Preface About This Manual This Kalypso Reference Manual is designed for operators of Kalypso systems. This manual is for both Kalypso Classic and Kalypso HD/Duo systems. Standard Documentation Set The standard Kalypso documentation set consists of a: • User Manual, •...
Page 16: Other Documentation
Preface Other Documentation The Kalypso Machine Control Interfaces Installation Instructions, provided with the KAL-IF-PROFILE and KAL-IF-VTR options, contains information about installing and configuring external machine control software. The Kalypso Emergency Bypass Option Instruction Manual, shipped with the Emergency Bypass option hardware, contains information about installing, configuring, and operating this option.
Page 17: Section 1 - System Overview
Section System Overview Introduction The Kalypso Video Production Center is much more than a switcher. The Kalypso system not only features powerful digital video switching, mixing, and keying with E-MEM, but also provides integrated control of other production devices (e.g., facility routers, external effects systems, DDRs).
Page 18: 4-M/E Kalypso Classic Options
Section 1 — System Overview • Source name display standard on PGM PST, • Effects Send (internal and external) available on every key bus, • Unlimited re-entry, • Look ahead and other preview modes, • Touch screen Menu panel, • Local Aux panel, with source name display standard, •...
Page 19: 2-M/E Kalypso Classic Standard Features
Introduction • SuperStill, adds advanced Still Store capabilities with two inputs, eight outputs, animation, disk storage, and includes the Still Store Loader application for image transfer to and from PCs, • KlipCache (for SuperStill), increases cache storage capacity to about 1800 frames, •...
Page 20: Kalypso Hd Features
Section 1 — System Overview Kalypso HD Features 4-M/E Kalypso HD Standard Features • 720p/59.94 and 60, • 1080i/29.97, 30, and 25, • 1080sf/24, 25, 30 • 15 auto-timed inputs (configured as single inputs or video/key pairs), • 48 timed outputs (configured as single outputs or video/key pairs), •...
Page 21: 2-M/E Kalypso Hd System Standard Features
Introduction • Chromatte Advanced Dual Chroma Keyer, adds two floating chroma keyers, able to be assigned to any keyer in the system at any time. Up to eight dual chroma keyers (16 total) can be installed, • FlexiKey Programmable Clean Feed, permits two independent program streams, using key substitution, through one or more M/Es, •...
Page 22: 2-M/E Kalypso Hd System Options
Section 1 — System Overview 2-M/E Kalypso HD System Options The 2-M/E Kalypso system has the same options as the 4-M/E Kalypso system, with the following differences: • 2 - 3 M/E upgrade (2-M/E to 3-M/E, or 3-M/E to 4-M/E system), and •...
Page 23: Control Surface
System Components Figure 1. 4-M/E Kalypso System Components Menu Panel Removable Local Aux Panel Media Video Processor Frame Drives Bypass Active Emergency Bypass Assign 4-M/E Select Source Main Panel Video Processor Power Supply Frame Control Surface Control Surface The modular design of Kalypso control panels provides flexibility for mounting component panels in various environments, and allows the addition of specialized accessory control panels.
Page 24 Section 1 — System Overview Figure 2. Kalypso Control Surface Menu Panel Local Aux Panel 4-M/E Main Panel Zip Drive Local Aux Panel Menu Panel Integrated into 2-M/E Main Panel 2-M/E Main Panel Zip Drive 1-M/E Main Panel Menu Panel (option) Zip Drive (customer supplied option)
Page 25: 4-M/E Kalypso System
System Components 4-M/E Kalypso System 4-M/E Main Panel The Main panel provides real time button, knob, and lever arm control of the Kalypso system. The panel is organized into subpanels that contain groups of related controls (Figure Figure 3. Kalypso 4-M/E Main Panel Source M/E Source Name M/E Keyer...
Page 26 Section 1 — System Overview Two models of 4-M/E Main panel exist. Late model designs shipping at the time of this manual’s publication have the connections shown in Figure This model Main panel works with the Enhanced Menu panel. Figure 4. Late Model 4-M/E Main Panel, Rear View AC In Panel Panel...
Page 27 System Components Earlier model 4-M/E Main panels have additional connectors (Figure used with the original Kalypso Menu panel. If this model is modified for Enhanced Menu panel operation, the indicated connectors are inactive. Figure 6. Early Model 4-M/E Main Panel, Rear View AC In SCSI* Mouse*...
Page 28: Menu Panel
Section 1 — System Overview The actual type and location of equipment installed in early model Main panels varies, depending on date of manufacture. Some earlier designs used Hard Disk drives with the Real Time (RT) processor, and some used Disk on Chip hardware.
Page 29 System Components Ports located on the rear of the Menu panel (Figure 9) provide connections to the Main panel, Video Processor frame, an external Zip drive, a PS/2 mouse and keyboard, and other devices. Figure 9. Enhanced Menu Panel, Bottom View of Connectors Alternative Four Hole Pattern for = Hole pair for Adaptable Mounting Bracket (5) Adjustable Freestanding Console Bracket...
Page 30 Section 1 — System Overview The Menu System Processor for these models resides in the Main panel, and so extra connections are required for operation (Figure 11). Figure 11. Original Menu Panel, Bottom View of Connectors Bottom View Side View 8.4 in.
Page 31: Local Aux Panel
System Components Local Aux Panel The Local Aux panel provides control of the Kalypso System Aux buses, Still Store source selection, some switched preview, and also supports Router source selection and Emergency Bypass option operation (Figure 13). Figure 13. Kalypso Local Aux Panel Source Select Emergency Bypass (4) Bus #1...
Page 32: Removable Media Drives
Section 1 — System Overview The Local Aux panel is generally installed directly above the left side of the Main panel so the Source Select buttons are aligned, though it can be mounted in any convenient location. If the Emergency Bypass option is installed, a redundant power supply for the Local Aux panel is available to ensure bypass operation even if the Main panel loses power.
Page 33 System Components Figure 15. Kalypso 2-M/E Main Panel Bank Delegation ----- M/E Modifiers ----- Subpanel Keyers, Masks Mattes, Local Aux Aux Bus M/E Status Macros Subpanels Copy/Swap Subpanel Status Display Displays (2) Subpanel Subpanels Source Name Displays (3) Machine Control Preview M/E Keyer Transition...
Page 34 Section 1 — System Overview Late model Kalypso 2-M/E Main panels have connectors at the rear that are identical to those on a late model 4-M/E system, except there are addi- tional Local Aux panel connections (Figure 16). Figure 16. Late Model 2-M/E Main Panel, Rear View Emergency Diagnostic Emergency...
Page 35 System Components Early model 2-M/E Main panel rear connectors are shown in Figure 18. If modified for Enhanced Menu panel operation the indicated connectors are inactive. Figure 18. Early Model 2-M/E Main Panel, Rear View Emergency Diagnostic Emergency Redundant Bypass Mixer Bypass Router DC Power In Menu Panel...
Page 36: 1-M/E Main Panel
Section 1 — System Overview 1-M/E Main Panel A 1-M/E Main panel is intended to act as an accessory control surface for a 4-M/E or 2-M/E Kalypso system, not as the primary system control point. A 1-M/E Main panel can be used for pre- or post-production, or be used during live production to permit another operator to assist the TD.
Page 37 System Components The 1-M/E Main panel has a reset button on the rear and one inside the lever arm slot, to permit easy reset when installed in a console. Figure 21. Kalypso 1-M/E Main Panel, Rear View LINE 1 SATELLITE DIAGNOSTIC RESET COM 1...
Page 38: Control Panel Options
Section 1 — System Overview Control Panel Options Remote Aux Panels Remote Aux panels provide control of selected Kalypso Aux buses from a remote location. Three 24-Crosspoint and two 32-Crosspoint Remote Aux panels are available for 4-M/E and 2-M/E systems. Any combination of these aux panels may be used in a Kalypso system.
Page 39 System Components All three 24-Crosspoint panels have the same rear panel layout (Figure 25). Figure 25. 24-Crosspoint Remote Aux Panel Rear Panel Test Mode Panel Address and Force High Tally Communications Bus DC Power Joystick Override FORCE HIGH TALLY TEST PANEL DC POWER MODE...
Page 40: Shot Box Option
Section 1 — System Overview Both 32-Crosspoint Panels have the same rear panel layout (Figure 29). These panels have a built-in power supply and use a standard removable AC power cable. Figure 29. 32-Crosspoint Remote Aux Panel Rear View AC Power Camera Joystick Override CAMERA JOYSTICK OVERRIDE...
Page 41: Kalypso Classic Video Processor Frame
System Components Kalypso Classic Video Processor Frame 4-M/E Kalypso Classic Video Processor Frame The Kalypso Classic Video Processor frame houses most of the system elec- tronics, with slots in the front and rear that hold individual modules. The front bay holds system control, video routing, and signal processing mod- ules.
Page 42 Section 1 — System Overview The rear bay holds input and output modules and provides reference and system control connections. A fully loaded system is shown in Figure Some of the modules illustrated are optional and may not be included in your Kalypso system.
Page 43: 2-M/E Kalypso Classic Video Processor Frame
System Components 2-M/E Kalypso Classic Video Processor Frame The 2-M/E Kalypso Classic system uses the same frame hardware as the 4-M/E Kalypso system, except some slots are not filled in the standard con- figuration. Because only two M/Es are standard (M/E 1 and PGM PST), only two M/E modules and two crosspoint modules are provided (Figure 33).
Page 44 Section 1 — System Overview The standard 2-M/E Kalypso system includes one Input module and the Effects Send module to support video inputs and outputs (Figure 34). Up to four additional Input and Output modules can be installed. Slot B16 (labeled on the frame as Output 1, 1-8) is not available for use on a standard 2-M/E Kalypso system.
Page 45: Kalypso Classic M/E Module Control Assignments
System Components Kalypso Classic M/E Module Control Assignments Table 1 shows how the Main panel banks are assigned to M/E modules in a factory configured Kalypso Classic Video Processor frame. Table 1. Banks and M/E Module Locations Video Processor Frame Slot Bank 4-M/E 2-M/E...
Page 46: Kalypso Hd/Duo Video Processor Frame
Section 1 — System Overview Kalypso HD/Duo Video Processor Frame The Kalypso HD Video Processor frame houses most of the system elec- tronic. Slots in the front hold system control, video routing, and signal pro- cessing modules. A fully loaded system is shown in Figure 31.
Page 47 System Components The rear of the Video Processor frame has input and output connectors and provides reference and system control connections (Figure 32). Figure 36. Kalypso Video Processor Frame, Rear View Air Exhaust Timecode Reader Input 15 Standard Inputs SD Reference (with up to 5 Looping Input 15 Input options...
Page 48: Kalypso Video Processor Power Supply
Section 1 — System Overview Kalypso Video Processor Power Supply A separate Video Processor Power Supply provides power to the Kalypso Video Processor. The same type of power supply is used by Kalypso Classic and Kalypso HD systems. The Video Processor Power Supply frame holds up to three Video Processor Power Supply modules (Figure 37).
Page 49: Video Processor Frame Options
System Components Video Processor Frame Options Still Store Option The Kalypso Still Store is used to grab, save, and display images. Still Store features include: • Instant access to non-volatile stills (fixed names “Still 1”, “Still 2”, etc.), • Up to 1800 full frame images, •...
Page 50 Section 1 — System Overview available on each M/E for easy control of complicated transforms. The Kalypso system uses its Effects Send feature to supply translation and transformation capabilities to any keyer on any M/E. Transform Engine features include: • Source and Target space selection, •...
Page 51: Kalypso Facility Example
Kalypso Facility Example Kalypso Facility Example A simplified diagram of a small live studio is shown in Figure 39. In this facility the Kalypso Video Production Center has control of a portion of the facility router for pre-selecting various sources into the switcher. The camera control operator is able to remotely control a Kalypso Aux bus for selecting camera views to shade.
Page 52: Functional Overview
Section 1 — System Overview Functional Overview Kalypso System Control System control for the Kalypso Video Production Center is designed for flexibility and simplicity. Ethernet and other standard data interfaces are used for system component interconnections. Multiple hard disks are included to permit storage of large numbers of data files.
Page 53 Functional Overview Late model 2-M/E Kalypso system control is the same as the 4-M/E Kalypso system, except the Local Aux panel is built into the 2-M/E Main panel (Figure 41). Figure 41. Late Model 2-M/E Kalypso Control Kalypso Video Processor Frame Still Store LAN To networked image sources...
Page 54 Section 1 — System Overview Early model Kalypso system control is shown in Figure 42 (4-M/E system) Figure 43 (2-M/E system). Figure 42. Early Model 4-M/E Kalypso Control Kalypso Video Processor Frame Still Store LAN To networked image sources Tally (Relay) 16 GPI In 16 GPI Out Shot Box...
Page 55: Video Signal Flow
Functional Overview Figure 43. Early Model 2-M/E Kalypso Control. Kalypso Video Processor Frame Still Store LAN To networked image sources Tally (Relay) 16 GPI In 16 GPI Out Shot Box 8 Serial 2 Synchronous Serial Boot Facility LAN Config BU Ethernet Flash Hard...
Page 56: Kalypso Classic System Signal Flow
Section 1 — System Overview Kalypso Classic System Signal Flow Figure 44. Simplified Kalypso Classic Video Flow Diagram (part 1) Video or Key Signals Deserializer and Reclock M/E 1 Program A Serializer M/E 1 Program B M/E 1 Program C M/E 1 Program D M/E 1 Preview A M/E 1 Preview 2...
Page 57 Functional Overview Figure 45. Simplified Kalypso Classic Video Flow Diagram (part 2) Effects Send Module Standard 8 Dual Outputs 41 - 48 2 of 8 Channels Shown Channels Shown in Output Mode Switches Up for Effects Send Mode Output Mode with No Shape/Unshape: Input A = Video or Key Input B = Video or Key To/From All...
Page 58: Kalypso Hd System Signal Flow
Section 1 — System Overview Kalypso HD System Signal Flow Figure 46. Simplified Kalypso HD Video Flow Diagram Video or Input Crosspoint PGM/PST - Output Key Signals Variable Delay Deserializer and Reclock Variable Delay Serializer Variable Delay Variable Delay Variable Delay 12 Dual Variable Delay Outputs Per...
Page 59: Section 2 - Control Panels
Section Control Panels Introduction A basic Kalypso system is equipped with a Main panel, a Local Aux panel, a Menu panel, and removable media drives. These separate control panel components make up a Kalypso control surface. Interactions occur between the components of the control surface. For example, changing controls on the Main panel can change the status of soft buttons on the Menu panel, and vice versa.
Page 60: Alternate Action
Section 2 — Control Panels On some single press buttons, pressing the button again while the action is being performed (the button will be lit) halts the action. The Auto Trans button is an example of a single press button that can be halted. Alternate Action Some system functions have two states, and are turned on and off by a single alternate action button.
Page 61: Double Press
Introduction ling keyer opacity to controlling border opacity. A hold down latch param- eter exists in user configuration that permits single handed operation by extending the hold down behavior for a user-specified period of time after the button is released. Hold down buttons that do not light during normal use will go high tally when a hold down is active.
Page 62: Dialogs And Prompting
Section 2 — Control Panels Flashing tally is reserved for situations where the operator needs to be aware that some expected panel behavior has been changed (see Dialogs and Prompting below). Tallys will be off for buttons whose functions are off or not available. If a disabled button is pressed a warning notification occurs (audible beep and/or message on the Menu panel).
Page 63 Introduction matte generators, making dedicated controls for each object unfeasible. Delegation connects a group of controls, typically a subpanel, to a partic- ular object. Delegation can greatly reduce confusion over which button to press or which knob to turn to control each object in the system. See the separate Kalypso User Manual for more information about delegation.
