Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
Edge & Edge 3s BF Gas Stove
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 8019 (Issue 3)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Edge BF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick Edge BF

Summary of Contents for Charlton & Jenrick Edge BF

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions Edge & Edge 3s BF Gas Stove Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 SECTION ONE Introduction (Users Instructions) ..5 SECTION TWO Operating the Appliance (Users EXTENDED FIVE YEAR PARTS Instructions) ..............7 WARRANTY SECTION THREE Cleaning (Users Instructions) ... 8 SECTION FOUR Fuel Bed Cleaning and Layout (Users Instructions) ..............

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 Important For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: Edge / Edge 3s BF GAS Serial STOVE This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Introduction (Users Instructions)

    SECTION ONE Introduction (Users Instructions) Consumer Protection Information As manufacturers and suppliers of heating products, we take every care, as far as is reasonably practicable, that these products are so designed and constructed as to meet the general safety requirement when properly used and installed. To this end, our products are thoroughly tested and examined before despatch.
  • Page 6 Important Information • The Edge BF is for use on Natural Gas (G20 @ 20mbar) or LPG (G31 @ 37mbar). • The Edge 3s BF is for use on Natural Gas (G20 @ 20mbar) only. • Failure to install appliance correctly could lead to prosecution.

  • Page 7: Section Two Operating The Appliance (Users Instructions)

    SECTION TWO Operating the Appliance (Users Instructions) To light the appliance using the remote handset: A. Point the remote control handset in the direction of the appliance and simultaneously press the buttons marked ‘ off’ and ‘standby’. Continue to hold in these two buttons until a ‘bleep’...

  • Page 8: Section Three Cleaning (Users Instructions)

    Glass Cleaning From time to time it will be necessary to clean the glass panel of your Edge BF Gas Stove. We recommend you use a Ceramic hob cleaner these are available for all leading super markets: - i.e. ASDA, TESCO, SAINSBURY’S Etc.

  • Page 9: Section Four Fuel Bed Cleaning And Layout (Users Instructions)

    SECTION FOUR Fuel Bed Cleaning and Layout (Users Instructions) Warning: - • Before you clean any part of the appliance ensures that the appliance is turned off and cold. • Use only the fuel bed components provided and no additional parts must added. •...
  • Page 10 Place the other 3 base shapes as shown above. Place Embaglow in the 3 areas indicated. Place the front row of logs as shown above. LT8019...
  • Page 11 Place logs 8 & 9 as shown above. Place logs 10 & 11 as shown above www.charltonandjenrick.co.uk LT8019...
  • Page 12 Place the final 3 log shapes as shown. Please ensure that the flat edge of log 14 is touching the rear glass panel. LT8019...

  • Page 13: Section Five General Points (Users Instructions)

    Like all appliances incorporating an aerated burner a low frequency noise may be heard, particularly on the low setting, this is quite normal and does not affect the operation of the appliance. It is advised that a competent person service the EDGE BF fire annually. The fire is more likely to provide trouble-free operation.
  • Page 14 Edge BF Natural Gas (G20) Version LPG (G31) Version Category of appliance C II C II Class Efficiency Class Gas Category I 2H I 3P Gas Type G20 Natural Gas G31 LPG Gas Pressure +/- 1.0mbar 20 mbar 37 mbar...

  • Page 15: Appliance Dimensions

    Appliance Dimensions EDGE BF EDGE 3s BF www.charltonandjenrick.co.uk LT8019...

  • Page 16: Section Seven Regulations And Warnings (Installation Instructions)

    When unpacking the appliance please check the following items are included: Fuel Bed Owner Manual Handset Transformer Top blanking plate Front Cover grille Flue spigots SECTION SEVEN Regulations and Warnings (Installation Instructions) • This appliance must only be installed in Great Britain or Ireland. •...

  • Page 17: Section Eight Siting The Appliance (Installation Instructions)

    SECTION EIGHT Siting the Appliance (Installation Instructions) General Requirements Rear Exit • The flue and air duct length must be between 100mm to 600mm. The flue and air duct must not have any bends. The 600mm length of flue assembly can be cut down as required. •...

