Frog X Spike.pdf 1 24/07/2020 13:29:11
IMPORTANT: All wiring connections must be made before switching on mains power.
Xicato LED Module
This product should not be disposed of in your general waste
Please retain these instructions for future reference
Mike Stoane Lighting Ltd
20 Dryden Road Bilston Glen Ind Est.
Loanhead Midlothian EH20 9LZ UK
Frog X Spike
Installation and Maintenance
Instructions
Class III - Extra Low Voltage
IP66 Dust tight and protected against powerful jets of water.
European Conformity
T: +44 (0) 131 440 1313
F: +44 (0) 131 440 0049
sales@mikestoanelighting.com
www.mikestoanelighting.com
VAT No GB682885284
Limited Company 188910
Advertisement
Table of Contents
Related Manuals for Stoane Lighting Frog X Spike
Summary of Contents for Stoane Lighting Frog X Spike
- Page 1 Frog X Spike.pdf 1 24/07/2020 13:29:11 Frog X Spike Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. Xicato LED Module Class III - Extra Low Voltage This product should not be disposed of in your general waste IP66 Dust tight and protected against powerful jets of water.
- Page 2 Frog X Spike.pdf 2 24/07/2020 13:29:12 Electrical Supply Installation Installation must be carried out by a qualified electrician in Check that the ground is suitable for the installation of accordance with BS 7671:2008 Wiring Regulations. this fitting. For hard ground some preparation may be 230/240V AC 50/60Hz mains supply to a suitable SELV required for spike installation.
- Page 3 Frog X Spike.pdf 3 24/07/2020 13:29:12 MODULE AND ACCESSORIES The fitting uses a Xicato LED module. The colour temperature and lumen output can be found on the product label on the fitting. Tilt lock To Add/Remove accessories: Pan lock Isolate the fitting from the supply and allow to cool.
