Charlton & Jenrick PV5W Owner's Manual

Freestanding gas stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
PV5W FREESTANDING GAS STOVE
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 7271 (ISS 2)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PV5W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick PV5W

Summary of Contents for Charlton & Jenrick PV5W

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions PV5W FREESTANDING GAS STOVE Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 EXTENDED FIVE YEAR Benchmark Scheme ............. 3 PARTS WARRANTY SECTION ONE Introduction (Users Instructions) ..5 SECTION TWO Operating the Appliance (Users Instructions) ..............7 In order to validate your extended 5 years parts SECTION THREE Cleaning (Users Instructions) ..

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 Important For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: PV5W FREESTANDING GAS Serial STOVE This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Introduction (Users Instructions)

    The PV5W has been designed and tested for use in GB (Great Britain) and IE (Ireland).  The PV5W incorporates a single gas valve which selects ignition pilot, with variable setting between low and high setting and is operated via remote control hand device . This system is powered by battery pack consisting of 6 off High Power Alkaline C 1.5V.

  • Page 6: Important Information

    Important Information  The appliance is for use on Natural Gas (G20 @ 20mbar) Only.  The chimney or flue (unless new or previously used with a gas appliance) shall be swept before installation if it has been used for solid fuel. ...

  • Page 7: Section Two Operating The Appliance (Users Instructions)

    SECTION TWO Operating the Appliance (Users Instructions) To light the appliance using the remote hand set: a. Point the remote control hand set in the direction of the appliance and press the button. Continue to hold the button for approximately 2 seconds and release. When released a bleep should be and heard the appliance will automatically go through the ignition sequence and the pilot should ignite.
  • Page 8 TO REPLACE BATTERY IN HAND SET (3 AAA TYPE BATTERIES) Remove the cover from the rear of the handset and fit replacement battery. Clock Regulation As soon as the batteries are fitted the timer digits will blink. Using the arrow key increase or decrease the hour, minutes and week`s value.
  • Page 9 TO REPLACE APPLIANCE BATTERIES (6 High Power Alkaline C 1.5V) a. Remove the trim or inlet cover plate. b. Remove the battery holder from within the protective cover or battery holder and replace the six high power alkaline C batteries as a complete set. WARNING, batteries will overheat if fitted incorrectly, when fitting the batteries ensure that they are fitted as per the marking on the rear of the holder (i.e.

  • Page 10: Section Three Cleaning (Users Instructions)

    Glass Cleaning From time to time it will be necessary to clean the glass panel of your PV5W Gas Stove. We recommend you use a Ceramic hob cleaner these are available for all leading super markets: - i.e. ASDA, TESCO, SAINSBURY’S Etc.

  • Page 11: Section Four Fuel Bed Cleaning And Layout (Users Instructions)

     On stubborn stains (where the appliance as been used for a long period without glass panel being cleaned), use a new Brillo Pad well wetted with the Hob cleaner applied directly to it.  Ensure all the residues of the cleaner are removed with a damp cloth and the glass panel is completely dry before closing/rehanging the door and refastening the door to the stove.
  • Page 12 Log Fuel Bed Layout LT7271 (ISS 2)
  • Page 13 www.charltonandjenrick.co.uk LT7271 (ISS2)
  • Page 14 LT7271 (ISS 2)
  • Page 15 www.charltonandjenrick.co.uk LT7271 (ISS2)

  • Page 16: Section Five General Points (Users Instructions)

    Like all appliances incorporating an aerated burner a low frequency noise may be heard, particularly on the low setting, this is quite normal and does not affect the operation of the appliance. It is advised that a competent person service the PV5W fire annually. The fire is more likely to provide trouble-free operation.
  • Page 17 Appliance Dimensions :- PV5W GAS STOVE DIMENTIONS Data Badge located on the base of the Fire box. NOTE: The efficiency of this appliance has been measured as specified in BS EN 613:2001 and the result is 67.0%. The gross calorific value of the fuel has been used for this efficiency calculation. GasTec have certified the test data from which it has been calculated.

  • Page 18: Section Seven Regulations And Warnings (Installation Instructions)

    SECTION SEVEN Regulations and Warnings (Installation Instructions)  This appliance must only be installed in Great Britain or Ireland.  The appliance is suitable for use on natural gas and propane  GB (Great Britain) This fire does not normally require purpose build ventilation. ...

