. Still Store Icon Descriptions Kalypso Reference Manual...
Page 295: Still Store Cache Menu
Still Store Menus Still Store Cache Menu The Cache menu reports cache usage, and can be used to help manage the cache. Manual cache management is optional, as the still store cache oper- ates without operator intervention. When the cache becomes completely ﬁlled, older unlocked cached are deleted to make room for the caching of new items.
Page 296 Section 3 — Menus button clears the locked statuses of all cached items (those Unlock All loaded to outputs). Unlocking an item does not uncache it, but allows it to be uncached. Thus, after this button is pressed an item loaded to output could be automatically uncached, even if on-air.
Page 297: Matte Menus
Matte Menus Matte Menus The Matte menus give you control over matte color, type, and appearance. Category selection buttons exist at the bottom of each menu, allowing you to select M/E or Background mattes. Matte - M/E Menu When M/E or Pgm Pst is selected (Figure 203), touch pads are displayed for each keyer, and for the two wipes of that M/E.
Page 298: Matte - Background Menu
Section 3 — Menus Matte - Background Menu When is selected (Figure 204), the menu displays two panes for BKGD control of Bkgd 1 and Bkgd 2, including base and wash colors, wash direc- tion and offset, and wash edge texture attributes. Each touch pad activates the soft knobs to control those parameters.
Page 299: Transforms Menu
Transform Engine Menus Transform Engines also make use of the Effects Send menu, accessed from the Home menu by touching . This menu is used to turn on M/E. Effects Send Effects Send and assign Transform Engines to keyers (see Effects Send Menu on page 344).
Page 300: Transform Engine Menu Delegation
Section 3 — Menus Transform Engine Menu Delegation The Transform Engine menu contains a data pad matrix in the upper left for delegation (Figure 205). Data pads for keyers with Transform Engines assigned and Effects Send on will be active. Data pads for keyers that do not have Effects Send on will be grayed out and inactive.
Page 301: Crop Controls
Transform Engine Menus channel’s coordinate system for reference. Selecting the button pro- Target vides image adjustment using the screen as the reference. Only one space button is selectable at a time. Note Target Rot displays only Target Rotate transform parameter values, even when Source space is selected.
Page 302: Path Controls
Section 3 — Menus Path Controls The path control pane is located to the right of the data pad delegation matrix. , and interpolation touch buttons are available. S Linear Linear Curve When is selected, soft knob controls for , and soft Curve Tension...
Page 303: Picture Menu
Transform Engine Menus Picture Menu The Picture menu controls the appearance of an image (Blur, Freeze) and provides motion interpolation controls. This menu is available on Kalypso Classic systems, and on Kalypso HD/Duo systems running an interlaced video format. The menu is accessed by touching Transform Picture (Figure...
Page 304: Blur
Section 3 — Menus Blur The Blur feature is only available on Kalypso Classic systems. Incoming video on these systems can be blurred with the controls. When the Blur Blur button is active (green indicator on), touching the Blur data pad below the button activates a Blur soft knob on the upper right.
Page 305: Interpolation Path
Transform Engine Menus interpolation disables motion detection and forces the creation of all Field new pixels from only one ﬁeld (the other ﬁeld’s pixels are ignored in the interpolation). This minimizes motion artifacts, but the entire resulting image will have a lower vertical resolution. Interpolation Path The path controls on this menu only apply to interpolation, and...
Page 306: Transform Subpanel Drop Shadow Controls
Section 3 — Menus When is selected soft knobs for , and , are Shadow X Offset Y Offset Size Opacity available on all Kalypso systems. When Shadow Color is selected soft knobs for Hue, Saturation, and Bright- ness are available. On Kalypso Classic systems the control is available (Figure 207 on...
Page 307: Shadow Crop Controls
Transform Engine Menus Shadow Crop Controls The Shadow Crop controls are used to adjust shadow cropping and edge softness. The current parameter names and values are displayed on the data pads. When is selected, crop values of the shadow match the Follow Image Crop crop values used for the primary image.
Page 308: Position/Size Modulation Mode
Section 3 — Menus Position/Size Modulation Mode Position and Size Modulation is an effect in which the source video is posi- tion or size modulated through an additive process with either a single wave train, or two wave trains with the second wave at a right angle to the ﬁrst.
