This unit is double insulated, and hence does not
need connection to earth. If earth continuity is
required, please use earth terminal on wall plate.
To reinstall the unit on the wall plate hook the top of
the unit over the retaining tabs, and push firmly back.
There will be some resistance from the terminals.
Once in place, secure with the retaining screws.
Restore mains to the unit after checking all system
wiring is complete.
4. Operation
Decide whether weekday/weekend (5-2) or individual
(7) day programming is required, and move the jumper
on the rear of the product (see Fig. 2). Also move the
system jumper to either G (gravity) or P (pumped) as
appropriate for the system.
It is important to make these decisions first, as after
any change of jumper position, reset needs to be
pressed, which will return the unit to default time
and programme.
Reset
When programming a new unit or one that has been
disconnected from the mains for more than
24 hours, open the program access flap and press the
reset button (see Fig. 1a) using a pen or
similar implement which will clear the memory.
All of the screen segments will show briefly, and then
the default programme will be displayed.
Setting time and date
To programme the current time and date,
simultaneously press and hold both the select
and set buttons for 3 seconds.
The option 12 hour or 24 hour is displayed and needs
to be set. Use the up and down buttons
the required mode. Press select to move to setting the
hours. Use the up and down buttons
hour, and press select to set the minutes. Again use
the up and down buttons to set the minutes,
and then select to set the year (y), the month (m), the
day (d), and automatic summer/winter time change or
daylight saving (dls) on/off, in each case using the up
and down buttons . Once the time and date have
been set, press set to exit back to the operating mode.
If at any time a button is not pressed for 15 seconds,
the unit will return to operating mode.
Individual (7 day) programming on/off times
The default on/off times for heating and hot water are
as follows:
6:00 AM on
8:00 AM off
10:00 PM on
12:00 PM off
6:00 PM on
10:00 PM off
These apply to every day independent of whether
weekday/weekend (5-2) or individual (7) day option
is chosen.
Note: to omit days and programmes please refer
to "Omitting days and programmes"
To change from default values, proceed as follows:-
Press set and MON will flash (with programme (P) Press set and MON will flash (with programme (P)
to select
1 on time for heating
P1 on hour digit(s) will flash, use
to set the
the required hours.
Press select and P1 on minute digits will flash,
use buttons to get the required minutes.
Press select and P1 off hour digit(s)) will flash,
use buttons to get the required hours.
Press select and P1 off minute digits will flash,
use buttons to get the required minutes.
Press select and programme (P) 2 on hour digit(s)
will flash, use
Press select and programme (P) 2 on minute digits
will flash, use
minutes. This procedure of alternatively using select
and can be continued to set programmes P2
and P3.
Once complete the programmes for hot water
Monday can be started by pressing the set button
when when MON will begin to flash and the hot water
symbol will be displayed. Press the
displayed). Press select and
buttons to get
buttons to get the required hours.
buttons to get the required
on
buttons
