Charlton & Jenrick Ltd
GO ECO & GO ECO PLUS
STOVES
Freestanding Stove Range
5kW & 5kW Wide Nominal Outputs.
With Patented
Air System
TTi
Installation and Operating Instructions
Please hand these instructions to the stove user when the installation is complete. Leave the stove
ready for operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – These products must be installed by a suitably qualified
installer.
Clean Air Act Exemption
The CJ GO ECO & GO ECO Plus 5Kw, 5kw Wide stoves only have been exempted under the Clean Air
Act 1993 to burn seasoned wood logs in designated smokeless zones in the UK. This is subject to the
correct fitting of the air control plate (the part and fitting instructions are packed separately)
maintaining the air wash control at a minimum opening at all times. Instructions for wood burning
MUST be followed in order to ensure compliance at all times.
Charlton & Jenrick Ltd
Unit D Stafford Park 2, Telford, Shropshire, TF3 3AR
T: 0845 519 5991
F: 0845 519 5992
A Charlton and Jenrick Group Company
Advertisement
Table of Contents
Related Manuals for Charlton & Jenrick GO ECO 5Kw
Summary of Contents for Charlton & Jenrick GO ECO 5Kw
- Page 1 Charlton & Jenrick Ltd GO ECO & GO ECO PLUS STOVES Freestanding Stove Range 5kW & 5kW Wide Nominal Outputs. With Patented Air System Installation and Operating Instructions Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for operation and instruct the user in the correct use of the appliance and operation of controls.
-
Page 2: Table Of Contents
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. Charlton & Jenrick cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation. TABLE OF CONTENTS Section Page No 1. - Page 3 7. Operating Instructions 7.1 Safety Notes for your guidance 7.1.1 Fireguards 7.1.2 Modifications 7.1.3 Overfiring 7.1.4 Fume Emission 7.1.5 Chimney Fire 7.1.6 CO Alarms 7.2 Warnings 7.3 Clean Air Act (Smoke Control Zones) 7.4 Air controls 7.4.1 Air Control Operation 7.4.2 Air Wash 7.4.3 Tertiary Air 7.4.4 Multifuel Grate...
-
Page 4: Component Identification And Controls
2.0 Component Identification and Controls List of Components Description of Parts GO ECO Stove Assembly Fig 1 – GO ECO Ashpan Tool Assembly and controls. Ash Pan 5 Plus model shown. Flue Spigot Collar (installed) Flue Blanking Plate (installed) Stove Operating Gloves GO ECO Range Issue 01.1 05/17... -
Page 5: Preparation Of Stove For Installation
3.0 Preparation of Stove for Installation Your stove comes fully assembled, checked and packed in a protective plywood crate. Carefully remove the straps and lift off the top and upper crate. Remove any plastic packaging, open the door and remove all the contents. See List of Components section (above) and check contents carefully. -
Page 6: Important Safety Information
4.0 Important Safety Information 4.1. WARNINGS AND IMPORTANT SAFETY INFORMATION 4.1.1. READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION! These instructions cover the basic principles to ensure satisfactory installation of the stove, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with current local regulations including Building Regulations, Local Authority Byelaws and other specifications or regulations including UK or EU standards referred to as they affect the installation of the stove. -
Page 7: Fuels
4.1.5. Fuels Only use recommended fuels which are seasoned (or kiln dried) wood logs or smokeless briquetted fuels. The appliance can be damaged by burning petroleum coke, liquid fuels or general rubbish and this will invalidate your warranty and risk your personal safety. The appliance must not be used as a rubbish incinerator. -
Page 8: Ventilation
Where the chimney is believed to have previously served an open fire installation, it is possible that the higher flue gas temperature from the stove may loosen deposits that were previously firmly adhered, with the consequent risk of flue blockage. It is therefore recommended that the chimney be swept a second time within a month of regular use after installation. -
Page 9: Material Clearance Dimensions
5.5.1. Safety Distances from Combustible Surfaces: FREESTANDING MODELS Model Side (Full wall) Rear Rear Single Wall Flue Twin Wall Flue GO ECO 5kW (inc Plus) 700mm 450mm 300mm (From Top Plate) (From Top Plate) (From Heatshield) GO ECO 5kW Wide (inc... -
Page 10: Commissioning & Handover
The appliance shall be installed on a floor with adequate load-bearing capacity. If the existing construction does not meet this requirement, suitable measures (e.g. load distributing plate) should be provided to achieve it. 5.7. Commissioning and Handover CO Alarm: Building Regulations require that whenever a new or replacement fixed solid fuel or wood/biomass appliance is installed in a dwelling a carbon monoxide alarm must be fitted in the same room as the appliance. -
