50mm ADL CP X.pdf 1 11/12/2019 12:49:26
IMPORTANT: All wiring connections must be made before switching on mains power.
Xicato LED Module
Not suitable for covering with thermally insulating material
This product should not be disposed of in your general waste
Please retain these instructions for future reference
Mike Stoane Lighting Ltd
20 Dryden Road Bilston Glen Ind Est.
Loanhead Midlothian EH20 9LZ UK
50mm ADL CP.X
Installation and Maintenance
Instructions
Class III - Extra Low Voltage
IP20
Indoor Use Only
European Conformity
T: +44 (0) 131 440 1313
F: +44 (0) 131 440 0049
sales@mikestoanelighting.com
www.mikestoanelighting.com
VAT No GB682885284
Limited Company 188910

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50mm ADL CP.X and is the answer not in the manual?

Questions and answers

Related Manuals for Stoane Lighting 50mm ADL CP.X

Summary of Contents for Stoane Lighting 50mm ADL CP.X

  • Page 1 50mm ADL CP X.pdf 1 11/12/2019 12:49:26 50mm ADL CP.X Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. Xicato LED Module Class III - Extra Low Voltage IP20 Not suitable for covering with thermally insulating material...
  • Page 2 50mm ADL CP X.pdf 2 11/12/2019 12:49:26 Electrical Supply Installation Installation must be carried out by a qualified electrician in Check that the mounting surface is suitable for the accordance with BS 7671:2008 Wiring Regulations. installation of this fitting. 230/240V AC 50/60Hz mains supply to a suitable SELV LED Driver.
  • Page 3 50mm ADL CP X.pdf 3 11/12/2019 12:49:26 Pan & Tilt locking Ø92mm cut out To LED driver Tightening the installation screws will swing out the tabs which clamp ceiling surface from behind, retaining the fitting. To Fit the Cover Plate Centrally locate the cover plate onto the bezel Slot aligning the slot with the flats on the ADL bezel.
  • Page 4 50mm ADL CP X.pdf 4 11/12/2019 12:49:26 MODULE AND ACCESSORIES The fitting uses a Xicato LED module. The colour temperature, drive current and lumen output can be found on the product label on the fitting. To Add/Remove accessories: Isolate the fitting from the supply and allow to cool. Step 1 Remove the circlip and any accessories.