Page 64 Section 2 — Control Panels • DPOP (Double Press Open) and SPOP (Single Press Open) Menu dele- gation, in which double or single pressing a button brings up the appropriate menu on the Menu panel. Active DPOP and SPOP buttons and their menus are listed in Table 3 Table 3.
Page 65: Time Value Entry
Introduction • Keypad delegation. Besides being used to recall effects, the E-MEM and Master E-MEM keypads are also used to enter numeric values. Pressing a numeric prefix button delegates the keypad to numeric entry for that function. The numeric prefix buttons and controlled numeric functions are listed in Table Table 4.
Page 66: 4-M/E Main Panel
Section 2 — Control Panels You can actually enter any combination of seconds, frames and fields. The Kalypso system will do the conversion and display the result in seconds, frame, field format. Decimal values for other non-time parameters are also input on the Master E-MEM subpanel with the numeric keys, the Undo/•...
Page 67: Source Selection
4-M/E Main Panel Source Selection Sources are selected in an M/E. Each M/E has four rows of interlocked buttons, two rows for key source selection and two rows for background source selection. Each row contains 32 source buttons and has three re- entry buttons from the other M/Es (Figure 48 Figure...
Page 68 Section 2 — Control Panels Only one source at a time can be selected for each bus on the row of inter- locked buttons. The left source will be selected if more than one button on a row is pressed simultaneously. Holding down a source select button when recalling an E-MEM register performs a source override.
Page 69: Source Button Tally
4-M/E Main Panel A Keyer bus can be delegated for Macro operations, and the re-entry buttons for that bus can be used as alternates to Macro features (see Macros Subpanel on page 130). Source Button Tally Source buttons go high tally when selected and on-air, and low tally when selected but not on-air.
Page 70: Special Function Buttons
Section 2 — Control Panels Also, the button tally indicators in the Transition subpanel and the transi- tion pattern shape displayed in the M/E Status display reports information for only the Primary partition. See the separate Kalypso User Manual for more information about Double- Take split Mode M/E partitions.
Page 71: Source Select Modifier Buttons
4-M/E Main Panel Figure 50. Split Source Name Displays Shifted Name Test Net E Cam 1 Cam 2 Cam 3 CG 1 CG 2 Net W Unshifted Name When delegated to Macro operations, the source name displays show the names of the macros associated with each button (see Macro Delegation page 131) Source Select Modiﬁer Buttons...
Page 72 Section 2 — Control Panels Alt Buses Alt Buses source select modifier button is used to delegate a button row to its alternative bus. Each key and background source buttons on each M/E can control an alternate bus (Table Table 5. Direct and Alternate Buses Direct Alternate Key 1...
Page 73: M/E Status Displays
4-M/E Main Panel the bus (aux buses or buses with Effects Send active). When a Near Side button is not held down, a change in source selection is applied to Far Side both the near and far sides. Inactive Buttons Key Add Key Drop buttons on the main panel are inactive in Kalypso...
Page 74: M/E Status Information
Section 2 — Control Panels M/E Status Information The M/E Status Display shows information for all four keyers (K1 - K4) and all four background buses (A, B, U 1 and U 2). The following informa- tion is displayed for each keyer and background: •...
Page 75: Lever Arm Progress Bar
4-M/E Main Panel Lever Arm Progress Bar The lever arm progress bar shows the current location of a transition, as a percent of completion. It also shows the location of the lever arm and whether it is out of sync with the transition. Transition progress is reported with a vertical transition bar with thin lines at the limits.
Page 76: Transition Subpanels
Section 2 — Control Panels Transition Subpanels Each M/E on the Kalypso system, including PGM PST, is functionally identical to each other and provides complete mix, wipe, and keying capa- bilities. Each M/E has a transition subpanel used to control these compos- iting operations (Figure 53).
Page 77: Main Transition Controls
4-M/E Main Panel Main Transition Controls The main transition controls are used to select the signal elements that will be involved in the transition, define the type of transition, and perform the transition. Transition Elements The upper group of buttons selects the elements that will change during the next transition.
Page 78 Section 2 — Control Panels Wipe 1 Wipe 2 buttons select one of two user adjustable wipe transi- tions. Each predefined wipe can use either the Complex A or Complex B wipe generator or one of the Utility buses as the wipe shape. Wipe pattern selections are made in the Wipe menu, which these buttons DPOP to.
Page 79 4-M/E Main Panel when it has been selected. The Preset Black button is unique, in that its func- tion is activated on the release of its button press, not on first press as are all other buttons. This is necessary to support fade to black. Two successive transition commands ( button, button, or...
Page 80: Keyer Transition Controls
Section 2 — Control Panels Keyer Transition Controls Each keyer has its own cut and mix transition system, separate from the main M/E transition mechanism. Individually numbered Key 1-4 Cut button pairs located to the right of the control Key 1-4 Mix Transition Lever Arm these transitions.
Page 81: Other Transition Control Interactions
4-M/E Main Panel When a Trans Rate button is pressed, the Auto Trans and the four Key 1-4 Mix buttons will flash and the E-MEM readout prompts for the rate to be set. Pressing one of the flashing buttons delegates the E MEM keypad to that transition rate and its current rate appears on the readout.
Page 82: M/E Keyer Delegation Buttons
Section 2 — Control Panels M/E Keyer Delegation Buttons The M/E Keyer delegation buttons allow the operator to make quick and sure changes to any desired keyer. These buttons can also be used to momentarily delegate a key bus for source selection, and can be used for hold to preview.
Page 83: Multiple Keyer Delegations
4-M/E Main Panel Multiple Keyer Delegations The M/E Keyer Delegation buttons can delegate the Keyers, Mattes, Masks, and/or the Transform subpanels to more than one keyer. If a sub- panel’s controls have been delegated to multiple keyers, the subpanel del- egation buttons will go off, to indicate a single keyer is not being controlled by that subpanel.
Page 84: M/E Modifiers
Section 2 — Control Panels M/E Modiﬁers The M/E Modifiers area is divided into four subpanels corresponding to Keyers, Masks, Mattes, and Copy/Swap functions (Figure 55). Figure 55. M/E Modifiers on Main Panel M/E Modifiers Area Mattes Subpanel Copy Swap Subpanel Masks Subpanel Keyers Subpanel Delegation determines which M/E and keyer, or matte is being controlled...
Page 85: Keyers Subpanel
4-M/E Main Panel Keyers Subpanel The Keyers subpanel (Figure 56) provides controls that can be delegated to control any of the 16 Kalypso keyers (4 in each M/E). Many buttons in this subpanel are organized into interconnected groups, allowing selection of only one button at a time in each group.
Page 86 Section 2 — Control Panels Manual delegation of an individual keyer involves selecting one button in each group. Two additional delegation buttons are also used for masking (see Inhibit and Force Mask Delegation Buttons on page 90). Manually changing the selection in one of these button groups does not change the current selection in the other group.
Page 87 4-M/E Main Panel Key Type Buttons The four buttons in the Key Type button group selects from five different key types for the delegated keyer. Single button selection is available for Fixed Linear Key, Luminance Key, Chroma Key, and Preset Pattern. An Adjustable Linear Key is also available.
Page 88 Section 2 — Control Panels Matte Fill Button Matte Fill button determines what signal will be used as the key fill by the keyer. When off, the key fill signal currently selected on the fill bus will be used. When on, a matte signal will be used. Video Key Button Video Key button determines what signal the keyer will use to cut the...
Page 89: Masks Subpanel
4-M/E Main Panel Borderline and Related Buttons The buttons in this group can be used to add various types of border edges around the keyed area of the delegated keyer or preset pattern border. Do not confuse this Borderline feature with a wipe transition pattern border, which is a different feature.
Page 90 Section 2 — Control Panels and force masks may be set up for each keyer. Masks can be created by pattern generators, or can be based on a video source that has been clip and gain adjusted to create the mask control signal. Masks cannot be applied to preset patterns.
Page 91 4-M/E Main Panel Mask Control Knobs Masks subpanel knobs are used to control mask opacity, position, size, edge softness, edge location, and clip and gain. The overall opacity of any delegated mask can be controlled by holding down the button and adjusting the knob in Inhibit Mask Force Mask...
Page 92 Section 2 — Control Panels When is selected with Sep Edges off, the following knobs are available (Figure 58). Preset Pattern can also be adjusted using these mask controls. Figure 58. Box Pattern Mask Knob Parameters without Separate Edges Box Edge Softness Masks Vertical Location Top / Soft / Gain...
Page 93 4-M/E Main Panel When Utility 1 Utility 2 is selected the following knobs are available (Figure 60). control is not available for utility masks. Joystick Figure 60. Utility Mask Knob Parameters Masks Gain Top / Soft / Gain Clip Left / Horiz Right / Vert Mask Mask...
Page 94: Mattes Subpanel
Section 2 — Control Panels Mattes Subpanel The Mattes subpanel is used to control the Kalypso system’s 58 Matte gen- erators. Mattes can be used in backgrounds, in the borders of keys and wipes, to edge preset patterns, and as matte fill. Figure 61.
Page 95 4-M/E Main Panel Mattes Subpanel Delegation Buttons M/E and keyer delegation is controlled with four button groups (M/E and Background, Keyer and Wipe, Key Matte Type, and Base/Wash Fill. • The M/E 1-3 Pgm Pst , and Bkgd 1-2 buttons manually delegate the Mattes subpanel to control either an M/E or one of the two Background mattes.
Page 96 Section 2 — Control Panels Mattes Subpanel Delegation Control Buttons Auto Deleg Last Deleg buttons in the Delegation Control group affect the current delegation of the Mattes subpanel. (The Keyers/Masks sub- panel has its own independent delegation control buttons for those sub- panels).
Page 97 4-M/E Main Panel Note When a Background matte generator has been selected for control, only the Keyer Wipe button will light when either the Keyer Wipe, C1 Wipe, or C2 Wipe button is pressed. Background mattes have their own simple wipe pattern generator producing a single line that can be rotated, offset, softened, and textured.
Page 98 Section 2 — Control Panels For example (Figure 62), delegating to the Wipe 1 transition, then selecting for the wash gives the knob Offset control (if the C1 pattern gener- C1 Wipe ator is assigned to Wipe 1). This wash edge will track the transition as it is being performed.
Page 99 4-M/E Main Panel When either Bkgd 1 Bkgd 2 is selected when a wash is active, the Keyer Wipe geometry button will light and the knobs control the Offset and Softness of the wash edge (Figure 64). Backgrounds actually do not use Keyer wipe generators.
Page 100: Copy/Swap Subpanel
Section 2 — Control Panels Copy/Swap Subpanel The Copy/Swap subpanel is located at the upper right corner of the Main panel (Figure 66). Figure 66. Copy Swap Subpanel Copy Swap Subpanel M/E Modifiers Mattes Copy / Swap Active Copy Swap Buttons (3) Wash Geometry Base...
Page 101 4-M/E Main Panel To Copy an M/E, press M/E Copy , press the Mattes delegation button of the source M/E, then press the Mattes delegation button of the destination M/E. To Swap M/Es, press , press the Mattes delegation button of the M/E Swap first M/E to swap, then press the Mattes delegation button of the other M/E to swap.
Page 102: E-Mem Subpanels
Section 2 — Control Panels The transform data, however, is still transferred to the destination M/E even if a Transform Engine is not acquired. If the destination M/E subse- quently acquires a Transform Engine, the copied transform effects will run correctly.
Page 103: Keypad Numeric Entry Buttons
4-M/E Main Panel Keypad Numeric Entry Buttons The E-MEM keypad has 12 numeric entry buttons ( ) and Undo/• Enter five prefix buttons. The prefix buttons are used to delegate the keypad to different numeric entry functions (see below). Same Bank Effect Recall The default use of the keypad when a prefix button is not active is to recall an effect to that M/E.
Page 104: Keypad Prefix Buttons
Section 2 — Control Panels Keypad Preﬁx Buttons The same keypad buttons are used to enter values for different functions. The prefix buttons ( Lock/Learn Effect Dis , ↑/ Bank Trans Rate ) determine which function will be affected by the values entered. Some functions are nested.
Page 105 4-M/E Main Panel The next empty register will receive the effect data and become the current effect. This action will not occur and an error will be displayed if there are no empty registers. To learn M/E settings to a register in a different bank, the new bank must be specified.
Page 106 Section 2 — Control Panels being executed terminates the sequence operation. Any any effect dissolve (or effect run) will complete, and the last recalled register will remain the current effect. Note that once a register has been learned as a sequence, it will always proceed to the next programmed register when recalled as a sequence.
Page 107: Time Value Entry
4-M/E Main Panel Trans Rate Button Trans Rate button on the E-MEM subpanel is used to set transition rates for M/E main and keyer transitions. See Transition Rates on page 80 for more information. When either the prefix buttons are lit, the button Effect Dis Trans Rate...
Page 108: Run And Recall Control
Section 2 — Control Panels Entries in seconds can be entered by adding one separator. For example, a time of 1 second is input by pressing: • Enter An odd field is input by pressing as the last entry. For example, a time of one second 15 frames and one field is input by pressing: •...
Page 109: E-Mem Readout Display
4-M/E Main Panel E-MEM Readout Display The E-MEM readout display has 16 alphanumeric characters, and is used to show the status of the current register status, display messages, and prompt the user. When displaying the status of the current effect, the first readout character position is either blank or indicates with an “L”...
Page 110: Master E-Mem Subpanel
Section 2 — Control Panels Master E-MEM Subpanel The Master E-MEM subpanel (Figure 70) is organized similar to an indi- vidual E-MEM subpanel, but has additional capabilities. Like the E-MEM subpanel on each M/E, the Master E-MEM subpanel can be used to Learn and Recall effects for PGM PST (with Lock, Sequence, and Effect Dissolve control).
Page 111: Master E-Mem Operating Modes (Normal Mode Or 300 Mode)
4-M/E Main Panel Master E-MEM subpanel operation is closely related to the Effects Edit and Effect Run subpanels, which are used to edit and run effects. Functionally, these three subpanels actually form one integrated set of E-MEM controls. The Master E-MEM keypad can also be delegated to enter values for other Main panel controls (including any knob).
Page 112: Master E-Mem Keypad
Section 2 — Control Panels Delegates Button Delegates button affects the behavior of the Enable buttons, and is used when editing effects. During effect editing, you may want to apply edits to only some of the levels in an effect, but permit other levels to run along with the levels being edited.
Page 113 4-M/E Main Panel Lock/Learn (See Lock/Learn Button on page 104.). The Lock/Learn button can also be used with the button to update register header information. Mod/MdAll See Learn Modify on page 123. (See Sequence Button on page 105.) (See Effect Dissolve Button on page 106) Effect Dis...
Page 114: Master E-Mem Direct Bank Selection Buttons
Section 2 — Control Panels +/- Button button changes the sign of the value currently being input on the Master E-MEM keypad. This button can be pressed either before or after the value has been typed into the keypad, but before it is completed with .
Page 115 4-M/E Main Panel Put Eff button goes high tally when pressed, and the E-MEM readout displays a prompt. For example, if Bank 0 and register 7 are currently selected, the display prompts PUT CUR INTO 0x. To perform a put operation use the following procedure: Put Eff (bank selection) register...
Page 116 Section 2 — Control Panels Go To KF – The Go To KF button is used to move the cursor to a specified key- frame number on the master timeline. Pressing the button turns it on and delegates the Master E-MEM keypad for number entry. Type a number and press to go to that master timeline keyframe.
