INSTALLATION & MAINTENANCE MANUAL
SFPLxx
General INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
SFPLBC / SFPLMW
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this product is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
• This product is Class I and must be earthed
INSTALLATION
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires
• Ensure the wall surface is flat and smooth
• This unit is fitted with a gasket – this must not be removed: this gasket is to stop discolouration of the plate
due to natural moisture in some wall finishes
• This product must be fitted only after painting and decorating is complete
• Remove the front plate by placing a medium size flat-head screwdriver in the notch at the side and lever
off gently (see Fig. 1)
• Connect the accessory as per the diagram in this manual, ensuring the correct polarity is observed:
L – LIVE – Brown
N – NEUTRAL – Blue
EARTH – Green and yellow
• All earth connections must be made and maintained. Use green/yellow sleeving on earth conductors that
are not insulated
• Check all electrical connections are secure with no loose strands of cable
• Fit the unit into a suitable wall box taking care not to compress, damage, or trap any cables, and secure
with the screws provided. If using metal mounting boxes with four lugs, remove the top and bottom lugs
or bend fully back
• Clip the front plate onto the main assembly ensuring the screwdriver notch is at the side