Page 309: Mod Type Pane
Transform Engine Menus of the pattern. When off, the soft knob is available to adjust the Speed speed of the pattern’s motion. Negative values can be entered to reverse the direction of the motion. — deﬁnes the angle of the Position Modulation with respect to H/V Angle the source X and Y axes.
Page 310 Section 3 — Menus Figure 211. Available Wave Patterns Normal + Only Normal + Only Sine Circle Triangle Random (Illogical, pattern lost) Square Pulse Ramp Trap When is selected in the Mod Type pane, the Size Mod Center data Size Mod pad in the Modulation pane is active.
Page 311: Slits Mode
Transform Engine Menus Slits Mode Slits is an effect in which the source video is split into a number of parallel slits. The width of the slits may be uniform or random, and an angle may be speciﬁed. An offset function is provided which controls the amount of displacement of alternating slits in opposite directions (to cause a transition type effect).
Page 312 Section 3 — Menus When the data pad is selected a menu similar to Figure 214 appears. Slits Figure 214. Kurl Menu, Slits Soft knob controls are provided to control various attributes of the slits: Offset — sets the distance adjoining slits move away from each other. This can be used for transition effects, using a zero offset for the starting keyframe and an off the screen offset for the ending keyframe.
Page 313: Page Turn/Roll Mode
Transform Engine Menus Page Turn/Roll Mode Page Turn is a transition effect with the video being mapped to an original plane, a cylinder, and a ﬁnal plane parallel to the original plane. Page Roll maps the video to an original plane and a cylinder. Page Turn and Roll are parallel projections to the target screen with no perspective.
Page 314: Show Sides Pane
Section 3 — Menus — positions the page turn cylinder with respect to the source Offset plane and, when interpolated between keyframes, causes the page to turn. The offset would typically change from one edge or corner of the source raster to the opposite edge or corner for the turn. —...
Page 315: Ripple Mode
Transform Engine Menus Ripple Mode Ripple is an effect in which the source video mapped to a plane is effec- tively distorted into and out of the target screen by a train of concentric waves. This is a parallel projection to the target screen with no perspective. Touch the Kurl Mode button to access the slits controls.
Page 316 Section 3 — Menus When the data pad is selected a menu similar to Figure 217 Position/Aspect appears. Figure 217. Kurl Menu, Ripple Soft knob controls are provided to control various attributes of the Ripple pattern. — controls the horizontal position of the center of the ripple. H Position —...
Page 317: Sphere Mode
Transform Engine Menus Sphere Mode Sphere is an effect in which the source video is mapped to the surface of a sphere. Controls are provided which change the aspect and size of the sphere, the point in source video to be mapped to the center of the front surface of the sphere, and the horizontal and vertical scaling of the source video to be mapped.
Page 318 Section 3 — Menus When Wrap is selected in the Sphere pane, the following menu appears (Figure 219). Figure 219. Kurl Menu, Sphere Wrap The following soft knob controls are available: — controls where the image is mapped onto the sphere Horizontal Position by moving the image horizontally on the sphere’s surface.
Page 319: Splits Mirrors Menu
Transform Engine Menus Splits Mirrors Menu The Splits and Mirrors function allows you to divide a picture horizontally and/or vertically, and create mirror images of the image along these axes. Touch the button to access the Split and Mirror controls. When Splits/Mirrors button is on, the following controls are available.
Page 320: Split Modifiers Pane
Section 3 — Menus When the Sep Sides data pad is selected, individual soft knob controls for separation are available (T Separate, L Separate, R Separate, B Separate). These controls allow movement of individual Top, Left, Right and Bottom portions of the split image. Split Modiﬁers Pane The Split Modiﬁers pane has mirror and double image controls.
Page 321: Glow Menu
Transform Engine Menus Glow Menu Glow controls are available on the Transform Engine Glow menu, accessed . The Glow controls on the menu affect the delegated Transform Glow keyer on the menu. Only one keyer can be delegated at a time (Figure 221).
Page 322: Glow Matte Pane
Section 3 — Menus When the Glow pane is activated, knob controls for Glow Width Aspect , and are available. Opacity Softness Note Glow Softness is linked with Drop Shadow Softness and has priority. When both the Glow and Drop Shadow features are on, Glow Softness values are applied to both Glow and Drop Shadow Softness (see page 306).