Page 117: Master E-Mem Readout Display
4-M/E Main Panel Master E-MEM Readout Display The Master E-MEM readout is organized the same as the individual E-MEM readouts. See E-MEM Readout Display on page 109. The Master E-MEM readout can also display additional level related information, and shows different prompts for the other Master E-MEM keypad prefix func- tions (Figure 71).
Page 118: Effects Edit Subpanel
Section 2 — Control Panels Ind Run Button Ind Run button is inactive in Release 12.0 and defaults to off. With Inde- pendent Run mode off, when enabled levels are triggered they run their timelines under the control of the Master E-MEM timeline. Sequence delays and effects dissolves between the different levels are synchronized.
Page 119 4-M/E Main Panel updated as the settings for sources modified. The Clear Wk Bfr can be used to return work buffer and source memory settings to known states. This can be helpful when creating effects. Work buffer and source memory values are not set to zero when they are cleared.
Page 120: Restore Work Buffer Button
Section 2 — Control Panels Restore Work Buffer Button – Restores the work buffer to its original keyframe values or Rest WrkBfr interpolated state. For example, if you recall an effect and make changes to its settings in the work buffer, pressing removes the changes that Rest WrkBfr were made and restores the original values.
Page 121: Timeline Edit Button Group
4-M/E Main Panel keyframes. When keyframe navigation buttons are used to move the cursor, the work buffer continues to be updated. Edit operations occur at the combined cursor location using the current work buffer values. – When is selected, the time and edit cursors can be sepa- Edit Crsr Edit Crsr rated.
Page 122: Timeline Modify, Insert Button Group
Section 2 — Control Panels Paste – Inserts the data currently in the clipboard into the effect at the cursor location. The data remains in the clipboard for reuse. Keyframes on all del- egated timelines in the effect move later in time to accommodate the dura- tion in the clipboard.
Page 123 4-M/E Main Panel Insert After – When the cursor is on a keyframe, pressing Insert After inserts a new keyframe (with the currently specified keyframe duration) after the keyframe the cursor was on, and shifts all the following keyframes later in the effect, which increases the total duration of the effect.
Page 124: Effects Run Subpanel
Section 2 — Control Panels Effects Run Subpanel The Effects Run subpanel primary function is to control the running of multiple keyframe effects. Also located on this subpanel is the Hold Inputs button used to control E-MEM source changes (Figure 73).
Page 125: Run Control Buttons
4-M/E Main Panel Run Control Buttons – When the button is on, subsequent effects runs will stop Stop Next Stop Next at the next keyframe encountered. With this feature on, you can step key- frame by keyframe through an effect by pressing the button repeatedly.
Page 126: Transform Subpanel
Section 2 — Control Panels Transform Subpanel The Transform subpanel (Figure 74) is be used to control image and wipe pattern placement, size, angle, and other attributes. This panel is equipped with a Joystick, particularly suitable for adjusting position and rotation parameters.
Page 127: Joystick
4-M/E Main Panel Joystick The Kalypso system Joystick is a precision three-axis device. Moving the joystick towards or away from you controls the Y-axis, moving the Joystick left and right controls the X-axis, and rotating the Joystick controls the Z- axis (Figure 75).
Page 128: Transform Buttons
Section 2 — Control Panels occur when the joystick is delegated to multiple points of use. For example, it is possible to delegate the joystick to M/E 3 Key 1 and Key 2 where Key 1 has a Transform Engine and Key 2 does not. In this case, the Key 1 button will be high tally but the Key 2 button will low tally.
Page 129 4-M/E Main Panel Source and Target Space Related Buttons The Source and Target Space buttons affect the five other transform param- eter buttons in that group ( Loc 3D Size Loc Rot, Locate Axis Spin button delegates source space control of the selected trans- Src Space form parameter.
Page 130: Axis Buttons
Section 2 — Control Panels Post T-form button controls the movement of an image along the X and Y axes of two-dimensional screen space (this appears to move over a flat space and perspective changes do not occur). Deflecting the Joystick along its Z axis will scale the picture in 2D (post scale).
Page 131: Macro Delegation
4-M/E Main Panel Macro Delegation button delegates a keyer source select button row Macro Deleg (PGM PST K1/K3 is the default) for macro operations and reports that macro mode is active (high tally). Pressing toggles the macro Macro Deleg delegation on and off. On the Main panel, any keyer source select button row on any M/E can be delegated for macro operations.
Page 132: Insert Delay
Section 2 — Control Panels If another macro register button is pressed while a macro is being recorded, the macro contents of this other macro are appended to the currently recorded macro. There is no cross-reference or call other macro function- ality.
Page 133: Pre Attach, Post Attach, Replace Attach
4-M/E Main Panel Pre Attach, Post Attach, Replace Attach Macros can be attached to other panel buttons so the macro runs when that button is pressed. Macros can run before the normal function of that button, after the normal function, or completely replace that button func- tion.
Page 134: Macro Alternate Buttons
Section 2 — Control Panels the macro register buttons, or with the Macro menu. The Attach Enable button is active whether or not macro mode is active, so it can be instantly turned on and off at any time. Macro Alternate Buttons The PGM PST K1/K3 M/E re-entry buttons (the default macro row) are labeled with additional macro capabilities (Figure...
Page 135: Machine Control Subpanel
4-M/E Main Panel Machine Control Subpanel The Machine Control subpanel (Figure 78) can be used to control devices like DDRs, VTRs, still stores, character generators, etc. This subpanel can also control the Kalypso Still Store and GPIs to any external device. Figure 78.
Page 136: Readout Display
Section 2 — Control Panels Once delegated to a bus, any source selected on that bus will be subject to Machine Control subpanel commands. The current bus selection is saved as part of User Prefs. The new bus will be used for device control delega- tion until changed by the user or a User Pref with a different bus selection is loaded.
Page 137: Control Of Devices With Still Recall Only
4-M/E Main Panel Play/Gang Roll button plays the controlled device. When Gang Roll is active, multiple devices can be triggered for playback simultaneously. For DDRs and VTRs, pressing Fast Fwd fast forwards or rewinds to the beginning or end of the currently loaded clip. VTRs will require time for these actions.
Page 138: Auto Start
Section 2 — Control Panels Auto Start button is used to make an external machine start playing Auto Start when it is taken on-air. To do this, delegate the device with the PGM PST B bus, then press so it is illuminated. On-air status causing play- Auto Start back can be achieved by a bus source change, turning on a key, or recalling an E-MEM register, to name a few.
Page 139: Preview Signal Selection
Local Aux Panel The Preview subpanel also works with the Local Aux panel, which pro- vides a selection mechanism for viewing sources and program outputs of the M/Es on the switched preview output. Note that the switched preview will automatically show the appropriate signal during Hold to Preview, Show Key, Color Pick and Auto Key Setup operations, replacing whatever signal may have been selected for previewing.
Page 140: Local Aux Panel Source Selection
Section 2 — Control Panels Figure 80. Local Aux Panel Source Select Emergency Bypass (4) Bus #1 Aux Bus Status M/E Select Source Select Modifiers (6) Bus #1 (32) (option) Delegation (15) Display (2 segments) Bus #2 (4) for Bus #1 Bypass Active Emergency Bypass...
Page 141: Source Selection Buses
Local Aux Panel Source Selection Buses Source selection on the Local Aux panel is identical to the Main panel. Thirty two source buttons are available in a single row on each bus. The source name display between the buses identify the sources available for selection on both buses.
Page 142: Router Assignment
Section 2 — Control Panels Router Assignment The Local Aux panel can be assigned to control external router source selections, if configured for that feature, using the Router Assignment buttons at the lower left of the panel. See Router Interface Operation in the Kalypso User Manual for operating information.
Page 143: 2-M/E Main Panel
2-M/E Main Panel 2-M/E Main Panel The 2-M/E Main panel is similar to the 4-M/E panel (Figure 81). Instead of 3 M/Es and a PGM PST, the 2-M/E Main panel has one M/E bank and one PGM PST bank, though three M/Es and PGM PST are accessible via dele- gation.
Page 144: Bank Delegate Subpanel
Section 2 — Control Panels Bank Delegate Subpanel The two banks on the 2-M/E Main panel can be delegated to control dif- ferent M/Es (provided the Kalypso Video Processor is equipped with additional M/E modules). The Bank Delegate subpanel is located at the upper center of the panel (Figure 82).
Page 145: Master E-Mem Subpanel
2-M/E Main Panel Master E-MEM Subpanel On the 2-M/E Main panel, the Master E-MEM subpanel (Figure 83) always operates as Master E-MEM. Delegating the PGM PST bank to control an M/E does not change this panel into a dedicated E-MEM subpanel. You can use the Enable buttons to delegate control of the Master E-MEM panel to the desired E-MEM levels.
Page 146: Macros Subpanel
Section 2 — Control Panels Macros Subpanel The Macros subpanel on the 2-M/E Main panel is located next to the Keyers subpanel, at the upper center part of the panel (Figure 85). See Macros Subpanel on page 130 for specific information. Figure 85.
Page 147: Local Aux Subpanel
2-M/E Main Panel Local Aux Subpanel The 2-M/E Main panel has a built-in Local Aux subpanel is located at the (Figure 86). This subpanel performs the same functions as the separate Local Aux Panel used by the 4-M/E Kalypso system. The 2-M/E Local Aux subpanel has 24 source selection button columns, rather than the 32 on the 4-M/E Kalypso system.
Page 148: 1-M/E Main Panel
Section 2 — Control Panels 1-M/E Main Panel A 1-M/E Main panel (Figure 87) is designed to operate in conjunction with a 4-M/E or 2-M/E Main panel as an accessory workstation. Though the 1-M/E Main panel has only one M/E control bank, it can be delegated to control any of the M/Es of a 2 or 4-M/E Kalypso system.
Page 149: Bank Delegate Subpanel
1-M/E Main Panel Bank Delegate Subpanel The Bank Delegate subpanel selects which Kalypso system M/E will be controlled by the 1-M/E Main panel, and also affects how the E-MEM sub- panel operates. Figure 88. 1-M/E Bank Delegate Subpanel Bank Delegate Subpanel (affects E-MEM and M/E Bank)
Page 150: E-Mem Subpanel
Section 2 — Control Panels E-MEM Subpanel The E-MEM subpanel is used to Learn and Recall E -MEM effects, and also has E-MEM Recall and Run controls. Figure 89. E-MEM Subpanel Master E-MEM E-MEM Indicator Subpanel Readout Master Display E-MEM Misc Misc Select...
Page 151: Master E-Mem Mode
1-M/E Main Panel Master E-MEM Mode The E-MEM subpanel operates as Master EMEM when delegated to Pgm Pst in the Bank Delegate subpanel. In this mode you can enable multiple E-MEM levels for control, and the buttons listed above are active. The E-MEM indicator illuminates in this mode.
Page 152: Menu/Joystick Delegate Subpanel
Section 2 — Control Panels Menu/Joystick Delegate Subpanel The Menu/Joystick Delegate subpanel has a built-in menu display, which can be used instead of a separate Menu panel. This subpanel also has a joy- stick which can be delegated for various purposes. This subpanel is also used to adjust Source Name Display contrast.
Page 153: Source Selection
1-M/E Main Panel Source Selection Source selection on the 1-M/E Main panel is identical to the 2 and 4-M/E subpanels, except there are 12 source select buttons. The 1-M/E Main panel does not have M/E status displays. The bus indicators for each button Shift row indicates whether that row is in shifted source selection mode.
Page 154: Transition Subpanel
Section 2 — Control Panels Transition Subpanel The Transition subpanel operates essentially the same as a 2 or 4-M/E Main panel, except there are no Keyer Cut buttons. Lever Arm sync indica- tors and a Transition Rate readout has been added, to display information reported in the M/E Status displays of 2 and 4-M/E Main panels.
Page 155: 1-M/E Main Panel Reset
1-M/E Main Panel 1-M/E Main Panel Reset A reset button is located inside the lower Transition Lever Arm slot, besides on the rear panel, permitting easy reset should the unit be installed in a console or rack. The button can be pressed with a small screwdriver. Macros Subpanel On a 1-M/E Main panel the Macro buttons are located at the center left of the panel...
Page 156 Section 2 — Control Panels Kalypso — Reference Manual...
Page 157: Section 3 - Menus
Section Menus Introduction The Kalypso system’s Menu panel provides capabilities that compliment the operation of the Main panel and the Local Aux panel. The Menu panel controls most system functions, and has additional controls not available on the Main panel (for example, wipe pattern selection, chroma key manual controls, and configuration menus).
Page 158: Enhanced Menu Panel
Section 3 — Menus Enhanced Menu Panel The Enhanced Menu panel (Figure 94) includes a touch screen display, five knobs for adjusting parameter values, a cooling fan, and an internal CD-ROM drive. Figure 94. Enhanced Menu Panel Soft Knobs (5) Touch Screen Display CD-ROM...
Page 159: Touch Screen
Introduction played. The button for the currently displayed menu will be high tally. Menu selection is also available via the Home menu (Figure 102 on page 166). Touch Screen CAUTION Do not apply any sharp or rigid object (no pens or pencils) to the touch screen display surface.
Page 160: Data Pads And Touch Buttons
Section 3 — Menus egations may also be available to access specific parameters. In general, once a menu category/subcategory has been selected, levels of delegation are available in a left to right and top to bottom order. This generally results in placing some parameters next to the soft knobs for easy adjustment.
Page 161: Menu Top Line
Introduction Note that a single touch of a data pad will not change any Kalypso system settings, but just brings up controls that permit changes. You can safely touch any data pad to explore that object’s parameters and settings. Actual changes are enacted on the screen with the touch buttons, by turning a soft knob, or by entering a value on a keypad.
Page 162: Menu Category Selection
Section 3 — Menus Menu Category Selection Menu category selection touch buttons are arranged along the bottom of the screen ( Mode B-Line Priority , etc. in the example). Touching one of these buttons takes you directly to that category. The currently selected category is shown by the green indicator on the touch button.
Page 163: Menu Access Touch Button
Introduction Menu Access Touch Button In some cases it is handy to jump to a different menu and delegation to adjust related controls. For example, an operator setting up a mask may need to adjust a pattern in the wipe menu. To make menu navigation easier, a menu access button can be included on one menu that links to a different, related menu.
Page 164: Alphanumeric Keypad
Section 3 — Menus Alphanumeric Keypad Touching the pad for a text parameter brings up an alphanumeric keypad (Figure 99). You can also use a standard computer keyboard to enter infor- mation while this display is active. Figure 99. Alphanumeric keypad Scrolling Lists When multiple items are available for selection, scrolling lists are used Figure 100.
Page 165: Menu Summaries
Menu Summaries Figure 101. Paired Scroll Lists with Lock On Menu Summaries In the remainder of this section, figures of several Kalypso system menus are presented to familiarize you with various screen layouts. Because each menu controls different aspects of the Kalypso system, the screen parame- ters and organization will vary, but the basic principles previously described are followed.
Page 166: Home Menu
Section 3 — Menus Home Menu The Home menu (Figure 102) is used to access the other Kalypso system menus. Touch the button of the desired menu type to go directly to that menu. If multiple menus are available for that type, the last selected menu will be displayed.
Page 167 Home Menu Table 7. Menu Selection Button Functions Menu Buttons Purpose E-MEM E-MEM registers load and save Copy Swap Copy Swap menu controls (M/E, Wipe, Matte, Keyer, and Source Memory) Still Store Still Store controls Matte Matte adjustment controls T-Form Transform Engine controls Mix Effects Mode selection (including Programmable Clean Feed), and Effects Send Keyer...
