Stoane Lighting G3.2 Installation And Maintenance Instructions

Exterior led channel

Download this manual

IMPORTANT: All wiring connections must be made before switching on mains power.

IP66 Dust tight and protected against powerful jets of water.

Please retain these instructions for future reference

This product should not be disposed of in your general waste

G3.2 LED Strip Standard Output

Power

16.8 w per metre

Output

1496 lm per metre

STOANE LIGHTING

G3.2 Exterior LED Channel

Installation and Maintenance

Instructions

410 381 1497 inter-lux.com answers@inter-lux.com

Inter-lux reserves the right to make technical changes without notice.

Class III - Extra-low voltage

European Conformity

Suitable for Exterior use

G3.2 LED Strip High Output

Power

31.2 w per metre

Output

2702 lm per metre

Need help?

Do you have a question about the G3.2 and is the answer not in the manual?

Page 1 Please retain these instructions for future reference European Conformity Suitable for Exterior use This product should not be disposed of in your general waste G3.2 LED Strip Standard Output G3.2 LED Strip High Output Power 16.8 w per metre Power 31.2 w per metre...
Page 2 Dimming control circuit source must be of SELV insulation class. Ensure supply PSU and connectors are housed indoors OR in a suitably IP rated enclosure. STOANE LIGHTING 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
Page 3 PSU Mains Supply Power Supply Unit - 24V LED Strip LED Strip OT DIM (Optional) LED Strip 1 - 10V Dimmer LED Strip STOANE LIGHTING 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
Page 4 DO NOT OVER TIGHTEN TAB SCREWS Use the Allen key as shown to be finger tight only Over tightening the screws could result in irreparable damage. STOANE LIGHTING 410 381 1497 inter-lux.com answers@inter-lux.com Inter-lux reserves the right to make technical changes without notice.