Page 323: Defocus Menu
Transform Engine Menus Defocus Menu Defocus controls are available on the Transform Engine Defocus menu, accessed via (Figure 223). Transform Defocus Figure 223. Defocus Menu Defocus Pane — The Defocus effect is deactivated. — The Defocus effect is applied to the original keyed image. Defocus —...
Page 324: Nam Matte Pane
Section 3 — Menus When the Defocus pane is activated, knob controls for Video Defocus , and are available. Video Aspect NAM Ratio — Adjusts the total amount of defocus applied to the Video Defocus image. — Adjusts the percentage of defocus applied to the vertical Video Aspect and horizontal axes of the image.
Page 325: Lighting Menu
Transform Engine Menus Lighting Menu The Lighting menu provides four colored light sources positional in 3D space for each delegated keyer. Each light source can be a Point, Bar, or Plane. The apparent reﬂection of the light source simulates the physics of incident light falling on a surface, including specular effects and light falloff due to distance and geometry.
Page 326: Shadow Pane
Section 3 — Menus Shadow Pane The Shadow pane applies to all of the light sources for the delegated keyer and controls ambient lighting effects. You can control the color of the ambient lighting, and the amount of shadow falloff for the light sources. Soft knobs for degrees, and , and...
Page 327: Lighting Path Controls
Transform Engine Menus Flare When light reﬂects off a surface two lighting components result, the primary reﬂected light and a glare (ﬂared halo) of scattered light. The Flare controls provide soft knobs to adjust this lighting component. Controls the amount of the ﬂare light scattered off the Flare Intensity —...
Page 328: M/E Menus
Section 3 — Menus M/E Menus M/E Mode Menu The M/E Mode menu can be used to select different M/E operating modes, including programmable clean feeds. The menu is accessed by touching (Figure 226). Mode Figure 226. M/E Mode Menu operating mode an M/E provides a main program output, a Normal preview output, and a totally clean feed output (no keys).
Page 329: Video Processing Menu
M/E Menus operating mode, available with the DoubleTake option, an M/E is Split divided into a primary and secondary partition. Each Split Mode M/E par- tition can be assigned resources (keyers and wipe generators) of that M/E. Each partition can be setup and controlled from the Main panel using the delegation buttons, and each partition has its own E-MEM level, permitting precise independent control of M/E partition effects.
Page 330: Proc Amp Controls
Section 3 — Menus Menu delegation panes (M/E, Bus) on the left permit selecting which bank and bus the menu’s video processing controls will be delegated to control. A central Function pane selects the video processing function. Controls for the selected function appear on the right. Soft knobs are available for con- tinuously variable parameters, and touching a soft knob data pad permits entry of exact values.
Page 331 M/E Menus CAUTION When adjusting Proc Amp controls, illegal colors could be generated. Illegal colors have equivalent red, green, and blue color components that take on negative values. Illegal colors can cause problems in picture monitors and other equipment downstream of the switcher. The amount of adjustment that can cause this problem depends on the original picture content.
Page 332: Proc Amp Lum Graphic Detailed Description
Section 3 — Menus The Proc Amp Chroma parameter group can modify the gain and offset for individual chroma components Cb and Cr. The range, nominal values, and units for these controls are shown in Table Table 11. Proc Amp Chroma Parameters Control Minimum Maximum...
Page 333: Pseudocolor Controls
M/E Menus For example, an increase in Cb offset moves the entire oval to the right. Labeled cross-hair graticules identify the Cb and Cr graph axes. A unity gain circle graticule is shown as a dotted line. Hue rotation is indicated with a straight radial line from the center of the oval.
Page 334 Section 3 — Menus uses the luminance component of the processed video Color Modulation signal to mix between two color mattes. Clip ( ) and gain ( Modulation Clip Mod- ) parameters can then be used to control a matte wash between ulation Gain the two color mattes, which are set up similarly to the Base Matte and Wash Matte on the matte generator menu (see...
Page 335 M/E Menus (Figure 230) operates like Color Modulation, but instead of Hue Modulation mixing between two color mattes, the modulating signal maps incoming luminance to matte hue. As the instantaneous luminance value of the incoming video changes from black to white, the instantaneous hue of the processed picture changes in hue angle.
Page 336 Section 3 — Menus Note Incoming levels above clip hi and below clip low will not affect the output color, making large areas of the screen a ﬁxed color. These controls should remain set to defaults unless the operator wants to restrict the range of incoming luminance levels that affect the output.