Page 168: Daily Setups Menus
Section 3 — Menus Daily Setups Menus The Daily Setups menus contain controls operators may need to change routinely to meet various project requirements. Daily Setups Save-Load Menu The Daily Setups Save-Load menu employs the Kalypso file browser and is used to save and load User Profiles, Suite Profiles, and Source Memory information.
Page 169: Suite Prefs Menus
Daily Setups Menus Suite Prefs Menus A Kalypso suite is a grouping of one or more control surfaces. Systems with more than one control surface may be used by more than one operator at the same time. Suite Preference controls define how all the control sur- faces associated with a Kalypso suite behave.
Page 170 Section 3 — Menus The following overlays can be displayed on a Kalypso system Preview output: • Safe title (10% underscan), • Safe action (5% underscan), • Center of screen, • Screen unit grid, • User Lines (horizontal and vertical). All overlays except User Lines follow SMPTE RP187.
Page 171: Default Keyframe Menu
Daily Setups Menus Default Keyframe Menu The Default Keyframe menu is used to learn the current Kalypso panel state to the system’s Default Keyframe, and to set the Default Keyframe back to factory settings. The Default Keyframe is applied when the button is pressed.
Page 172: E-Mem Prefs Menu
Section 3 — Menus E-MEM Prefs Menu E-MEM Prefs menu is used to set E-MEM level assignments, and to select 300 Mode operation. The menu is accessed by touching Daily Setups (Figure 106). Suite Prefs E-MEM Prefs Figure 106. E-MEM Prefs Menu The Kalypso E-MEM system has 19 levels and many sublevels.
Page 173 Daily Setups Menus Default assignments are shown in Table 8. You can to reassign E-MEM levels to different Enable buttons with the E-MEM Prefs menu. Table 8. E-MEM Level Default Assignments E-MEM Level E-MEM Sub Level Button Misc 1 Background 1 and 2 Macros Misc 3 Aux buses...
Page 174: Master E-Mem Mode
Section 3 — Menus On the left individual levels can be selected for assignment (the selected level is yellow). Touching one of the E-MEM Enable buttons will assign that level to that button. Click on to return to the previous menu, from Done which you can access other levels to change.
Page 175: Re-Entry Preferences
Daily Setups Menus Re-Entry Preferences The Kalypso system normally restricts the re-entry of the outputs of an M/E back into the same M/E. This prevents the timing related one line downward shift of the video, and also prevents video feedback. However, this restricts some useful modes of operation.
Page 176: Suite Gpi Menu
Section 3 — Menus Suite GPI Menu The Suite GPI menu is used to program the 16 Kalypso system GPI inputs. Various actions can be performed when a GPI contract closes, including recalling a macro, selecting a source on a bus, recalling an E-MEM, and triggering a transition.
Page 177: Video Settings Menu
Daily Setups Menus Video Settings Menu The Video Settings menu is used to set video standards to be used by the Kalypso system. This menu is accessed by touching Daily Setups Suite Prefs (Figure 110). Aspect Ratio, Matte Limiting, and Default Trans- Video Settings form Engine Crop controls are active on this menu.
Page 178: Default Transform Engine Crop
Section 3 — Menus Both – This limiter mode is similar to Decodable , except that maximum levels are reduced slightly around yellow and cyan to prevent over modulating an NTSC transmitter. – In this mode, no limiting is imposed. Analog signal paths and mon- None itors may behave poorly to some colors produced in this mode.
Page 179: Command Processing
Daily Setups Menus Command Processing These controls determine when commands (like source selections or the initiation of mixes or wipes) will be enacted by the Kalypso system (also known as field dominance). These controls can be useful for consistent match frame editing. –...
Page 180: Logical Source Selection Pane
Section 3 — Menus Figure 111. Source Patch Menu Logical Source Selection Pane The Source Patch menu has a scrolling list of Logical sources displayed in ascending Logical ID order. The Logical Source soft knob can be used to scroll up and down the list and select a different Logical source. Touching the soft knob label data pad brings up a numeric keypad that can be used to scroll the list to the entered Logical ID number and select that source.
Page 181 Daily Setups Menus neering source by eye. Touching the soft knob label data pad brings up a numeric keypad that can be used to select an Engineering source by its Engineering ID number. Engineering source selection is also possible using a source picker. Touching an Engineering Source data pad in the Logical source selection pane brings up a scrolling Engineering source picker (Figure...
Page 182: Display Color
Section 3 — Menus Display Color The Main panel and Local Aux panel source name displays can display red, green, and amber colors, which can be applied either to the text or the background. One example of using these tri-color displays is to make the names of all the cameras appear green, all the character generators appear yellow, and the network feeds appear red.
Page 183: Source Memory Menu
Daily Setups Menus Source Memory Menu The Source Memory menu is used to enable and disable Source Memory. The menu is accessed by touching Daily Setups Suite Prefs Source Memory (Figure 113). Figure 113. Source Memory Menu When (green indicator on the button is illuminated), key type and Enabled source memory settings will change as different sources are selected on that bus.
Page 184: Key Drop Menu
Section 3 — Menus Source Memory Operation Rule Changes Starting with Kalypso software version 10.0 the following rules for Source Memory Operations apply: • While Source Memory is active, if it is loaded or copied or swapped, the new Source Memory will be immediately applied to the Current Work Buffer.
Page 185: Bus Linking Menu
Daily Setups Menus Bus Linking Menu The Bus Linking menu allows the operator to set up bus links and source associations and enable the linking. This menu is accessed via Daily Setups, Suite Prefs, Bus Linking (Figure 115). Refer to the separate Kalypso User Manual for specific instructions on how to use the Bus Linking feature.
Page 186: Bus Picker
Section 3 — Menus Bus Picker Touching the data pad at the top of either the Controlling Bus or Linked Bus pane facilitates selecting a bus via a popup bus picker (Figure 116). Figure 116. Bus Picker Popup The type of bus to display ( ) is chosen with the Bus M/E Buses Aux Buses...
Page 187: Shortcut Menu
Daily Setups Menus Shortcut Menu Touching the button brings up a menu that can help Display Shortcut Menu reduce the time required to build Link Mapping tables (Figure 117). Figure 117. Bus Linking Shortcut Menu The current Controlling Bus and Linked Bus are identified in the data pads at the top of the pane.
Page 188: Display All Links Menu
Section 3 — Menus Display All Links Menu Touching the button on the Bus Linking menu brings up a Display All Links scrolling list of all the defined bus links (Figure 118). This can be used to help manage the links. Buses that are not linked are not shown. Figure 118.
Page 189: Button Mapping Menus
Daily Setups Menus Button Mapping Menus The Button Mapping menus are used for source to button mapping, which permits arranging sources in any order on the source selection buses. This menu is also used to map Joystick overrides. The menu is accessed by touching (Figure 119).
Page 190 Section 3 — Menus When Remote is selected, a Remote Panels panel appears permitting selec- tion of multiple remote panels (Figure 120). Figure 120. Source Button Mapping Menu, Remote Panel Type Selected See Button Mapping in the Kalypso User Manual for specific operating instructions.
Page 191: Aux Delegation Mapping Menus
Daily Setups Menus Aux Delegation Mapping Menus The Aux Delegation Mapping menus are used to map the delegation buttons on the Local Aux panel, and on any configured Remote Aux panels. The menu is accessed by touching Daily Setups User Prefs Aux Deleg (Figure 121).
Page 192: Shift Preferences Menu
Section 3 — Menus Shift Preferences Menu The Shift Preferences menu is used to configure which source will be selected on the Kalypso Main panel or Local Aux panel when a shift mod- ifier button is not held down. Shift preferences can be set on individual buses.
Page 193: Source Display Menu
Daily Setups Menus Source Display Menu The Source Display menu is used to configure source name displays. The source name displays can show the names of the unshifted sources, show the shifted sources, or show both in a split display. The menu is accessed by touching (Figure 123).
Page 194: Clip Hi Lo Preferences Menu
Section 3 — Menus Clip Hi Lo Preferences Menu The Clip Hi-Lo Preferences menu controls how Clip and Gain knobs behave. The menu is accessed by touching Daily Setup User Prefs Clip Hi-Lo (Figure 124). Prefs Figure 124. Clip Hi-Lo Prefs Menu The Clip and Gain knobs on the Kalypso system Main panel and Menu panel can control either Clip and Gain, or Clip Hi and Clip Low, depending on the preference set.
Page 195: Double Press Alternate Source Selection
Daily Setups Menus Double Press Alternate Source Selection Selected buses on the Kalypso Main panel can be configured to take the alternate (shifted or unshifted) source when the source select button is pressed twice quickly. The first press will still shows the original source, then the second press selects the alternate source.
Page 196: Eic Login Menu
Section 3 — Menus EIC Login Menu The EIC Login menu is used to log in as the Engineering In Charge (EIC). The menu is accessed via . This menu is different, Daily Setups EIC Login depending on whether Single Suite mode or Multi Suite mode is active. Figure 126 illustrates this menu in Single Suite mode.
Page 197 Daily Setups Menus An Identity pane appears on the EIC Login menu when in Multi Suite mode (Figure 127). When logged in as the EIC (a password may be required), the buttons in this pane are active, permitting access to either control surface in either suite.
Page 198: Eic Login Shortcut
Section 3 — Menus EIC Login Shortcut If while in an Engineering Setup menu you attempt to make a change when not logged in as the EIC, the EIC login popup appears (Figure 128), allowing you to login without having to navigate to the Daily Setups EIC login menu.
Page 199: Acquire Resources Menu
Daily Setups Menus Acquire Resources Menu The Acquire Resources menu (accessed via Daily Setups Acquire ) is used to specify what resources are desired for use by a suite, and acquire and release those resources (Figure 129). This menu only becomes available when Multi Suite mode is in operation, In Single Suite mode the Acquire button is grayed out, as depicted in proceeding menus.
Page 200: Physical Components Pane
Section 3 — Menus A Desired indicator column shows what logical components are desired for use by that suite. A green box indicates that resource is desired, and a blank area indicates the resource is not desired. Touching the button Desired in the central Resource Action pane toggles this status on and off for the delegated component.
Page 201: Resource Action Panes
Daily Setups Menus Resource Action Panes The middle panes control the actual acquisition and release of resources. The upper middle pane is delegated with the Logical buttons in the left pane to a specific logical component. The contents of this pane is context sensitive depending on the type of resource delegated.
Page 202 Section 3 — Menus When a Transform Engine or Chroma Keyer Logical component has been delegated, the upper Resource Action pane changes (Figure 130). Figure 130. Acquire Resources Menu with Chroma Keyer Selected Touching the top data pad brings up a popup keypad. Entering a value specifies the total number of the currently delegated component type desired by the suite.
Page 203: Configuration Data
Daily Setups Menus Release All button releases all components, including those marked as desired. This should only be used to shut down a suite when not in use, making all the resources available to the other suite. Conﬁguration Data The desired resource list is part of Suite Preferences. This data is saved and loaded as part of a Suite Profile or Suite Pref disk operation.
Page 204: Eng Setups Menus
Section 3 — Menus Eng Setups Menus The Eng Setups menus contain controls generally used by engineering per- sonnel to setup and configure the Kalypso system. Note Eng Setups conﬁguration procedures are covered in the separate Kalypso Installation and Service Manual. Eng Setup Save-Load Menu The Eng Setup Save-Load menu employs the Kalypso file browser and is used to save and load Engineering Setup information.
Page 205 Eng Setups Menus current path is displayed at the top of the pane. Touching an icon selects that item. Touching a selected icon de-selects it. Double touching a folder or drive icon opens it. On the upper right, below the top line message area, is a file operations message pane.
Page 206: Source Definition Menu
Section 3 — Menus Source Deﬁnition Menu Kalypso system sources are defined in the Source Definition menu. Touching a source button on the scrolling list at the top of the screen selects that source for definition. The data pads and touch buttons in the remainder of the screen applies to the selected source.
Page 207: Output Assignments Menu
Eng Setups Menus Output Assignments Menu The Eng Setups Output Assignments menu is used to assign Kalypso system outputs to specific physical connectors on the rear of the Video Pro- cessor frame. The menu is accessed by touching Eng Setup Outputs (Figure 133).
Page 208 Section 3 — Menus If Multi Suite mode is active, the Suite pane becomes available in the Output Assignments menu (Figure 134). Figure 134. Output Assignments Menu, Multi Suite Mode, buttons are used to assign the currently selected Suite 1 Suite 2 output to a suite.
Page 209: Port & Device Definition Menus
Eng Setups Menus Port & Device Deﬁnition Menus The Eng Setups Port and Device menus are used to create and edit Device Definitions. Each Device Definition contains the settings required to use the unique features of that device. DDRs, VTRs, and DPMs are associated with sources, while GPI and PBus devices are not.
Page 210 Section 3 — Menus Touching an already defined item in the scrolling Device List on the left brings up information for that device. Figure 136 shows the settings for a Krystal DPM. Figure 136. Port & Device Definition Menu, Krystal DPM Kalypso —...
Page 211 Eng Setups Menus Touching the New Device button brings up a menu used to create a new device definition (Figure 137). Figure 137. Port & Device Definition Menu, New Device The AMP (Serial and Ethernet) feature is a software enabled option, avail- able only when the feature has been activated.
Page 212: Tally Menus
Section 3 — Menus Tally Menus The Tally menus are used to configure the tally system. There are multiple tally calculators, three different tally calculation methods, and user assign- ment of tally relays. The results of the tally calculators are applied to the tally relays on the Tally modules in the Video Processor frame, and those relays control external tally lights.
Page 213: Tally Relay Assignments Menu
Eng Setups Menus Tally Relay Assignments Menu Touch (the Relay Assign button is in the Function Eng Setup Tally, Relay Assign pane) to access the Tally Relay Assignments menu (Figure 139). Figure 139. Tally Relay Assignments Menu Kalypso — Reference Manual...
Page 214: Router Interface Setup Menu
Section 3 — Menus Router Interface Setup Menu The Router Interface Setup menu (Figure 140) is used to set the IP Address(es) the Kalypso system will use to communicate to the external router. The Connection Status indicator is red when communication is not detected, and is green when communication is established.
Page 215: System Menus
Eng Setups Menus System Menus The System menus are used to set various system parameters. Subcategory selection buttons for these controls are located on the left. Suite Deﬁnition Menu The Suite Definition menu is accessed by touching Eng Setup System Suite Def (Figure 141).
Page 216: Still Store Pane
Section 3 — Menus Note If this ﬁeld is changed, the Kalypso Menu application must be exited and relaunched or the Menu panel must reset before the Menu will use this dif- ferent IP address to communicate with a Video Processor frame. buttons toggle between Single and Multi Single Suite Multi Suite...
Page 217: Security Account Setup Menu
Eng Setups Menus Security Account Setup Menu Security setup is covered in the separate Kalypso Installation and Service Manual. Remote Aux Panel Setup Menu The Aux Panel Configuration menu is accessed by touching Eng Setup System Aux Panel , then touching either the Add Panel Edit Panel buttons.
Page 218 Section 3 — Menus When in Multi-Suite mode a menu similar to Figure 143 is displayed. Figure 143. Eng Setup Aux Panel Menu, Multi-Suite Modes buttons assign that Aux panel to control Suite 1 Indep Suite 2 Indep the Aux buses of that suite. The configuration settings for this Aux panel are saved with Eng setups, however, and so are independent from indi- vidual Suite and User Pref settings.
Page 219: Emerg Bypass Menu
Eng Setups Menus Emerg Bypass Menu Emergency Bypass option configuration, installation, and operation is covered in the separate Kalypso Emergency Bypass Instruction Manual. This option supports Kalypso Classic and Duo systems, but does not operate with Kalypso HD systems when run in HD mode. Kalypso Classic Sync/Timing Menu On Kalypso Classic systems, the Sync/Timing menu, accessed via , reports the status of the internal sync generator of...
