Icom OPC-2275 Instruction Manual page 2

REPLACING THE CONNECTOR
If the cable becomes damaged, replace the connector(s). Make wire connections as described below.
• Spare connectors* are supplied with the VE-PG3.
1
* 1 Manufacturer: DDK. Name: 232D-04S1B-DA5-FA (Equivalent to the OPC-2275 connector.)
The connector has two parts; a black base and a clear insert. DO NOT lock the connector parts before inserting all wires.
1
Inser t the wires into the holes
according to the assigned pin
numbers.
Connector Connector Connector
(Supplied with (Supplied with (Supplied with
the VE-PG3) the VE-PG3) the VE-PG3)
The wires for each hole are
assigned by color. See the
illustration below.
OPC-2275 connection and wires assignment
• Turn OFF the VE-PG3 and the transceiver before connecting or disconnecting the OPC-2275.
VE-PG3 (Rear view) VE-PG3 (Rear view) VE-PG3 (Rear view)
To [TRX1] (Upper slots)
A A B C
To the transceiver
• Follow the example to correctly connect the transceiver to [TRX1] on the VE-PG3.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan
2
Press the clear insert down
until it locks in place.
• After the insert is locked, it is
impossible to release it again.
PHONE LINE2 LINE1
Connector top (Expanded view)
B C
A
OPC-2275 White White White
Gray Gray Gray
Green Green Green
Black Black Black
RECOMMENDATION
If reconnecting is re-
peated about 30 times,
cut the wires
the connector and re-
place the connector.
*
2
* 3
A B
1 2 3 4 1 2 3
Brown Brown Brown Yellow Yellow Yellow
near
* *
2 3
1 2 3 4
Remove the cable from the VE-PG3,
before cutting the wires.
DO NOT cut the wires too short. Other-
wise it will be difficult to reconnect them
to the VE-PG3.
C
4 1 2 3 4
Red Red Red
Blue Blue Blue