Page 337: Quantizer Controls
M/E Menus Quantizer Controls Touching in the Function panel displays the Quantizer menu Quantizer (Figure 232), which controls posterization and solarization. Posterization breaks smoothly changing luminance values into quantized levels. Solar- ization creates quantized chrominance levels. Figure 232. Quantizer Controls Separate on/off controls for in the Quantizer Mode Solarize...
Page 338: Pixelator Controls
Section 3 — Menus Pixelator Controls Touching in the Function panel displays the Pixelator menu Pixelator (Figure 233). The Pixelator produces a mosaic appearance. A representa- tion of the resulting mosaic effect is shown in the Pixelator Transfer Func- tion display. Figure 233.
Page 339: Mix Profile Display And Soft Knob Controls
M/E Menus User transitions are deﬁned using the User Transition menu and the Mattes menu. Controls on these menus adjust the appearance and timing of the Mix Through Video transition. User transitions are selected during produc- tion with the , and Next Transition buttons in each bank’s User 1 User 2...
Page 340: Intermediate Video Settings
Section 3 — Menus control determines at what point the initial video Initial Mix Ends at becomes completely invisible and the intermediate video is completely opaque. determines where the ﬁnal video begins to be visible Final Mix Starts at and intermediate video begins its transition to being invisible. The results of changes to these controls are reported in real-time in the Mix Proﬁle display.
Page 341: Matte Menu And Mix Through Video Transitions
M/E Menus Matte Menu and Mix Through Video Transitions Figure 235. Set Up White Matte To use a matte as intermediate video, select the button in the Base Matte Color – Source pane on the right of the menu. Use the matte controls to set the desired matte settings for the intermediate video.
Page 342: Source Select Menu
Section 3 — Menus Source Select Menu A Source Select menu is accessible from the M/E and Keyer menus. The Source Select menu is used to change sources in real-time from the Menu panel. This menu makes it possible to select sources that are not mapped to any source select buttons.
Page 343 M/E Menus Figure 237. Source Select Menu, Bkgd Layers Selected Sources are changed by choosing either the Key Layers or the Bkgd Layers, delegating the desired item (for example, M/E 1, Keyer 1 Fill, Near Side Source), and then selecting the source from the scrolling list on the right. You can tap the green area of the slider to display the next group of sources, and you can drag your ﬁnger on the slider handle to quickly scroll the list.
Page 344: Effects Send Menu
Section 3 — Menus Effects Send Menu The Effects Send menu is used to assign Transform Engines and DPMs to Keyers, and to turn keyer Effects Send on and off. The menu is accessed by touching (Figure 238). The Transform Engine menu also has Effects Send a button that provides access to this menu.
Page 345: Effects Send Status
M/E Menus Touching the button will toggle Effects Send on or off for the Efx Send Active delegated keyer. When toggled off, the Transform Engine or DPM Effect Send path channel becomes available for assignment to another keyer. Touching the button locks the assignment of that Transform Engine or Lock DPM to that keyer, and it will not be released when Effects Send is toggled...
Page 346 Section 3 — Menus from occurring by keeping a key off air for two ﬁelds when it is likely the wrong video would be displayed. Table 12 shows when the Kalypso system delays bringing an Effects Send key on air. Table 12.
Page 347: Color Corrector Menu
M/E Menus Color Corrector Menu RGB Color Correction is a software enabled option available on Kalypso HD and Duo systems. This feature converts the video signal on a particular video bus from color difference format to RGB (red, green, blue) color com- ponent format, applies separate offset, gain, and gamma to each RGB com- ponent, then converts from RGB back to color difference (Y, Cb, Cr) format.
Page 348 Section 3 — Menus The Color Corrector Transfer Function pane contains three data boxes which serve as delegators. Each of these data boxes contains the Gain, Lift, and Gamma values. The three oscilloscopes show the input to output transfer characteristics of each color component's processor. They do not show actual video.
Page 349 M/E Menus The value ranges are shown in Table Table 13. Color Corrector Value Ranges Control Minimum Maximum Nominal Units Gain Lift +100 Gamma -100 +100 Black +100 White +300 When one of the , or color component's data box is selected, Green Blue the knobs for...
Page 350 Section 3 — Menus ponent is not turned on, it is still possible to adjust its color correction values, but they are not applied to the video. When a component is not turned on, the scope trace for the component is made a darker shade of green to further indicate that the transfer function is not being applied to the video.