  • Page 19: Section Eight Siting The Appliance (Installation Instructions)

    Note: Dampers or register plates must not restrict any of the above flues. The flue must only service a single appliance and not have any branches or traps, which may impede the natural draught. If a terminal is fitted it must be suitable for the purpose. Note: A non combustible hearth must be provided beneath the appliance and must extend outwards all around the appliance base.
  • Page 20 Flue pipe used for this type of installation must be 125mm ( 5ins ) minimum diameter and 3 metres minimum effective height. Rear Exit : Using optional PV5W Gas Stove rear vent Kit ( Part Number A-0644 ) LT7271 (ISS 2)
  • Page 21 To achieve the rear exit option, the appliance gather hood will need to be removed. The outlet spigot from with the rear vent kit will need to be attached to the firebox assembly and engaged within the closure plate. www.charltonandjenrick.co.uk LT7271 (ISS2)
  • Page 22 LT7271 (ISS 2)
  • Page 23 Note:- When installing the appliance using the above method. The appliance must sit hard against the closure place. This will allow 50mm of the rear spigot assembly to protrude into the catchment area. Distances from combustible materials: It is strongly recommended that any furniture or other combustible materials are kept at least 900mm clear from the front of the stove.
  • Page 24 Clearance to Shelf Minimum clearance from hearth to underside of combustible shelf should be 740mm provided the shelf depth is 75mm (3”). This gives a minimum clearance above the appliance of 150mm. For a shelf of 150mm (6”) the minimum height above the hearth must be 800mm.

  • Page 25: Section Nine To Install The Appliance (Installation Instructions)

    SECTION NINE To Install the Appliance (Installation Instructions) CHECKING THE FLUE AND FIRE OPENING  Check that the chimney conforms to the required specifications as previously stated. Examine the condition and carry out any remedial work including removing any debris from the base. ...

  • Page 26: Section Ten Checking Operation Of Fire (Installation Instructions)

    CHECKING GAS SOUNDNESS Checking gas soundness and running pressure. Turn on the supply to the appliance and check for soundness in accordance with the current codes of practice. Turn off the gas supply at the external isolation valve. Remove the pressure test point screw from the inlet elbow and connect the pressure gauge. Turn on the gas to the appliance at the isolation valve.
  • Page 27 Once fuel bed is fitted refit the glass Locate the glass panel within the bottom retaining slot and push back against the seals. (Please see Fig 11). Position the top fixing bracket over the top edge of the glass panel and slide over the four M4 studs.

  • Page 28: Section Eleven Maintenance (Maintenance Instructions)

    ADVISE CUSTOMER THAT:  The glass front of this fire acts as a dress guard, conforming to BS 1945 (1997) and satisfies the heating appliance regulations (1991) however; a fireguard conforming to BS6539 (1997) must be used to protect young children, the elderly, or infirm.
  • Page 29 To Remove The Burner Carrier Assembly Remove the glass panel as described on page 10 of the users instruction section. Remove the Loose shapes and the air tray assembly. Remove the four screws retaining the gas inlet plate and the ECU cover. Shut off the restrictor elbow and disconnect the 8mm inlet nut.
  • Page 30 Replacement Of The Gas Valve Follow the sequence to remove the burner carrier assembly. Disconnect the thermocouple from the rear of the gas valve. Undo the three compression nuts securing the pipes to the gas valve and remove the two M4 nuts fixing the valve to the valve mounting brackets.
  • Page 31 Replacement of the burner Assembly Remove the glass panel as described on page 10 of the users instruction section. Remove the Loose shapes and the air tray assembly. Undo the three fixing screws retaining the burner assembly with the carrier. Lift the burner clear of the silencer and injector tip.
  • Page 32 LT7271 (ISS 2)
  • Page 33 Register your appliance online today to active your warranty www.charltonandjenrick.co.uk LT7271 (ISS2)

  • Page 34: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 35: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 36 PV5W Gas Stove A-0634 Product Serial No ID Label Prefix Burner Tray / Box Assembly Restrictor Elbow (2189) Log Fuel Bed (7176 ) Glass Panel Closure Plate Data Badge Warning Label ID Label & Packing Labels Owners Book Bottle Of Black Paint...
