Charlton & Jenrick PARAGON BF Owner's Manual

Room sealed inset live fuel effect gas stove
Hide thumbs Also See for PARAGON BF:
Table of Contents

Advertisement

Quick Links

Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
PARAGON BF STOVE REMOTE
ROOM SEALED INSET LIVE FUEL EFFECT GAS STOVE
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARAGON BF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick PARAGON BF

Summary of Contents for Charlton & Jenrick PARAGON BF

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions PARAGON BF STOVE REMOTE ROOM SEALED INSET LIVE FUEL EFFECT GAS STOVE Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Literature NO 7613 Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 User instructions ............5 EXTENDED FIVE YEAR PARTS SECTION ONE Important Information ....5 WARRANTY SECTION TWO Introduction ........7 SECTION THREE Operating the Appliance ....7 In order to validate your extended 5 years parts SECTION FOUR Cleaning &...

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: PARAGON BF GAS STOVE Serial No. REMOTE This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: User Instructions

     The PARAGON BF REMOTE GAS STOVE is available in Natural Gas (G20 @ 20 mbar) and L.P.G (G31 @ 37 mbar). The markings (G20 for natural gas and G30 for L.P.G) on the packaging and the data badge specify the gas for which the appliance has been factory set.
  • Page 6  The slot located at the top of the PARAGON BF REMOTE GAS STOVE are the hot air outlets and as such must not be obstructed in any way (particularly by clothes or other combustibles). In addition the base of the appliance should not be obstructed by such items as this may adversely affect the performance of the appliance.

  • Page 7: Section Two Introduction

    SECTION TWO Introduction  The PARAGON BF REMOTE GAS STOVE is a freestanding room sealed live fuel-effect gas appliance designed for use in locations that do not have a conventional chimney. The appliance must be installed against an outside wall because the air to support combustion is taken from the outside and the products of combustion are expelled to the outside.
  • Page 8 (low setting) or ‘ B. The appliance can be adjusted up or down by pressing the appropriate button (high setting).There are 5 heat settings and the fire will give a double bleep when the maximum or minimum heat setting is reached. To switch off the appliance press the OFF button or if the appliance is to be switch off for a short period it is recommended that the ‘standby’...

  • Page 9: Section Four Cleaning & Fuel Bed Laying

    SECTION FOUR Cleaning & Fuel Bed Laying Warning: -Before you clean any part of the appliance ensure that the appliance is switched off and cool. CLEANING: BLACK PAINTED SURFACES  These surfaces should be dusted regularly and any marks removed with a soft cloth. ...
  • Page 10 Note: - If the fuel bed has not been placed correctly, causing the gas flame to contact the glass this may result in glass staining that cannot be removed by cleaning. Re-assemble in reverse order ensuring the seal is compressed evenly at the top and bottom Close the door and secure with the handle CLEANING AND REPLACING Fuel Bed Parts Important: - Refer to the ‘Health &...

  • Page 11: Log Bed Layout

    LOG BED LAYOUT The Log set as shown consists of:  Front Matrix  Rear Matrix  5 x Logs as shown  The Front Matrix is located as shown in front of the burner  The Rear Matrix is located so that it fits behind the burner (ensure it is not placed over the burner) www.charltonandjenrick.co.uk LT7613 ISS1...
  • Page 12  When positioning the rear matrix be careful not to cover the burner ports  Position the Logs as shown.  That completes the Log fuel bed assembly  Go to section eleven to complete the appliance assembly  Ensure the glass panel and other associated parts are fitted before lighting the appliance LT7613 ISS1...

  • Page 13: Section Five Replacement Parts

    SECTION FIVE Replacement Parts The only user removable parts are,  Glass panel frame  Refractory fuel bed components  Batteries www.charltonandjenrick.co.uk LT7613 ISS1...

  • Page 14: Installation Instructions

    INSTALLATION INSTRUCTIONS SECTION SIX Appliance Data Overall dimensions: Height 583 mm Width 490 mm Forward Projection: 335 mm Weight: 38.5kg 37kg Flue Length and duct length: 350mm (minimum) to 970mm (maximum) Standard lengths supplied with fire 2 x 535mm.Additional 535mm & 1m tubes supplied as optional extras. (No bends should be fitted in the flue pipe) Injector Tips ………………………………………...
  • Page 15 MODEL NG (G20) LPG (G31) Category of appliance C II C II Class Efficiency Class Gas Category Gas Type G20 Natural Gas G31 L.P.G Gas Pressure +/- 1.0mbar 20 mbar 37 mbar Gas Input (Max) 5.4 kW Gross 4.9 KW Gross (Min) 2.4 kW Gross 2.4KW Gross...