Page 351: Keyer Menus
Keyer Menus scope’s border will turn white to show that Red is attached to Blue. Changing from Blue to either Green or Red in the Color Corrector Transfer Function pane will cancel the attachment. Touching the button will reset all attached components. Reset to Unity Keyer Menus Keyer menu controls are organized into several subcategories., each with a...
Page 352 Section 3 — Menus button displays the processed black and white keyer cut Show Key signal on the preview monitor. This is useful for evaluating the quality of the key. button displays the key on the preview output over the Push to Preview program signal.
Page 353: Borderline Menu
Keyer Menus Borderline Menu The Keyer Borderline menu is used for controlling Borderline.This menu subcategory is accessed by touching (Figure 244). B-Line Figure 244. Borderline Menu The 4 x 4 grid of data pads on the left are used to delegate one of the 16 keyers.
Page 354: Keyer Priority Menu
Section 3 — Menus Keyer Priority Menu Touching the subcategory button takes you to the Keyer Priority Priority menu (Figure 245). Notice that delegations remain the same when you move from one menu to another with the Subcategory touch buttons. In the ﬁgures, M/E 1 Keyer 1 is delegated in all the Keyers menus, and remains so unless changed with a delegation touch pad or from the Main menu.
Page 355: Keyer Priority Menu, Partition Delegation
Keyer Menus Keyer Priority Menu, Partition Delegation delegation buttons are active when the Double- Primary Secondary Take option is installed. When the Keyer Priority Stack pane is delegated to one of a split M/E’s partitions, only the keyers in that partition can be selected for stack reordering.
Page 356: Source Select Menu
Section 3 — Menus Figure 247. Keyer Priority Menu, Current Priorities Changed See the separate Kalypso User Manual for more information about Double- Take split Mode M/E partitions. Source Select Menu A Source Select menu is accessible from the M/E and Keyer menus. The Source Select menu is used to change sources in real-time from the Menu panel (see Source Select Menu on page...
Page 357: Wipe Menus
Wipe Menus Wipe Menus The Wipe menus like the Keyer menus, have a delegation area at upper left, which in this case contains pattern touch pads for every wipe pattern gen- erator point of use. The currently selected shape is displayed on these touch pads.
Page 358 Section 3 — Menus In this menu you can pick the wipe pattern generator that will be used by a point of use, pick the direction of the transition wipe pattern, specify its border and softness, etc. For operating simplicity, you may decide to use the Complex wipe generators (C1 and C2) for main transitions, and the simpler Box and Keyer wipe pattern generators for the keyers.
Page 359: Primary And Secondary Partition Delegation
Wipe Menus Primary and Secondary Partition Delegation buttons allow menu delegation for transition wipe point of use attributes of an M/E split mode partition (available with the DoubleTake option). The button delegations only affect the transition wipe columns in the delegation matrix. The labels for these columns change , or ) when the delegation changes.
Page 360: Pattern Selection Menu
Section 3 — Menus Pattern Selection Menu Touching the touch pad in the C1 Generator window (the white area of the pattern will go blue) brings up the palette of wipe shapes available (Figure 250). Figure 250. Pattern Selection Menu Kalypso Reference Manual...
Page 361: Pattern Modifiers Menus
Wipe Menus Pattern Modiﬁers Menus The other touchpads in the C1 Generator window bring up other wipe pattern modiﬁers (Figure 251). Figure 251. Pattern Modiﬁers Menu, Kalypso Reference Manual...
Page 362: Wipe Pattern Number Guide
Section 3 — Menus Wipe Pattern Number Guide The following wipe patterns are speciﬁed by number for Kalypso system external editor control and for pattern selection on the 1-M/E Main panel. Table 14. Wipe Pattern Number and Name 0 Vertical 15 PENTAGON 30 H SPLIT 45 8 PT STAR –...
Page 363: Other Menus
Other Menus Other Menus As the Kalypso software is enhanced, additional menus, subcategories, and controls will become available (see the Kalypso Release Notes for the latest menu additions and changes). Once you understand the principles of Kalypso system menu organization and operation, you will be able to quickly learn these new menus and use them effectively for your work.
Page 364 Section 3 — Menus Kalypso Reference Manual...
