Stoane Lighting Badger M Installation And Maintenance Instructions

Badger M with Install Sleeve.pdf 1 20/08/2020 15:49:24

IMPORTANT: All wiring connections must be made before switching on mains power.

MSL Type M 8.7V

6W @ 700mA

This product should not be disposed of in your general waste

Please retain these instructions for future reference

Mike Stoane Lighting Ltd

20 Dryden Road Bilston Glen Ind Est.

Loanhead Midlothian EH20 9LZ UK

Badger M

Installation and Maintenance

Instructions

Class III - Extra Low Voltage

IP66 Dust tight and protected against powerful jets of water.

European Conformity

T: +44 (0) 131 440 1313

F: +44 (0) 131 440 0049

sales@mikestoanelighting.com

www.mikestoanelighting.com

VAT No GB682885284

Limited Company 188910

Table of Contents

Need help?

Do you have a question about the Badger M and is the answer not in the manual?

Page 1 Badger M with Install Sleeve.pdf 1 20/08/2020 15:49:24 Badger M Installation and Maintenance Instructions IMPORTANT: All wiring connections must be made before switching on mains power. MSL Type M 8.7V 6W @ 700mA Class III - Extra Low Voltage This product should not be disposed of in your general waste IP66 Dust tight and protected against powerful jets of water.
Page 2 Badger M with Install Sleeve.pdf 2 20/08/2020 15:49:24 Electrical Supply Installation Installation must be carried out by a qualified electrician in Check that the mounting surface is suitable for the accordance with BS 7671:2008 Wiring Regulations. installation of this fitting. Max static load 5kN.
Page 3 Badger M with Install Sleeve.pdf 3 20/08/2020 15:49:24 Wiring diagram 230/240V Mains Waterproof Fitting connector SELV Driver S.E.L.V Output Series circuit: See driver instructions for further connection details and maximum fitting per driver. (if supplied) Wiring by others 110mm...
Page 4 Badger M with Install Sleeve.pdf 4 20/08/2020 15:49:24 Well drained ground Waterproof connector...
Page 5 Badger M with Install Sleeve.pdf 5 20/08/2020 15:49:24 Tilt and Pan Adjustment ENSURE that the locks are NOT OVER TIGHTENED Step 1 Remove the magnetic coverplate with the gloves supplied. Push the coverplate down and rotate Use the Allen key as shown to be...
