- Page 2 11 12...
- Page 3 Notes on safety Please observe the following instructions: The radio should only be connected to 230v / 50Hz A.C.. We recommend that you disconnect the power cord from the mains during extended absences. The ambient temperature should not exeed 35 C. Avoid locations close to radiators and do not expose direct sunlight.
- Page 4 Elements of operation - summary 2.1 Radio =On/off switch =Automatic Tuning System =Display for: Power on/Stereo =Switch for FM reception Mono/Stereo FM MONO STEREO =Antenna adjustment for the satellite clock =Setting frequencies/station search TUNING to higher frequencies =Setting frequencies/station search TUNING to lower frequencies =Display...
- Page 5 Installing the appliance The installation diagram can be found on the rear fold-out page. Your clock radio is designed to be installed under borders, kitchen cupboards or shelves etc. The front of the loudspeakers must be mounted pointing downwards and be free of obstructions to ensure the best possible sound quality.
- Page 6 Initial connection Plug the mains plug into a 230V / 50Hz AC socket. As soon as the appliance is plugged into the power supply the entire frequency range of the radio is searched for stations. A maximum of 20 stations will be programmed into the station keys 1-10 in accordance with their reception quality.
- Page 7 Innitial connection / Radio play 4.2 Setting the time manually If the clock radio does not receive the time signal with the switch at 2 you can also set the time manually. First press key and enter the correct time using the number keys 1-0 while holding this key down.
- Page 8 Radio play Press the keys briefly and the appliance moves 100kHz higher ( key )or lower frequencies ( key Holding key pressed for a short time, starts the station search which stops at the next station received. If a station is received which is already in the memory, M appears in the display followed by the applicable station number 5.3 ATS If the automatic tuning system (ATS) is to be restarted press...
- Page 9 Radio play 5.5 Interchanging two pre-programmed stations For example, to play the first station with station key 1 and to receive the second station with station key 2, the order of the stations from the automatic programming can be changed. Example: The first program is at station key 16 and should be played at Station key 1.
- Page 10 Timer 6.1 Automatic switch-on-alarm Your appliance has two independent alarm memories; one for the alarm with radio and one for the alarm with the beeper. Switch the alarm function on with key . By repeatedly pressing you can choose between radio alarm (display ), beeper alarm (display ) and the alarm with both beeper and radio (display + ).
- Page 11 Timer 2.Setting the alarm time To set the alarm time, press and hold key and enter the desired time using the number keys After releasing key the alarm time is active (the symbol is displayed followed by the programmed alarm time). At the pre-programmed time the appliance switches the last station heard The alarm time blinks.
- Page 12 Time 6.2 Sleep function With the radio turned on press key for a few seconds. In the display the minutes still to be played from 60:00 10:00 are displayed along with the symbol Upon reaching the desired remaining playing time, release key. The symbol and the remaining time are displayed to show that the sleep function is active.