Page 220: Kalypso Hd/Duo Sync Timing Menu
Section 3 — Menus Kalypso HD/Duo Sync Timing Menu Kalypso HD and Duo systems have a different Sync Timing Menu that, besides reporting the Sync Ref status, includes other controls (Figure 145). Figure 145. Sync/Timing Menu, HD System A Timing Analyzer is available, as well as controls to select the sync refer- ence that switches the system between HD and SD operating modes.
Page 221: Install Options Menu
Eng Setups Menus Install Options Menu The Instal Options menu (Figure 146) is used to authorize software enabled options. This procedure is covered in the separate Kalypso Installation and Service Manual. Figure 146. Install Options Menu Kalypso — Reference Manual...
Page 222: Test Patterns Menu
Section 3 — Menus Test Patterns Menu The Eng Setup-Test Patterns menu (Figure 147) allows the selection of dif- ferent video test patterns. The chosen test pattern will be displayed when the Test source is selected. Figure 147. Test Patterns Menu Kalypso —...
Page 223: Macro Menus
Macro Menus Macro Menus The Macro menus provide access to many, but not all, Kalypso system macro functions. With Kalypso software version 12.0 the Macro menus can be used to: • Record a new macro and append record onto an existing macro, •...
Page 224: Macro Save Load Menu
Section 3 — Menus Macro Save Load Menu The Macro Save Load menu (Figure 148) is accessed by touching the Save Load category selection button at the bottom of the Macro menu. Figure 148. Macro Save-Load Menu This menu operates the same as he E-MEM save load menu. You can select all macro registers, or a range of macro registers, to save to disk.
Page 225: Macro Catalog Menu
Macro Menus Macro Catalog Menu The Macro Catalog menu (Figure 149) is used to record, play, and name macros. It is also used to include a macro in an E-MEM. Figure 149. Macro Catalog Menu Macro Catalog Pane The Macro Catalog pane has a scrolling list of all 100 macro registers. touching a Macro Register button selects that register for Macro menu control operations.
Page 226: Control Pane
Section 3 — Menus Control Pane The buttons in the Control pane affect the selected macro register, per- forming the labeled functions. CAUTION Unlike macro operations on the Main panel, you must ﬁrst select the desired register and then press the desired macro function button (Record, Append, Delete Macro).
Page 227: Append Macros Pane
Macro Menus Append Macros Pane You can append the contents of one macro into another macro using the Macro Catalog menu. After touching either the Record Append button on the menu, touching another Macro Register button on the menu opens an Append Macros pane (Figure 150).
Page 228: Soft Knob Register Selection
Section 3 — Menus Soft Knob Register Selection Macro registers can be selected using the labeled soft knob on the right, and a specific register number can be entered on the data pad to go directly to that register. E-MEM Pane The E-MEM pane is used to add a macro to an E-MEM.
Page 229: Macro Copy Swap Menu
Macro Menus Macro Copy Swap Menu The Macro Copy/Swap menu (Figure 151) is accessed by touching the category selection button at the bottom of the Macro menu. This Copy Swap menu can also be accessed via the Copy Swap menu. Figure 151.
Page 230: Macro Attachments Pane
Section 3 — Menus Note Macro attachments are saved and loaded with User Prefs. One set of attach- ments exists for each control surface. Be sure the User Prefs you load are compatible with the Macro registers you are currently using, to avoid acci- dentally running incorrect attached Macros.
Page 231 Macro Menus Note The display will show buttons for the maximum used by a Kalypso system. This means that if you have a 2-M/E system, the button set will still display all the buttons for a 4-M/E system. Ignore any extra buttons displayed. Selecting a Panel Button for a Macro Attachment You can use the Macro Attach menu to select a panel button, by touching the section (M/E 1 - Misc) and scrolling the list to display the button name.
Page 232: Unattach Macros
Section 3 — Menus Unattach Macros button is used to clear all the current macro Remove all Attachments attachments. A popup pane appears asking you to confirm the action. Panel Attach Mode The buttons in the Panel Attach Mode duplicate the functions of those five Macro subpanel buttons on the Kalypso Main panel, and are also included on the menu as a convenience.
Page 233: All Files Menu
File Operations Menus All Files Menu The File Operations All Files menu provides access to all Kalypso files (Figure 154). Figure 154. File Operations All Files Menu On the left side of the File Operations menu is a file display pane equipped with a scroll bar.
Page 234 Section 3 — Menus button goes to the top directory that displays the local and network drives. Also displayed is the Frame User Directory, which provides access to the Kalypso Video Processor frame. Individual files and folders located on the Kalypso Menu panel Windows desktop are not shown. Open button opens the selected folder or drive.
Page 235: Dest Pane
File Operations Menus Dest Pane Pressing the button opens a destination pane for Paste operations. Dest Pane The lower , and Open buttons are used to navigate through the file hierarchy for this destination directory (Figure 155). Figure 155. File Operations Source and Destination Panes Show Menu The File Ops Show menu is used to create, save, and load Shows.
Page 236: Access To Other File Ops Menus
Section 3 — Menus The standard navigation, copy, and other file and folder controls are located at the upper right of this menu. Show related controls are located on the lower right in the Show Create and Load pane (Figure 156).
Page 237: Status/Diags - Versions Menu
Status/Diags - Versions Menu Status/Diags - Versions Menu The Versions menu displays currently loaded software versions for all the Kalypso system components. This menu also displays Node Names and Types and Control Surface assignments defined for Resource Sharing (Figure 157). Touch to access this menu.
Page 238: External Device E-Mem Menus
Section 3 — Menus External Device E-MEM Menus The External Device menus are used to control external devices that have been configured with the Kalypso system. Five menus are available: • Enables – Enables and disables control of external devices. •...
Page 239: Devices Pane
External Device E-MEM Menus Disabling device control temporarily can be useful. For example, during a rehearsal you may not want to cue or roll VTRs. With the External Device Enables menu you can control which devices will respond without having to rebuild effects or change engineering configuration.
Page 240 Section 3 — Menus Map Sources button accesses the External Device Mapping menu (Figure 160). This menu will allow the user to map any or all of the Kalypso sources to editor sources. The menu does not know how many sources the editor can control, so it is the responsibility of the user to map the correct number of sources based on the protocol used by the editor device.
Page 241: Dpm Panes
External Device E-MEM Menus Mapping Shortcuts button accesses shortcuts for the Editor menu (Figure 161). Figure 161. Editor Mapping Shortcuts Menu • Touching the Map Sources 1:1 button does a quick mapping of the sources 1 to 1, (Switcher Source 1 to Editor Source 1, etc.). •...
Page 242 Section 3 — Menus Switcher Controls DPM and the DPM Controls Aux Bus buttons toggle on and off. The three possible combinations are: Switcher Controls DPM is On and DPM Controls Aux bus is On. The switcher changes to the aux bus are sent as a request to the DPM. The DPM replies to the switcher with the report of the new source.
Page 243 External Device E-MEM Menus Mapping Shortcuts button accesses shortcuts for the DPM menu (Figure 163). Figure 163. DPM Mapping Shortcuts Menu • Touching the button does a quick mapping of the Map Sources 1:1 sources 1 to 1, (Switcher Source 1 to Editor Source 1). •...
Page 244: External Device Time Code Selection
Section 3 — Menus External Device Time Code Selection On the External Device Enables menu you can specify what type of time- code the Kalypso system will use with each device. The current time code mode is displayed in the Time Code column (Figure 158 on page 238).
Page 245: Timeline Events Menu
External Device E-MEM Menus Timeline Events Menu After the external devices are configured with the Kalypso system, they can be controlled using events learned to effect keyframes. Events act as triggers for specific behaviors, similar to GPI or Peripheral Bus II com- mands.
Page 246: Device Pane
Section 3 — Menus Device Pane The Device pane on the left is a scrolling list of all configured external devices, as described in the External Device Enables menu on page 239. The name of each device is shown on the left, and its status is indicated in the adjacent box (see Device Statuses on page 239).
Page 247: External Device Control Menu
External Device E-MEM Menus Stop button instructs the device to stop playback when that keyframe is encountered. Turning on automatically turns off if it was Stop Play selected. button turns off events at the current keyframe for only the Clear Events delegated device.
Page 248: Device Name
Section 3 — Menus The smaller control panes on the right have Cue to Begin Stop , and Play control buttons. Var Play Speed button turns the variable speed function On and Off. When On, the device will play at the speed displayed when the Play button is pressed.
Page 249: Preset And Program Clip
External Device E-MEM Menus Preset and Program Clip Devices that allow clip selection (DDRs for example) are loaded with a spe- cific clip with the Preset Clip Program Clip data pads. Touching these pads bring up a clip picker menu. If the device is using the optional AMP Serial Machine Control feature, both folder and clip selections are available (Figure 168).
Page 250: Manual Control
Section 3 — Menus Manual Control Control settings in this menu are not saved to E-MEM. Use the Timeline Events menu and/or the Links menus for E-MEM control of external devices. External Device Event List Menu An Event List of DDR clips can be created and edited to arrange selected clips in a particular order.
Page 251: Clip Browser
External Device E-MEM Menus Clip Browser The name of the external device the menu is delegated to control is dis- played on the Device data pad at the upper left. Touching this data pad brings up the Device Picker, permitting selection of a different device (Figure 167 on page 248).
Page 252 Section 3 — Menus Paste button pastes the contents of the clipboard into the location cur- rently selected in the Event List. Move Up Move Down buttons moves the clip selected in the Event List up or down one location. When at the beginning or end of the, only one of these buttons will be active.
Page 253: Event List
External Device E-MEM Menus Event List The name of the currently selected list, if it has been saved, appears at the top of this scrolling pane. The green Loaded indicator illuminates for the clip that is currently loaded for playback (Figure 169 on page 250).
Page 254 Section 3 — Menus Figure 171. External Device Links Menu The External Device Links menu has two panes with scrolling lists, each listing the devices setup for Kalypso system control. A primary device is selected in the Primary Links pane on the left, and the devices that are to be linked to that primary device are selected in the pane on the right.
Page 255: E-Mem Control
External Device E-MEM Menus E-MEM Control The settings in this menu can be saved as E-MEM keyframes. When used in conjunction with the Timeline Events menu, it becomes possible to have an E-MEM register load, cue, and sync roll devices. External Device Newton Menu The separate Newton modular control system offers real-time control of Grass Valley modular products.
Page 256: R-Mem Menus
Section 3 — Menus R-MEM Menus The R-MEM menus are used on Kalypso systems that have been config- ured with an external router. Additional routed sources become available for pre-selection on the Kalypso source select buttons, increasing the number of inputs the Kalypso system can handle at one time. R-MEM Save-Load Menu The R-MEM Save-Load menu employs the Kalypso file browser and is used to save and load Router Memory files.
Page 257: R-Mem Menu
R-MEM Menus R-MEM Menu The R-MEM menu is used to learn, recall, and preview R-MEM registers. R-MEM registers are similar to E-MEM registers, but hold router source information used with the Kalypso system router interface feature. By recalling R-MEMs you can change one or more router sources associated with Kalypso system sources.
Page 258: Router Select Menu
Section 3 — Menus Router Select Menu The Router Select menu is used to select a different router source for a par- ticular router destination, and so changes that switcher source signal on the Kalypso system. It is also used to set router protections. The menu is accessed by touching (Figure 175).
Page 259: Pbus & Gpi Out Menus
PBus & GPI Out Menus PBus & GPI Out Menus The PBus (Peripheral Bus II) & GPI menus are used to specify the sending of trigger commands to external devices. GPI and PBus triggers are placed on keyframes when an effect is created. When working on an effect, this menu is used to change the working buffer to include trigger commands.
Page 260 Section 3 — Menus Up to 16 PBus triggers (0-15) can be associated with each external device on the PBus. When a device is defined (Eng Setups), names can be given to the device and each of its triggers. The actual action performed when a partic- ular trigger is sent is determined by the external device.
Page 261: Gpi Out Triggers Menu
PBus & GPI Out Menus GPI Out Triggers Menu The GPI Out Triggers menu is used to specify the sending of GPI type com- mands to external devices. The Kalypso system supports a total of 16 GPI outputs (1-16). The menu is reached by touching PBus &...
Page 262: Pbus & Gpi Out Enables Menu
Section 3 — Menus GPI Out Deterministic Triggers Kalypso version 10.1 adds a one field delay for GPI Out triggers to improve the deterministic behavior of E-MEM effects containing these triggers. Note Any E-MEM effects built with earlier software versions that rely on determin- istic timing of GPI or PBus triggers will need to be tested and probably adjusted.
Page 263: Aux Bus Menu
Aux Bus Menu Aux Bus Menu The Aux Bus menu is a source selector for Aux buses and can be used to define the B channel of an Aux Pair as either . It also allows the Video operator to set up the to be selected in Near Side Source Far Side Source...
Page 264 Section 3 — Menus panel is used to change the B side source. When a different source is chosen for the B channel (not associated with the video signal in the Sources menu) the SPLIT indicator will light to indicate a split key has been performed. Paired outputs are typically used with external DPMs.
Page 265: Timeline Menus
Timeline Menus Timeline Menus The Timeline menus provide a graphical representation of the current effect. Timeline menus can be used in conjunction with the Keyframe Edit controls in the Master E-MEM subpanel on the Main panel. The Timeline menus provide also editing controls for modifying keyframe effects on the timeline.
Page 266: Timeline - Edit Menu
Section 3 — Menus Timeline – Edit Menu The Timeline – Edit menu is accessed by touching Timeline Edit . When an effect is has been recalled the Timeline – Edit menu shows the location in time of all the keyframes for the currently enabled groups, and displays the current location of the time and edit cursors (Figure 181).
Page 267: Effect Editing Controls
Timeline Menus Two types of master timeline keyframes exist. Those from timelines that are delegated for editing are solid (edit keyframes). Those created from timelines that are not delegated for editing are colored cyan (time key- frames). Conceptually, there are actually two timelines superimposed on one another, the edit timeline and the time (or run) timeline.
Page 268 Section 3 — Menus The following soft knob controls are also available on all Timeline menus: soft knob is used to scroll to or enter the number of the key- Go to KF frame to move the cursor to. soft knob is used to scroll the cursor through the time of Jog Effect an effect.
Page 269 Timeline Menus Enable button brings up a screen that permits control of E-MEM level enables and delegates (Figure 182). Figure 182. Timeline Menu Enables and Delegations Controls Kalypso — Reference Manual...
Page 270: Timeline - Adjust Time Menu
Section 3 — Menus Timeline – Adjust Time Menu The Timeline – Time Adjust menu is used to modify keyframe and effect durations. The Timeline-Time Adjust menu is accessed by touching Time- (Figure 183). line Time Adjust Figure 183. Timeline- Adjust Time Menu The controls on this menu are duplicated in other Timeline menus, with the following exception: •...
Page 271: Timeline - Recall Run Menu
Timeline Menus Timeline - Recall Run Menu The Timeline - Recall Run menu (Figure 184) brings E-MEM functions pre- viously available only on the Main panel to the Menu panel. Recall, Run, Learn, Learn Sequence, Clear, and other related functions are accessible. Note E-MEM operations are available on both the Timeline-Recall Run menu and Main panel E-MEM subpanel.
Page 272: Mode
Section 3 — Menus Sequence indicator goes green when a effect Sequence is underway. Note The Effect Dissolve and Sequence indicators only report current activity. They do not indicate whether these attributes have been learned in the currently selected register. Mode The Mode pane selects which function will be performed with the other buttons on the menu (Recall, Learn, Learn Sequence).
