Vesta Smart Home Security Alarm System Installation Manual page 8

8
2
C Unpack all the parts
Door/ Window Magnetic Contact
1 Pull out the plastic
pull tab on the back of
the Keypad. This will
activate the batteries.
Panic / Help Button
1 Pull out the plastic
pull tab on the back of
the Keypad. This will
activate the batteries.
EXTERNAL OUT— DOOR Siren
Learn/Testing
Button
Magnetic install
Side indicators
Screw x 1
Learn/Testing
Button
Screw x 1
Installing / replacing Batteries in the Door /window contacts
Step 1. undo the screw at the button of the contact
Step 2. insert AAA battery supplied
Step 3. return the back and re - screw cover.
Step 4. Press learning/Testing button to active Sensor. (red light
Flash)
Step 5. Installing door magnet on the side marked on the door
contacts
Installing / replacing Batteries in the Panic Help Button
Step 1. undo the screw at the button of the contact
Step 2. insert EL123 battery supplied
Step 3. return the back and re –screw cover.
Step 4. Press learning/Testing button to active Sensor. (red light
Flash)
Installing / replacing Batteries in the External Out Door Siren
Step 1. undo the screw at the bottom of the Siren
Step 2. insert 4 x D cell battery supplied
Step 3. return the back and re –recrew
DOOR MAGNET
cover.
Door / window
Contacts
Diagram
6
8
