DSLR-A200W

Specifications

General
Megapixel: 10.2MP
Imaging Device: 10.2 (effective) APS CCD Sensor;
23.6 x 15.8 mm; RGB primary color filter
Convenience
White Balance: Auto plus 8 Modes (Daylight,
Shade, Cloudy, Tungsten, Fluorescent, Flash,
Color Tempature/Color filter, Custom), each
with +/-3 adjustable step.
Self Timer: Yes (10 seconds, 2 seconds, Off)
Red-Eye Reduction: On/Off (all modes)
Burst Mode: Up to 3FPS; Unlimited to capacity of
media (JPEG L/M/S); Maximum 3 frames (RAW
+ JPEG); Maximum 6 frames (RAW)
Color Mode(s): Standard, Vivid, Portrait,
Landscape, Night view, Sunset, Black & White,
Adobe RGB (Except for Adobe RGB, all other
color modes use the sRGB color space)
Scene Mode(s): Portrait, Landscape, Sunset, Night
View/Night Portrait
Convenience Features
Histogram Display: Yes - RGB, playback only
AF Illuminator Light: Yes, On/Off Select
Multi-Pattern Measuring: 40 Segment, Center
Weighted, Spot
Clear RAW NR: N/A
Movie Mode(s): N/A
Inputs and Outputs
USB Port(s): Yes, Supports USB 2.0 Hi-speed
Output(s): Video: Yes, NTSC/PAL Selectable
Hardware
1
LCD: 2.7" TFT (230k pixels) LCD with Clear
Photo™ design
Viewfinder: Optical: TTL, 0.83x magnification with
50mm lens at infinity; 95% coverage
Microphone: N/A
Operating Conditions
Flash Effective Range: GN12 at ISO 100 (39 feet/
12 meters)
Flash Mode(s): Built-in Auto Pop-up: Auto, Fill-
flash, Rear flash sync, Slow Sync, High Speed
Sync, Wireless off camera flash (with Flash HVL-
F56AM, F36AM)
Optics/Lens
Focus: Auto Focus: TTL Phase Detection, Multi-
point: 9 Area, 8 Line, 1 Cross Sensor, Auto Focus
Mode: Yes, Adjustable Spot AF: Selectable
Sensor, Visual Focus Confirm: Direct via
Spherical Acute Matte Screen
Shutter Speed: 30 < 1/4000 sec 52 step, Bulb
EV Compensation: ±2.0 EV, 1/3 EV Steps
Exposure: Program Shift: Yes, Command Dial
Lens Type: Interchangeable A-mount
Power
Battery Type: NP-FM500H Lithium-ion rechargeable
battery
Battery Capacity: 7.2V, 1600 mAh; CIPA
4
standard: approx. 750 pictures
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
DSLR Camera w/ DT 18-70mm F3.5-5.6 Zoom & 75-300mm F4.5-5.6 Telephoto Zoom
Software
Supplied Software: Image Data Converter SR
ver.2.0, Image Data Lightbox SR ver.1.0, (all
Windows & Macintosh), Picture Motion Browser
Ver.2.1.02 (Windows only)
Operating System Compatibility: Microsoft®
Windows® 2000 Professional, ME, XP Home
and Professional; Macintosh® OS X (v 10.3 or
later). OS must be installed at the factory.
Processor
BIONZ™ Engine: Yes (LSI with Dynamic Range
Optimizer (DRO/DRO+))
Control
ISO: Auto/100/200/400/800/1600/3200
Dimensions
Weight: 1 lb. 2.8 oz (532g) body, not including
battery, lens and media
Measurements: (WHD) 5 3/16" x 3 7/8" x 2
13/16" (130.8 x 98.5 x 71.3 mm)
Service and Warranty Information
Limited Warranty Term: 1 Year Parts & Labor
Supplied Accessories
DT 18-70mm f3.5 Zoom lens (27 - 105 35mm eq),
75-300mm f/4.5-5.6 Compact Super Telephoto
Zoom
NP-FM500H rechargeable battery
BC-VM10 battery charger
Video and USB cables
Shoulder strap with eyepiece cap and Remote
Commander clip
Body cap
Software/USB Driver CD-ROM
NOTE: No Memory Stick media nor adaptors are
included.
Optional Accessories
Compact Flash Card (NCFB1G)
External Flash (HVL-F56AM)
External Flash (HVL-F36AM)
M Series Lithium Battery (NP-FM500H)
Vertical Grip (VG-B30AM)
AC Adaptor/Charger (AC-VQ900AM)
Color: Black
UPC Code: 027242714212
1: Viewable area, measured diagonally.
2: Actual results may vary based on product settings, usage patterns
and environmental conditions.
3: PhotoTVHD feature requires output via supplied Sony USB connector
cable with select Sony BRAVIA® HDTV; HDTV sold separately.