Page 273: Learn Mode Controls
Timeline Menus Learn Mode Controls When mode is selected, the controls shown in Figure 185 become Learn available. Figure 185. Timeline Menu - Recall Run - Learn Mode button is used to specify the setting of this attribute when Effect Dissolve the register is learned.
Page 274: Learn Sequence Mode Controls
Section 3 — Menus Learn Sequence Mode Controls When mode is selected, the controls shown in Figure 186 become Learn Seq available. Figure 186. Timeline Menu - Recall Run - Learn Sequence Mode In this mode, pressing Bank and Register buttons on the right will immedi- ately update the registers with their sequence links.
Page 275: Path Control Access
Interpolation Paths Menu Path Control Access The Path category selection button at the bottom of the menu accesses the Interpolation Paths menu that provides controls over interpolation between keyframes (see page 275). Interpolation Paths Menu Path control determines how interpolation is performed through key- frames.
Page 276 Section 3 — Menus The menu is organized with Levels, Sublevels, and Path Group delegation panes on the left, and the actual path controls on the right. Some delegation panes scroll to access additional buttons. What appears in the Sublevels delegation pane depends on what has been selected in the Levels pane;...
Page 277 Interpolation Paths Menu Graphic symbols representing the Linear, S-Linear, Curve, and Hold path types appear on the Path control buttons. The selected path type symbol also appears next to each group delegation button. This symbol also appears next to each level or sublevel delegation button when all the sub- levels and/or groups for that item have the same path type (Figure 188).
Page 278: E-Mem Menus
Section 3 — Menus E-MEM Menus E-MEM - Save Load Menu The E-MEM Save-Load menu employs the Kalypso file browser and is used to save and load E-MEM files. Only this file format is supported in the menu. The menu is accessed by touching (Figure 189).
Page 279 E-MEM Menus Registers Datapad Register(s) datapad displays the currently selected registers. Registers are selected by touching their icons in the large pane on the upper left, and/or by touching this datapad (when active) to open a keypad where a register number or ranges or register numbers can be entered. Target Location field identifies where the selected registers will be saved Target Location...
Page 280 Section 3 — Menus • The Load button will be active if register(s) are specified in the text entry box. • The Save button will be active if register(s) are specified and the Start Reg button is off. Clicking Save or Load after selecting saves or loads the range Enter Reg(s) entered in the Register(s) text entry box to the Target Location specified...
Page 281 E-MEM Menus Select Reg(s) Button Selecting the Select Reg(s) button disables and clears the Register(s) text entry box, and automatically selects the Current Directory as the target location (Figure 193): Figure 193. File Operations E-MEM Select Reg(s) Button To enter a range you select a file or a set of files in the large pane on the upper left.
Page 282 Section 3 — Menus Figure 195. File Operations Load To Keypad For example, in Figure 196 clicking will load E-MEM files 1-3, and 9 Load into Registers 60-62, and 68. Because the box is set to 60, the system Load To starts loading at this new location.
Page 283: Source Holds Menu
E-MEM Menus Source Holds Menu The Source Holds menu is used to program holds into E-MEM effects. The menu is accessed by touching (Figure 197). E-MEM Source Holds Figure 197. Source Holds Menu During E-MEM recalls and effect runs sources can be programmed to change.
Page 284: E-Mem - Register Ops Menu
Section 3 — Menus E-MEM - Register Ops Menu The Register Ops Menu has a status pane on the upper left, a Function pane on the left, an Enable Group pane center left, and a Number Keypad on the right (Figure 198).
Page 285: Enable Groups
E-MEM Menus button copies the contents of the enabled levels of the current effect register to the specified register. Lock button locks the enabled levels of the specified register(s) or bank(s) of registers, preventing them from being changed unless the lock is removed.
Page 286: Input Mode Pane
Section 3 — Menus Input Mode Pane When a , or button is selected, the Input Mode Lock Unlock Clear Clear Seq Pane is displayed (Figure 199). Figure 199. E-MEM Register Operations Menu, Lock Selected The Input Mode pane is used to specify the scope of the action to be per- formed.
Page 287: Copy Swap Menus
Copy Swap Menus Copy Swap Menus The Copy Swap menus are used for copying setups from one part of the system to another. For example, if a chroma key was set up on M/E 1, but the operator needs the key while M/E 1 is in use, he can copy the keyer’s setup to M/E 2 and place the chroma key on air there.
Page 288: Copy Swap Me Menu
Section 3 — Menus Copy Swap ME Menu The Copy Swap ME menu is used to copy an entire setup from one M/E to another. Touch to access the menu (Figure 201). Copy Swap Figure 201. Copy Swap ME Menu Kalypso —...
Page 289: Copy Swap Wipe Menu
Copy Swap Menus Copy Swap Wipe Menu The Copy Swap Wipe menu is used to copy wipe settings from one location to another. Touch to access the menu (Figure 202). Copy Swap Wipe Figure 202. Copy Swap Wipe Menu Kalypso — Reference Manual...
Page 290: Copy Swap Matte Menu
Section 3 — Menus Copy Swap Matte Menu Touch Copy Swap Matte to access the Copy Swap Matte menu (Figure 203). Figure 203. Copy Swap Matte Menu Some combinations of M/E level, Key level, and matte generator level do not exist. For example, in Figure 203, the destination matte is M/E 1’s Trans Wipe.
Page 291: Copy Swap Keyer Menu
Copy Swap Menus Copy Swap Keyer Menu Touch Copy Swap Keyer to access the Copy Swap Keyer menu (Figure 204). Figure 204. Copy Swap Keyer Menu The menu enables the copying and swapping of entire keyers, including the mapping of key cutter and key fill sources. It is a direct copy of what is currently in the chosen From keyer, including key type, key split condition, and all parameters describing the key’s behavior.
Page 292: Copy Swap Source Memory Menu
Section 3 — Menus Copy Swap Source Memory Menu Touch Copy Swap Source Memory to access the Copy Swap Source Memory menu (Figure 205). Figure 205. Copy Swap Source Memory Menu The user delegates the M/E level, the keyer within the M/E, and the num- bered input source to the keyer.
Page 293 Copy Swap Menus When the All Sources button is off, the user can select a single source by touching the Source text box. This pops up the Source Picker menu arranged in numerical order, see Figure 206. Figure 206. Copy Swap Source Picker Menu Copying or swapping of keyer parameters applies only to like types of keying.
Page 294: Copy Swap Macro Menu
Section 3 — Menus Several defaults can be transferred in a single operation. The To pane’s selectors change to on/off LED buttons. The user can choose any combina- tion of default. The following scenarios might exist allowing the user to copy: •...
Page 295: Thumbnail View
Still Store Menus Thumbnail View Low resolution thumbnail views of Still Store images are displayed by default on the Still Store menu (Figure 207). Figure 207. Still Store Menu, Thumbnails View For animations, you can choose which frame to use as the thumbnail image for that clip (see Clip Playback Editing Controls on page 308).
Page 296 Section 3 — Menus 3. Touch the No Thumbnail View Style button (Figure 209). Figure 208. Still Store Menu, No Thumbnails View 4. After selecting a view style you are returned to your last Still Store operating menu (either Playback or Create Edit). Kalypso —...
Page 297: Still Store Icons
Still Store Menus Still Store Icons The Kalypso Still Store handles different types of stills and clips that can also be in different states (cached, locked, etc.). Icons are used to indicate the type and status of each clip and animation. Touching the button on the Still Store Playback or Create Edit menu Legend and Options brings up descriptions of what each icon represents...
Page 298: Still Store Playback Menu
Section 3 — Menus Still Store Playback Menu The Still Store Playback menu provides menu delegation to an output, still and clip selection, clip playback, video/key pair control, and position and crop controls. Touch to access this menu (Figure 210). Still Store Playback Figure 210.
Page 299: Preset Transfer To Program
Still Store Menus When an item is loaded to either a Program Preset button it is automati- cally locked into the cache, which protects it from being overwritten by other caching operations. When an item is unloaded from an output, either by being replaced with another item or with the button, the Unload Output...
Page 300: Delete Button
Section 3 — Menus Delete Button button initiates the delete process for the selected item in the Delete browser. When an item is deleted it is removed from the cache and its files are also deleted from that folder on the disk. If the item was loaded to an output, that output image will be blanked, even if on-air.
Page 301: Playback Controls
Still Store Menus Playback Controls When the Playback menu is selected, the center pane provides playback controls for the delegated output. button controls pairing of the delegated output for use Video Key Pair with key signals. Pairs are consecutive with the odd numbered output the video and the even numbered output the key (1-2, 3-4, 5-6, 7-8).
Page 302 Section 3 — Menus Touching the Position data pad brings up a pane on the right with Horizontal controls associated with the soft knobs Position Vertical Position (Figure 211). The image can be positioned anywhere on the screen. If crops have been applied, the crops track the position changes.
Page 303 Still Store Menus Touching the Crop data pad brings up a similar menu with Top Crop , and controls (Figure 212). The image can be Bottom Crop Left Crop Right Crop cropped to any rectangular shape. These controls are keyframeable but res- olution is limited to pixels and lines so interpolated motion may not appear smooth.
Page 304: Still Store Create Edit Menu
Section 3 — Menus Still Store Create Edit Menu The Still Store Create Edit menu provides many of the same controls as the Playback menu, but also provides still capture, clip recording, save con- trols, and also provides access to clip mark and loop editing controls. Touch to access this menu (Figure...
Page 305 Still Store Menus Grab Key button permits grabbing only the key portion of an image. This button is active only after a Video and Key grab has been performed. can be used if the video and key are supplied from separate Grab Key sources or are laid down sequentially on a graphics reel.
Page 306: Create Edit Menu Position And Crop Controls
Section 3 — Menus Create Edit Menu Position and Crop Controls Touching the Position and Crop data pads brings up the same controls available from the Still Store Playback menu (see Figure 211 on page 302 Figure 212 on page 303).
Page 307: Freeze And Clip Playback Editing Controls
Still Store Menus Note When the cache is full, older items will be uncached to make room for the new item. Long duration recordings involve lots of data and will clear many cached items. Saving a long recording also takes considerable time. Fenced recording can be used to reduce storage requirements and save times.
Page 308: Freeze Controls
Section 3 — Menus Freeze Controls The Freeze controls affect the appearance of a still image or a stopped clip. These controls are keyframeable. button selects a two field display. This display offers the highest Frame resolution, but moving video can cause flicker between the fields. buttons selects the specified single field display.
Page 309: Clip Loop Controls
Still Store Menus Note The Disable Marks button is intended for use as a clip playback debugging tool. The button automatically turns off when a different item is loaded to an output, when the output delegation is changed, and when the pane is closed with the Show Details button.
Page 310 Section 3 — Menus The Loop data pad at the bottom of the pane displays the loop points and loop count. Touching this data pad brings up a pane of soft knob controls on the right (Figure 217). Figure 217. Still Store Create Edit Menu, Loop Controls Note Loop button settings are ignored when Disable Marks is turned on.
Page 311: Still Store Cache Menu
Still Store Menus Still Store Cache Menu The Cache menu reports cache usage, and can be used to help manage the cache. Manual cache management is optional, as the still store cache oper- ates without operator intervention. When the cache becomes completely filled, older unlocked cached are deleted to make room for the caching of new items.
Page 312: Still Store File Ops Menu
Section 3 — Menus Unlock All button clears the locked statuses of all cached items (those loaded to outputs). Unlocking an item does not uncache it, but allows it to be uncached. Thus, after this button is pressed an item loaded to output could be automatically uncached, even if on-air.
Page 313: Still Store File Operations
Still Store Menus After a Still Store working directory change, if items from the previous folder have been cached, those items will continue be displayed on the list (they will be shaded) and they remain available for use. Note Avoid changing the working directory unnecessarily. Still Store material may become inaccessible or the wrong material may be loaded if items with the same names reside in different folders.
Page 314: Matte Menus
Section 3 — Menus Matte Menus The Matte menus give you control over matte color, type, and appearance. Category selection buttons exist at the bottom of each menu, allowing you to select M/E or Background mattes. Matte - M/E Menu When M/E or Pgm Pst is selected (Figure 220), touch pads are displayed...
Page 315: Matte - Background Menu
Transform Engine Menus Matte - Background Menu When BKGD is selected (Figure 221), the menu displays two panes for control of Bkgd 1 and Bkgd 2, including base and wash colors, wash direc- tion and offset, and wash edge texture attributes. Each touch pad activates the soft knobs to control those parameters.
Page 316: Transforms Menu
Section 3 — Menus Transform Engines also make use of the Effects Send menu, accessed from the Home menu by touching . This menu is used to turn on M/E. Effects Send Effects Send and assign Transform Engines to keyers (see Effects Send Menu on page 363).
Page 317: Transform Engine Menu Delegation
Transform Engine Menus Transform Engine Menu Delegation The Transform Engine menu contains a data pad matrix in the upper left for delegation (Figure 222). Data pads for keyers with Transform Engines assigned and Effects Send on will be active. Data pads for keyers that do not have Effects Send on will be grayed out and inactive.
Page 318: Crop Controls
Section 3 — Menus channel’s coordinate system for reference. Selecting the Target button pro- vides image adjustment using the screen as the reference. Only one space button is selectable at a time. Note Target Rot displays only Target Rotate transform parameter values, even when Source space is selected.
Page 319: Path Controls
Transform Engine Menus Path Controls The path control pane is located to the right of the data pad delegation matrix. S Linear Linear , and Curve interpolation touch buttons are available. When is selected, soft knob controls for , and soft Curve Tension...
Page 320: Picture Menu
Section 3 — Menus Picture Menu The Picture menu controls the appearance of an image (Blur, Freeze, Strobe) and provides motion interpolation controls for video interlaced formats. The menu is accessed by touching . These menus Transform Picture have different controls, depending on video format. The Kalypso Classic system menu is shown in Figure 223, and the Kalypso...
Page 321: Blur
Transform Engine Menus Note On Kalypso HD/Duo systems, frozen images are not ﬁltered when trans- formed. A frozen image will look perfect when captured, but transforming the image may produce visible artifacts. These artifacts are not present when live video is transformed on Kalypso HD/Duo systems, and are not present on Kalypso Classic systems with either live or frozen transformed video.
Page 322: Interpolation Path
Section 3 — Menus Frame interpolation disables motion detection and forces the creation of all new pixels from both fields of the interlaced frame. This is appropriate for still images and provides full vertical resolution processing. interpolation disables motion detection and forces the creation of all Field new pixels from only one field (the other field’s pixels are ignored in the interpolation).
Page 323: Drop Shadow Menu
Transform Engine Menus For example, 12 frames of frozen video with a 100% frozen duty cycle can be specified. The Transform Engine would then grab a frame and freeze it for 12 frames, and grab a new frozen video image every 12 frames. With a 50% frozen duty cycle using the same setting for 12 frames of frozen video, a still-frame would be displayed for 6 frames of video, followed by 6 frames of motion video.
Page 324: Drop Shadow Controls
Section 3 — Menus Drop Shadow Controls The Drop Shadow feature is turned on with the button in the Drop Shadow Drop Shadow pane. When turned on, soft knob controls become available on the right. Different soft knob controls appear, depending on which data pad has been selected in that pane.
Page 325: Transform Subpanel Drop Shadow Controls
Transform Engine Menus Transform Subpanel Drop Shadow Controls button on the Main panel Transform Subpanel delegates the Drop Shdw joystick to drop shadow control. The joystick X and Y axis adjust the drop shadow offset from the primary image and the joystick Z axis controls the size of the drop shadow.