Page 11: Technical Data & Declaration Of Performance
6.0 Technical Data & Declaration of Performance (DoP) Manufacturer: Charlton & Jenrick Ltd. Range Designation: GO ECO freestanding stoves. Models: GO ECO 5, 5 Wide, 5 Plus and 5 Wide Plus with nominal outputs of 5kW. Intended Use: Domestic heating appliances Independently Performance &... -
Page 12: Operating Instructions
7.0 Operating Instructions Safety Notes for your guidance 7.1. 7.1.1. FIRES CAN BE DANGEROUS – Always use a fireguard to BS 8423:2002 Fireguards for use with solid fuel appliances in the presence of children, the elderly or the infirm. 7.1.2. DO NOT perform modifications to the appliance as this could seriously compromise safety in operation. -
Page 13: Warnings
Warnings: This appliance is not designed for open operation and therefore should not be operated with the doors open. This stove is designed to burn wood and smokeless fuels cleanly with high efficiency. However, for this product to work properly it must be used correctly. If used correctly this stove will burn with the very useful feature of clean glass. -
Page 14: Air Controls
Air Controls Keep air controls and inlets/outlets clean and free from ash or debris at all times. Keep ventilator air inlet grille (if fitted) clean and clear at all times. Do not leave air controls fully open unless monitoring the fire as over firing damage (typically bucking of components) can result which is not covered by any warranty. -
Page 15: Multifuel Grate
stove is controlled automatically by the draught in the flue and firebox. At certain stages of burning you will notice “jets” of swirling flame emerging near the air holes to the rear of the firebox. This is not always visible depending upon the fuels and burn cycle stage so there is nothing untoward happening if it cannot be seen. -
Page 16: Important Notes For Wood Burning
Note: Warning!- Petroleum coke fuels or household waste must not be burnt on this appliance. Should any difficulties arise over fuel quality or suitability, consult your local approved fuel merchant. Important Information for Wood Burning With a full load of wood and burning near nominal output the stove will need to be refuelled approximately every 45 min to 1.5 hours. -
Page 17: Primary Air Left Open
7.7.4 Primary Air left open Operation with the primary air controls left open: The air spinner on the door can create excess smoke and over-fire the stove if left open when burning wood. Leaving the door ajar when hot can also cause over firing and smoke emissions. Information on Smokeless Fuel (Maxibrite) burning Maxibrite, briquetted smokeless and smokeless coal type fuels require very different burning conditions to log burning and the stove has been designed to allow for this. -
Page 18: Re-Fuelling
Allow the fuel to reach a steady burn and usually the initial fuel can be left to burn down to charcoal without much further attention. Next build the fire up carefully by adding a couple of small split logs or an amount of Maxibrite briquettes at a time. -
Page 19: Shutting Down
7.11 Shutting Down The stove will normally shut down by itself as the fuel is consumed so there is no need to close the air control towards the end of the burn. In order to shut down the stove for other reasons, close air controls. -
Page 20: Maintenance Guide
8.0 Maintenance Guide 8.1.1 Removing Door. Remove the stove door by firstly removing the securing circlips from the bottom of each hinge pin. Use narrow nose pliers and keep the clips safe to re-fit later. Open the door to approximately 30 degrees and lift away to disengage the hinge pins. -
Page 21: Repainting
adhesive continuously onto the mounting face and apply the new rope evenly all around. NOTE: Ensure NO gaps at the meeting ends of any continuous loops or butt joints and that the rope sits properly into corners. Close the stove door and leave to dry for several hours before firing. -
Page 22: Dimensions
8.2 GO ECO 5kW Stove Principal Dimensions All Dimensions shown in mm. GO ECO Range Issue 01.1 05/17... -
Page 23: Go Eco & Go Eco Plus 5 Wide
8.3 GO ECO 5kW WIDE Stove Principal Dimensions All Dimensions shown in mm. GO ECO Range Issue 01.1 05/17... -
Page 24: Frequently Asked Questions
9.0 Frequently Asked Questions 1 Do stoves require a chimney or a liner? All of our stoves require a suitable chimney or professionally installed flue system. A liner may or may not be required depending on flue conditions and only your installer can confirm. Our stoves do not mandatorily require a liner. 2 How do I clean the chimney? You will require a chimney sweep to clean the chimney.