Page 365: Section 4 - 1-M/E Panel Built In Menu
Section 1-M/E Panel Built In Menu Introduction The Kalypso 1-M/E Main panel has a built-in menu system, permitting operation without a separate Menu panel. This menu system uses an alpha- numeric text display, ﬁve soft knobs, ﬁve soft buttons, and dedicated cate- gory and navigation buttons that permit adjustment of various operational parameters.
Page 366: Menu/Joystick Delegate Subpanel
Section 4 — 1-M/E Panel Built In Menu Menu/Joystick Delegate Subpanel The Menu/Joystick Delegate subpanel (Figure 253) has a menu system and joystick that can be delegated to various control functions. The menu system and joystick is also used to adjust Source Name Display contrast. Figure 253.
Page 367: Valid Menu Delegation Combinations
Menu/Joystick Delegate Subpanel One selection in each of the top two rows is typically required to specify a speciﬁc point of use. For example, to delegate the menu to one of the 16 keyers, the operator speciﬁes an M/E and a keyer (e.g., M/E 1, Key 2). However, there are cases where the delegation is completely identiﬁed by the top row alone.
Page 368: Active Joystick Delegations
Section 4 — 1-M/E Panel Built In Menu Active Joystick Delegations The joystick delegation interacts with the menu delegation buttons. The main delegations described above for the built-in menu, combined with the menu category buttons provide the basis for joystick point of use delega- tion.
Page 369: Built-In Menu Layout And Generic Behavior
Menu/Joystick Delegate Subpanel Built-In Menu Layout and Generic Behavior The menu system consists of ﬁve soft knobs, a two line 40 character alpha- numeric readout display, ﬁve soft function buttons (labeled ), and dedicated buttons (Figure 254). More Figure 254. Built-In Menu System Menu Readout Width...
Page 370: Current Parameter Value Display
Section 4 — 1-M/E Panel Built In Menu In a few cases, the soft knob or function button label displays a parameter’s value in addition to the parameter name. In these cases, the legend is of the form label : value In most cases, no delegation information is displayed in the menu.
Page 371 Menu Organization Figure 255 shows the menu for a Box, KeyWipe, or Complex wipe gener- ator. Figure 255. Width Opacity Size Soft Border Dir:N Gen:KW GenAdj Soft ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ The ﬁve soft knobs for this menu adjust wipe point of use parameters. buttons turn the border and softness wipe point of use Border Soft...
Page 372: Wipe Direction Menu
Section 4 — 1-M/E Panel Built In Menu Wipe Direction Menu ↓ ↓ ↓ ↓ This menu sets the direction of the wipe. Press the button to access this Dir: menu. Figure 257. M/E 1 Transition Wipe 1 direction Normal Reverse are a radio group.
Page 373: Complex Wipe Generator Adjust Menus
Menu Organization Complex Wipe Generator Adjust Menus This set of menus adjusts the complex wipe generator (C1 or C2). Press the ↓ ↓ ↓ ↓ button to access this menu. Pressing the button accesses each GenAdj: More menu page in turn. Figure 261.
Page 374: Wipe Positioner Mode Menu
Section 4 — 1-M/E Panel Built In Menu knob adjusts the magnitude of the pattern split. The button Split Split turns pattern split on and off. H Freq H Amp V Freq , and V Amp adjust the frequency and amplitude of the horizontal and vertical modulation, respectively.
Page 375: Wipe Modulation Waveform Menu
Menu Organization Logic for this group of buttons includes two parameters: an on/off for the rotation and a mode selection. Pressing turns the rotation off or on. Rotate Pressing any other button sets the mode parameter. Making a selection returns to the parent menu. Wipe Modulation Waveform Menu This menu selects the mode for pattern modulation.
Page 376: Drop Shadow Menus
Section 4 — 1-M/E Panel Built In Menu adjusts the softness of all four edges equally. Soft The joystick adjusts position and size when delegated to the point of use. Making a selection returns to the parent menu. Drop Shadow Menus Drop Shadow Top Menu Press the button to access the Drop Shadow menus.
Page 377: Mask Menus
Menu Organization are a radio group that set the drop shadow crop mode. When Follow Follow is selected, the shadow crop follows the crop deﬁned for the main image. With Independent selected, the drop shadow crop can be adjusted independently from the controls in this menu. are a local radio group that assign parameters to the soft CropEdg CropSft...