  • Page 18: Section Nine Preparing The Appliance For Installation

    Change spigot positions and fit the restrictor plate (if required) if installing with the top outlet flue system. • The appliance is now ready for installation. Optional stand The Edge Bf product can be fitted stove body only or with one the following options. LT8019...
  • Page 19 Front air deflector plate which is attached via the 4 screws and nuts needs to be removed when being fitted with the log store www.charltonandjenrick.co.uk LT8019...
  • Page 20 Please note suitable wall plugs fixings and screws must be used to support the weight of both mounting bracket / stove. Non-combustible hearth requirements The appliance must be fitted with a hearth that is 50mm high and projects 100mm to the front and sides. Minimum size of 626mm wide x 456mm deep x 50mm high.
  • Page 21 www.charltonandjenrick.co.uk LT8019...
  • Page 22 LT8019...

  • Page 23: Section Ten Installing The Appliance (Installation Instructions)

    SECTION TEN Installing the Appliance (Installation Instructions) INSTALLING THE APPLIANCE ONTO A CAVITY WALL. (When installing in a timber framed dwelling reference must be made to the specific installation requirements stated later in this Section ‘Installing The Appliance In Timber Framed Dwelling’).
  • Page 24 • Position and fix the flue cover bracket centrally to the core drilled hole. This will space the appliance 50mm from the rear wall or back panel. • Offer the appliance into position and mark through the gas pipe entry hole (see connecting the gas supply section).

  • Page 25: Timber Framed Dwelling

    • Pass a tape measure through the core-drilled hole and record the distance from the inner and outer spigots to the surface of the outside wall. Include the length of the spigots themselves in this measurement for the engagement allowance. •...

  • Page 26: Top Flue Up & Out

    TOP FLUE UP & OUT A top flue exit kit will be required (Part Number A-0803) consisting the following 1 off Restrictor plate. (Only to be fitted when vertical runs exceed 2 metres). 1 off Horizontal Terminal. 1 off 90 degree Elbow. 1 off 500mm Flue Pipe.

  • Page 27: Optional Flue Lengths

    Optional flue lengths Addition Flue Length Part Number 500mm Flue Length 8107 1000mm Flue Length 8108 Support Brackets 8117 SECTION ELEVEN connecting the gas supply (Installation Instructions) GAS SUPPLY ROUTING :- Use rigid or semi – rigid tube to connect the supply. Determine the gas supply pipe route to the appliance before installing the Stove.
  • Page 28 The cable system consists of retro fitting plug sockets which offers the following options. (Please see figure 5). The battery manual override option is a back supply in case of a power failure / power cut to the property. The battery holder and adaptor lead are provide as an optional extra.

  • Page 29: Section Twelve Checking Operation Of Fire (Installation Instructions)

    SECTION TWELVE Checking Operation of Fire (Installation Instructions) LAY FUEL BED Important: - Refer to the ‘Health & Safety Notice located on page 5 of this booklet before laying or replacing any refractory material. In the event of replacing fuel bed components please use only the specified number of components as illustrated. Only use fuel bed component provided for this appliance.

  • Page 30: Section Thirteen Maintenance (Maintenance Instructions)

    SECTION THIRTEEN Maintenance (Maintenance Instructions) GENERAL • Servicing should be carried out annually by a competent person such as a Gas Safe-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance. • Before commencing any service or replacement of parts, turn off the gas supply to the fire.
  • Page 31 Turn on the gas supply, check for soundness and re-commission the appliance. Replacement of the Electronic Control Unit (ECU) Undo the one M3 nut retaining the ECU unit and remove the connection bracket. Disconnect the power lead from the (ECU) Unplug the connections from the ECU board.

  • Page 32: Section Fourteen Wiring Diagram (Maintenance Instructions)

    SECTION FOURTEEN Wiring Diagram (Maintenance Instructions) LT8019...

  • Page 33: Section Fifteen Short Spares List

    SECTION FIFTEEN Short Spares List Parts able to be ordered by customer Part Description Part Number Bluetooth Handset 8081 Log Set 8096 Glass Panel 8100 Black Glass Left Side Liner 8099 Black Glass Right Side Liner 8098 Black Glass Rear Liner 8097 C cell battery holder (optional extra) 6878...
  • Page 34 Register your appliance online today to active your warranty LT8019...

  • Page 35: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 36: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 37 www.charltonandjenrick.co.uk LT8019...
  • Page 38 LT8019...
  • Page 39 www.charltonandjenrick.co.uk LT8019...
  • Page 40 Edge BF & Edge 3s BF Gas Stove A-0771 A-0864 Product Serial No A-0826 ID Label Prefix A-0865 A-0836 Burner Tray / Box Assembly Restrictor Elbow (2189) Log Fuel Set 8096 Glass Panel Data Badge Warning Label ID Label & Packing Labels...
