Stoane Lighting Mini Module Installation And Maintenance Instructions

Download this manual

Mini Module.pdf 1 11/12/2019 17:27:43

IMPORTANT: All wiring connections must be made before switching on mains power.

MSL Type S 2.85V

1.4W @ 500mA

This product should not be disposed of in your general waste

Please retain these instructions for future reference

Mike Stoane Lighting Ltd

20 Dryden Road Bilston Glen Ind Est.

Loanhead Midlothian EH20 9LZ UK

Mini Module

Installation and Maintenance

Instructions

Class III - Extra Low Voltage

IP65 Protected against low power jets of water.

European Conformity

T: +44 (0) 131 440 1313

F: +44 (0) 131 440 0049

sales@mikestoanelighting.com

www.mikestoanelighting.com

VAT No GB682885284

Limited Company 188910

Need help?

Do you have a question about the Mini Module and is the answer not in the manual?

Page 1 Mini Module.pdf 1 11/12/2019 17:27:43 Mini Module Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. MSL Type S 2.85V 1.4W @ 500mA Class III - Extra Low Voltage IP65 Protected against low power jets of water.
Page 2 Mini Module.pdf 2 11/12/2019 17:27:43 Electrical Supply Installation Installation must be carried out by a qualified electrician in Check that the mounting surface is suitable for the accordance with BS 7671:2008 Wiring Regulations. installation of this fitting. 230/240V AC 50/60Hz mains supply to a suitable SELV LED Driver.
Page 3 Mini Module.pdf 3 11/12/2019 17:27:43 OPTIC CHANGE To change the optic unscrew the front bezel, remove the black lens retaining collar and let the optic drop out. Repeat the process in reverse to fit the new optic. Suitable fixing Warning - Failure to tighten the bezel fully may result in premature failure of fitting.
Page 4 Mini Module.pdf 4 11/12/2019 17:27:43 Series Wiring SUPPLY Installation must be carried out by a qualified electrician in accordance with BS 7671:2008 Wiring Regulations. 230/240V AC 50/60Hz mains supply. Mains cables must be double insulated and strain relieved. Observe polarity: Positive (+) is marked as RED.