Page 378: Keyer Menus
Section 4 — 1-M/E Panel Built In Menu Keyer Menus Press the delegation button to access these menus. Keyer Keyer Top Menus The Keyer top menu has three pages. cycles between them. More Figure 274. Clip Gain Size Opacity Typ:CK CK Adj B’Line AutoSet...
Page 379: Chroma Key Adjust Menus
Menu Organization adjust the associated parameters for the delegated keyer. These Clip Gain knobs appear in both pages of this menu. The Clip and Gain control labels change to if the delegated keyer type uses that control Clip Hi Clip Low methodology.
Page 380: Effect Send Select Menu
Section 4 — 1-M/E Panel Built In Menu Figure 281. Fringe Flare Sdw Den SdwClip SdwGain Fringe Flare Shadow AutoSet , and knobs adjust the associated keyer param- Clip Hi Clip Lo Size Opacity eters. (selectivity) and (color and luma suppression) Pri Hue Pri Sel PriCsup...
Page 381: Borderline Menu
Menu Organization Borderline Menu ↓ ↓ ↓ ↓ Press the button to access the Borderline Menu. B’Line Figure 284. Width Opacity Border Shadow Extrude Outline The soft knobs in this menu adjust the border line width, direction (8 steps) and opacity parameters. The ﬁve function buttons are a true radio group that sets the border line mode.
Page 382: Matte Menus
Section 4 — 1-M/E Panel Built In Menu Function buttons dim tally if they have not been speciﬁed. At the start, all buttons dim tally. They go out once they have been pressed to indicate they are no longer available (you can’t press the same keyer button a second time).
Page 383: Matte Point Of Use Delegation Menu
Menu Organization knobs controls the position or size of the wash. It is Offset Size labeled when the wash being adjusted is associated with a wipe Offset border (keyer preset pattern or transition wipe) and the generator chosen for the wash is the same as that chosen for the wipe itself. In this case the parameter controls the position relative to the center of the border allowing the wash to track the pattern size.
Page 384: Wash Generator Select Menu
Section 4 — 1-M/E Panel Built In Menu Wash Generator Select Menu This menu selects the generator used as the source for a wash point of use. ↓ ↓ ↓ ↓ Press the button to access this menu. It is similar to the generator Gen: selection menus for mattes and wipes.
Page 385: Effect Edit Menus
Effect Edit Menus Effect Edit Menus The Effect Edit menus are accessed by pressing the category button. Eff Edit Functions in these menus interact with the E-MEM subpanel. Effect editing operations are applied to delegated E-MEM levels which are set using the Master E-MEM enable buttons.
Page 386 Section 4 — 1-M/E Panel Built In Menu The ﬁrst two buttons in the ﬁrst page perform modify all operations either as a Relative modiﬁcation or as an Absolute modiﬁcation. The soft knobs above these buttons have no function and their label space is used to help label the buttons.
Page 387 Index Symbols 2-M/E Main panel models 300 Mode 112, +/- button 32-Crosspoint Remote Aux panel 4-M/E Kalypso Classic system Numerics options standard features 1-M/E Main panel 34, 154, 4-M/E Kalypso HD system and Resource Sharing options Bank Delegate subpanel standard features DPOP 156, 4-M/E Kalypso system...
Page 388 Index Auto Load button Auto Recall Still Store Auto Run 109, Auto Setup Auto Recall button Auto Start Auto Run button 109, Base Fill Auto Setup button behavior Auto Start button Borderline Automatic subpanel delegation C1-2 Wipe Aux bus current source displays on panel Clear Entry Clear Wk Bfr Aux Bus menu...
Page 389 Index Keyer Wipe Rest-WrkBfr keypad prefix KF Dur KF Time Knob Set Router Asgn Last Deleg on Keyers subpanel 109, Last Menu Sec (secondary) Level Start Time see also touch button Lever Enable Select All Levels Loc 3D Locate Axis Set Deleg Lock/Learn Shadw...
Page 390 Index cache button behavior Still Store Local Aux Menu capture controls options CD-ROM see also control surface Menu panel control surface CD-ROM drive overview center of screen overlay user preferences Chr button control surface assignment of node Chroma Key menu controlling devices clean feed with playback capability...
Page 391 Index delegation display information Auto Deleg and Last Deleg buttons M/E Status automatic subpanel documentation data group in Menu panel Kalypso system Double Press Open (DPOP) button documentation online explained double press button behavior Force Mask button Double Press Prefs menu Inhibit Mask button DoubleTake option Joystick...
