- Page 1 TRITON routing switcher Digital Audio Router 8x8 – 110 Ohm With Local Control Panel Product model no. TTN-BES-0808CP/110 INSTALLATION MANUAL MANUAL PART NO. 04-049754-002 Rev. 2 FEBRUARY 28, 2003 the most watched worldwide...
- Page 2 FRANCE Nevada City, CA 95959-7900 Copyright 2003 Thomson Broadcast and Media Solutions, Inc. All rights reserved. Grass Valley, Jupiter, and Triton are trademarks of Thomson. Specifications subject to change without notice. For customer service, please call (800) 547-8949. For comments or questions concerning this manual, please contact: Technical Publications Department, P.O.
-
Page 3: Table Of Contents
Contents Electromagnetic Radiation Notice Hardware Warranty and Software License Parts and Service Revision history General Specifications Connection drawing Power connection Connecting the BES-0808CP/110 to your PC Selection of router level Pin-out of RS-232 connector Maximum cable length NCB connection Several routers in one system Connecting control panels Pin-out and cable type 4.3.1... - Page 4 7.2.2 Example: Several units connected by NCB RS232 Commands 7.5.1 Audio crosspoint set 7.5.2 Audio crosspoint set acknowledge 7.5.3 Video crosspoint set 7.5.4 Video crosspoint set acknowledge 7.5.5 Crosspoint status request Control panel operation Front panel drawing PANEL ENABLE button V/A TOGGLE button Operating crosspoints TAKE function...
-
Page 5: Electromagnetic Radiation Notice
88 - 216 216 - 1000 The policy of Thomson is one of continual development and improvement. For that reason Thomson uses components and manufacturing techniques that provide the current state-of-the-art suppression of electromagnetic radiation. This equipment, in production before October 1, 1981, has not been tested to the above listed measurements. However, equipment such as this delivered after October 1, 1983 will have the measurements on record at the factory. -
Page 6: Hardware Warranty And Software License
Please contact your local Thomson representative for hardware warranty and software license information. Parts and Service Thomson maintains a full stock of replacement parts available for immediate shipment. NORTH AMERICA PARTS AND SERVICE Please call toll-free 1-800-547-8949. You will be switched automatically to the parts and service representative nearest you. -
Page 7: Revision History
Revision history Current revision of this document is the uppermost in the table below. Revision Replaces Date Change Description 28/02/03 Updated with new Thomson/GVG design. 30/01/01 Corrected error in baud rate setting 10/10/00 Initial Revision... -
Page 9: General
BES-0808CP/110 Rev. 2 1 General The BES-0808CP/110 is an 8x8 AES/EBU digital audio router with balanced in- and outputs and transformer coupling. This state of the art router provides high performance circuits in SMD technology for maximum system performance. The BES-0808CP/110 is designed for all demanding routing tasks in digital studio and broadcast environments. -
Page 10: Power Connection
BES-0808CP/110 can also be delivered with DC ±5V / 30W, which may be fed by a 36 – 72 VDC mains power source. A Frame mounted power supply solution is also available. Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley for this information. -
Page 11: Ncb Connection
0808CP/110 router to other Triton devices, with RJ45 connectors, an RJ45 to 5-pin DIN interface is necessary. This converter can be ordered from Thomson Grass Valley. The NCB system allows connection of up to 16 routers with different levels on the same bus. Control panels dedicated to work with a specific router must be configured to the same level as the router. -
Page 12: Pin-Out And Cable Type
BES-0808CP/110 Rev. 2 Pin-out and cable type 4.3.1 RJ45 connectors On some Triton devices, the NCB cable can be connected to RJ-45 connectors. The following pin-out is used: Pin 1 = Not Connected Pin 2 = Not Connected Pin 3 = Not Connected Pin 4 = data Pin 5 = data Pin 6 = Not Connected... -
Page 13: Rj45 To 5-Pin Din Converter
BES-0808CP/110 Rev. 2 4.3.3 RJ45 to 5-pin DIN converter In configurations that include both devices with RJ45 connectors, and devices with 5-pin DIN connectors, an RJ45 to 5-pin DIN converter may be used to complete the control loop. This converter holds both connector types, and may work both ways, thus from RJ45 to 5-pin DIN, as well as from 5-pin DIN to RJ45. - Page 14 BES-0808CP/110 Rev. 2 o Universal Control Panel to control all devices above, with user configurable default level. Pay attention to the figure below, in order to achieve full controllability of all devices in the loop. • Triton - RCS Complete the Control loop, by connecting all Control bus connections to all Triton devices, before •...