  • Page 16: Section Seven Regulations And Warnings

    SECTION SEVEN Regulations and Warnings  This appliance must only be installed in Great Britain or Ireland.  The appliance is available in natural gas and L.P.G.  Confirm that the appliance is suitable prior to installation (G20 for natural gas and G30 for L.P.G) (refer to data badge on base of appliance).

  • Page 17: Section Eight Siting The Appliance

    SECTION EIGHT Siting the Appliance GENERAL REQUIREMENTS *To minimise the risk of cracking due to heat expansion the use of a 3 – piece back panel is recommended*  The back panel of the surround must have a cut-out within the maximum and minimum dimensions as shown. ...
  • Page 18 Note: These dimensions are taken from the center of the circular flue outlet. Distances from NON-combustible materials: The stove can be recessed in a suitable sized non-combustible fireplace but a permanent free air gap of at least 50mm must be left around the sides and top of the stove to obtain reasonable heat output and for access to the stove for removal and maintenance.
  • Page 19 Clearance to Sides of Fire Minimum width between vertical sides of combustible surround and the sides of the stove should not be less than 300mm provided fire is central to the surround and sides do not project more than 50mm. When vertical side forward projection is increased by 12.5 mm add 50 mm to inside width of surround.

  • Page 20: Section Nine To Install The Appliance

    SECTION NINE To Install the Appliance INSTALLING THE APPLIANCE ONTO CAVITY WALL ( When installing in a timber framed dwelling reference must be made to the specific installation requirements stated later in this Section Installing The Appliance In Timber Framed Dwelling’). ...
  • Page 21 TIMBER FRAMED DWELLING This method allows for installation in timber frame buildings. Where removal of any part of the inner timber leaf of the wall is involved the structural integrity of the wall must be maintained and the advice of your local Building Control Department should be sought.

  • Page 22: Section Ten Assemble The Appliance

    SECTION TEN Assemble the Appliance  Position the refractory fuel bed components as described in section four of this manual, it is important that the fuel bed is positioned exactly as described to ensure the correct operation of the appliance. Badly positioned fuel bed components may result in the gas flame being driven forward onto the glass and permanently marking it.

  • Page 23: Maintenance Instruction

    MAINTENANCE INSTRUCTION SECTION THIRTEEN General  Servicing should be carried out annually by a competent person such as a Gas Safe-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance. Warning: - Before commencing any service or replacement of parts, turn off the gas supply to the fire. ...
  • Page 24 4. Reconnect the battery pack and test the operation of the appliance. When ordering parts quote ‘PARAGON BF GAS STOVE REMOTE’ and the serial number of the fire, which can be found on the data badge located on a plate attached to the rear leg.

  • Page 25: Section Fourteen Short Spare's List

    SECTION FOURTEEN Short Spare’s List Parts may vary/change due to development of products. A serial number should always be supplied when ordering parts to make sure you receive the correct part. Parts able to be ordered by customer Part Description Part Number Glass panel 7489...

  • Page 26: Section Fifteen Wiring Diagram (Maintenance Instructions)

    SECTION FIFTEEN Wiring Diagram (MAINTENANCE INSTRUCTIONS) Attach to the valve LT7613 ISS1...
  • Page 27 www.charltonandjenrick.co.uk LT7613 ISS1...
  • Page 28 LT7613 ISS1...
  • Page 29 www.charltonandjenrick.co.uk LT7613 ISS1...

  • Page 30: Balanced Flue Gas Fire Commissioning Checklist

    BALANCED FLUE GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.

  • Page 31: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 32 Serial No A-0677 Product ID Label Prefix (Ng) Serial No A-0692 Prefix (Lpg) Data Badge Burner Tray / Box Assembly Air Test Completed Warning Label (1409) Grommet (4554) Glass Sub-Assembly “AAA” Batteries ( 2) Remote Control Hand Set “AA” Batteries (12) Handset (6598) Battery Holder Log Set/coal set ( Complete )