Page 326: Menu Access
Section 3 — Menus Menu Access The Kurl menus are accessed by touching the button on the Home Transform menu, touching the Kurl category button, then touching the Kurl Mode button of the desired mode. Position/Size Modulation Mode Position and Size Modulation is an effect in which the source video is posi- tion or size modulated through an additive process with either a single wave train, or two wave trains with the second wave at a right angle to the first.
Page 327: Mod Type Pane
Transform Engine Menus Frequency — defines the modulation frequency and therefore the number of pattern cycles to appear across the source. Phase Speed knobs — The Phase Lock button on the right controls whether the pattern is fixed (on) or moving (off). When is on, Phase Lock Phase...
Page 328 Section 3 — Menus Cycle Limiting — activates the Cycles soft knob. This control can be used to limit the number of wave pattern cycles. Cycles + Only — selects only the positive portion of the wave cycle. Rep- resentative wave shapes are shown in Figure 229.
Page 329 Transform Engine Menus When Size Mod is selected in the Mod Type pane, the Size Mod Center data pad in the Modulation pane is active. When this data pad is selected soft knob controls for , and are available H Position V Position H/V Angle (Figure...
Page 330: Slits Mode
Section 3 — Menus Slits Mode Slits is an effect in which the source video is split into a number of parallel slits. The width of the slits may be uniform or random, and an angle may be specified. An offset function is provided which controls the amount of displacement of alternating slits in opposite directions (to cause a transi- tion type effect).
Page 331 Transform Engine Menus When the Slits data pad is selected a menu similar to Figure 232 appears. Figure 232. Kurl Menu, Slits Soft knob controls are provided to control various attributes of the slits: Offset — sets the distance adjoining slits move away from each other. This can be used for transition effects, using a zero offset for the starting keyframe and an off the screen offset for the ending keyframe.
Page 332: Page Turn/Roll Mode
Section 3 — Menus Page Turn/Roll Mode Page Turn is a transition effect with the video being mapped to an original plane, a cylinder, and a final plane parallel to the original plane. Page Roll maps the video to an original plane and a cylinder. Page Turn and Roll are parallel projections to the target screen with no perspective.
Page 333: Show Sides Pane
Transform Engine Menus Offset — positions the page turn cylinder with respect to the source plane and, when interpolated between keyframes, causes the page to turn. The offset would typically change from one edge or corner of the source raster to the opposite edge or corner for the turn. Base Opacity —...
Page 334: Ripple Mode
Section 3 — Menus Ripple Mode Ripple is an effect in which the source video mapped to a plane is effec- tively distorted into and out of the target screen by a train of concentric waves. This is a parallel projection to the target screen with no perspective. Touch the Kurl Mode button to access the slits controls.
Page 335 Transform Engine Menus When the Position/Aspect data pad is selected a menu similar to Figure 235 appears. Figure 235. Kurl Menu, Ripple Soft knob controls are provided to control various attributes of the Ripple pattern. — controls the horizontal position of the center of the ripple. H Position —...
Page 336: Sphere Mode
Section 3 — Menus Sphere Mode Sphere is an effect in which the source video is mapped to the surface of a sphere. Controls are provided which change the aspect and size of the sphere, the point in source video to be mapped to the center of the front surface of the sphere, and the horizontal and vertical scaling of the source video to be mapped.
Page 337 Transform Engine Menus When Wrap is selected in the Sphere pane, the following menu appears (Figure 237). Figure 237. Kurl Menu, Sphere Wrap The following soft knob controls are available: — controls where the image is mapped onto the Horizontal Position sphere by moving the image horizontally on the sphere’s surface.
Page 338: Splits Mirrors Menu
Section 3 — Menus Splits Mirrors Menu The Splits and Mirrors function allows you to divide a picture horizontally and/or vertically, and create mirror images of the image along these axes. Touch the button to access the Split and Mirror controls. When Splits/Mirrors button is on, the following controls are available.
Page 339: Split Modifiers Pane
Transform Engine Menus When the Sep Sides data pad is selected, individual soft knob controls for separation are available (T Separate, L Separate, R Separate, B Separate). These controls allow movement of individual Top, Left, Right and Bottom portions of the split image. Split Modiﬁers Pane The Split Modifiers pane has mirror and double image controls.
Page 340: Glow Menu
Section 3 — Menus Glow Menu Glow controls are available on the Transform Engine Glow menu, accessed . The Glow controls on the menu affect the delegated Transform Glow keyer on the menu. Only one keyer can be delegated at a time (Figure 239).
Page 341: Glow Matte Pane
Transform Engine Menus When the Glow pane is activated, knob controls for Glow Width Aspect , and are available. Opacity Softness Note Glow Softness is linked with Drop Shadow Softness and has priority. When both the Glow and Drop Shadow features are on, Glow Softness values are applied to both Glow and Drop Shadow Softness (see page 324).
Page 342: Defocus Menu
Section 3 — Menus Defocus Menu Defocus controls are available on the Transform Engine Defocus menu, accessed via (Figure 241). Transform Defocus Figure 241. Defocus Menu Defocus Pane — The Defocus effect is deactivated. — The Defocus effect is applied to the original keyed image. Defocus Defocus NAM + —...
Page 343: Nam Matte Pane
Transform Engine Menus When the Defocus pane is activated, knob controls for Video Defocus , and are available. Video Aspect NAM Ratio Video Defocus — Adjusts the total amount of defocus applied to the image. — Adjusts the percentage of defocus applied to the vertical Video Aspect and horizontal axes of the image.
Page 344: Lighting Menu
Section 3 — Menus Lighting Menu The Lighting menu provides four colored light sources positional in 3D space for each delegated keyer. Each light source can be a Point, Bar, or Plane. The apparent reflection of the light source simulates the physics of incident light falling on a surface, including specular effects and light falloff due to distance and geometry.
Page 345: Shadow Pane
Transform Engine Menus Shadow Pane The Shadow pane applies to all of the light sources for the delegated keyer and controls ambient lighting effects. You can control the color of the ambient lighting, and the amount of shadow falloff for the light sources. Soft knobs for degrees, and , and...
Page 346: Lighting Path Controls
Section 3 — Menus Flare When light reflects off a surface two lighting components result, the primary reflected light and a glare (flared halo) of scattered light. The Flare controls provide soft knobs to adjust this lighting component. Controls the amount of the flare light scattered off the Flare Intensity —...
Page 347: M/E Menus
M/E Menus M/E Menus M/E Mode Menu The M/E Mode menu can be used to select different M/E operating modes, including programmable clean feeds. The menu is accessed by touching (Figure 244). Mode Figure 244. M/E Mode Menu operating mode an M/E provides a main program output, a Normal preview output, and a totally clean feed output (no keys).
Page 348: Video Processing Menu
Section 3 — Menus Split operating mode, available with the DoubleTake option, an M/E is divided into a primary and secondary partition. Each Split Mode M/E par- tition can be assigned resources (keyers and wipe generators) of that M/E. Each partition can be setup and controlled from the Main panel using the delegation buttons, and each partition has its own E-MEM level, permitting precise independent control of M/E partition effects.
Page 349 M/E Menus Video processing is controlled with the Video Processing menu, accessed by touching (Figure 245). Video Proc Figure 245. Video Processing Menu – Luminance Proc Amp Controls Menu delegation panes (M/E, Bus) on the left permit selecting which bank and bus the menu’s video processing controls will be delegated to control.
Page 350: Proc Amp Controls
Section 3 — Menus Proc Amp Controls Proc Amp Luma and Chroma controls are available. Touching the upper Proc Amp data box in the Function pane displays Luma controls (Figure 245 on page 349). Touching the lower Proc Amp data box displays Chroma controls (Figure 246).
Page 351: Proc Amp Lum Graphic Detailed Description
M/E Menus indicator is displayed announcing uncalibrated video (Figure 245). When off, no processing is applied regardless of the values displayed, and the Proc Amp graphic traces dim (Figure 246). Parameter values are main- tained even when the function is off to permit convenient A/B comparison between processed and unprocessed video.
Page 352: Proc Amp Chroma Graphic Detailed Description
Section 3 — Menus signify the nominal black to white range. The solid graticule lines mark the absolute limits of the graph. The vertical scale is such that zero is at the black dotted line, 100 IRE is at the white dotted line. Luminance gain is represented by the slope of the trace.
Page 353 M/E Menus Mode button brings up controls for that function. The PseudoColor menu also has buttons that operate like those on the Proc Amp Reset to Unity menu. Figure 247. PseudoColor –Color Modulation Controls Color Modulation uses the luminance component of the processed video signal to mix between two color mattes.
Page 354 Section 3 — Menus Reset to Unity button sets the Mattes to white and black, set s Modulation Clip to 50%, and set Modulation Gain to 100%. Figure 248. PseudoColor – Hue Modulation Controls (Figure 248) operates like Color Modulation, but instead of Hue Modulation mixing between two color mattes, the modulating signal maps incoming luminance to matte hue.
Page 355 M/E Menus Saturation control can be adjusted from 0 to 100%. 100% means the chroma levels are the same as 100% SMPTE bars. 0% means black and white. The luminance values pass through the Hue Modulation processor unaffected. Modulation Gain Modulation Clip operate similar to standard Clip and Gain controls.
Page 356: Quantizer Controls
Section 3 — Menus Quantizer Controls Touching in the Function panel displays the Quantizer menu Quantizer (Figure 250), which controls posterization and solarization. Posterization breaks smoothly changing luminance values into quantized levels. Solar- ization creates quantized chrominance levels. Figure 250. Quantizer Controls Separate on/off controls for Solarize Posterize...
Page 357: Pixelator Controls
M/E Menus Pixelator Controls Touching in the Function panel displays the Pixelator menu Pixelator (Figure 251). The Pixelator produces a mosaic appearance. A representa- tion of the resulting mosaic effect is shown in the Pixelator Transfer Func- tion display. Figure 251. Pixelator Controls soft knob adjusts size of the tiles, in pixels.
Page 358: Mix Profile Display And Soft Knob Controls
Section 3 — Menus User transitions are defined using the User Transition menu and the Mattes menu. Controls on these menus adjust the appearance and timing of the Mix Through Video transition. User transitions are selected during pro- duction with the , and Next Transition buttons in each User 1...
Page 359: Intermediate Video Settings
M/E Menus Initial Mix Ends at control determines at what point the initial video becomes completely invisible and the intermediate video is completely opaque. determines where the final video begins to be visible Final Mix Starts at and intermediate video begins its transition to being invisible. The results of changes to these controls are reported in real-time in the Mix Profile display.
Page 360: Matte Menu And Mix Through Video Transitions
Section 3 — Menus Matte Menu and Mix Through Video Transitions Figure 253. Set Up White Matte To use a matte as intermediate video, select the button in the Base Matte Color – Source pane on the right of the menu. Use the matte controls to set the desired matte settings for the intermediate video.
Page 361: Source Select Menu
M/E Menus Source Select Menu A Source Select menu is accessible from the M/E and Keyer menus. The Source Select menu is used to change sources in real-time from the Menu panel. This menu makes it possible to select sources that are not mapped to any source select buttons.
Page 362 Section 3 — Menus Figure 255. Source Select Menu, Bkgd Layers Selected Sources are changed by choosing either the Key Layers or the Bkgd Layers, delegating the desired item (for example, M/E 1, Keyer 1 Fill, Near Side Source), and then selecting the source from the scrolling list on the right. You can tap the green area of the slider to display the next group of sources, and you can drag your finger on the slider handle to quickly scroll the list.
Page 363: Effects Send Menu
M/E Menus Effects Send Menu The Effects Send menu is used to assign Transform Engines and DPMs to Keyers, and to turn keyer Effects Send on and off. The menu is accessed by touching (Figure 256). The Transform Engine menu also has Effects Send a button that provides access to this menu.
Page 364: Effects Send Status
Section 3 — Menus Touching the Efx Send Active button will toggle Effects Send on or off for the delegated keyer. When toggled off, the Transform Engine or DPM Effect Send path channel becomes available for assignment to another keyer. Touching the button locks the assignment of that Transform Engine or Lock...
Page 365 M/E Menus from occurring by keeping a key off air for two fields when it is likely the wrong video would be displayed. Table 12 shows when the Kalypso system delays bringing an Effects Send key on air. Table 12. Key On Delay Conditions Effect Send State Off ->...
Page 366: Color Corrector Menu
Section 3 — Menus Color Corrector Menu RGB Color Correction is a software enabled option available on Kalypso HD and Duo systems. This feature converts the video signal on a particular video bus from color difference format to RGB (red, green, blue) color com- ponent format, applies separate offset, gain, and gamma to each RGB com- ponent, then converts from RGB back to color difference (Y, Cb, Cr) format.
Page 367 M/E Menus The Color Corrector Transfer Function pane contains three data boxes which serve as delegators. Each of these data boxes contains the Gain, Lift, and Gamma values. The three oscilloscopes show the input to output transfer characteristics of each color component's processor. They do not show actual video.
Page 368 Section 3 — Menus The value ranges are shown in Table Table 13. Color Corrector Value Ranges Control Minimum Maximum Nominal Units Gain Lift +100 Gamma -100 +100 Black +100 White +300 When one of the , or color component's data box is selected, Green Blue the knobs for...
Page 369 M/E Menus ponent is not turned on, it is still possible to adjust its color correction values, but they are not applied to the video. When a component is not turned on, the scope trace for the component is made a darker shade of green to further indicate that the transfer function is not being applied to the video.
Page 370: Keyer Menus
Section 3 — Menus scope’s border will turn white to show that Red is attached to Blue. Changing from Blue to either Green or Red in the Color Corrector Transfer Function pane will cancel the attachment. Touching the button will reset all attached components. Reset to Unity Keyer Menus Keyer menu controls are organized into several subcategories., each with a...
Page 371 Keyer Menus Show Key button displays the processed black and white keyer cut signal on the preview monitor. This is useful for evaluating the quality of the key. button displays the key on the preview output over the Push to Preview program signal.
Page 372: Borderline Menu
Section 3 — Menus Borderline Menu The Keyer Borderline menu is used for controlling Borderline.This menu subcategory is accessed by touching (Figure 262). B-Line Figure 262. Borderline Menu The 4 x 4 grid of data pads on the left are used to delegate one of the 16 keyers.
Page 373: Keyer Priority Menu
Keyer Menus Keyer Priority Menu Touching the Priority subcategory button takes you to the Keyer Priority menu (Figure 263). Notice that delegations remain the same when you move from one menu to another with the Subcategory touch buttons. In the figures, M/E 1 Keyer 1 is delegated in all the Keyers menus, and remains so unless changed with a delegation touch pad or from the Main menu.
Page 374: Keyer Priority Menu, Partition Delegation
Section 3 — Menus Keyer Priority Menu, Partition Delegation delegation buttons are active when the Double- Primary Secondary Take option is installed. When the Keyer Priority Stack pane is delegated to one of a split M/E’s partitions, only the keyers in that partition can be selected for stack reordering.
Page 375: Keyer Mask Menu
Keyer Menus Figure 265. Keyer Priority Menu, Current Priorities Changed See the separate Kalypso User Manual for more information about Double- Take split Mode M/E partitions. Keyer Mask Menu Touching the button on the Home menu, then touching the sub- Keyer Mask category button takes you to the Keyer Mask Point of Use menu.
Page 376: Mask Sources
Section 3 — Menus Figure 266. Keyer Mask Point of Use Menu Mask Sources For either type of selected mask (Force or Inhibit) six different mask sources are available and will appear in the data pad on the right of the screen.
Page 377 Keyer Menus Figure 267. Keyer Wipe Mask • Select the data pad below the data pad to Rotate Repeat Aspect bring up the pattern modifiers available for the keyer wipes. These include pattern positioner, rotate, H and V multiply, and aspect con- trols, similar to the controls in the separate Wipe Menu.