-
Page 15: Router Configuration
BES-0808CP/110 Rev. 2 5 Router configuration Router level Switch 1 - 4 on the configuration switch set the router’s level for communication with the Triton Router Control System, and other units in the NCB system. The panels on the NCB dedicated to operate with the router must be configured to the same level as that router. -
Page 16: Router Mode
BES-0808CP/110 Rev. 2 Router mode The BES-0808CP/110 router allows switching in different modes. You can choose among: AES/EBU 1 Channel AES/EBU 2 Channel AES/EBU 4 Channel Switch 5 - 6 on the configuration switch set the router’s mode. The Triton Router Control System software must be configured according to the mode chosen on the router. -
Page 17: Power Up Mode
BES-0808CP/110 Rev. 2 Ch2 Signal Input Ch2 Signal Output AES/EBU 4 Channel Ch1 Signal Input Ch1 Signal Output Ch2 Signal Input Ch2 Signal Output Ch3 Signal Input Ch3 Signal Output Ch4 Signal Input Ch4 Signal Output Power up mode Switch 8 on the configuration switch defines the power up mode. The BES-0808CP/110 router provides two modes for powering up the system. -
Page 18: Programming Of Restrictions
BES-0808CP/110 Rev. 2 Programming of restrictions If the user enables the Restrictions option, the previously programmed restrictions will be fetched from the on-board memory during power-up. New restrictions may be programmed by putting the panel in “Programming mode”. This is done, starting from Panel Disable state, by pushing and holding “V/A toggle”, “Take On/Off”... -
Page 19: Control And Connection Of Triton Systems, Interface Protocol
BES-0808CP/110 Rev. 2 7 Control and connection of Triton systems, interface protocol Important notes regarding the Triton Control Protocol 7.1.1 Binary Code The strings shown on the next pages are in binary coded format. Please be aware of the fact that any terminal program you may use to control a Triton unit from a PC must be able to generate hexadecimal characters. -
Page 20: Example: Several Units Connected By Ncb
BES-0808CP/110 Rev. 2 7.2.2 Example: Several units connected by NCB Messages sent to the RS232 of a single unit will be returned once no matter what address or input/output number the message has, unless it is a matrix which recognizes one of the conditions a) or b) above. If none of the cases a) or b) is fulfilled the message will also be transmitted on the NCB. -
Page 21: Commands
BES-0808CP/110 Rev. 2 Commands 7.5.1 Audio crosspoint set Only for use with Audio routers. Command for setting of crosspoints: 1001nnnn 0kkk kkkk 0vvv vvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128... -
Page 22: Video Crosspoint Set Acknowledge
BES-0808CP/110 Rev. 2 7.5.4 Video crosspoint set acknowledge Only for use with Video routers. Command for acknowledging setting of crosspoints: 1011nnnn 0kkkkkkk 0vvvvvvv - nnnn is the matrix address from 0 up to 15. - kkk kkkk is the output which shall be controlled. kkk kkkk = output number 0 = output 1 127 = output 128... -
Page 23: Control Panel Operation
BES-0808CP/110 Rev. 2 8 Control panel operation The built-in panel in the BES-0808CP/110 offers 8 input select buttons on the top row. The input buttons are equipped with two LED indicators for displaying both video and audio status during breakaway operations.
