01. Overview

Multifunctional programmable 3rd generation MOSFET. The AEG controller has 11
functions. Its latest feature is the 3-rd Burst Mode, which allows for limiting the
number of shots. MERF 3.2 allows for lossless rate of fire adjustment. It protects
Li-Ion batteries: LiPoly and LiFePO4. It has a built-in active brake and it protects
contacts against damage. The Smart Trigger function enables achieving faster
trigger response. Thanks to two operating modes, the system works with both the
original and the modified AEG installation. The system is designed for all replicas
and especially for the upgraded ones. It has been adapted to work even with the
most powerful springs, including M170.
Main Functions
• MOSFET
• Active Brake
• Electronic Fuse
• Battery Protection
• Over temperature protection
• Debouncing
rd
• 3 Gen MOSFET
• ROF Control
• Smart Trigger
• 3-rd Burst
• Plug&Play
Operating Limits
Battery Voltage 7.2 - 12.8V
Battery Type NiCd, NiMH, Li-ion,
Li-Poly, LiFePO
Spring
M170, M210
WWW.GATEE.EU
Features
• The system works correctly in a wide
range of voltages 3.2 - 15V
• Compatibility with the strongest AEG
replicas
• Simple installation
• Protections
• Very low current consumption in
stand-by (0.15mA)
• Very low resistance ~2,4mΩ
• Compatible with all types of GearBox
• 4 LED Display
• DEANS-T Connectors
Absolute Maximum Ratings
Maximum continuous current
4
Supply Voltage
Maximum current (3 min)
Resistance
3.2 - 15V
35A
50A
2.4mΩ
