Warnings
Warning! Do not place the touchscreen near sources of
heat or expose to direct sunlight for an extended period
of time.
AVERTISSEMENT ! Ne placez pas l'unité près des
sources de chaleur ou exposition pour diriger la lumière
du soleil pendant une période prolongée.
Warning! Install in accordance with all national, state,
and local electrical codes.
AVERTISSEMENT ! Installez selon tous les national, état,
et codes électriques locaux.
Warning! This product generates heat. The room must
have adequate ventilation or the ability to dissipate heat
effectively.
AVERTISSEMENT ! Ce produit produit de la chaleur.
La salle doit avoir à ventilation proportionnée ou la
capacité d'absorber la chaleur efficacement.
Warning! Use this product only in dry locations.
AVERTISSEMENT ! Employez ce produit seulement dans
des endroits secs.
Caution! Do not use pens or sharp objects to navigate
or make selections on the touchscreen. To select an item
or scroll through a list, use your fingertip.
AVERTISSEMENT ! N'employez pas les stylos ou les
objets pointus pour diriger ou pour faire des choix sur
l'écran. Pour choisir un article ou un rouleau par une
liste, employez votre bout du doigt.
Caution! Improper use or installation can cause
DAMAGE OF PROPERTY.
AVERTISSEMENT ! L'utilisation ou l'installation inexacte
peut causer DAMAGE DE PROPRIÉTÉ.
Important! Using this product in a manner other than
outlined in this document voids your warranty. Further,
Control4 is NOT liable for any damage incurred with the
misuse of this product. See "Warranty."
Important ! Utilisant ce produit en quelque sorte autre
que décrit dans ce document vide votre garantie. De
plus, Control4 n'est pas responsable d'aucun dommage
encouru avec l'abus de ce produit. Voyez que «
Warranty. »
2

Specifications and requirements

Specifications
C4-T4IW10-BL, C4-T4IW10-WH,
Model Numbers
C4-T4IW8-BL, C4-T4IW8-WH
Resolution: 1920 × 1200, capacitive touch
Screen
Camera: 720p
Ethernet or Wi-Fi
• 802.11b/g/n 2.4 GHz
• 802.11a/n/ac 5 GHz
• Security: WEP, WPA/WPA2 PSK, 802.1x EAP, PEAP
Notes: (1) While technically the touchscreen can
use 802.11b, 802.11b is not supported. (2) 802.11n
Network
is recommended for best performance. Even
with 802.11n, broadcasting to several devices will
degrade Video Intercom response time and images.
Broadcasting to additional devices will further
degrade performance. See "Wireless Network
Limitations."
Power supply PoE (IEEE 802.3af) 13 W peak
8" model: 202 × 142 × 15 mm (8.0 × 5.6 × 0.59")
10" model: 239 × 165 × 13 mm (9.4 × 6.5 × 0.53")
Dimensions (W × H × D)
Wall box: 68 × 104 × 61 mm (2.7 × 4.1 × 2.4")
Power box: 71 × 114 × 46 mm (2.8 × 4.5 × 1.8")
8" model: 0.41 kg (0.9 lb)
Weight (with mid-box)
10" model: 0.68 kg (1.5 lb)
Operating temperature
0 to 40 ˚C (32 to 104 ˚F)
Storage temperature
-20 to 70 ˚C (-4 to 158 ˚F)
Requirements
• A controller fully installed and configured with Control4
OS 3.2.1 or later.
• Control4 Touchscreen wall box installed. See "Accessories."
• If using Ethernet with PoE power:
• Ethernet network installed and available that includes a
gateway/router/switch
• Control4 PoE Injector (model #AC-POE1-B) or another
third-party, UL/ANSI-certified PoE injector or switch.
• Two Ethernet Cat 5/6 cables: (1) one that runs from the
Ethernet gateway/router/switch to the PoE injector/switch
and (2) one that runs from the PoE injector/switch to the
Ethernet connection in the touchscreen's wall box.
• If using Wi-Fi with a PoE injector:
• Wireless network (IEEE 802.11b/g/n) installed and
available with a wireless access point (AP). Security can
be WEP, WPA/WPA2 PSK, 801.1x EAP, or PEAP.