Page 392 Index filled keyframe memory including a macro facility configuration example keypad FAQ database level assignments lock register fence controls Master readout Still Store Master subpanel field dominance operating modes 112, any field readout display even field sequence odd field subpanel File Operations menu E-MEM Prefs menu Fixed Lin button...
Page 393 Index HD Transform Engine difference from Classic Joystick hold button delegation Hold button joystick delegation hold down modifier button behavior 1-M/E Main panel Hold Inputs button Hold to Preview via Keyer delegation button Home button Kalypso Classic system Home menu Kalypso Classic Video Processor hot swapping modules described and illustrated...
Page 394 Index Keyer Mode menu levels 160, delegating for editing Keyer priority enabling partition delegation enabling all Keyer Priority button Lever Arm Current Prior out of sync Keyer Priority menu Keyer status Transition transition progress bar keyer transition control Lever Enable button Keyer Wipe button Lighting menu Keyers subpanel...
Page 395 Index module assignment 1-M/E menu system performing transitions Main panel Preset Black transition button 1-M/E described and illustrated source select bus delegation 2-M/E described and illustrated source selection buttons 4-M/E described and illustrated split mode component access 24, 25, Status display information connections Status display overview delegation use...
Page 396 Index memory usage bar graph Port & Device Definition Preview Prefs menu Profiles Acquire Resources Remote Aux Panel Setup 216, Aux Bus R-MEM Aux Deleg mapping Router Interface Setup Borderline Router Select Bus Linking Save-Load (Daily Setups) Button Mapping Save-Load (E-MEM) Chroma Key Save-Load (Eng Setups) Clip Hi-Lo Prefs...
Page 397 Index Enhanced Momentary delegation installation and orientation momentary delegation Menu Access touch button monitor menu category selection More button menu screen multi-suite operating mode Menu Selection buttons Mode Selection touch buttons numeric keypad original Next Event button Parameter Control area power No Border button power supply...
Page 398 Index Pre Attach button prefix button group panel Master E-MEM 1-M/E Main prefix buttons on keypad 2-M/E Main Preset Black button 4-M/E Main Prev Event button Enhanced Menu Local Aux preview Menu overlays original Menu Preview Prefs menu panel options preview signal selection Parameter Control area Preview subpanel...
Page 399 Index E-MEM Remote Aux panel assignment Machine Control subpanel Rest WrkBfr button Rec (Macro) button Rev button recalling effect in same bank Rew button record RGB color correction Macro R-MEM menu Still Store Rot button record macro Router Asgn button using Macro menu Router Interface Setup menu re-entry...
Page 400 Index settings, transferring from one M/E to another source override Source Patch menu Shadw button source select button shift preferences tally when opposite shift pref setting Source Select menu 342, Shift Preferences menu source select modifier button Shift source select modifier button Alt Buses Key Split Shot Box Option...
Page 401 Index loop controls Main panel power menu playback controls Sync Ref playback edit controls Sync/Timing menu position control system control position crop control overview record System menu save Still Store button Still Store Cache menu Still Store Create Edit menu tally Still Store Playback menu button...
Page 402 Index user preferences Transform Engine User Transition menu Advanced Effects option 298, Util 1 button Blur button default crop Util 1 HD difference from Classic Util 2 button Kurl option Transform Engine Interpolation menu Transform Engine menu Transform subpanel Var Play Speed button transition variable speed playback control elements...
Page 403 Index web site software download wipe partition delegation Wipe C 1-2 button Wipe menus 1-M/E Main panel Wipe Pattern Mask Knob parameters Wipe Pattern Modifiers menu wipe pattern number guide Wipe Pattern Selection menu wipe patterns Wipe Point of Use menu work buffer buttons Clear Wk Bfr Zip drive...
Page 404 Index Kalypso Reference Manual...

This manual is also suitable for:

Grass valley kalypso classic Grass valley kalypso hdGrass valley kalypso duo

THOMSON Grass Valley Kalypso Reference Manual

Preface

Section 1 - System Overview

Section 2 - Control Panels

Section 3 - Menus

Quick Links

Related Manuals for THOMSON Grass Valley Kalypso

Summary of Contents for THOMSON Grass Valley Kalypso