Page 378: Mask On Button
Section 3 — Menus Figure 268. Keyer Mask Modulation Menu – The Utility Bus mask sources originate from the utility bus in the Utility Bus chosen M/E. Typically these are used to bring in garbage masks from a Still Store or some external device. controls are available with this Clip Gain...
Page 379: Wipe Menus
Wipe Menus Wipe Menus The Wipe menus like the Keyer menus, have a delegation area at upper left, which in this case contains pattern touch pads for every wipe pattern gen- erator point of use. The currently selected shape is displayed on these touch pads.
Page 380 Section 3 — Menus In this menu you can pick the wipe pattern generator that will be used by a point of use, pick the direction of the transition wipe pattern, specify its border and softness, etc. For operating simplicity, you may decide to use the Complex wipe generators (C1 and C2) for main transitions, and the simpler Box and Keyer wipe pattern generators for the keyers.
Page 381: Primary And Secondary Partition Delegation
Wipe Menus Primary and Secondary Partition Delegation buttons allow menu delegation for transition wipe point of use attributes of an M/E split mode partition (available with the DoubleTake option). The button delegations only affect the transition wipe columns in the delegation matrix. The labels for these columns change , or ) when the delegation changes.
Page 382: Pattern Selection Menu
Section 3 — Menus Pattern Selection Menu Touching the touch pad in the C1 Generator window (the white area of the pattern will go blue) brings up the palette of wipe shapes available (Figure 271). Figure 271. Pattern Selection Menu Kalypso —...
Page 383: Pattern Modifiers Menus
Wipe Menus Pattern Modiﬁers Menus The other touchpads in the C1 Generator window bring up other wipe pattern modifiers (Figure 272). Figure 272. Pattern Modifiers Menu, Kalypso — Reference Manual...
Page 384: Wipe Pattern Number Guide
Section 3 — Menus Wipe Pattern Number Guide The following wipe patterns are specified by number for Kalypso system external editor control and for pattern selection on the 1-M/E Main panel. Table 14. Wipe Pattern Number and Name Vertical PENTAGON H SPLIT 8 PT STAR –...
Page 385: Other Menus
Other Menus Other Menus As the Kalypso software is enhanced, additional menus, subcategories, and controls will become available (see the Kalypso Release Notes for the latest menu additions and changes). Once you understand the principles of Kalypso system menu organization and operation, you will be able to quickly learn these new menus and use them effectively for your work.
Page 386 Section 3 — Menus Kalypso — Reference Manual...
Page 387: Section 4 - 1-M/E Panel Built In Menu
Section 1-M/E Panel Built In Menu Introduction The Kalypso 1-M/E Main panel has a built-in menu system, permitting operation without a separate Menu panel. This menu system uses an alphanumeric text display, five soft knobs, five soft buttons, and dedicated category and navigation buttons that permit adjustment of various opera- tional parameters.
Page 388: Menu/Joystick Delegate Subpanel
Section 4 — 1-M/E Panel Built In Menu Menu/Joystick Delegate Subpanel The Menu/Joystick Delegate subpanel (Figure 274) has a menu system and joystick that can be delegated to various control functions. The menu system and joystick is also used to adjust Source Name Display contrast. Figure 274.
Page 389: Valid Menu Delegation Combinations
Menu/Joystick Delegate Subpanel One selection in each of the top two rows is typically required to specify a specific point of use. For example, to delegate the menu to one of the 16 keyers, the operator specifies an M/E and a keyer (e.g., M/E 1, Key 2). However, there are cases where the delegation is completely identified by the top row alone.
Page 390: Active Joystick Delegations
Section 4 — 1-M/E Panel Built In Menu Active Joystick Delegations The joystick delegation interacts with the menu delegation buttons. The main delegations described above for the built-in menu, combined with the menu category buttons provide the basis for joystick point of use delega- tion.
Page 391: Built-In Menu Layout And Generic Behavior
Menu/Joystick Delegate Subpanel Built-In Menu Layout and Generic Behavior The menu system consists of five soft knobs, a two line 40 character alpha- numeric readout display, five soft function buttons (labeled ), and dedicated buttons (Figure 275). More Figure 275. Built-In Menu System Menu Readout Width...
Page 392: Current Parameter Value Display
Section 4 — 1-M/E Panel Built In Menu In a few cases, the soft knob or function button label displays a parameter’s value in addition to the parameter name. In these cases, the legend is of the form label : value In most cases, no delegation information is displayed in the menu.
Page 393 Menu Organization Figure 276 shows the menu for a Box, KeyWipe, or Complex wipe gener- ator. Figure 276. Width Opacity Size Soft Border Dir:N Gen:KW GenAdj Soft ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ The five soft knobs for this menu adjust wipe point of use parameters. buttons turn the border and softness wipe point of use Border Soft...
Page 394: Wipe Direction Menu
Section 4 — 1-M/E Panel Built In Menu Wipe Direction Menu ↓ ↓ ↓ ↓ This menu sets the direction of the wipe. Press the button to access this Dir: menu. Figure 278. M/E 1 Transition Wipe 1 direction Normal Reverse are a radio group.
Page 395: Complex Wipe Generator Adjust Menus
Menu Organization Complex Wipe Generator Adjust Menus This set of menus adjusts the complex wipe generator (C1 or C2). Press the ↓ ↓ ↓ ↓ GenAdj: button to access this menu. Pressing the More button accesses each menu page in turn. Figure 282.
Page 396: Wipe Positioner Mode Menu
Section 4 — 1-M/E Panel Built In Menu Split knob adjusts the magnitude of the pattern split. The Split button turns pattern split on and off. H Freq H Amp V Freq , and V Amp adjust the frequency and amplitude of the horizontal and vertical modulation, respectively.
Page 397: Wipe Modulation Waveform Menu
Menu Organization Logic for this group of buttons includes two parameters: an on/off for the rotation and a mode selection. Pressing turns the rotation off or on. Rotate Pressing any other button sets the mode parameter. Making a selection returns to the parent menu. Wipe Modulation Waveform Menu This menu selects the mode for pattern modulation.
Page 398: Drop Shadow Menus
Section 4 — 1-M/E Panel Built In Menu Soft adjusts the softness of all four edges equally. The joystick adjusts position and size when delegated to the point of use. Making a selection returns to the parent menu. Drop Shadow Menus Drop Shadow Top Menu Press the button to access the Drop Shadow menus.
Page 399: Mask Menus
Menu Organization Follow are a radio group that set the drop shadow crop mode. When Follow is selected, the shadow crop follows the crop defined for the main image. With Independent selected, the drop shadow crop can be adjusted independently from the controls in this menu. CropEdg CropSft are a local radio group that assign parameters to the soft...
Page 400: Keyer Menus
Section 4 — 1-M/E Panel Built In Menu Keyer Menus Press the Keyer delegation button to access these menus. Keyer Top Menus The Keyer top menu has three pages. cycles between them. More Figure 295. Clip Gain Size Opacity Typ:CK CK Adj B’Line AutoSet...
Page 401: Chroma Key Adjust Menus
Menu Organization Clip Gain adjust the associated parameters for the delegated keyer. These knobs appear in both pages of this menu. The Clip and Gain control labels change to if the delegated keyer type uses that Clip Hi Clip Low control methodology.
Page 402: Effect Send Select Menu
Section 4 — 1-M/E Panel Built In Menu Figure 302. Fringe Flare Sdw Den SdwClip SdwGain Fringe Flare Shadow AutoSet Clip Hi Clip Lo Size , and Opacity knobs adjust the associated keyer param- eters. Pri Hue Pri Sel (selectivity) and PriCsup PriLsup (color and luma suppression)
Page 403: Borderline Menu
Menu Organization Borderline Menu ↓ ↓ ↓ ↓ Press the button to access the Borderline Menu. B’Line Figure 305. Width Opacity Border Shadow Extrude Outline The soft knobs in this menu adjust the border line width, direction (8 steps) and opacity parameters. The five function buttons are a true radio group that sets the border line mode.
Page 404: Matte Menus
Section 4 — 1-M/E Panel Built In Menu Function buttons dim tally if they have not been specified. At the start, all buttons dim tally. They go out once they have been pressed to indicate they are no longer available (you can’t press the same keyer button a second time).
Page 405: Matte Point Of Use Delegation Menu
Menu Organization Offset Size knobs controls the position or size of the wash. It is labeled when the wash being adjusted is associated with a wipe Offset border (keyer preset pattern or transition wipe) and the generator chosen for the wash is the same as that chosen for the wipe itself. In this case the parameter controls the position relative to the center of the border allowing the wash to track the pattern size.
Page 406: Wash Generator Select Menu
Section 4 — 1-M/E Panel Built In Menu Wash Generator Select Menu This menu selects the generator used as the source for a wash point of use. ↓ ↓ ↓ ↓ Press the Gen: button to access this menu. It is similar to the generator selection menus for mattes and wipes.
Page 407: Effect Edit Menus
Effect Edit Menus Effect Edit Menus The Effect Edit menus are accessed by pressing the category button. Eff Edit Functions in these menus interact with the E-MEM subpanel. Effect editing operations are applied to delegated E-MEM levels which are set using the Master E-MEM enable buttons.
Page 408 Section 4 — 1-M/E Panel Built In Menu The first two buttons in the first page perform modify all operations either as a Relative modification or as an Absolute modification. The soft knobs above these buttons have no function and their label space is used to help label the buttons.
Page 409 Index Symbols 2-M/E Main panel models 300 Mode 111, +/- button 32-Crosspoint Remote Aux panel 4-M/E Kalypso Classic system Numerics options standard features 1-M/E Main panel 36, 153, 4-M/E Kalypso HD system and Resource Sharing options Bank Delegate subpanel standard features DPOP 155, 4-M/E Kalypso system...
Page 410 Index impact on Keyers and Masks subpanels Alt Buses source select modifier Auto Load button alternate action behavior Still Store Aspect Auto Recall Attach Enable R-MEM Auto Deleg on Keyers subpanel Auto Recall button Auto Recall Auto Run button 108, Auto Run 108, Auto Setup button...
Page 411 Index Go To Mark End Go To KF Mark Thumb Go To Mark Mask Invert Go To Time Mask On Grab Key mask source Grab SW Diag Data Master E-MEM Enable hold down modifier behavior Master E-MEM prefix group Hold Inputs Matte Fill Home Mattes subpanel base/wash fill group...
Page 412 Index Set as working directory capture controls Set Deleg CD-ROM Shadw Menu panel Shift source select modifier CD-ROM drive Show Input center of screen overlay Show Key change directory Show Macro Still Store restriction Shutdown OS Choose Load button single press behavior Chr button Size Loc Skew...
Page 413 Index keyer transition on Timeline menu transition Cut button control interactions other transitions control panel 1-M/E Main Daily Setups menus 2-M/E Main data pad 4-M/E Main explained button behavior Default Keyframe menu Local Aux Defocus menu Menu Delay data pad options Delegates button see also control surface...
Page 414 Index Dest Pane button natural duration recall Detent button Effect Dis button device status on source name display Effect Dissolve delay device definition Effect Dissolve button dialog button behavior Effect Dissolve indicator direct bank buttons Effect Dur button direct bank selection buttons on Timeline menu Master E-MEM Effect Edit menus...
Page 415 Index E-MEM Prefs menu odd field E-MEM subpanel File Operations All Files menu 1-M/E Main panel File Operations Show Save Load menu Emerg Bypass menu Fixed Lin button Enable buttons floppy disk drive Master E-MEM flow of video signal on Menu panel Force Mask button enabling forced duration...
Page 416 Index Interpolation Paths menu IP address hard disk drives Kalypso system nodes HD Transform Engine Still Store difference from Classic Video Processor frame hold Hold button hold down modifier button behavior Joystick button Hold Inputs button delegation Hold to Preview joystick delegation via Keyer delegation button 1-M/E Main panel...
Page 417 Index Keyer Delegation button Radius Keyer delegation button Kurl option bus delegation Hold to Preview momentary delegation Keyer Mask menu Lamina Video Compositing Keyer menus Last Deleg button 1-M/E Main panel impact on Keyers and Masks subpanels Keyer Mode menu 160, Last Menu button Keyer priority...
Page 418 Index and scrolling lists controlling Still Store on Menu panel delegation Still Store readout display Lock/Learn button macro adding to an E-MEM Locked append macro contents E-MEM indicator append using menu loop controls delete using menu Still Store insert delay using menu Loop From button record using menu Loop Sel button...
Page 419 Index mask controls Default Keyframe Defocus Mask Invert button Double Press Prefs Mask menus Effects Send 1-M/E Main panel EIC Login Mask On button E-MEM Prefs mask source buttons Emerg Bypass mask sources Eng Setups masking key control External Device Control External Device Enables Masks subpanel External Device Event List...
Page 420 Index Save-Load (Eng Setups) installation and orientation Save-Load (R-MEM) Menu Access touch button Security Account Setup menu category selection Shift Preferences menu screen Source Definition Menu Selection buttons Source Display Mode Selection touch buttons Source Memory numeric keypad Source Patch original Source Select Parameter Control area...
Page 421 Index monitor More button panel multi-suite operating mode 1-M/E Main 2-M/E Main 4-M/E Main Enhanced Menu natural duration Local Aux New Seq button Menu original Menu Newton External Device menu panel options Next Empty (.) button Parameter Control area Next Event button parameter display No Border button on 1-M/E Main panel menu...
Page 422 Index prefix button group readout display Master E-MEM E-MEM Machine Control subpanel prefix buttons on keypad Rec (Macro) button Preset Black button Recall button Prev Event button recalling effect in same bank Preview R-MEM record Macro preview Still Store overlays Record button (Still Store) Preview Prefs menu record macro...
Page 423 Index and 1-M/E panel operation scrolling lists component status Lock button desired component 200, Sec (secondary) button nodes Security Account Setup menu release all components Select All Levels button release component selecting release one component source release undesired components selecting menu categories Remote Aux panel assignment selecting preview signal Rest WrkBfr button...
Page 424 Index slot numbering standard features 2-M/E Classic system soft knob 2-M/E HD system Menu panel 4-M/E Classic system software download from web 4-M/E HD system source button tally Kalypso Duo Source Definition menu Start at KF button Source Display menu Status display source displays M/E information...
Page 425 Index Still Store File Operations menu System menu Still Store files independent of Show Still Store Playback menu tally stop clip event button using External Device menu function during M/E Copy/Swap stop macro of opposite shift pref source select button using Macro menu source button Stop Next button...
Page 426 Index transferring settings from one M/E to another Unshift source select modifier button Up Arrow Bank prefix button Transform Engine Up button Advanced Effects option 315, button Blur default crop Update Show button HD difference from Classic USB 250 MB Zip drive Kurl option user lines overlay Strobe...
Page 427 Index C1-2 Wipe button Wash Fill delegation button wash geometry button group Wash Geometry knobs web site documentation web site FAQ database web site Grass Valley web site software download wipe partition delegation Wipe C 1-2 button Wipe menus 1-M/E Main panel Wipe Pattern Mask Knob parameters Wipe Pattern Modifiers menu wipe pattern number guide...
Page 428 Index Kalypso — Reference Manual...

This manual is also suitable for:

Grass valley kalypso hd Grass valley kalypso duo

THOMSON Grass Valley Kalypso Classic Reference Manual

Preface

Section 1 - System Overview

Section 2 - Control Panels

Section 3 - Menus

Quick Links

Related Manuals for THOMSON Grass Valley Kalypso Classic

Summary of Contents for THOMSON Grass Valley Kalypso Classic
