Charlton & Jenrick INFINITY 780 FL Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
780 FL
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 5878 (ISS 14)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INFINITY 780 FL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick INFINITY 780 FL

Summary of Contents for Charlton & Jenrick INFINITY 780 FL

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions 780 FL Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 SECTION ONE Introduction (user instructions) ..5 EXTENDED FIVE YEAR PARTS SECTION TWO Operating the Appliance (user WARRANTY instructions) ..............7 SECTION THREE Cleaning (user instruction) ....7 In order to validate your extended 5 years parts SECTION FOUR Fuel Bed Cleaning and Layout (user warranty please read the Benchmark Scheme on the...

  • Page 3: Benchmark Scheme

    For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: INFINITY 780 FL Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.
  • Page 4 Installer information required to register for the extended warranty Name: Date of installation: Gas safe number: LT5878 (ISS 14)

  • Page 5: Section One Introduction (User Instructions)

    SECTION ONE Introduction (user instructions) Consumer protection information As manufacturers and suppliers of heating products, we take every care, as far as is reasonably practicable, that these products are designed and constructed as to meet the general safety requirement when properly used and installed. To this end, our products are thoroughly tested and examined before despatch.
  • Page 6 IMPORTANT INFORMATION • The appliance is for use on Natural Gas (G20 @ 20mbar) or L.P.G. (G31 @ 37mbar) only. • The chimney or flue (unless new or previously used with a gas appliance) shall be swept before installation if it has been used for solid fuel.

  • Page 7: Section Two Operating The Appliance (User Instructions)

    SECTION TWO Operating the Appliance (user instructions) Display overview Press to awaken the handset from its dormant sleep mode at any time. Fig 1 shows the display neutral, ready to turn on. Turn on (start up). displays an “UNLOCK” graphic Fig 2 prompting the Pressing and holding button to be pressed simultaneously.
  • Page 8 Flame height adjustment Once the fire has been started the flame height can be decreased by moving your finger clock wise or decreased moving your finger anti-clock wise using the selector wheel. Once the desired flame level is set, remove your finger from the selector wheel to transmit your selection to the receiver. Six flame levels and a pilot setting are selectable.
  • Page 9 Adjusting target temperature Use the selection wheel to increase or decrease the temperature to the desired level, release your finger from the wheel to transmit the target temperature (See Fig 5) to the receiver. The “auto” function will now modulate the flame height to achieve your target temperature. The selectable temperature range is 1 degree C to 29 degree C.

  • Page 10: Section Three Cleaning (User Instruction)

    SECTION THREE Cleaning (user instruction) Warning: - Before you clean any part of the appliance ensure that the appliance is turned off and cold. CLEANING: PILOT ASSEMBLY (Before cleaning ensure that the appliance is turned off and cold) In some instances you may experience ignition problems even when the appliance is new. This may be due to the aeration hole in the pilot body being partial blocked with dust, pet hairs, or other foreign matter.

  • Page 11: Section Four Fuel Bed Cleaning And Layout (User Instructions)

    GLASS CLEANING From time to time it will be necessary to clean the glass panel of your 780 FL. We recommend you use a Ceramic hob cleaner these are available for all leading super markets: - i.e. ASDA, TESCO, SAINSBURY’S Etc. Brands of hob cleaning we have tested and found suitable are - HOB BRITE &...
  • Page 12 Once liners are in place fit the air-tray and lay fuel bed. Fitting the air tray When fitting the air tray it is very IMPORTANT that it is seated correctly : Ensure all liner securing tabs are bent correctly (See below) Failure to do this could stop the air tray from sitting flat and lead to operational issues •...
  • Page 13 • Place the small bark shapes as shown above. (Please note that vermiculite will be provided on LPG models). • Place the bark shapes around the edge of the air tray as shown above. www.charltonandjenrick.co.uk LT5878 (ISS 14)
  • Page 14 • Place the 2 log shapes as shown above. • Place the 2 log shapes as shown above. • Place the 2 log shape as shown above. LT5878 (ISS 14)

  • Page 15: Section Five General Points (User Instructions)

    SECTION FIVE General Points (user instructions) Like all appliances incorporating an aerated burner a low frequency noise may be heard, particularly on the low setting, this is quite normal and does not affect the operation of the appliance. It is advised that a competent person service the 780 FL fire annually. The fire is more likely to provide trouble-free operation.

