Introduction

1.9. Connecting the myintercom video door intercom

LAN connection
The LAN connection is generally in the form
of an RJ-45 plug
nect the individual leads directly to a terminal
strip ; in accordance with EIA/TIA 568 B,
the network is connected to the terminals as
follows: 3 (green-white), 6 (green), 1 (orange-
white) and 2 (orange) whereby the number
denotes the respective pin of the RJ-45 plug
or socket.
Power supply
Power is supplied to the myintercom video
door intercom via the Behnke 15V power
supply. The use of any other power supply is
not permitted.
Switch output
Potential-free output for controlling a door
opener, maximum load 24V, 2A.
12V ~ 1A output
Power supply for door opener
Switch output
Potential-free output for controlling an exter-
nal door bell (recommended), maximum load
20V, 2A
34
. It is also possible to con-
If power supply for door opener is not availa-
ble on site:
If power supply for door opener is available
on site:
Connecting an external door bell:
External open door button
(on site)
Open door
function
External open door button
(on site)
Open door
function
External open door power
supply unit, max. 24 V, 2 A
Gong
(on site)
bell transformer (on site)
