Assembly Instruction
4-fold switch decoder
from the Digital-Professional-Series !
SA-DEC-4-DC-B
Compatible to the DCC-Format:
(e.g. Lenz Digital Plus, Arnold-, Märklin-Digital=, Intellibox,
TWIN-CENTER, Roco-Digital, EasyControl, ECoS,
KeyCom-DC, Digitrax, DiCoStation, Zimo and others.)
(switching via Lokmaus 2® and R3® is possible)
For the digital control of:
⇒ consumers of up to 4 Ampere on each output
(e.g. illumination, switching track sections voltage free).
⇒
jammed turnout- and signal drives
(drives with integrated end switch).
This product is not a toy! Not suitable for children under 14 years of age!
The kit contains small parts, which should be kept away from children under 3!
Improper use will imply danger of injuring due to sharp edges and tips! Please
store this instruction carefully.
CE Part-No.:
21 21 72
yellow point
Introduction:
You have purchased a kit for your model railway supplied within
the assortment of Littfinski DatenTechnik (LDT).
The SA-DEC-4 kit is a high quality product which is easy to
assemble.
We are wishing you having a good time for assembling and
application of this product.
General:
Tools required for the assembly
Please assure that the following tools are available:
• a small side cutter
• a mini soldering iron with a small tip
• solder tin (if possible 0,5mm diameter)
Safety Instructions
• All electrical and electronic components included in this kit
shall be used on low voltage only by using a tested and
approved voltage transducer (transformer). All components
are sensitive to heat. During soldering the heat shall be
applied for a very short period only.
• The soldering iron develops a heat up to 400°C. Please keep
continual attention to this tool. Keep sufficient distance to
combustible material. Use a heat resistant pad for this work.
• This kit consist of small parts which can possibly be
swallowed from children. Children (especially under 3 years)
shall not participate on the assembly without supervision.
LDT
)
210211
Part-No.:
>> kit <<
Set-Up:
For the board-assembly please follow exact the sequence of the
below assembly list. Cross each line off as done after
completing the insertion and the soldering of the respective
part.
For the diodes and zener diodes please keep special attention
to the correct polarity (marked line for the cathode).The zener
diode D4 has a thicker connection wire and is suitable for
position D4 only.
With reason to different makes of electrolytic capacitors you
will find different markings of the polarity. Some are marked with
"+" and some are marked with "-". Each capacitor has to be
assembled to the board that the marking on the capacitor is in
correspondence with the marking on the pc-board.
Integrated circuits (IC`s) are either marked with a half round
notch on one end or a printed point for the correct mounting
position. Push the IC`s into the socket assuring that the notch or
the point is corresponding with the triangular marking on the pc-
board.
Please attend to the sensitivity of the IC`s to electrostatic
discharge which will cause immediate damage of the IC.
Before touching those components please discharge yourself
by contacting an earthed metal (for example an earthed
radiator) or work with an electrostatic safety pad.
Please attend to the mark "+" of the rectifiers. Some
manufacturers mark the "+" connections additionally with a
longer connection wire. If the rectifier shows as marking a
flattened side this side has to correspond with the marking on
the pc-board.
The relays are marked with a thick line on one side. This line
has to correspond to the marking on the pc-board.
Assembly List:
Pos. Qty. Component
1
1 Printed circuit board
2
1 Z-Diode BZX ... 5V1
3
2 Diodes 1N4148
4
1 Z-Diode BZX ... 30
5
4 Resistors 1,5kOhm
6
1 Resistor 18kOhm
7
1 Resistor 220kOhm
8
1 Resistor 1MOhm
9
1 Resistor 470 Ohm
10
3 Capacitors 100nF
11
2 IC-Sockets 18poles
12
1 IC-Socket 8poles
13
1 IC-Socket 6poles
14
1 Resonator
15
1 Electrolytic-cap. 100µF/25V attend to the polarity!
16
1 Electrolytic-cap. 220µF/35V attend to the polarity!
17
1 Rectifier
18
1 Push Button
19
4 Relays
20
2 Clamps 2poles
21
4 Clamps 3poles
22
1 IC: Z86E0..PSC
23
1 IC: ULN2803A
24
1 IC: 93C06 or 93C46
25
1 IC: 4N25 or CNY17
Internet: http://www.ldt-infocenter.com
Subject to technical changes and errors. © 05/2013 by LDT
Arnold, Digitrax, Lenz, Märklin, Motorola, Roco and Zimo are
Remarks
Ref.
attend to the polarity!
D1
attend to the polarity!
D2, D3
attend to the polarity!
D4
brown-green-black-brown R1..R4
brown-grey-black-red
R5
red-red-black-orange
R6
brown-black-black-yellow R7
yellow-violet-black-black R9
100nF = 104
C3..C5
IC1, IC3
IC4
IC5
CR1
C6
C7
attend to the polarity!
GL1
S1
attend to the position!
REL1..4
KL1, KL2
KL3..KL6
attend to the polarity!
IC1
attend to the polarity!
IC3
attend to the polarity!
IC4
attend to the polarity!
IC5
Final control
Made in Europe by
Littfinski DatenTechnik (LDT)
Kleiner Ring 9
D-25492 Heist/Germany
Phone: 0049 4122 / 977 381
Fax: 0049 4122 / 977 382
registered trade marks.
Done