  • Page 16: Section Six Appliance Data (Installation Instructions)

    SECTION SIX Appliance Data (installation instructions) NATURAL GAS PROPANE GAS Gas Type: CATEGORY I 2 H CATEGORY I 3 P Gas Pressure: 20 mbar +/- 1.0mbar 37mbar +/- 1.0mbar Pressure Test Point Location: Gas inlet elbow Gas Input: 6.6 kW Gross (Max.) 7.0 kW Gross (Max.) 2.4kW Gross (Min.) 2.4 kW Gross (Max.)

  • Page 17: Section Seven Regulations And Warnings (Installation Instructions)

    SECTION SEVEN Regulations and Warnings (installation instructions) • This appliance must only be installed in Great Britain or Ireland. • The appliance is suitable for use on natural gas only. • GB (Great Britain) This fire does not normally require purpose build ventilation. •...

  • Page 18: Section Eight Siting The Appliance (Installation Instructions)

    SECTION EIGHT Siting the Appliance (installation instructions) • CLASS ONE That is a conventional brick or stone chimney as used for a solid fuel appliance with an effective cross-sectional dimension of 225 x 225 mm (9” x 9”) or a lined flue with a minimum diameter of 125mm (5”). The chimney must have a minimum effective height of at least 3 metres.
  • Page 19 PREPARING THE OPENING FOR INSTALLATION WITH MARBLE SLIPS 930 min to 970 max This area behind the trim/fascia must be clear of combustible material and be flat for the seal. 665 min to 690max 350mm Min Depth Floor The front face and the base of the fire opening must be flat to ensure that a good seal is formed between the rear and base of the appliance and the chimney to avoid any reduction of natural draught.

  • Page 20: Section Nine To Install The Appliance (Installation Instructions)

    CHECKING THE FLUE AND FIRE OPENING • Check that the chimney conforms to the required specifications as previously stated. Examine the condition and carry out any remedial work including removing any debris from the base. • If the flue has been used for solid fuel it should be swept prior to the installation •...
  • Page 21 CHECKING GAS SOUNDNESS AND RUNNING PRESSURE. *power must be connected before proceeding with any soundness testing* • Turn on the gas supply to the appliance and check for soundness in accordance with current codes of practice. • Turn off the gas supply at the external Isolation valve. •...

  • Page 22: Section Ten Checking Operation Of Fire (Installation Instructions)

    FIT LINERS (See Page 11) LAY FUEL BED Important: - Refer to the Health & Safety Notice located on page 3 of this booklet before laying or replacing any refractory material. In the event of replacing fuel bed components please use only the specified number of components as illustrated. Only use fuel bed component provided for this appliance.

  • Page 23: Section Eleven Maintenance (Maintenance Instructions)

    ADVISE CUSTOMER THAT: • The glass front of this fire acts as a dress guard, conforming to BS 1945 (1997) and satisfies the heating appliance regulations (1991) however; a fireguard conforming to BS6539 (1997) must be used to protect young children, the elderly, or infirm.
  • Page 24 REPLACEMENT OF GAS CONTROL • Follow the burner tray removal sequence. • Disconnect the thermocouple from the rear of the gas valve. • Undo the three compression nuts securing the pipes to the gas valve and remove the two screws fixing the valve to the bracket.
  • Page 25 Power lead routing The power supply for this appliance is provided via AC power adaptor 230 VAC. The main cable terminates at the rear Right hand side of the fire box. The length of the cable provided with the appliance is 1.65 metres.

  • Page 26: Section Twelve Wiring Diagram (Maintenance Instructions)

    SECTION TWELVE Wiring Diagram (maintenance instructions) Attach to the valve LT5878 (ISS 14)
  • Page 27 Register your appliance online today to activate your warranty www.charltonandjenrick.co.uk LT5878 (ISS 14)

  • Page 28: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 29: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 30 LT5878 (ISS 14)
  • Page 31 www.charltonandjenrick.co.uk LT5878 (ISS 14)
  • Page 32 Product Serial No Product Serial No A-0272 MA (Ng) A-0339 MV (LPG) ID Label Prefix ID Label Prefix Burner Tray / Box Assembly Burner Tray / Box Assembly Complete Log Fuel Bed (5752) Complete Log Fuel Bed (5752) Grommet (1092) Grommet (1092) 1 X Bag of Black Chippings (6462) 1 X Bag of Vermiculite (5880)
