Mushroom.pdf 1 02/06/2020 09:07:29
IMPORTANT: All wiring connections must be made before switching on mains power.
5 x MSL Star - 14.25V
7.1W (Total) @ 500mA
F
This product should not be disposed of in your general waste
Please retain these instructions for future reference
Mike Stoane Lighting Ltd
20 Dryden Road Bilston Glen Ind Est.
Loanhead Midlothian EH20 9LZ UK
Mushroom
Installation and Maintenance
Instructions
Class III - Extra Low Voltage
IP20
Indoor Use Only
European Conformity
T: +44 (0) 131 440 1313
F: +44 (0) 131 440 0049
sales@mikestoanelighting.com
www.mikestoanelighting.com
VAT No GB682885284
Limited Company 188910
Advertisement
Table of Contents
Related Manuals for Stoane Lighting Mushroom
Summary of Contents for Stoane Lighting Mushroom
- Page 1 Mushroom.pdf 1 02/06/2020 09:07:29 Mushroom Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. 5 x MSL Star - 14.25V 7.1W (Total) @ 500mA Class III - Extra Low Voltage This product should not be disposed of in your general waste...
- Page 2 Mushroom.pdf 2 02/06/2020 09:07:29 Electrical Supply Installation Installation must be carried out by a qualified electrician in Check that the ground is suitable for the installation of accordance with BS 7671:2008 Wiring Regulations. this fitting. For hard ground some preparation may be 230/240V AC 50/60Hz mains supply to a suitable SELV required for spike installation.
- Page 3 Mushroom.pdf 3 02/06/2020 09:07:29 Outdoor Indoor/Dry environment From 500mA LED driver 230/240V Supply LED Driver Soft ground...
- Page 4 Mushroom.pdf 4 02/06/2020 09:07:29 TH391 TEETUBE Connector WIRING IN SERIES These connectors can also be supplied in a 4-pole version which allows for series wiring. Observe polarity: Positive (+) is marked as RED. Incorrect supply or reverse polarity can cause irreparable damage.
