WWW.ORIONIMAGES.COM
User's Manual
8" Fever Detection Kiosk
(8 inch body detection interactive kiosk)
• Before using the product, please read this manual carefully and keep it for later.
• Image drawings and notations in this document may slightly differ from the actual product.
• The contents of this document are subject to change without notice.
Model :
8FIDKR
English
WWW.ORIONIMAGES.COM
Rev.AH 1.0-1
Copyright © 2020 ORION Images Corporation.
All Rights Reserved
Advertisement
Table of Contents
Related Manuals for Orion 8FIDKR
Summary of Contents for Orion 8FIDKR
- Page 1 • Image drawings and notations in this document may slightly differ from the actual product. • The contents of this document are subject to change without notice. Model : 8FIDKR English WWW.ORIONIMAGES.COM Rev.AH 1.0-1 Copyright © 2020 ORION Images Corporation. All Rights Reserved...
-
Page 2: Table Of Contents
3.6 Access record……………….……………………………….……………………………………………... 3.7 List of registrants …………………………..…………………………………........4. Countermeasure………………………………………………………………………………........5. Product specification.…………………………………………………………..………….…………………..6. Product diagram…………………………………………………………………….……………..…………………. 7. Product description(display) …………….……………………………………………………………………. 8. Product description…….......…..……………………………………………………………..………. 9. Product port description ..…………………………………………..…………………………………………. 10. Maintenance ………………………………………………………..…………………………….…………………. Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 3: Fever Detection Kiosk Overview
2) Turn on your device and wait for a while to launch the app and it takes about 30 seconds to use it. 3) In order to use a stable device, connect the power to the device and wait about 3 minutes before using it. Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 4: How To Use 8" Fever Detection Kiosk
The mask detection function allows you to display the access only when you are wearing a mask. If you are not wearing a mask, you will be asked to wear a mask, and a warning sign will be displayed. Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 5: Fever Detection Kiosk Screen Description
When the mouse is connected and the wheel button is pressed, the password input window appears, and when the correct password is entered, the main menu is displayed on the screen. ※ The initial password is '123456'. Copyright © 2020 ORION Images Corporation. All Rights Reserved... - Page 6 Application Check various information of the device. information Displays a list of people who have measured the Pass record temperature. Face Shows a list of people registered in the database. database Copyright © 2020 ORION Images Corporation. All Rights Reserved...
-
Page 7: Setting
WWW.ORIONIMAGES.COM 3.3 Setting This is a detailed menu for setting up a 8" Fever Detection Kiosk. (1) Name setting Set the device name and company name. Copyright © 2020 ORION Images Corporation. All Rights Reserved... - Page 8 Stranger mode notifies them that it is a stranger. Off is use Stranger mode. On is No Stranger mode Stranger record When a stranger is detected, the captured picture is saved separately. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 9 It is a function to identify the biometric detection (whether the face in front of the camera is a real person Liveness or an image manipulation such as a photo) when detection recognizing the person. The default is off. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 10 30 seconds even if the app is daemon not on the screen. If the setting is on, the camera function will restart if an Application error occurs while the camera is on. thread daemon Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 11 WWW.ORIONIMAGES.COM (6) Application information settings Set whether to display information such as MAC address, IP, and company name on the initial screen. < Hide / Show app info setting > Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 12 If the dimmer setting is a single light, this setting is not visible. Set whether to use all colors such as white / red / green Photo flood lamp lights or only white light. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 13 This menu is for changing the password. ※ The default password value is '123456'. (9) Camera resolution setting Change the camera captured screen resolution. There are 640 * 480 resolution and 1280 * 720 resolution. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 14 (11) Restart time setting Enter the hour in the upper column and the minute in the lower column on a 24-hour basis. Reboot or shut down the device at the specified time. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 15 The relay is closed and opened for the set “delay time” and then closed again. Mode 2 Set the operation time of the relay. Delay The initial value is 5 seconds, and the setting is from 0 to 63 time seconds. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 16 Enter if callback setting is required. If you select On, a field for entering content appears. Communication Enter the IP and port number of the server to address setting communicate with. The format is IP: PORT Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 17 ※ Once the program initialization function is activated, it cannot be reversed. ※ Back up data before initialization. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
-
Page 18: Registration Of Access Information
Press the Gather button at the top to take a picture. The picture which was taken is scaled to fit the person's face. Enter ID and name, select gender and click Save to save it to the Face database. Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 19: Device Information
WWW.ORIONIMAGES.COM 3.5 Device information Displays information about apps and devices. Information such as firmware version, memory, brightness, and volume is displayed. Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 20: Access Record
Enter the time zone you want to see and press the 'query' button to retrieve only the records for that time. If you connect a USB storage device and press the 'Export' button, you can save the records currently in the list separately. Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 21: List Of Registrants
If you click Registration of visitor information' button, you will be taken to the Registration of visitor information menu. Click the Delete button on the right to delete the person's information from the database. Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 22: Countermeasure
Tap the circled button in the middle to go to the Android home screen and open Settings. In the settings window, go to the language and input settings menu as shown in the following figure. Copyright © 2020 ORION Images Corporation. All Rights Reserved... - Page 23 Changing the system language also changes the language of the 8" Fever Detection Kiosk. When changing the system language, it is recommended to reboot the device for better usage. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
-
Page 24: Product Specification
Serial communication 1 RS232 serial port Relay 1 Point Contact (2A 30VDC, 0.28A 220VAC) Interface One Wiegand 26/34 output, one Wiegand 26/34 input Wiegand cable is ORION’s future research and Wiegand development. Upgrade button Support Uboot upgrade button Wired network... -
Page 25: Product Diagram
WWW.ORIONIMAGES.COM 6. Product diagram Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 26: Product Description(Display)
WWW.ORIONIMAGES.COM 7. Product description(display) Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 27: Product Description
WWW.ORIONIMAGES.COM 8. Product description Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 28: Product Port Description
WWW.ORIONIMAGES.COM 9. Product port description OIC Future development OIC Future development For installation experts and For installation experts and administrators administrators WG IN WG OUT (Wiegand input) (Wiegand output) RS232 Copyright © 2020 ORION Images Corporation. All Rights Reserved... -
Page 29: Maintenance
7. Do not disassemble the equipment if it does not work properly. Otherwise, there is no warranty for the equipment. 8. Avoid extreme environments. High temperature (or low temperature), high humidity, vibration, radiation, chemicals, etc. Copyright © 2020 ORION Images Corporation. All Rights Reserved... - Page 30 WWW.ORIONIMAGES.COM 11. Remote Access (Customized program by user) You can make programs as APK using ORION’s API. You can realize various function as Email Alarm, restart system, Fan on/off, Face detection, system settings. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
- Page 31 Q : How long will be the warranty? A : 12 months of manufacture hardware warranty coverage after purchase. Whereby customer could engaged ORION Distributor to process Return Material Authorization (RMA) services by sending the faulty device (i.e. Return For Repair :RFR) to ORION services depot for warranty claims.
- Page 32 Finally, only when you wear your mask and temp. normal, then the door will open. Q : what is the feature of Wiegand cable ? A : Wiegand cable is ORION’s future research and development. ORION products are NDAA compliant.
- Page 33 WWW.ORIONIMAGES.COM Tel: +1(714)766-6300 x 109 e-mail: sales@orionimages.com WWW.ORIONIMAGES.COM All specifications are subject to change without prior notice to improve the product. Copyright © 2020 ORION Images Corporation. All Rights Reserved...
